The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
Key Highlights | Ammann ARS 110.2 | LiuGong 611 |
---|
Particulars | Ammann ARS 110.2 | LiuGong 611 |
---|
Brand | Ammann | LiuGong |
---|---|---|
Type | Soil Compactor | Soil Compactor |
Ex-Showroom Price | Price Available Soon | ₹ 34-36 Lakhs |
Weight | 11100 kg | 11000 kg |
Drum Width | 2130 mm | 2130 mm |
Engine | Ashok Leyland 101 HP | KOEL 110 HP |
Static Linear Load | 28.6 kg/cm | 29.1 kg/cm |
Centrifugal Force (High/Low) | 270/125 kN | 270/125 kN |
Travel Speed | 0-13 km/hr | 0-13 km/hr |
Quick Overview: | The Ammann ARS 110.2 Soil Compactor is a solid single drum roller built for great compaction in challenging projects like highways, airports, and large infrastructure work. Weighing about 11,100 kg and with a 2,130 mm drum width, this vibratory roller provides top-tier centrifugal force at 275 kN high and 160 kN low. It also has dual amplitude and frequency settings for the best results across soil and asphalt surfaces. Its Ashok Leyland engine meets CEV Stage V emissions standards, ensuring lower pollution and strong performance. With an ECOdrop system, operator comfort features, and easy maintenance points, the ARS 110.2 roller compactor promises efficiency, durability, and a high return on investment. Reliable as a road roller, it excels in combining precision and productivity. |
The LiuGong 611 Soil Compactor is a rugged single drum roller designed for high-output compaction in roadworks, dams, airports, and infrastructure projects. Powered by a 110 HP Kirloskar engine with CEV Stage IV compliance, this vibratory roller generates up to 270 kN centrifugal force and has dual vibration amplitudes of 1.8 mm and 0.8 mm for versatile soil performance. With an operating weight of around 11,000 kg and a drum width of 2,130 mm, the LiuGong 611 roller compactor ensures deep, uniform density. Its articulation steering, hydrostatic drive, and spacious operator cabin include safety features, making it a dependable road roller suitable for demanding applications. |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Brand | |
Ammann | LiuGong |
Type | |
Soil Compactor | Soil Compactor |
Ex-Showroom Price | |
Price Available Soon | ₹ 34-36 Lakhs |
Weight | |
11100 kg | 11000 kg |
Drum Width | |
2130 mm | 2130 mm |
Engine | |
Ashok Leyland 101 HP | KOEL 110 HP |
Static Linear Load | |
28.6 kg/cm | 29.1 kg/cm |
Centrifugal Force (High/Low) | |
275/160 kN | 270/125 kN |
Travel Speed | |
11.5 km/hr | 0-13 km/hr |
Quick Overview: | |
The Ammann ARS 110.2 Soil Compactor is a solid single drum roller built for great compaction in challenging projects like highways, airports, and large infrastructure work. Weighing about 11,100 kg and with a 2,130 mm drum width, this vibratory roller provides top-tier centrifugal force at 275 kN high and 160 kN low. It also has dual amplitude and frequency settings for the best results across soil and asphalt surfaces. Its Ashok Leyland engine meets CEV Stage V emissions standards, ensuring lower pollution and strong performance. With an ECOdrop system, operator comfort features, and easy maintenance points, the ARS 110.2 roller compactor promises efficiency, durability, and a high return on investment. Reliable as a road roller, it excels in combining precision and productivity. |
The LiuGong 611 Soil Compactor is a rugged single drum roller designed for high-output compaction in roadworks, dams, airports, and infrastructure projects. Powered by a 110 HP Kirloskar engine with CEV Stage IV compliance, this vibratory roller generates up to 270 kN centrifugal force and has dual vibration amplitudes of 1.8 mm and 0.8 mm for versatile soil performance. With an operating weight of around 11,000 kg and a drum width of 2,130 mm, the LiuGong 611 roller compactor ensures deep, uniform density. Its articulation steering, hydrostatic drive, and spacious operator cabin include safety features, making it a dependable road roller suitable for demanding applications. |
Ammann ARS 110.2 | LiuGong 611 | |
Engine Make | Ashok Leyland H4C510122 | KOEL 4R1190TA1 |
Fuel Tank | 310 L | 280 L |
Hydraulic Tank | 52 L | 90 L |
Vibration Frequency (Hi/Low) | 32/35 Hz | 32/34 Hz |
Nominal Amplitude (High/Low) | 1.85/0.9 mm | 1.8/0.8 mm |
Max. Gradeability | 35% | 35% |
Steering Angle | ±36° | ± 35° |
Turning Radius, Outside | NA | 6750 mm |
Wheelbase | 2930 mm | 2900 mm |
Tyre Size | 23.1-26-12PR | 23.1-26-12PR |
Overall Length | 5750 mm | 5900 mm |
Overall Width | 2260 mm | 2300 mm |
Overall Height | 3000 mm | 3232 mm |
Telematics | Optional | Optional |
Warranty | 1 Year | 1 Yr. / 2000 hr. |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Engine Make | |
Ashok Leyland H4C510122 | KOEL 4R1190TA1 |
Fuel Tank | |
310 L | 280 L |
Hydraulic Tank | |
52 L | 90 L |
Vibration Frequency (Hi/Low) | |
32/35 Hz | 32/34 Hz |
Nominal Amplitude (High/Low) | |
1.85/0.9 mm | 1.8/0.8 mm |
Max. Gradeability | |
35% | 35% |
Steering Angle | |
±36° | ± 35° |
Turning Radius, Outside | |
NA | 6750 mm |
Wheelbase | |
2930 mm | 2900 mm |
Tyre Size | |
23.1-26-12PR | 23.1-26-12PR |
Overall Length | |
5750 mm | 5900 mm |
Overall Width | |
2260 mm | 2300 mm |
Overall Height | |
3000 mm | 3232 mm |
Telematics | |
Optional | Optional |
Warranty | |
1 Year | 1 Yr. / 2000 hr. |
Ammann ARS 110.2 | LiuGong 611 | |
Engine Make | Ashok Leyland H4C510122 | KOEL 4R1190TA1 |
Engine Type | CEV Stage V; Water Cooled; DOC+SCR+ASC+DPF | CEV-IV; 4 Cylinders; Turbocharged diesel engine |
Max. Power | 101 HP (74 kW) @ 2200 RPM | 110 HP (82 kW) @ 2200 RPM |
Battery | 12V, 150 Ah | 12V / 150Ah |
Ammann ARS 110.2 | LiuGong 611 | |
Static Linear Load | 28.6 kg/cm | 29.1 kg/cm |
Nominal Amplitude (High/Low) | 1.85/0.9 mm | 1.8/0.8 mm |
Vibration Frequency (Hi/Low) | 32/35 Hz | 32/34 Hz |
Centrifugal Force (High/Low) | 275/160 kN | 270/125 kN |
Ammann ARS 110.2 | LiuGong 611 | |
Transmission Type | Hydrostatic | Hydrostatic |
Max. Gradeability | 35% | 35% |
Working Speed | 6 km/hr | 0-7 km/hr |
Travel Speed | 11.5 km/hr | 0-13 km/hr |
Ammann ARS 110.2 | LiuGong 611 | |
Travel System | Axial piston – closed loop | Variable Closed Loop Axial Piston Pump with Mechanical Servo Proportional control |
Vibration System | Axial piston – closed loop | Variable Closed Loop Axial Piston Pump with Two Point Electric Control |
Ammann ARS 110.2 | LiuGong 611 | |
Service | Hydrostatic | Hydrostatic Propulsion System |
Parking/Emergency | Multi-disc spring brake | Spring Applied; Hydraulic Release |
Ammann ARS 110.2 | LiuGong 611 | |
Fuel Tank | 310 L | 280 L |
Hydraulic Tank | 52 L | 90 L |
Engine Crank Case | NA | 8.5 L |
Coolant | NA | 18 L |
Adblue/ DEF tank | 24 L | 16 L |
Ammann ARS 110.2 | LiuGong 611 | |
Steering Type | Gear pump | Articulated with limited slip differential |
Steering Angle | ±36° | ± 35° |
Oscillation | ±10° | NA |
Turning Radius, Outside | NA | 6750 mm |
Turning Radius, Inside | 3250 mm | NA |
Ammann ARS 110.2 | LiuGong 611 | |
Operating Weight | 11100 kg | 11000 kg |
Ammann ARS 110.2 | LiuGong 611 | |
Overall Length | 5750 mm | 5900 mm |
Overall Width | 2260 mm | 2300 mm |
Overall Height | 3000 mm | 3232 mm |
Wheelbase | 2930 mm | 2900 mm |
Drum Diameter | 1500 mm | 1500 mm |
Drum Width | 2130 mm | 2130 mm |
Drum Shell Thickness | 25 mm | NA |
Ground Clearance | 465 mm | 480 mm |
Curb Clearance | 450 mm | NA |
Tyre Size | 23.1-26-12PR | 23.1-26-12PR |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Engine Make | |
Ashok Leyland H4C510122 | KOEL 4R1190TA1 |
Engine Type | |
CEV Stage V; Water Cooled; DOC+SCR+ASC+DPF | CEV-IV; 4 Cylinders; Turbocharged diesel engine |
Max. Power | |
101 HP (74 kW) @ 2200 RPM | 110 HP (82 kW) @ 2200 RPM |
Battery | |
12V, 150 Ah | 12V / 150Ah |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Static Linear Load | |
28.6 kg/cm | 29.1 kg/cm |
Nominal Amplitude (High/Low) | |
1.85/0.9 mm | 1.8/0.8 mm |
Vibration Frequency (Hi/Low) | |
32/35 Hz | 32/34 Hz |
Centrifugal Force (High/Low) | |
275/160 kN | 270/125 kN |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Transmission Type | |
Hydrostatic | Hydrostatic |
Max Gradeability | |
Not Available | Not Available |
Working Speed | |
6 km/hr | 0-7 km/hr |
Travel Speed | |
11.5 km/hr | 0-13 km/hr |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Travel System | |
Axial piston – closed loop | Variable Closed Loop Axial Piston Pump with Mechanical Servo Proportional control |
Vibration System | |
Axial piston – closed loop | Variable Closed Loop Axial Piston Pump with Two Point Electric Control |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Service | |
Hydrostatic | Hydrostatic Propulsion System |
Parking/Emergency | |
Multi-disc spring brake | Spring Applied; Hydraulic Release |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Fuel Tank | |
310 L | 280 L |
Hydraulic Tank | |
52 L | 90 L |
Engine Crank Case | |
NA | 8.5 L |
Coolant | |
NA | 18 L |
Adblue/ DEF tank | |
24 L | 16 L |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Steering Type | |
Gear pump | Articulated with limited slip differential |
Steering Angle | |
±36° | ± 35° |
Oscillation | |
±10° | NA |
Turning Radius, Outside | |
NA | 6750 mm |
Turning Radius, Inside | |
3250 mm | NA |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Operating Weight | |
11100 kg | 11000 kg |
Ammann ARS 110.2 | LiuGong 611 |
---|---|
Overall Length | |
5750 mm | 5900 mm |
Overall Width | |
2260 mm | 2300 mm |
Overall Height | |
3000 mm | 3232 mm |
Wheelbase | |
2930 mm | 2900 mm |
Drum Diameter | |
1500 mm | 1500 mm |
Drum Width | |
2130 mm | 2130 mm |
Drum Shell Thickness | |
25 mm | NA |
Ground Clearance | |
465 mm | 480 mm |
Curb Clearance | |
450 mm | NA |
Tyre Size | |
23.1-26-12PR | 23.1-26-12PR |
