Add Equipment
The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|
| Particulars | Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|
The Sany SY20U Mini Excavator boasts higher engine power and fuel efficiency, making it suitable for tasks requiring more power and longer operational times. In contrast, the Tata Hitachi ZAXIS 23U provides a larger bucket capacity and higher tracking force, ideal for larger volumes of earthmoving while maintaining stability.
Choosing between the Sany SY20U and Tata Hitachi ZAXIS 23U depends on the needs of your project. If you require a more powerful engine and efficiency in fuel consumption for extended work periods, the Sany SY20U is a strong choice. However, if bucket capacity and dumping height are more critical for your operations, and you benefit from a larger fuel tank, the Tata Hitachi ZAXIS 23U would be more applicable.
| Brand | Tata Hitachi | SANY |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | Price Available Soon | ₹ 22-23 Lakhs |
| Price | ₹ 23 - 24 Lakhs | ₹ 22-23 Lakhs |
| Weight | 2356 Kg | 1980 Kg |
| Bucket | 0.07 m³ | 0.05 m³ |
| Max Digging Depth | 2330 mm | 2385 mm |
| Engine | Yanmar 17.4 HP | Yanmar 19.8 HP |
| Warranty | 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | NA | 1810 mm |
| Quick Overview: | ZAXIS 23U mini excavator by Tata Hitachi is used for small-scale earthmoving and landscaping jobs and offers high adaptability and durability. |
The Sany SY20U mini excavator is perfect for landscaping and small agricultural tasks being compact and efficient. |
| Agency review | Get the best price for the Tata Hitachi ZAXIS 23U Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Sany SY20U Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
The Sany SY20U Mini Excavator boasts higher engine power and fuel efficiency, making it suitable for tasks requiring more power and longer operational times. In contrast, the Tata Hitachi ZAXIS 23U provides a larger bucket capacity and higher tracking force, ideal for larger volumes of earthmoving while maintaining stability.
Choosing between the Sany SY20U and Tata Hitachi ZAXIS 23U depends on the needs of your project. If you require a more powerful engine and efficiency in fuel consumption for extended work periods, the Sany SY20U is a strong choice. However, if bucket capacity and dumping height are more critical for your operations, and you benefit from a larger fuel tank, the Tata Hitachi ZAXIS 23U would be more applicable.
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Brand | |
| Tata Hitachi | SANY |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 23 - 24 Lakhs | ₹ 22-23 Lakhs |
| Weight | |
| 2356 Kg | 1980 Kg |
| Bucket | |
| 0.07 m³ | 0.05 m³ |
| Max Digging Depth | |
| 2330 mm | 2385 mm |
| Engine | |
| Yanmar 17.4 HP | Yanmar 19.8 HP |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| NA | 1810 mm |
| Quick Overview: | |
ZAXIS 23U mini excavator by Tata Hitachi is used for small-scale earthmoving and landscaping jobs and offers high adaptability and durability. |
The Sany SY20U mini excavator is perfect for landscaping and small agricultural tasks being compact and efficient. |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Engine Make | Yanmar 3TNV76 | Yanmar 3TNV80F |
| Fuel Tank | 34 L | 21 L |
| Engine Displacment | 1.115 L | 1.22 L |
| Under Carriage | 1910 mm | 1580 mm |
| Hydraulic System | 19 L | NA |
| Arm | NA | 1130 mm |
| Max Digging Reach | 4190 mm | 4010 mm |
| Fuel Consumption | NA | 2.5 L/hour |
| Overall Width | 1400 mm | 980 mm / 1350 mm |
| Overall Length | 3860 mm | 3515 mm |
| Bucket Digging Force | 18.6 kN | 15.3 kN |
| Tailswing Radius | 725 mm | 675 mm |
| Track Shoe Width | 250 mm | 230 mm |
| AC Cabin | Not Available | Not Available |
| GPS | Not Available | Not Available |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Engine Make | |
| Yanmar 3TNV76 | Yanmar 3TNV80F |
| Fuel Tank | |
| 34 L | 21 L |
| Engine Displacment | |
| 1.115 L | 1.22 L |
| Under Carriage | |
| 1910 mm | 1580 mm |
| Hydraulic System | |
| 19 L | NA |
| Arm | |
| NA | 1130 mm |
| Max Digging Reach | |
| 4190 mm | 4010 mm |
| Fuel Consumption | |
| NA | 2.5 L/hour |
| Overall Width | |
| 1400 mm | 980 mm / 1350 mm |
| Overall Length | |
| 3860 mm | 3515 mm |
| Bucket Digging Force | |
| 18.6 kN | 15.3 kN |
| Tailswing Radius | |
| 725 mm | 675 mm |
| Track Shoe Width | |
| 250 mm | 230 mm |
| AC Cabin | |
| Not Available | Not Available |
| GPS | |
| Not Available | Not Available |
| 3619 | 3597 | |
| Model | Yanmar 17.4 HP | Yanmar 19.8 HP |
| Fuel | Diesel | Diesel |
| Type | 3 cylinder swirl-chamber type , 4 Cycle , Water Cooled | 3 Cylinder Water Cooled , Four Stroke |
| Rated Engine Power | 17.4 HP (13.1 kW) @ 2200 rpm | 19.8 HP (14.6 kW) @ 2400 rpm |
| Maximum Torque | 62.8 Nm @ 1600 rpm | 67.4 Nm @ 1800 rpm |
| Piston Displacement | 1.115 L | 1.22 L |
| Alternator | NA | NA |
| Battery | NA | 12V |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | 1 | 2 |
| No of bottom rollers | 3 | 3 |
| Track Shoes (Each Side) | 2 | 37 |
| Track Guard | NA | NA |
| Track Shoe width | 250 mm | 230 mm |
| Ground bearing pressure | NA | 30 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 25° (47%) | 70°(35%) |
| Travel Speed-Low | 2.6 Km/h | 3 Km/h |
| Travel Speed-High | 4.4 Km/h | 4.2 Km/h |
| Max Tracking Force | 18.6 kN | 15.6 kN |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Hydraulic pump | 2 Variable displacement axial piston pumps 1 gear pump | Variable displacement axial piston pump |
| Maximum Flow | 2 x 26.4, 1 x 14.3 L/min | 70 L/min |
| Pilot Pump | 1 Gear Pump | Gear Pump |
| Implement Circuit | 20.6 MPa | 24.5 MPa |
| Swing Circuit | 17.1 MPa | 16.3 MPa |
| Travel circuit | 20.6 MPa | 24.5 MPa |
| Pilot circuit | 3.9 MPa | 4.0 MPa |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Travel | Variable Displacement axial piston motor | Axial Piston Motor |
| Swing | NA | Hyd Operated Automatically; Oil Disc Brake |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Fuel tank | 34 L | 21 L |
| Engine Coolant | 3.1 L | 3.8 L |
| Engine oil | 3.2 L | 2 L |
| Hydraulic system | 19 L | NA |
| Hydraulic tank | 30 L | 21 L |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Operating Weight | 2356 Kg | 1980 Kg |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Boom length | NA | 1810 mm |
| Arm length | NA | 1130 mm |
| Max Digging Reach | 4190 mm | 4010 mm |
| Max Digging Reach on ground | 4060 mm | NA |
| Max digging depth | 2330 mm | 2385 mm |
| Max digging height | 4080 mm | 3410 mm |
| Max Dump Height | 2800 mm | 2350 mm |
| Max vertical wallcut depth | 1940 mm | 210 mmm |
| Min swing radius | 1760 mm | 2475 mm |
| Max Height at Min Swing radius | NA | 1655 mm |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 18.6 kN | 15.3 kN |
| Arm Digging Force | 12.3 kN | 9.2 kN |
| Swing Speed | 9.2 rpm | 10 rpm |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | 320 mm | 310 mm |
| Approach Angle | NA | NA |
| Width | 1410 mm | NA |
| Height | 310 mm | 270 mm |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Bucket Capacity | 0.07 m³ | 0.05 m³ |
| Tata Hitachi ZAXIS 23U | Sany SY20U | |
| Overall Length | 3860 mm | 3515 mm |
| Overall width | 1400 mm | 980 mm / 1350 mm |
| Overall Height | 2410 mm | 2495 mm |
| Overall Height of Cab | 2410 mm | NA |
| Upper Width | 1390 mm | 980 mm |
| Track Lengh on Ground | 1500 mm | 1225 mm |
| Undercarriage overall length | 1910 mm | 1580 mm |
| Tailswing radius | 725 mm | 675 mm |
| Min Ground clearance | 290 mm | 160 mm |
| Track gauge | 1200 mm | 750 mm / 1120 mm |
| Width over tracks | 1450 mm | NA |
| Track Height | 430 mm | NA |
| Counterweight Clearance | 490 mm | NA |
| Track Shoe Width | 250 mm | 230 mm |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Model | |
| Yanmar 17.4 HP | Yanmar 19.8 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 3 cylinder swirl-chamber type , 4 Cycle , Water Cooled | 3 Cylinder Water Cooled , Four Stroke |
| Rated Engine Power | |
| 17.4 HP (13.1 kW) @ 2200 rpm | 19.8 HP (14.6 kW) @ 2400 rpm |
| Maximum Torque | |
| 62.8 Nm @ 1600 rpm | 67.4 Nm @ 1800 rpm |
| Piston Displacement | |
| 1.115 L | 1.22 L |
| Alternator | |
| NA | NA |
| Battery | |
| NA | 12V |
| Starting Motor | |
| NA | NA |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| No of Top rollers | |
| 1 | 2 |
| No of bottom rollers | |
| 3 | 3 |
| Track Shoes (Each Side) | |
| 2 | 37 |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 250 mm | 230 mm |
| Ground bearing pressure | |
| NA | 30 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 25° (47%) | 70°(35%) |
| Travel Speed-Low | |
| 2.6 Km/h | 3 Km/h |
| Travel Speed-High | |
| 4.4 Km/h | 4.2 Km/h |
| Max Tracking Force | |
| 18.6 kN | 15.6 kN |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Hydraulic pump | |
| 2 Variable displacement axial piston pumps 1 gear pump | Variable displacement axial piston pump |
| Maximum Flow | |
| 2 x 26.4, 1 x 14.3 L/min | 70 L/min |
| Pilot Pump | |
| 1 Gear Pump | Gear Pump |
| Implement Circuit | |
| 20.6 MPa | 24.5 MPa |
| Swing Circuit | |
| 17.1 MPa | 16.3 MPa |
| Travel circuit | |
| 20.6 MPa | 24.5 MPa |
| Pilot circuit | |
| 3.9 MPa | 4.0 MPa |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Fuel tank | |
| 34 L | 21 L |
| Engine Coolant | |
| 3.1 L | 3.8 L |
| Engine oil | |
| 3.2 L | 2 L |
| Hydraulic system | |
| 19 L | NA |
| Hydraulic tank | |
| 30 L | 21 L |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Operating Weight | |
| 2356 Kg | 1980 Kg |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Boom length | |
| NA | 1810 mm |
| Arm length | |
| NA | 1130 mm |
| Max Digging Reach | |
| 4190 mm | 4010 mm |
| Max Digging Reach on ground | |
| 4060 mm | NA |
| Max digging depth | |
| 2330 mm | 2385 mm |
| Max digging height | |
| 4080 mm | 3410 mm |
| Max Dump Height | |
| 2800 mm | 2350 mm |
| Max vertical wallcut depth | |
| 1940 mm | 210 mmm |
| Min swing radius | |
| 1760 mm | 2475 mm |
| Max Height at Min Swing radius | |
| NA | 1655 mm |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 18.6 kN | 15.3 kN |
| Arm Digging Force | |
| 12.3 kN | 9.2 kN |
| Swing Speed | |
| 9.2 rpm | 10 rpm |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| 320 mm | 310 mm |
| Approach Angle | |
| NA | NA |
| Width | |
| 1410 mm | NA |
| Height | |
| 310 mm | 270 mm |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Bucket Capacity | |
| 0.07 m³ | 0.05 m³ |
| Tata Hitachi ZAXIS 23U | Sany SY20U |
|---|---|
| Overall Length | |
| 3860 mm | 3515 mm |
| Overall width | |
| 1400 mm | 980 mm / 1350 mm |
| Overall Height | |
| 2410 mm | 2495 mm |
| Overall Height of Cab | |
| 2410 mm | NA |
| Upper Width | |
| 1390 mm | 980 mm |
| Track Lengh on Ground | |
| 1500 mm | 1225 mm |
| Undercarriage overall length | |
| 1910 mm | 1580 mm |
| Tailswing radius | |
| 725 mm | 675 mm |
| Min Ground clearance | |
| 290 mm | 160 mm |
| Track gauge | |
| 1200 mm | 750 mm / 1120 mm |
| Width over tracks | |
| 1450 mm | NA |
| Track Height | |
| 430 mm | NA |
| Counterweight Clearence | |
| 490 mm | NA |
| Track Shoe Width | |
| 250 mm | 230 mm |
