XCMG XE245i LR VS Liugong 925E XLR Excavator

desi-machines-xcmg-excavator-xe245i-lr-featured

XCMG XE245i LR

Weight

22800 Kg
Bucket

0.5 m³
Dig. Depth

11610 mm
Engine

Cummins 141.4 HP
Warranty

1 Yr. / 2500 hr.
Boom

8140 mm

Price Available Soon^*

Long Reach

desi-machines-liugong-excavator-925e-xlr-2

Liugong 925E XLR

Weight

25400 Kg
Bucket

0.5 m³
Dig. Depth

15124 mm
Engine

Cummins 148 HP
Warranty

1 Yr. / 2500 hr.
Boom

10350 mm

Price Available Soon^*

Long Reach

Add Equipment

The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.

Key Highlights	XCMG XE245i LR	Liugong 925E XLR

XCMG XE245i LR VS Liugong 925E XLR Excavator

XCMG XE245i LR

Price Available Soon

Liugong 925E XLR

Price Available Soon

Particulars	XCMG XE245i LR	Liugong 925E XLR

XCMG XE245i LR Vs Liugong 925E XLR Excavator Price, Technical Specifications & Features


Brand	XCMG	LiuGong
Type	Long Reach	Long Reach
Operating Cost	Price Available Soon	Price Available Soon
Price	Price Available Soon	Price Available Soon
Weight	22800 Kg	25400 Kg
Bucket	0.5 m³	0.5 m³
Max Digging Depth	11610 mm	15124 mm
Engine	Cummins 141.4 HP	Cummins 148 HP
Warranty	1 Yr. / 2500 hr.	1 Yr. / 2500 hr.
Boom	8140 mm	10350 mm
Quick Overview:	Designed for extended tasks, XCMG XE245i LR long-reach excavator excels in dredging and waterfront construction.	Ideal for deep excavation and dredging tasks, Liugong 925E XLR long-reach excavator is a combination of advanced systems and durability.
Agency review	Get the best price for the XCMG XE245i LR Long Reach Excavator from authorized dealers. Contact us now for exclusive deals!	Get the best price for the Liugong 925E XLR Long Reach Excavator from authorized dealers. Contact us now for exclusive deals!

XCMG XE245i LR Vs Liugong 925E XLR Excavator Price, Technical Specifications & Features

XCMG XE245i LR	Liugong 925E XLR
Brand
XCMG	LiuGong
Type
Long Reach	Long Reach
Price
Price Available Soon	Price Available Soon
Weight
22800 Kg	25400 Kg
Bucket
0.5 m³	0.5 m³
Max Digging Depth
11610 mm	15124 mm
Engine
Cummins 141.4 HP	Cummins 148 HP
Warranty
1 Yr. / 2500 hr.	1 Yr. / 2500 hr.
Boom
8140 mm	10350 mm
Quick Overview:
Designed for extended tasks, XCMG XE245i LR long-reach excavator excels in dredging and waterfront construction.	Ideal for deep excavation and dredging tasks, Liugong 925E XLR long-reach excavator is a combination of advanced systems and durability.

XCMG XE245i LR Vs Liugong 925E XLR Excavator Key Highlights

	XCMG XE245i LR	Liugong 925E XLR
Engine Make	Cummins 6BT5.9	Cummins 6BTAA5.9
Fuel Tank	360 L	420 L
Engine Displacment	5.9 L	5.9 L
Under Carriage	4449 mm	4440 mm
Hydraulic System	300 L	339 L
Arm	6340 mm	8000 mm
Max Digging Reach	15430 mm	18361 mm
Fuel Consumption	NA	NA
Overall Width	3190 mm	3190 mm
Overall Length	12130 mm	14435 mm
Bucket Digging Force	NA	NA
Tailswing Radius	2890 mm	2780 mm
Track Shoe Width	800 mm	800 mm
AC Cabin	Standard	Standard
GPS	Not Available	Optional

XCMG XE245i LR Vs Liugong 925E XLR Excavator Key Highlights

XCMG XE245i LR	Liugong 925E XLR
Engine Make
Cummins 6BT5.9	Cummins 6BTAA5.9
Fuel Tank
360 L	420 L
Engine Displacment
5.9 L	5.9 L
Under Carriage
4449 mm	4440 mm
Hydraulic System
300 L	339 L
Arm
6340 mm	8000 mm
Max Digging Reach
15430 mm	18361 mm
Fuel Consumption
NA	NA
Overall Width
3190 mm	3190 mm
Overall Length
12130 mm	14435 mm
Bucket Digging Force
NA	NA
Tailswing Radius
2890 mm	2780 mm
Track Shoe Width
800 mm	800 mm
AC Cabin
Standard	Standard
GPS
Not Available	Optional

XCMG XE245i LR Vs Liugong 925E XLR Excavator Specifications

Engine

	3669	3676
Model	Cummins 141.4 HP	Cummins 148 HP
Fuel	Diesel	Diesel
Type	4 stroke , 6 Cylinder , turbocharged	CAC , turbocharged
Rated Engine Power	141.4 HP (105.5 kW) @ 2000 rpm	148 HP @ 2000 rpm
Maximum Torque	564 Nm @ 1600 rpm	626 Nm @ 1300 rpm
Piston Displacement	5.9 L	5.9 L
Alternator	NA	NA
Battery	12 V x 2	100Ah x2 , 12 V
Starting Motor	NA	24 V

Undercarriage

	24 V	24 V
No of Top rollers	2	2
No of bottom rollers	9	8
Track Shoes (Each Side)	49	49
Track Guard	NA	NA
Track Shoe width	800 mm	800 mm
Ground bearing pressure	NA	NA
Track Tensioning	Grease	Grease
Gradeability	35°	70 % (35°)
Travel Speed-Low	NA	3.0 Km.h
Travel Speed-High	5.5 Km/h	5.1 Km/h
Max Tracking Force	184 kN	212 kN

Hydraulic System

	XCMG XE245i LR	Liugong 925E XLR
Hydraulic pump	2 Piston Pumps	NA
Maximum Flow	2 x 224 L/min	2 x 224 L/min
Pilot Pump	1 Gear Pump	NA
Implement Circuit	34.3MPa	34.3 MPa / 37.3 MPa
Swing Circuit	28 MPa	28.5 MPa
Travel circuit	34.3 MPa	34.3 MPa
Pilot circuit	3.9 MPa	3.9 MPa

Hydraulic Motors

	XCMG XE245i LR	Liugong 925E XLR
Travel	NA	Axial Piston Motor
Swing	NA	Axial Piston Motor

Service Capacities

	XCMG XE245i LR	Liugong 925E XLR
Fuel tank	360 L	420 L
Engine Coolant	23 L	NA
Engine oil	16 L	20 L
Hydraulic system	300 L	339 L
Hydraulic tank	220 L	180 L

Machine Weight

	XCMG XE245i LR	Liugong 925E XLR
Operating Weight	22800 Kg	25400 Kg

Working Range

	XCMG XE245i LR	Liugong 925E XLR
Boom length	8140 mm	10350 mm
Arm length	6340 mm	8000 mm
Max Digging Reach	15430 mm	18361 mm
Max Digging Reach on ground	NA	18282 mm
Max digging depth	11610 mm	15124 mm
Max digging height	13500 mm	14726 mm
Max Dump Height	11150 mm	12606 mm
Max vertical wallcut depth	4730 mm	NA
Min swing radius	8800 mm	4539 mm
Max Height at Min Swing radius	NA	NA
Max height (above ground)	NA	NA
Dig depth (below ground)	NA	NA
Bucket Digging Force	NA	NA
Arm Digging Force	NA	NA
Swing Speed	13 rpm	12 rpm

Dozer Blade

	XCMG XE245i LR	Liugong 925E XLR
Dozer Type	NA	NA
Dozer Length	NA	NA
Digging depth for ground level	NA	NA
Approach Angle	NA	NA
Width	NA	NA
Height	NA	NA

Bucket

	XCMG XE245i LR	Liugong 925E XLR
Bucket Capacity	0.5 m³	0.5 m³

Static Dimensions

	XCMG XE245i LR	Liugong 925E XLR
Overall Length	12130 mm	14435 mm
Overall width	3190 mm	3190 mm
Overall Height	3034 mm	3200 mm
Overall Height of Cab	NA	3050 mm
Upper Width	2830 mm	2760 mm
Track Lengh on Ground	3370 mm	3650 mm
Undercarriage overall length	4449 mm	4440 mm
Tailswing radius	2890 mm	2780 mm
Min Ground clearance	477 mm	440 mm
Track gauge	2390 mm	2390 mm
Width over tracks	3190 mm	3190 mm
Track Height	927 mm	NA
Counterweight Clearance	1050 mm	1070 mm
Track Shoe Width	800 mm	800 mm
