JCB 433-5 VS Tata Hitachi TL340H Prime Wheel Loader

JCB 433-5
  • Engine
    JCB 130 HP
  • featIcon2 (1) alt
    Bucket
    1.5 m³
  • icon alt1
    Weight
    10835 kg
  • Fwd. Speed
    31 km/h
  • dumping height loader
    Dump Height
    2850 mm
  • tipping load
    Tripping Load
    6791 kg
Price Available Soon*
Small (8-15 Ton)
Tata Hitachi TL340H Prime
  • Engine
    Cummins 121 HP
  • featIcon2 (1) alt
    Bucket
    1.8 - 2.7 m³
  • icon alt1
    Weight
    10980 kg
  • Fwd. Speed
    30 km/h
  • dumping height loader
    Dump Height
    2792 mm
  • tipping load
    Tripping Load
    7340 kg
₹ 47-49 Lakhs*
Small (8-15 Ton)

Add Equipment

The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.

Key Highlights JCB 433-5Tata Hitachi TL340H Prime
JCB 433-5 VS Tata Hitachi TL340H Prime Wheel Loader
Jcb 433 5 wheel loader price in india | front End Loader
JCB 433-5
Price Available Soon
desi machines tata hitachi tl340h prime wheel loader featured
Tata Hitachi TL340H Prime
₹ 47-49 Lakhs
Particulars JCB 433-5 Tata Hitachi TL340H Prime
Overview Summary

Comparing the Tata Hitachi TL340H Prime and the JCB 433-5 reveals a trade-off between engine power and bucket capacity. The Tata Hitachi has an edge in bucket capacity, which can be crucial for certain jobs, while the JCB stands out with higher engine power and better speed performance that may improve overall job site efficiency.

Tata Hitachi TL340H Prime

Pros:
  • Enhanced fuel efficiency and operator comfort suitable for Indian urban construction
  • Powerful 121 HP (90.2 kW) Cummins engine with a high torque of 500 Nm
  • Higher bucket capacity range of 1.8 - 2.7 m³
Cons:
  • Top reverse speed is lower at 6 km/h, which may affect productivity in certain situations
  • Minor lack of information on certain specs like Alternator, cooling, and transmission oil

JCB 433-5

Pros:
  • Offers great fuel efficiency and productivity for diverse construction tasks
  • Higher engine power of 130 HP (97 kW) with torque capacity of 550 Nm
  • Improved forward and reverse speeds (31 km/h and 21 km/h respectively) for quicker operations
Cons:
  • Lower bucket capacity of 1.5 m³ which may be disadvantageous for certain operations
  • Engine emission is Stage 5, which is stringent, but it could affect operations if strict emissions laws are not in place

Pros:
Cons:

Closing Recommendation

The final recommendation would depend on the specific needs of the operation. If prioritizing the ability to move larger volumes in one go is key, the Tata Hitachi TL340H Prime may be preferable, particularly in urban settings. However, for operations that benefit from higher maneuverability and speed, along with greater engine power, the JCB 433-5 might be the more efficient choice.

Price, Technical Specifications & Features

Brand JCB Tata Hitachi
Type Small (8-15 Ton) Small (8-15 Ton)
Ex-Showroom Price Price Available Soon ₹ 47-49 Lakhs
Engine JCB 130 HP Cummins 121 HP
Bucket 1.5 m³ 1.8 - 2.7 m³
Weight 10835 kg 10980 kg
Max. Forward Speed 31 km/h 30 km/h
Dump Height 2850 mm 2792 mm
Tripping Load 6791 kg 7340 kg
Quick Overview:

The JCB 433-5 Wheel Loader offers enhanced fuel efficiency and productivity, making it ideal for diverse Indian construction and material handling tasks.

The Tata Hitachi TL 340H PRIME Wheel Loader offers enhanced fuel efficiency and operator comfort, ideal for Indian urban construction projects.
Overview Summary

Comparing the Tata Hitachi TL340H Prime and the JCB 433-5 reveals a trade-off between engine power and bucket capacity. The Tata Hitachi has an edge in bucket capacity, which can be crucial for certain jobs, while the JCB stands out with higher engine power and better speed performance that may improve overall job site efficiency.

Tata Hitachi TL340H Prime

Pros:
  • Enhanced fuel efficiency and operator comfort suitable for Indian urban construction
  • Powerful 121 HP (90.2 kW) Cummins engine with a high torque of 500 Nm
  • Higher bucket capacity range of 1.8 - 2.7 m³
Cons:
  • Top reverse speed is lower at 6 km/h, which may affect productivity in certain situations
  • Minor lack of information on certain specs like Alternator, cooling, and transmission oil

JCB 433-5

Pros:
  • Offers great fuel efficiency and productivity for diverse construction tasks
  • Higher engine power of 130 HP (97 kW) with torque capacity of 550 Nm
  • Improved forward and reverse speeds (31 km/h and 21 km/h respectively) for quicker operations
Cons:
  • Lower bucket capacity of 1.5 m³ which may be disadvantageous for certain operations
  • Engine emission is Stage 5, which is stringent, but it could affect operations if strict emissions laws are not in place

Pros:
Cons:

Closing Recommendation

The final recommendation would depend on the specific needs of the operation. If prioritizing the ability to move larger volumes in one go is key, the Tata Hitachi TL340H Prime may be preferable, particularly in urban settings. However, for operations that benefit from higher maneuverability and speed, along with greater engine power, the JCB 433-5 might be the more efficient choice.

Price, Technical Specifications & Features

JCB 433-5 Tata Hitachi TL340H Prime
Brand
JCB Tata Hitachi
Type
Small (8-15 Ton) Small (8-15 Ton)
Ex-Showroom Price
Price Available Soon ₹ 47-49 Lakhs
Engine
JCB 130 HP Cummins 121 HP
Bucket
1.5 m³ 1.8 - 2.7 m³
Weight
10835 kg 10980 kg
Fwd. Speed
31 km/h 30 km/h
Dump Height
2850 mm 2792 mm
Tripping Load
6791 kg 7340 kg
Quick Overview:

The JCB 433-5 Wheel Loader offers enhanced fuel efficiency and productivity, making it ideal for diverse Indian construction and material handling tasks.

The Tata Hitachi TL 340H PRIME Wheel Loader offers enhanced fuel efficiency and operator comfort, ideal for Indian urban construction projects.

Key Highlights

JCB 433-5 Tata Hitachi TL340H Prime
Engine Make JCB ecoMAX 448 Cummins B4.5 CIV121D221
Max Torque 550 Nm @ 1500 rpm 500 Nm @ 1500 rpm
Fuel Tank 210 L 165 L
Hydraulic System 164 L/min @ 2200 rpm 132 L/min @ 2200 rpm
Min. Ground Clearance 398 mm 479 mm
Payload 3396 kg 3375 kg
Steering Angle ±40° ±38°
Drive Type 4-wheel drive (4WD) 4-wheel drive (4WD)
Wheelbase 3000 mm 2840 mm
Tyres 14 x 25(20PR) E3/L3 (BKT/CEAT) 14x25 20PR
Max. Breakout Force 116 kN 103.3 kN
Overall Length 7450 mm 7200 mm
Warranty 1 Yr. / 2000 hr. 1 Yr. / 2000 hr.
AC Cabin Optional Optional
GPS Standard Standard

Key Highlights

JCB 433-5 Tata Hitachi TL340H Prime
Engine Make
JCB ecoMAX 448 Cummins B4.5 CIV121D221
Max Torque
550 Nm @ 1500 rpm 500 Nm @ 1500 rpm
Fuel Tank
210 L 165 L
Hydraulic System
164 L/min @ 2200 rpm 132 L/min @ 2200 rpm
Min. Ground Clearance
398 mm 479 mm
Payload
3396 kg 3375 kg
Steering Angle
±40° ±38°
Drive Type
4-wheel drive (4WD) 4-wheel drive (4WD)
Wheelbase
3000 mm 2840 mm
Tyres
14 x 25(20PR) E3/L3 (BKT/CEAT) 14x25 20PR
Max. Breakout Force
116 kN 103.3 kN
Overall Length
7450 mm 7200 mm
Warranty
1 Yr. / 2000 hr. 1 Yr. / 2000 hr.
AC Cabin
Optional Optional
GPS
Standard Standard

Specifications

Engine

JCB 433-5 Tata Hitachi TL340H Prime
Engine Make JCB ecoMAX 448 Cummins B4.5 CIV121D221
Engine Type 4 stroke; direct injection; Water cooled; Turbo charged; after cooler with after treatment system 4-cycle water-cooled; direct injection;
Aspiration Water cooled and Turbo charged Turbocharged with charge air cooler
Emission Stage 5 BSIV
Max Torque 550 Nm @ 1500 rpm 500 Nm @ 1500 rpm
Max Power 130 HP (97 kW) @ 2200 rpm 121 HP (90.2 kW) @ 2200 rpm
Piston Displacement 4.8 L 4.5 L
No Of Cylinders 4 Cylinders 4 Cylinders
Battery 2 x 12V / 110Ah 2 x 12V / 130Ah
Alternator 28V /100A NA

Power Train

JCB 433-5 Tata Hitachi TL340H Prime
Transmission Fully Automatic Powershift Transmission Electro Hydraulically Controlled Hydrostatic transmission
Drive Type 4-wheel drive (4WD) 4-wheel drive (4WD)
Torque Converter Single-stage; single-phase; heavy-duty torque converter Single-stage; 3-element torque converter

Brakes

JCB 433-5 Tata Hitachi TL340H Prime
Service Hydraulic wet disc service brake; spring-applied transmission-mounted parking brake. Full Hydraulic braking: Self-adjusting wet type disc brake integrated in wheel hub acts on all 4 wheels. HST (hydrostatic transmission) system provides additional Hydraulic braking capacity.
Parking Spring-applied; hydraulically released (SAHR) disc brake Solenoid actuated spring applied Hydraulically released at front axle.

Steering System

JCB 433-5 Tata Hitachi TL340H Prime
Type Hydrostatic Power Steering with a Priority Valve Articulated Frame Steering
Steering-Angle ±40° ±38°

Axles And Final Drive

JCB 433-5 Tata Hitachi TL340H Prime
Front Axle Heavy-duty planetary with LSD. Fixed to front frame
Rear Axle Oscillating planetary - LSD optional. Centre pivot on mamframe (oscillating type)
Oscillating Angle ±12° ±12°

Speed

JCB 433-5 Tata Hitachi TL340H Prime
Max. Forward Speed 31 km/h 30 km/h
Max. Reverse Speed 21 km/h 6 km/h

Hydraulic System

JCB 433-5 Tata Hitachi TL340H Prime
System Type Load-Sensing - Closed Center System Load sensing
Pump Type Variable Displacement Axial Piston Pump Variable Displacement Axial Piston Pump
Maximum Pump Flow 164 L/min @ 2200 rpm 132 L/min @ 2200 rpm
System Pressure 250 bar 260 Bar

Special Refill Capacities

JCB 433-5 Tata Hitachi TL340H Prime
Fuel Tank 210 L 165 L
Hydraulic System 115 L NA
Engine Oil 14 L 17 L
Cooling System 24 L NA
Rear Axle Oil 18 L 17.5 L
Front Axle Oil 18 L 17 L
Hydraulic Tank NA 130 L
Transmission Oil 21 L NA
Def Tank 23.1 L 26 L

Dimensions

JCB 433-5 Tata Hitachi TL340H Prime
Overall Length With Bucket 7450 mm 7200 mm
Wheel Base 3000 mm 2840 mm
Height Over Cab 3270 mm 3110 mm
Height Over Exhaust 2810 mm NA
Min Grond Clearance 398 mm 479 mm
Width Over Tyres 2230 mm 2325 mm
Wheel Tread 2230 mm 1940 mm
Tyre Size 14 x 25(20PR) E3/L3 (BKT/CEAT) 14x25 20PR

Performance

JCB 433-5 Tata Hitachi TL340H Prime
Bucket Capacity 1.5 m³ 1.8 - 2.7 m³
Bucket Width 2350 mm 2560 mm
Payload 3396 kg 3375 kg
Tipping Load Straight 7687 kg 8260 kg
Tipping Load Full Turn 6791 kg 7340 kg
Max. Breakout Force 116 kN 103.3 kN
Operating Weight 10835 kg 10980 kg
Max Dump Angle 43.3° 45°
Bucket Roll Back Angle Full Height 52.3° 58°
Bucket Roll Back At Carry 42.3° NA
Bucket Roll Back At Ground Level 38.3° 42°
Dumping Height, Fully Raised 2850 mm 2792 mm
Dumping Reach, Fully Raised 1140 mm 1153 mm
Max. Hinge Pin Height 3850 mm NA
Max. Digging Depth 48 mm 79 mm
Turning Radius Over Tyres 5230 mm 5165 mm
Turning Radius Over Bucket 5790 mm 6000 mm

Specifications

Engine

JCB 433-5 Tata Hitachi TL340H Prime
Engine Make
JCB ecoMAX 448 Cummins B4.5 CIV121D221
Engine Type
4 stroke; direct injection; Water cooled; Turbo charged; after cooler with after treatment system 4-cycle water-cooled; direct injection;
Aspiration
Water cooled and Turbo charged Turbocharged with charge air cooler
Emission
Stage 5 BSIV
Max Torque
550 Nm @ 1500 rpm 500 Nm @ 1500 rpm
Max Power
130 HP (97 kW) @ 2200 rpm 121 HP (90.2 kW) @ 2200 rpm
Piston Displacement
4.8 L 4.5 L
No Of Cylinders
4 Cylinders 4 Cylinders
Battery
2 x 12V / 110Ah 2 x 12V / 130Ah
Alternator
28V /100A NA

Power Train

JCB 433-5 Tata Hitachi TL340H Prime
Transmission
Fully Automatic Powershift Transmission Electro Hydraulically Controlled Hydrostatic transmission
Drive Type
4-wheel drive (4WD) 4-wheel drive (4WD)
Torque Converter
Single-stage; single-phase; heavy-duty torque converter Single-stage; 3-element torque converter

Brakes

JCB 433-5 Tata Hitachi TL340H Prime
Service
Hydraulic wet disc service brake; spring-applied transmission-mounted parking brake. Full Hydraulic braking: Self-adjusting wet type disc brake integrated in wheel hub acts on all 4 wheels. HST (hydrostatic transmission) system provides additional Hydraulic braking capacity.
Parking
Spring-applied; hydraulically released (SAHR) disc brake Solenoid actuated spring applied Hydraulically released at front axle.

Steering System

JCB 433-5 Tata Hitachi TL340H Prime
Type
Hydrostatic Power Steering with a Priority Valve Articulated Frame Steering
Steering-Angle
±40° ±38°

Speed

JCB 433-5 Tata Hitachi TL340H Prime
Max. Forward Speed
31 km/h 30 km/h
Max. Reverse Speed
21 km/h 6 km/h

Axles And Final Drive

JCB 433-5 Tata Hitachi TL340H Prime
Front Axle
Heavy-duty planetary with LSD. Fixed to front frame
Rear Axle
Oscillating planetary - LSD optional. Centre pivot on mamframe (oscillating type)
Oscillating Angle
±12° ±12°

Hydraulics System

JCB 433-5 Tata Hitachi TL340H Prime
System Type
Load-Sensing - Closed Center System Load sensing
Pump Type
Variable Displacement Axial Piston Pump Variable Displacement Axial Piston Pump
Maximum Pump Flow
164 L/min @ 2200 rpm 132 L/min @ 2200 rpm
System Pressure
250 bar 260 Bar

Tyres

JCB 433-5 Tata Hitachi TL340H Prime
Size
Not Available Not Available

Special Refill Cpacities

JCB 433-5 Tata Hitachi TL340H Prime
Fuel Tank
210 L 165 L
Hydraulic System
115 L NA
Engine Oil
14 L 17 L
Cooling System
24 L NA
Rear Axle Oil
18 L 17.5 L
Front Axle Oil
18 L 17 L
Hydraulic Tank
NA 130 L
Transmission Oil
21 L NA
Def Tank
23.1 L 26 L

Dimensions

JCB 433-5 Tata Hitachi TL340H Prime
Overall Length With Bucket
7450 mm 7200 mm
Wheel Base
3000 mm 2840 mm
Height Over Cab
3270 mm 3110 mm
Height Over Exhaust
2810 mm NA
Min Grond Clearance
398 mm 479 mm
Width Over Tyres
2230 mm 2325 mm
Wheel Tread
2230 mm 1940 mm
Tyre Size
14 x 25(20PR) E3/L3 (BKT/CEAT) 14x25 20PR

Performance

JCB 433-5 Tata Hitachi TL340H Prime
Bucket Capacity
1.5 m³ 1.8 - 2.7 m³
Bucket Width
2350 mm 2560 mm
Payload
3396 kg 3375 kg
Tipping Load Straight
7687 kg 8260 kg
Tipping Load Full Turn
6791 kg 7340 kg
Max. Breakout Force
116 kN 103.3 kN
Operating Weight
10835 kg 10980 kg
Max Dump Angle
43.3° 45°
Bucket Roll Back Angle Full Height
52.3° 58°
Bucket Roll Back At Carry
42.3° NA
Bucket Roll Back At Ground Level
38.3° 42°
Dumping Height, Fully Raised
2850 mm 2792 mm
Dumping Reach, Fully Raised
1140 mm 1153 mm
Max. Hinge Pin Height
3850 mm NA
Max. Digging Depth
48 mm 79 mm
Turning Radius Over Tyres
5230 mm 5165 mm
Turning Radius Over Bucket
5790 mm 6000 mm

© 2025 Desi Machines All rights reserved.

Designed & Developed by PromotEdge

Help Us Reach You!

Let's get started

Disclaimer

Desi Machines is a platform where you can see and compare construction equipment. It showcases images, brochures, features, technical specifications, brand details & dealer information. All these are taken from respective brand websites, brochures, and other public resources. We do not claim ownership of these materials and strive to ensure their accuracy. However, the disparity may happen and we advise users to verify directly with respective brands and dealers. Desi Machines is not liable for any inaccuracies or reliance on the information provided. Use of this website is at your own discretion.

Compare


    Kindly fill out the below form. Our representative will get in touch with you
