The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | JCB 81 | Sany SY80C-9 PRO |
|---|
| Particulars | JCB 81 | Sany SY80C-9 PRO |
|---|
When comparing the Sany SY80C-9 PRO and the JCB 81, both excavators are tailored to infrastructure and construction tasks, with features like optional AC cabins and standard GPS. The Sany excels in maneuverability and fuel efficiency, while the JCB boasts higher engine power and arm force.
Based on the provided specifications, the choice between Sany SY80C-9 PRO and JCB 81 may depend on the specific needs of the project. Consider the Sany SY80C-9 PRO for projects requiring efficient maneuverability and lower ground pressure, and the JCB 81 for tasks benefiting from higher power and digging force.
| Brand | JCB Excavator | SANY Excavator |
|---|---|---|
| Type | Small (6-15 Ton) | Small (6-15 Ton) |
| Operating Cost | ₹ 33-35 Lakhs | Price Available Soon |
| Price | ₹ 33-35 Lakhs | Price Available Soon |
| Weight | 8050 Kg | 7920 Kg |
| Bucket | 0.24 - 0.32 m³ | 0.32-0.35 m³ |
| Max Digging Depth | 4080 mm | 4020 mm |
| Engine | Kirloskar 76 HP | Kubota 58 HP |
| Warranty | 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | 3700 mm | 3720 mm |
| Quick Overview: | The JCB 81 excavator is an 8-ton hydraulic excavator designed for urban infrastructure, irrigation, and light earthmoving applications. Powered by a Kirloskar 4R1040 NA engine delivering 76 HP, it offers efficient hydraulics, stable operation, and low fuel consumption. With a bucket capacity of 0.24–0.32 m³ and an operating weight of around 8,050 kg, the JCB 81 ensures reliable digging performance, easy maintenance, and strong productivity for contractors, supported by JCB’s nationwide service network. |
Sany SY80C-9 PRO delivers reliable performance in infrastructure projects, offering excellent maneuverability and efficiency as a small excavator. |
| Agency review | Get the best price for the JCB 81 Small Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Sany SY80C-9 PRO Small Excavator from authorized dealers. Contact us now for exclusive deals! |
When comparing the Sany SY80C-9 PRO and the JCB 81, both excavators are tailored to infrastructure and construction tasks, with features like optional AC cabins and standard GPS. The Sany excels in maneuverability and fuel efficiency, while the JCB boasts higher engine power and arm force.
Based on the provided specifications, the choice between Sany SY80C-9 PRO and JCB 81 may depend on the specific needs of the project. Consider the Sany SY80C-9 PRO for projects requiring efficient maneuverability and lower ground pressure, and the JCB 81 for tasks benefiting from higher power and digging force.
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Brand | |
| JCB Excavator | SANY Excavator |
| Type | |
| Small (6-15 Ton) | Small (6-15 Ton) |
| Price | |
| ₹ 33-35 Lakhs | Price Available Soon |
| Weight | |
| 8050 Kg | 7920 Kg |
| Bucket | |
| 0.24 - 0.32 m³ | 0.32-0.35 m³ |
| Max Digging Depth | |
| 4080 mm | 4020 mm |
| Engine | |
| Kirloskar 76 HP | Kubota 58 HP |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 3700 mm | 3720 mm |
| Quick Overview: | |
The JCB 81 excavator is an 8-ton hydraulic excavator designed for urban infrastructure, irrigation, and light earthmoving applications. Powered by a Kirloskar 4R1040 NA engine delivering 76 HP, it offers efficient hydraulics, stable operation, and low fuel consumption. With a bucket capacity of 0.24–0.32 m³ and an operating weight of around 8,050 kg, the JCB 81 ensures reliable digging performance, easy maintenance, and strong productivity for contractors, supported by JCB’s nationwide service network. |
Sany SY80C-9 PRO delivers reliable performance in infrastructure projects, offering excellent maneuverability and efficiency as a small excavator. |
| JCB 81 | Sany SY80C-9 PRO | |
| Engine Make | Kirloskar 4R 1040 NA | Kubota V2607-DI-T-ES09 |
| Fuel Tank | 164 L | 150 L |
| Engine Displacment | NA | 2.615 L |
| Under Carriage | 2840 mm | 2820 mm |
| Hydraulic System | 92 L | 120 L |
| Arm | 1740 mm | 1620 mm |
| Max Digging Reach | 6450 mm | 6240 mm |
| Fuel Consumption | 5.5 L/hour | 5 L/hour |
| Overall Width | 2220 mm | 2300 mm |
| Overall Length | 6230 mm | 6125 mm |
| Bucket Digging Force | 56.4 kN | 56 kN |
| Tailswing Radius | 1840 mm | 1800 mm |
| Track Shoe Width | 450 mm | 450 mm |
| AC Cabin | Optional | Optional |
| GPS | Standard | Standard |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Engine Make | |
| Kirloskar 4R 1040 NA | Kubota V2607-DI-T-ES09 |
| Fuel Tank | |
| 164 L | 150 L |
| Engine Displacment | |
| NA | 2.615 L |
| Under Carriage | |
| 2840 mm | 2820 mm |
| Hydraulic System | |
| 92 L | 120 L |
| Arm | |
| 1740 mm | 1620 mm |
| Max Digging Reach | |
| 6450 mm | 6240 mm |
| Fuel Consumption | |
| 5.5 L/hour | 5 L/hour |
| Overall Width | |
| 2220 mm | 2300 mm |
| Overall Length | |
| 6230 mm | 6125 mm |
| Bucket Digging Force | |
| 56.4 kN | 56 kN |
| Tailswing Radius | |
| 1840 mm | 1800 mm |
| Track Shoe Width | |
| 450 mm | 450 mm |
| AC Cabin | |
| Optional | Optional |
| GPS | |
| Standard | Standard |
| 3544 | 8873 | |
| Model | Kirloskar 76 HP | Kubota 58 HP |
| Fuel | Diesel | Diesel |
| Type | NA | 4 cylinders , inline , Water Cooled |
| Rated Engine Power | 76 HP (57 kW) @ 2200 rpm | 58 HP (43kW) @2000 rpm |
| Maximum Torque | NA | 225 Nm @ 1400 rpm |
| Piston Displacement | NA | 2.615 L |
| Alternator | 85A | 30A |
| Battery | 12V | 12V System |
| Starting Motor | NA | 24V/3.2 kW |
| 24V/3.2 kW | 24V/3.2 kW | |
| No of Top rollers | 1 | 1 |
| No of bottom rollers | 5 | 5 |
| Track Shoes (Each Side) | 39 | 39 |
| Track Guard | NA | NA |
| Track Shoe width | 450 mm | 450 mm |
| Ground bearing pressure | NA | 33 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 70% (35°) | 70% (35°) |
| Travel Speed-Low | 3.1 Km/h | 2.4 Km/h |
| Travel Speed-High | 5.1 Km/h | 4.4 Km/h |
| Max Tracking Force | 55.1 kN | 58 kN |
| JCB 81 | Sany SY80C-9 PRO | |
| Hydraulic pump | Variable displacement axial piston type. | Variable displacement axial piston pump |
| Maximum Flow | 2 x 70.3 L/min | 149 L/min |
| Pilot Pump | Gear Pump | NA |
| Implement Circuit | 28.4 MPa | 28 MPa |
| Swing Circuit | 22.5 MPa | 23.5 MPa |
| Travel circuit | 28.4 MPa | 26.3 MPa |
| Pilot circuit | NA | 3.5 MPa |
| JCB 81 | Sany SY80C-9 PRO | |
| Travel | NA | 2 Axial Piston Motor With Swing Holding Break. |
| Swing | Axial piston type. Hydraulic braking assisted by spring applied disc-type parking brake. | NA |
| JCB 81 | Sany SY80C-9 PRO | |
| Fuel tank | 164 L | 150 L |
| Engine Coolant | 23 L | 12 L |
| Engine oil | 14 L | 10 L |
| Hydraulic system | 92 L | 120 L |
| Hydraulic tank | 55 L | 90 L |
| JCB 81 | Sany SY80C-9 PRO | |
| Operating Weight | 8050 Kg | 7920 Kg |
| JCB 81 | Sany SY80C-9 PRO | |
| Boom length | 3700 mm | 3720 mm |
| Arm length | 1740 mm | 1620 mm |
| Max Digging Reach | 6450 mm | 6240 mm |
| Max Digging Reach on ground | 6320 mm | NA |
| Max digging depth | 4080 mm | 4020 mm |
| Max digging height | 7100 mm | 7060 mm |
| Max Dump Height | 5400 mm | 5155 mm |
| Max vertical wallcut depth | 3680 mm | 3290 mm |
| Min swing radius | 1840 mm | 1720 mm |
| Max Height at Min Swing radius | NA | 5550 mm |
| Max height (above ground) | 366 mm | NA |
| Dig depth (below ground) | 243 mm | NA |
| Bucket Digging Force | 56.4 kN | 56 kN |
| Arm Digging Force | 40.5 kN | 38 kN |
| Swing Speed | 12.5 rpm | 11.5 rpm |
| JCB 81 | Sany SY80C-9 PRO | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | 26° | NA |
| Width | 2300 mm | NA |
| Height | 397 mm | NA |
| JCB 81 | Sany SY80C-9 PRO | |
| Bucket Capacity | 0.24 - 0.32 m³ | 0.32-0.35 m³ |
| JCB 81 | Sany SY80C-9 PRO | |
| Overall Length | 6230 mm | 6125 mm |
| Overall width | 2220 mm | 2300 mm |
| Overall Height | 2770 mm | 2570 mm |
| Overall Height of Cab | 2720 mm | NA |
| Upper Width | NA | 2040 mm |
| Track Lengh on Ground | 2240 mm | 2195 mm |
| Undercarriage overall length | 2840 mm | 2820 mm |
| Tailswing radius | 1840 mm | 1800 mm |
| Min Ground clearance | 365 mm | 290 mm |
| Track gauge | 1700 mm | 1750 mm |
| Width over tracks | 2150 mm | NA |
| Track Height | 660 mm | NA |
| Counterweight Clearance | 775 mm | NA |
| Track Shoe Width | 450 mm | 450 mm |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Model | |
| Kirloskar 76 HP | Kubota 58 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| NA | 4 cylinders , inline , Water Cooled |
| Rated Engine Power | |
| 76 HP (57 kW) @ 2200 rpm | 58 HP (43kW) @2000 rpm |
| Maximum Torque | |
| NA | 225 Nm @ 1400 rpm |
| Piston Displacement | |
| NA | 2.615 L |
| Alternator | |
| 85A | 30A |
| Battery | |
| 12V | 12V System |
| Starting Motor | |
| NA | 24V/3.2 kW |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| No of Top rollers | |
| 1 | 1 |
| No of bottom rollers | |
| 5 | 5 |
| Track Shoes (Each Side) | |
| 39 | 39 |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 450 mm | 450 mm |
| Ground bearing pressure | |
| NA | 33 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 70% (35°) | 70% (35°) |
| Travel Speed-Low | |
| 3.1 Km/h | 2.4 Km/h |
| Travel Speed-High | |
| 5.1 Km/h | 4.4 Km/h |
| Max Tracking Force | |
| 55.1 kN | 58 kN |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Hydraulic pump | |
| Variable displacement axial piston type. | Variable displacement axial piston pump |
| Maximum Flow | |
| 2 x 70.3 L/min | 149 L/min |
| Pilot Pump | |
| Gear Pump | NA |
| Implement Circuit | |
| 28.4 MPa | 28 MPa |
| Swing Circuit | |
| 22.5 MPa | 23.5 MPa |
| Travel circuit | |
| 28.4 MPa | 26.3 MPa |
| Pilot circuit | |
| NA | 3.5 MPa |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Fuel tank | |
| 164 L | 150 L |
| Engine Coolant | |
| 23 L | 12 L |
| Engine oil | |
| 14 L | 10 L |
| Hydraulic system | |
| 92 L | 120 L |
| Hydraulic tank | |
| 55 L | 90 L |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Operating Weight | |
| 8050 Kg | 7920 Kg |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Boom length | |
| 3700 mm | 3720 mm |
| Arm length | |
| 1740 mm | 1620 mm |
| Max Digging Reach | |
| 6450 mm | 6240 mm |
| Max Digging Reach on ground | |
| 6320 mm | NA |
| Max digging depth | |
| 4080 mm | 4020 mm |
| Max digging height | |
| 7100 mm | 7060 mm |
| Max Dump Height | |
| 5400 mm | 5155 mm |
| Max vertical wallcut depth | |
| 3680 mm | 3290 mm |
| Min swing radius | |
| 1840 mm | 1720 mm |
| Max Height at Min Swing radius | |
| NA | 5550 mm |
| Max height (above ground) | |
| 366 mm | NA |
| Dig depth (below ground) | |
| 243 mm | NA |
| Bucket Digging Force | |
| 56.4 kN | 56 kN |
| Arm Digging Force | |
| 40.5 kN | 38 kN |
| Swing Speed | |
| 12.5 rpm | 11.5 rpm |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| 26° | NA |
| Width | |
| 2300 mm | NA |
| Height | |
| 397 mm | NA |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Bucket Capacity | |
| 0.24 - 0.32 m³ | 0.32-0.35 m³ |
| JCB 81 | Sany SY80C-9 PRO |
|---|---|
| Overall Length | |
| 6230 mm | 6125 mm |
| Overall width | |
| 2220 mm | 2300 mm |
| Overall Height | |
| 2770 mm | 2570 mm |
| Overall Height of Cab | |
| 2720 mm | NA |
| Upper Width | |
| NA | 2040 mm |
| Track Lengh on Ground | |
| 2240 mm | 2195 mm |
| Undercarriage overall length | |
| 2840 mm | 2820 mm |
| Tailswing radius | |
| 1840 mm | 1800 mm |
| Min Ground clearance | |
| 365 mm | 290 mm |
| Track gauge | |
| 1700 mm | 1750 mm |
| Width over tracks | |
| 2150 mm | NA |
| Track Height | |
| 660 mm | NA |
| Counterweight Clearence | |
| 775 mm | NA |
| Track Shoe Width | |
| 450 mm | 450 mm |
