The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|
| Particulars | Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|
The Liebherr R 978 SME Litronic and Sany SY870C-10HD are both extra-large excavators designed for mining and heavy-duty engineering. The Liebherr features a strong engine and robust construction, while the Sany offers higher engine power and a more formidable bucket digging force as well as a better swing speed.
Choosing between the Liebherr R 978 SME Litronic and the Sany SY870C-10HD should be based on specific operational needs. If engine power and swing speed are a priority, the Sany SY870C-10HD would be the better option. However, for longer operation duration and potential stability in challenging conditions, the Liebherr R 978 SME Litronic may be preferable. Both machines offer advanced features such as AC cabins and GPS, ensuring comfort and convenience for the operator.
| Brand | Liebherr | SANY |
|---|---|---|
| Type | Extra-Large (>50 Ton) | Extra-Large (>50 Ton) |
| Operating Cost | Price Available Soon | Price Available Soon |
| Price | Price Available Soon | Price Available Soon |
| Weight | 78350 Kg | 78600 Kg |
| Bucket | 4.00 - 5.00 m³ | 4.6 - 5.4 m³ |
| Max Digging Depth | 7200 mm | 7247 mm |
| Engine | Liebherr 449 HP | Isuzu 506 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 7000 mm | 7000 mm |
| Quick Overview: | Liebherr R 978 SME Litronic extra-large excavator excels in high-capacity mining and heavy-duty engineering operations. |
Delivering unmatched reliability and capacity for large-scale mining and earthmoving, the Sany SY870C-10HD extra-large excavator is the right suited for this. |
| Agency review | Get the best price for the Liebherr R 978 SME Litronic Extra-Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Sany SY870C-10HD Extra-Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The Liebherr R 978 SME Litronic and Sany SY870C-10HD are both extra-large excavators designed for mining and heavy-duty engineering. The Liebherr features a strong engine and robust construction, while the Sany offers higher engine power and a more formidable bucket digging force as well as a better swing speed.
Choosing between the Liebherr R 978 SME Litronic and the Sany SY870C-10HD should be based on specific operational needs. If engine power and swing speed are a priority, the Sany SY870C-10HD would be the better option. However, for longer operation duration and potential stability in challenging conditions, the Liebherr R 978 SME Litronic may be preferable. Both machines offer advanced features such as AC cabins and GPS, ensuring comfort and convenience for the operator.
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Brand | |
| Liebherr | SANY |
| Type | |
| Extra-Large (>50 Ton) | Extra-Large (>50 Ton) |
| Price | |
| Price Available Soon | Price Available Soon |
| Weight | |
| 78350 Kg | 78600 Kg |
| Bucket | |
| 4.00 - 5.00 m³ | 4.6 - 5.4 m³ |
| Max Digging Depth | |
| 7200 mm | 7247 mm |
| Engine | |
| Liebherr 449 HP | Isuzu 506 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 7000 mm | 7000 mm |
| Quick Overview: | |
Liebherr R 978 SME Litronic extra-large excavator excels in high-capacity mining and heavy-duty engineering operations. |
Delivering unmatched reliability and capacity for large-scale mining and earthmoving, the Sany SY870C-10HD extra-large excavator is the right suited for this. |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Engine Make | Liebherr D9508 A7 | Isuzu GH-6WG1X |
| Fuel Tank | 1140 L | 940 L |
| Engine Displacment | 16.16 L | 15.68 L |
| Under Carriage | 5960 mm | 5946 mm |
| Hydraulic System | 920 L | NA |
| Arm | 2600 mm | 2600 mm |
| Max Digging Reach | NA | 11703 mm |
| Fuel Consumption | NA | NA |
| Overall Width | 4495 mm | 4320 mm |
| Overall Length | 12800 mm | 13002 mm |
| Bucket Digging Force | 392 kN | 432 kN |
| Tailswing Radius | NA | 4220 mm |
| Track Shoe Width | 500 mm | 650 mm |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Engine Make | |
| Liebherr D9508 A7 | Isuzu GH-6WG1X |
| Fuel Tank | |
| 1140 L | 940 L |
| Engine Displacment | |
| 16.16 L | 15.68 L |
| Under Carriage | |
| 5960 mm | 5946 mm |
| Hydraulic System | |
| 920 L | NA |
| Arm | |
| 2600 mm | 2600 mm |
| Max Digging Reach | |
| NA | 11703 mm |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 4495 mm | 4320 mm |
| Overall Length | |
| 12800 mm | 13002 mm |
| Bucket Digging Force | |
| 392 kN | 432 kN |
| Tailswing Radius | |
| NA | 4220 mm |
| Track Shoe Width | |
| 500 mm | 650 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| 3711 | 3684 | |
| Model | Liebherr 449 HP | Isuzu 506 HP |
| Fuel | Diesel | Diesel |
| Type | 4-stroke diesel Common-Rail , 8 cylinder V engine , after-cooled and fuel cooled , Engine Stage IIIA: with EGR , monoturbo , Water-cooled and integrated motor oil cooler | 6 Cylinder , direct injection , Water Cooled |
| Rated Engine Power | 449 HP (330 kW) @ 1800 rpm | 506 HP (377 kW) @ 1800 rpm |
| Maximum Torque | 2750 Nm @ 1100 rpm | 2138 Nm @ 1500 rpm |
| Piston Displacement | 16.16 L | 15.68 L |
| Alternator | Three-phase current 28 V / 140 A | 90A |
| Battery | 12 V , 2 x 180 Ah | 2 x 12 V |
| Starting Motor | 24 V - 7.8 kW | 24 V - 5.0 kW |
| 24 V - 5.0 kW | 24 V - 5.0 kW | |
| No of Top rollers | 2 | 3 |
| No of bottom rollers | 8 | 8 |
| Track Shoes (Each Side) | NA | 48 |
| Track Guard | NA | NA |
| Track Shoe width | 500 mm | 650 mm |
| Ground bearing pressure | 151 kPa | 114 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | NA | 70 % (35°) |
| Travel Speed-Low | NA | 2.9 km/h |
| Travel Speed-High | 3.5 Km/h | 4.5 Km.h |
| Max Tracking Force | 568 kN | 480 kN |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Hydraulic pump | Two Liebherr variable displacement swashplate pumps | 2 Variable Displacement Axial Piston Pumps |
| Maximum Flow | 2 x 410 L/min | 2 x 450 L/min |
| Pilot Pump | NA | 1 Gear Pump |
| Implement Circuit | 35.0 MPa | 34.3 MPa |
| Swing Circuit | NA | 29.4 MPa |
| Travel circuit | NA | 34.3 MPa |
| Pilot circuit | NA | 3.9 MPa |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Travel | Liebherr swashplate motor with brake valves on both sides | Axial Piston Motor with Parking Brake |
| Swing | Liebherr swashplate motor with integrated brake valve | Axial Piston Motor with Swing Holding Brake |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Fuel tank | 1140 L | 940 L |
| Engine Coolant | NA | 70 L |
| Engine oil | NA | 57 L |
| Hydraulic system | 920 L | NA |
| Hydraulic tank | 435 L | 620 L |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Operating Weight | 78350 Kg | 78600 Kg |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Boom length | 7000 mm | 7000 mm |
| Arm length | 2600 mm | 2600 mm |
| Max Digging Reach | NA | 11703 mm |
| Max Digging Reach on ground | 11650 mm | NA |
| Max digging depth | 7200 mm | 7247 mm |
| Max digging height | 11650 mm | 10910 mm |
| Max Dump Height | 7850 mm | 7047 mm |
| Max vertical wallcut depth | NA | NA |
| Min swing radius | NA | 5586 mm |
| Max Height at Min Swing radius | NA | 9802 mm |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 392 kN | 432 kN |
| Arm Digging Force | 357 kN | NA |
| Swing Speed | 5.6 rpm | 7.9 rpm |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Bucket Capacity | 4.00 - 5.00 m³ | 4.6 - 5.4 m³ |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD | |
| Overall Length | 12800 mm | 13002 mm |
| Overall width | 4495 mm | 4320 mm |
| Overall Height | 4200 mm | 4742 mm |
| Overall Height of Cab | 3665 mm | 3795 mm |
| Upper Width | 3515 mm | 3460 mm |
| Track Lengh on Ground | 4770 mm | 4770 mm |
| Undercarriage overall length | 5960 mm | 5946 mm |
| Tailswing radius | NA | 4220 mm |
| Min Ground clearance | 745 mm | 880 mm |
| Track gauge | 3350 mm | 3380 mm |
| Width over tracks | 4130 mm | 4320 mm |
| Track Height | 1460 mm | NA |
| Counterweight Clearance | 1585 mm | NA |
| Track Shoe Width | 500 mm | 650 mm |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Model | |
| Liebherr 449 HP | Isuzu 506 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4-stroke diesel Common-Rail , 8 cylinder V engine , after-cooled and fuel cooled , Engine Stage IIIA: with EGR , monoturbo , Water-cooled and integrated motor oil cooler | 6 Cylinder , direct injection , Water Cooled |
| Rated Engine Power | |
| 449 HP (330 kW) @ 1800 rpm | 506 HP (377 kW) @ 1800 rpm |
| Maximum Torque | |
| 2750 Nm @ 1100 rpm | 2138 Nm @ 1500 rpm |
| Piston Displacement | |
| 16.16 L | 15.68 L |
| Alternator | |
| Three-phase current 28 V / 140 A | 90A |
| Battery | |
| 12 V , 2 x 180 Ah | 2 x 12 V |
| Starting Motor | |
| 24 V - 7.8 kW | 24 V - 5.0 kW |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| No of Top rollers | |
| 2 | 3 |
| No of bottom rollers | |
| 8 | 8 |
| Track Shoes (Each Side) | |
| NA | 48 |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 500 mm | 650 mm |
| Ground bearing pressure | |
| 151 kPa | 114 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| NA | 70 % (35°) |
| Travel Speed-Low | |
| NA | 2.9 km/h |
| Travel Speed-High | |
| 3.5 Km/h | 4.5 Km.h |
| Max Tracking Force | |
| 568 kN | 480 kN |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Hydraulic pump | |
| Two Liebherr variable displacement swashplate pumps | 2 Variable Displacement Axial Piston Pumps |
| Maximum Flow | |
| 2 x 410 L/min | 2 x 450 L/min |
| Pilot Pump | |
| NA | 1 Gear Pump |
| Implement Circuit | |
| 35.0 MPa | 34.3 MPa |
| Swing Circuit | |
| NA | 29.4 MPa |
| Travel circuit | |
| NA | 34.3 MPa |
| Pilot circuit | |
| NA | 3.9 MPa |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Fuel tank | |
| 1140 L | 940 L |
| Engine Coolant | |
| NA | 70 L |
| Engine oil | |
| NA | 57 L |
| Hydraulic system | |
| 920 L | NA |
| Hydraulic tank | |
| 435 L | 620 L |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Operating Weight | |
| 78350 Kg | 78600 Kg |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Boom length | |
| 7000 mm | 7000 mm |
| Arm length | |
| 2600 mm | 2600 mm |
| Max Digging Reach | |
| NA | 11703 mm |
| Max Digging Reach on ground | |
| 11650 mm | NA |
| Max digging depth | |
| 7200 mm | 7247 mm |
| Max digging height | |
| 11650 mm | 10910 mm |
| Max Dump Height | |
| 7850 mm | 7047 mm |
| Max vertical wallcut depth | |
| NA | NA |
| Min swing radius | |
| NA | 5586 mm |
| Max Height at Min Swing radius | |
| NA | 9802 mm |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 392 kN | 432 kN |
| Arm Digging Force | |
| 357 kN | NA |
| Swing Speed | |
| 5.6 rpm | 7.9 rpm |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Bucket Capacity | |
| 4.00 - 5.00 m³ | 4.6 - 5.4 m³ |
| Liebherr R 978 SME Litronic | Sany SY870C-10HD |
|---|---|
| Overall Length | |
| 12800 mm | 13002 mm |
| Overall width | |
| 4495 mm | 4320 mm |
| Overall Height | |
| 4200 mm | 4742 mm |
| Overall Height of Cab | |
| 3665 mm | 3795 mm |
| Upper Width | |
| 3515 mm | 3460 mm |
| Track Lengh on Ground | |
| 4770 mm | 4770 mm |
| Undercarriage overall length | |
| 5960 mm | 5946 mm |
| Tailswing radius | |
| NA | 4220 mm |
| Min Ground clearance | |
| 745 mm | 880 mm |
| Track gauge | |
| 3350 mm | 3380 mm |
| Width over tracks | |
| 4130 mm | 4320 mm |
| Track Height | |
| 1460 mm | NA |
| Counterweight Clearence | |
| 1585 mm | NA |
| Track Shoe Width | |
| 500 mm | 650 mm |
