The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Liugong 9035E | XCMG XE40U |
|---|
| Particulars | Liugong 9035E | XCMG XE40U |
|---|
When comparing the Liugong 9035E and XCMG XE40U mini excavators, it's important to balance performance features and operator comforts. The Liugong 9035E boasts slightly higher digging capabilities and speed, while the XCMG XE40U offers enhanced operator amenities with its standard AC cabin and GPS, as well as higher stability due to its greater operating weight and engine displacement.
Your choice between these two models should be guided by your specific needs. If operator comfort and job site navigation are priorities and you work on varied terrain, the XCMG XE40U might be the better option, despite a minor compromise in digging reach and travel speed. For those prioritizing maximum reach and higher working speeds while willing to forego built-in GPS and an AC cabin, the Liugong 9035E would be a suitable choice.
| Brand | LiuGong | XCMG |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | ₹ 33-34 Lakhs | ₹ 34-35 Lakhs |
| Price | ₹ 33-34 Lakhs | ₹ 34-35 Lakhs |
| Weight | 3980 Kg | 4200 Kg |
| Bucket | 0.11 m³ | 0.12 m³ |
| Max Digging Depth | 3085 mm | 3060 mm |
| Engine | Yanmar 28.4 HP | Yanmar 30 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 2450 mm | 2560 mm |
| Quick Overview: | For landscaping and urban construction, Liugong 9035E is a mini excavator featuring advanced hydraulics for efficient performance. |
Compact and efficient is the other word for XCMG XE40U mini excavator that delivers precision and versatility for landscaping and small-scale construction. |
| Agency review | Get the best price for the Liugong 9035E Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the XCMG XE40U Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
When comparing the Liugong 9035E and XCMG XE40U mini excavators, it's important to balance performance features and operator comforts. The Liugong 9035E boasts slightly higher digging capabilities and speed, while the XCMG XE40U offers enhanced operator amenities with its standard AC cabin and GPS, as well as higher stability due to its greater operating weight and engine displacement.
Your choice between these two models should be guided by your specific needs. If operator comfort and job site navigation are priorities and you work on varied terrain, the XCMG XE40U might be the better option, despite a minor compromise in digging reach and travel speed. For those prioritizing maximum reach and higher working speeds while willing to forego built-in GPS and an AC cabin, the Liugong 9035E would be a suitable choice.
| Liugong 9035E | XCMG XE40U |
|---|---|
| Brand | |
| LiuGong | XCMG |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 33-34 Lakhs | ₹ 34-35 Lakhs |
| Weight | |
| 3980 Kg | 4200 Kg |
| Bucket | |
| 0.11 m³ | 0.12 m³ |
| Max Digging Depth | |
| 3085 mm | 3060 mm |
| Engine | |
| Yanmar 28.4 HP | Yanmar 30 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 2450 mm | 2560 mm |
| Quick Overview: | |
For landscaping and urban construction, Liugong 9035E is a mini excavator featuring advanced hydraulics for efficient performance. |
Compact and efficient is the other word for XCMG XE40U mini excavator that delivers precision and versatility for landscaping and small-scale construction. |
| Liugong 9035E | XCMG XE40U | |
| Engine Make | Yanmar 3TNV88-BPLY | Yanmar 3TNV88 |
| Fuel Tank | 40 L | 40 L |
| Engine Displacment | 1.6 L | 1.64 L |
| Under Carriage | 2100 mm | 1721 mm |
| Hydraulic System | NA | 60 L |
| Arm | 1320 mm | 1350 mm |
| Max Digging Reach | 5385 mm | 5300 mm |
| Fuel Consumption | NA | NA |
| Overall Width | 1700 mm | 1740 mm |
| Overall Length | 4810 mm | 4970 mm |
| Bucket Digging Force | 30 kN | NA |
| Tailswing Radius | 850 mm | 870 mm |
| Track Shoe Width | 300 mm | 300 mm |
| AC Cabin | Not Available | Standard |
| GPS | Not Available | Standard |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Engine Make | |
| Yanmar 3TNV88-BPLY | Yanmar 3TNV88 |
| Fuel Tank | |
| 40 L | 40 L |
| Engine Displacment | |
| 1.6 L | 1.64 L |
| Under Carriage | |
| 2100 mm | 1721 mm |
| Hydraulic System | |
| NA | 60 L |
| Arm | |
| 1320 mm | 1350 mm |
| Max Digging Reach | |
| 5385 mm | 5300 mm |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 1700 mm | 1740 mm |
| Overall Length | |
| 4810 mm | 4970 mm |
| Bucket Digging Force | |
| 30 kN | NA |
| Tailswing Radius | |
| 850 mm | 870 mm |
| Track Shoe Width | |
| 300 mm | 300 mm |
| AC Cabin | |
| Not Available | Standard |
| GPS | |
| Not Available | Standard |
| 8872 | 3660 | |
| Model | Yanmar 28.4 HP | Yanmar 30 HP |
| Fuel | Diesel | Diesel |
| Type | 3 cylinders | 3 cylinder , four stroke water cooled |
| Rated Engine Power | 28.4 HP (21.2 kW) @ 2400 rpm | 30 HP (22.4 kW) @ 2400 rpm |
| Maximum Torque | 107 Nm @ 1440 rpm | 106.4 Nm @ 1000 rpm |
| Piston Displacement | 1.6 L | 1.64 L |
| Alternator | NA | NA |
| Battery | NA | 12 V x 2 |
| Starting Motor | 12 V | NA |
| NA | NA | |
| No of Top rollers | 1 | 1 |
| No of bottom rollers | 4 | 4 |
| Track Shoes (Each Side) | 45 | 46 |
| Track Guard | NA | NA |
| Track Shoe width | 300 mm | 300 mm |
| Ground bearing pressure | NA | NA |
| Track Tensioning | Grease | Grease |
| Gradeability | NA | 30° |
| Travel Speed-Low | 2.5 Km/h | NA |
| Travel Speed-High | 4.2 Km/h | 3.6 Km/h |
| Max Tracking Force | 33 kN | 31.6 kN |
| Liugong 9035E | XCMG XE40U | |
| Hydraulic pump | Variable Displacement Piston Pump | 1 Piston Pump |
| Maximum Flow | 99 L/min | 1 x 108 L/min |
| Pilot Pump | NA | NA |
| Implement Circuit | 24.5 MPa | 23 MPa |
| Swing Circuit | NA | 16.7 MPa |
| Travel circuit | NA | 21 MPa |
| Pilot circuit | 3.9 MPa | 3.9 MPa |
| Liugong 9035E | XCMG XE40U | |
| Travel | NA | NA |
| Swing | Axial Piston Motor | NA |
| Liugong 9035E | XCMG XE40U | |
| Fuel tank | 40 L | 40 L |
| Engine Coolant | 7 L | 8 L |
| Engine oil | 7 L | 7 L |
| Hydraulic system | NA | 60 L |
| Hydraulic tank | 58 L | 45 L |
| Liugong 9035E | XCMG XE40U | |
| Operating Weight | 3980 Kg | 4200 Kg |
| Liugong 9035E | XCMG XE40U | |
| Boom length | 2450 mm | 2560 mm |
| Arm length | 1320 mm | 1350 mm |
| Max Digging Reach | 5385 mm | 5300 mm |
| Max Digging Reach on ground | 5270 mm | NA |
| Max digging depth | 3085 mm | 3060 mm |
| Max digging height | 4710 mm | 5000 mm |
| Max Dump Height | 3310 mm | 3600 mm |
| Max vertical wallcut depth | 2503 mm | 2260 mm |
| Min swing radius | 2416 mm | 2170 mm |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | 2610 mm | NA |
| Bucket Digging Force | 30 kN | NA |
| Arm Digging Force | 22kN | NA |
| Swing Speed | 10 rpm | 9 rpm |
| Liugong 9035E | XCMG XE40U | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | 390 mm | 360 mm |
| Approach Angle | NA | NA |
| Width | 1700 mm | NA |
| Height | 343 mm | NA |
| Liugong 9035E | XCMG XE40U | |
| Bucket Capacity | 0.11 m³ | 0.12 m³ |
| Liugong 9035E | XCMG XE40U | |
| Overall Length | 4810 mm | 4970 mm |
| Overall width | 1700 mm | 1740 mm |
| Overall Height | 2500 mm | 2535 mm |
| Overall Height of Cab | NA | NA |
| Upper Width | 1600 mm | NA |
| Track Lengh on Ground | 1675 mm | NA |
| Undercarriage overall length | 2100 mm | 1721 mm |
| Tailswing radius | 850 mm | 870 mm |
| Min Ground clearance | 430 mm | 297 mm |
| Track gauge | 1400 mm | 1440 mm |
| Width over tracks | 1700 mmm | 1740 mm |
| Track Height | NA | NA |
| Counterweight Clearance | 580 mm | 587 mm |
| Track Shoe Width | 300 mm | 300 mm |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Model | |
| Yanmar 28.4 HP | Yanmar 30 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 3 cylinders | 3 cylinder , four stroke water cooled |
| Rated Engine Power | |
| 28.4 HP (21.2 kW) @ 2400 rpm | 30 HP (22.4 kW) @ 2400 rpm |
| Maximum Torque | |
| 107 Nm @ 1440 rpm | 106.4 Nm @ 1000 rpm |
| Piston Displacement | |
| 1.6 L | 1.64 L |
| Alternator | |
| NA | NA |
| Battery | |
| NA | 12 V x 2 |
| Starting Motor | |
| 12 V | NA |
| Liugong 9035E | XCMG XE40U |
|---|---|
| No of Top rollers | |
| 1 | 1 |
| No of bottom rollers | |
| 4 | 4 |
| Track Shoes (Each Side) | |
| 45 | 46 |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 300 mm | 300 mm |
| Ground bearing pressure | |
| NA | NA |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| NA | 30° |
| Travel Speed-Low | |
| 2.5 Km/h | NA |
| Travel Speed-High | |
| 4.2 Km/h | 3.6 Km/h |
| Max Tracking Force | |
| 33 kN | 31.6 kN |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Hydraulic pump | |
| Variable Displacement Piston Pump | 1 Piston Pump |
| Maximum Flow | |
| 99 L/min | 1 x 108 L/min |
| Pilot Pump | |
| NA | NA |
| Implement Circuit | |
| 24.5 MPa | 23 MPa |
| Swing Circuit | |
| NA | 16.7 MPa |
| Travel circuit | |
| NA | 21 MPa |
| Pilot circuit | |
| 3.9 MPa | 3.9 MPa |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Fuel tank | |
| 40 L | 40 L |
| Engine Coolant | |
| 7 L | 8 L |
| Engine oil | |
| 7 L | 7 L |
| Hydraulic system | |
| NA | 60 L |
| Hydraulic tank | |
| 58 L | 45 L |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Operating Weight | |
| 3980 Kg | 4200 Kg |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Boom length | |
| 2450 mm | 2560 mm |
| Arm length | |
| 1320 mm | 1350 mm |
| Max Digging Reach | |
| 5385 mm | 5300 mm |
| Max Digging Reach on ground | |
| 5270 mm | NA |
| Max digging depth | |
| 3085 mm | 3060 mm |
| Max digging height | |
| 4710 mm | 5000 mm |
| Max Dump Height | |
| 3310 mm | 3600 mm |
| Max vertical wallcut depth | |
| 2503 mm | 2260 mm |
| Min swing radius | |
| 2416 mm | 2170 mm |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| 2610 mm | NA |
| Bucket Digging Force | |
| 30 kN | NA |
| Arm Digging Force | |
| 22kN | NA |
| Swing Speed | |
| 10 rpm | 9 rpm |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| 390 mm | 360 mm |
| Approach Angle | |
| NA | NA |
| Width | |
| 1700 mm | NA |
| Height | |
| 343 mm | NA |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Bucket Capacity | |
| 0.11 m³ | 0.12 m³ |
| Liugong 9035E | XCMG XE40U |
|---|---|
| Overall Length | |
| 4810 mm | 4970 mm |
| Overall width | |
| 1700 mm | 1740 mm |
| Overall Height | |
| 2500 mm | 2535 mm |
| Overall Height of Cab | |
| NA | NA |
| Upper Width | |
| 1600 mm | NA |
| Track Lengh on Ground | |
| 1675 mm | NA |
| Undercarriage overall length | |
| 2100 mm | 1721 mm |
| Tailswing radius | |
| 850 mm | 870 mm |
| Min Ground clearance | |
| 430 mm | 297 mm |
| Track gauge | |
| 1400 mm | 1440 mm |
| Width over tracks | |
| 1700 mmm | 1740 mm |
| Track Height | |
| NA | NA |
| Counterweight Clearence | |
| 580 mm | 587 mm |
| Track Shoe Width | |
| 300 mm | 300 mm |
