The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Liugong 9035E | Yanmar Vi050-6B |
|---|
| Particulars | Liugong 9035E | Yanmar Vi050-6B |
|---|
The comparison between the Liugong 9035E and Yanmar Vi050-6B mini excavators reveals key differences. The Liugong offers advanced hydraulics and efficient Yanmar engine performance suitable for landscaping and urban construction, while the Yanmar packs a stronger engine, higher bucket capacity, and optional AC cabin suitable for more demanding tasks.
For users needing a compact and efficient machine for small to medium-sized jobs, the Liugong 9035E may be the more economical choice. However, if the work demands greater power, larger capacity, and additional comfort and tech features such as an AC cabin and GPS, the Yanmar Vi050-6B would be worth the higher investment.
| Brand | LiuGong | Yanmar |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | ₹ 33-34 Lakhs | ₹ 35.5 - 36.5 Lakhs |
| Price | ₹ 33-34 Lakhs | ₹ 35.5 - 36.5 Lakhs |
| Weight | 3980 Kg | 4735 Kg |
| Bucket | 0.11 m³ | 0.15 m³ |
| Max Digging Depth | 3085 mm | 3360 mm |
| Engine | Yanmar 28.4 HP | Yanmar 37.7 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 2450 mm | NA |
| Quick Overview: | For landscaping and urban construction, Liugong 9035E is a mini excavator featuring advanced hydraulics for efficient performance. |
Yanmar Vi050-6B mini excavator ensures unmatched performance and durability, perfect for compact construction and landscaping tasks. |
| Agency review | Get the best price for the Liugong 9035E Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Yanmar Vi050-6B Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
The comparison between the Liugong 9035E and Yanmar Vi050-6B mini excavators reveals key differences. The Liugong offers advanced hydraulics and efficient Yanmar engine performance suitable for landscaping and urban construction, while the Yanmar packs a stronger engine, higher bucket capacity, and optional AC cabin suitable for more demanding tasks.
For users needing a compact and efficient machine for small to medium-sized jobs, the Liugong 9035E may be the more economical choice. However, if the work demands greater power, larger capacity, and additional comfort and tech features such as an AC cabin and GPS, the Yanmar Vi050-6B would be worth the higher investment.
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Brand | |
| LiuGong | Yanmar |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 33-34 Lakhs | ₹ 35.5 - 36.5 Lakhs |
| Weight | |
| 3980 Kg | 4735 Kg |
| Bucket | |
| 0.11 m³ | 0.15 m³ |
| Max Digging Depth | |
| 3085 mm | 3360 mm |
| Engine | |
| Yanmar 28.4 HP | Yanmar 37.7 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 2450 mm | NA |
| Quick Overview: | |
For landscaping and urban construction, Liugong 9035E is a mini excavator featuring advanced hydraulics for efficient performance. |
Yanmar Vi050-6B mini excavator ensures unmatched performance and durability, perfect for compact construction and landscaping tasks. |
| Liugong 9035E | Yanmar Vi050-6B | |
| Engine Make | Yanmar 3TNV88-BPLY | Yanmar 4TNV88-ZPBV |
| Fuel Tank | 40 L | 66 L |
| Engine Displacment | 1.6 L | NA |
| Under Carriage | 2100 mm | 2590 mm |
| Hydraulic System | NA | NA |
| Arm | 1320 mm | NA |
| Max Digging Reach | 5385 mm | NA |
| Fuel Consumption | NA | NA |
| Overall Width | 1700 mm | 1940 mm |
| Overall Length | 4810 mm | 5230 mm |
| Bucket Digging Force | 30 kN | 36.5 kN |
| Tailswing Radius | 850 mm | NA |
| Track Shoe Width | 300 mm | 350 mm |
| AC Cabin | Not Available | Optional |
| GPS | Not Available | Standard |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Engine Make | |
| Yanmar 3TNV88-BPLY | Yanmar 4TNV88-ZPBV |
| Fuel Tank | |
| 40 L | 66 L |
| Engine Displacment | |
| 1.6 L | NA |
| Under Carriage | |
| 2100 mm | 2590 mm |
| Hydraulic System | |
| NA | NA |
| Arm | |
| 1320 mm | NA |
| Max Digging Reach | |
| 5385 mm | NA |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 1700 mm | 1940 mm |
| Overall Length | |
| 4810 mm | 5230 mm |
| Bucket Digging Force | |
| 30 kN | 36.5 kN |
| Tailswing Radius | |
| 850 mm | NA |
| Track Shoe Width | |
| 300 mm | 350 mm |
| AC Cabin | |
| Not Available | Optional |
| GPS | |
| Not Available | Standard |
| 8872 | 3697 | |
| Model | Yanmar 28.4 HP | Yanmar 37.7 HP |
| Fuel | Diesel | Diesel |
| Type | 3 cylinders | Vertical 4-cylinder water-cooled direct injection diesel engine |
| Rated Engine Power | 28.4 HP (21.2 kW) @ 2400 rpm | 37.7 HP (28.1 kW) @ 2200 rpm |
| Maximum Torque | 107 Nm @ 1440 rpm | NA |
| Piston Displacement | 1.6 L | NA |
| Alternator | NA | NA |
| Battery | NA | NA |
| Starting Motor | 12 V | NA |
| NA | NA | |
| No of Top rollers | 1 | NA |
| No of bottom rollers | 4 | NA |
| Track Shoes (Each Side) | 45 | NA |
| Track Guard | NA | NA |
| Track Shoe width | 300 mm | 350 mm |
| Ground bearing pressure | NA | 29.9 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | NA | NA |
| Travel Speed-Low | 2.5 Km/h | 2.1 Km/h |
| Travel Speed-High | 4.2 Km/h | 4.3 Km.h |
| Max Tracking Force | 33 kN | NA |
| Liugong 9035E | Yanmar Vi050-6B | |
| Hydraulic pump | Variable Displacement Piston Pump | Variable Displacement Pump |
| Maximum Flow | 99 L/min | 2 x 42.5 L/min |
| Pilot Pump | NA | 1 Gear Pump |
| Implement Circuit | 24.5 MPa | 24.5 MPa |
| Swing Circuit | NA | 21.6 MPa |
| Travel circuit | NA | 24.5 MPa |
| Pilot circuit | 3.9 MPa | 3.9 MPa |
| Liugong 9035E | Yanmar Vi050-6B | |
| Travel | NA | NA |
| Swing | Axial Piston Motor | NA |
| Liugong 9035E | Yanmar Vi050-6B | |
| Fuel tank | 40 L | 66 L |
| Engine Coolant | 7 L | NA |
| Engine oil | 7 L | NA |
| Hydraulic system | NA | NA |
| Hydraulic tank | 58 L | 38 L |
| Liugong 9035E | Yanmar Vi050-6B | |
| Operating Weight | 3980 Kg | 4735 Kg |
| Liugong 9035E | Yanmar Vi050-6B | |
| Boom length | 2450 mm | NA |
| Arm length | 1320 mm | NA |
| Max Digging Reach | 5385 mm | NA |
| Max Digging Reach on ground | 5270 mm | NA |
| Max digging depth | 3085 mm | 3360 mm |
| Max digging height | 4710 mm | 5530 mm |
| Max Dump Height | 3310 mm | 3870 mm |
| Max vertical wallcut depth | 2503 mm | 2690 mm |
| Min swing radius | 2416 mm | 2190 mm |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | 2610 mm | NA |
| Bucket Digging Force | 30 kN | 36.5 kN |
| Arm Digging Force | 22kN | 22.7 kN |
| Swing Speed | 10 rpm | 10 rpm |
| Liugong 9035E | Yanmar Vi050-6B | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | 390 mm | NA |
| Approach Angle | NA | NA |
| Width | 1700 mm | 1970 mm |
| Height | 343 mm | 400 mm |
| Liugong 9035E | Yanmar Vi050-6B | |
| Bucket Capacity | 0.11 m³ | 0.15 m³ |
| Liugong 9035E | Yanmar Vi050-6B | |
| Overall Length | 4810 mm | 5230 mm |
| Overall width | 1700 mm | 1940 mm |
| Overall Height | 2500 mm | 2540 mm |
| Overall Height of Cab | NA | NA |
| Upper Width | 1600 mm | NA |
| Track Lengh on Ground | 1675 mm | NA |
| Undercarriage overall length | 2100 mm | 2590 mm |
| Tailswing radius | 850 mm | NA |
| Min Ground clearance | 430 mm | 345 mm |
| Track gauge | 1400 mm | 1590 mm |
| Width over tracks | 1700 mmm | 1940 mm |
| Track Height | NA | NA |
| Counterweight Clearance | 580 mm | NA |
| Track Shoe Width | 300 mm | 350 mm |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Model | |
| Yanmar 28.4 HP | Yanmar 37.7 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 3 cylinders | Vertical 4-cylinder water-cooled direct injection diesel engine |
| Rated Engine Power | |
| 28.4 HP (21.2 kW) @ 2400 rpm | 37.7 HP (28.1 kW) @ 2200 rpm |
| Maximum Torque | |
| 107 Nm @ 1440 rpm | NA |
| Piston Displacement | |
| 1.6 L | NA |
| Alternator | |
| NA | NA |
| Battery | |
| NA | NA |
| Starting Motor | |
| 12 V | NA |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| No of Top rollers | |
| 1 | NA |
| No of bottom rollers | |
| 4 | NA |
| Track Shoes (Each Side) | |
| 45 | NA |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 300 mm | 350 mm |
| Ground bearing pressure | |
| NA | 29.9 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| NA | NA |
| Travel Speed-Low | |
| 2.5 Km/h | 2.1 Km/h |
| Travel Speed-High | |
| 4.2 Km/h | 4.3 Km.h |
| Max Tracking Force | |
| 33 kN | NA |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Hydraulic pump | |
| Variable Displacement Piston Pump | Variable Displacement Pump |
| Maximum Flow | |
| 99 L/min | 2 x 42.5 L/min |
| Pilot Pump | |
| NA | 1 Gear Pump |
| Implement Circuit | |
| 24.5 MPa | 24.5 MPa |
| Swing Circuit | |
| NA | 21.6 MPa |
| Travel circuit | |
| NA | 24.5 MPa |
| Pilot circuit | |
| 3.9 MPa | 3.9 MPa |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Fuel tank | |
| 40 L | 66 L |
| Engine Coolant | |
| 7 L | NA |
| Engine oil | |
| 7 L | NA |
| Hydraulic system | |
| NA | NA |
| Hydraulic tank | |
| 58 L | 38 L |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Operating Weight | |
| 3980 Kg | 4735 Kg |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Boom length | |
| 2450 mm | NA |
| Arm length | |
| 1320 mm | NA |
| Max Digging Reach | |
| 5385 mm | NA |
| Max Digging Reach on ground | |
| 5270 mm | NA |
| Max digging depth | |
| 3085 mm | 3360 mm |
| Max digging height | |
| 4710 mm | 5530 mm |
| Max Dump Height | |
| 3310 mm | 3870 mm |
| Max vertical wallcut depth | |
| 2503 mm | 2690 mm |
| Min swing radius | |
| 2416 mm | 2190 mm |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| 2610 mm | NA |
| Bucket Digging Force | |
| 30 kN | 36.5 kN |
| Arm Digging Force | |
| 22kN | 22.7 kN |
| Swing Speed | |
| 10 rpm | 10 rpm |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| 390 mm | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| 1700 mm | 1970 mm |
| Height | |
| 343 mm | 400 mm |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Bucket Capacity | |
| 0.11 m³ | 0.15 m³ |
| Liugong 9035E | Yanmar Vi050-6B |
|---|---|
| Overall Length | |
| 4810 mm | 5230 mm |
| Overall width | |
| 1700 mm | 1940 mm |
| Overall Height | |
| 2500 mm | 2540 mm |
| Overall Height of Cab | |
| NA | NA |
| Upper Width | |
| 1600 mm | NA |
| Track Lengh on Ground | |
| 1675 mm | NA |
| Undercarriage overall length | |
| 2100 mm | 2590 mm |
| Tailswing radius | |
| 850 mm | NA |
| Min Ground clearance | |
| 430 mm | 345 mm |
| Track gauge | |
| 1400 mm | 1590 mm |
| Width over tracks | |
| 1700 mmm | 1940 mm |
| Track Height | |
| NA | NA |
| Counterweight Clearence | |
| 580 mm | NA |
| Track Shoe Width | |
| 300 mm | 350 mm |
