Add Equipment
The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Yanmar Vi050-6B | JCB 55Z |
|---|
| Particulars | Yanmar Vi050-6B | JCB 55Z |
|---|
The JCB 55Z stands out with its higher engine power and bucket digging force, ideal for heavy-duty tasks, while the Yanmar Vi050-6B, with its lower ground pressure and price, may be better suited for delicate surfaces and smaller budgets.
If you require robust performance and can accommodate a slightly higher budget, the JCB 55Z may be the better option. Conversely, for operations requiring delicacy and cost-effectiveness, the Yanmar Vi050-6B should be considered.
| Brand | Yanmar | JCB |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | ₹ 35.5 - 36.5 Lakhs | ₹ 37-38 Lakhs |
| Price | ₹ 35.5 - 36.5 Lakhs | ₹ 37-38 Lakhs |
| Weight | 4735 Kg | 5520 Kg |
| Bucket | 0.15 m³ | 0.22 m³ |
| Max Digging Depth | 3360 mm | 3600 mm |
| Engine | Yanmar 37.7 HP | Stage 47.8 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2000 hr. |
| Boom | NA | 2866 mm |
| Quick Overview: | Yanmar Vi050-6B mini excavator ensures unmatched performance and durability, perfect for compact construction and landscaping tasks. |
Excels in landscaping and precise construction applications, JCB 55Z mini excavator is designed for reliability. |
| Agency review | Get the best price for the Yanmar Vi050-6B Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the JCB 55Z Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
The JCB 55Z stands out with its higher engine power and bucket digging force, ideal for heavy-duty tasks, while the Yanmar Vi050-6B, with its lower ground pressure and price, may be better suited for delicate surfaces and smaller budgets.
If you require robust performance and can accommodate a slightly higher budget, the JCB 55Z may be the better option. Conversely, for operations requiring delicacy and cost-effectiveness, the Yanmar Vi050-6B should be considered.
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Brand | |
| Yanmar | JCB |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 35.5 - 36.5 Lakhs | ₹ 37-38 Lakhs |
| Weight | |
| 4735 Kg | 5520 Kg |
| Bucket | |
| 0.15 m³ | 0.22 m³ |
| Max Digging Depth | |
| 3360 mm | 3600 mm |
| Engine | |
| Yanmar 37.7 HP | Stage 47.8 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2000 hr. |
| Boom | |
| NA | 2866 mm |
| Quick Overview: | |
Yanmar Vi050-6B mini excavator ensures unmatched performance and durability, perfect for compact construction and landscaping tasks. |
Excels in landscaping and precise construction applications, JCB 55Z mini excavator is designed for reliability. |
| Yanmar Vi050-6B | JCB 55Z | |
| Engine Make | Yanmar 4TNV88-ZPBV | Stage 3A 404D-22 |
| Fuel Tank | 66 L | 76 L |
| Engine Displacment | NA | 2.179 L |
| Under Carriage | 2590 mm | 2490 mm |
| Hydraulic System | NA | 100 L |
| Arm | NA | 1570 mm |
| Max Digging Reach | NA | 6200 mm |
| Fuel Consumption | NA | 4 L/hour |
| Overall Width | 1940 mm | 1850 mm |
| Overall Length | 5230 mm | 5520 mm |
| Bucket Digging Force | 36.5 kN | 42 kN |
| Tailswing Radius | NA | 975 mm |
| Track Shoe Width | 350 mm | 400 mm |
| AC Cabin | Optional | Optional |
| GPS | Standard | Standard |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Engine Make | |
| Yanmar 4TNV88-ZPBV | Stage 3A 404D-22 |
| Fuel Tank | |
| 66 L | 76 L |
| Engine Displacment | |
| NA | 2.179 L |
| Under Carriage | |
| 2590 mm | 2490 mm |
| Hydraulic System | |
| NA | 100 L |
| Arm | |
| NA | 1570 mm |
| Max Digging Reach | |
| NA | 6200 mm |
| Fuel Consumption | |
| NA | 4 L/hour |
| Overall Width | |
| 1940 mm | 1850 mm |
| Overall Length | |
| 5230 mm | 5520 mm |
| Bucket Digging Force | |
| 36.5 kN | 42 kN |
| Tailswing Radius | |
| NA | 975 mm |
| Track Shoe Width | |
| 350 mm | 400 mm |
| AC Cabin | |
| Optional | Optional |
| GPS | |
| Standard | Standard |
| 3697 | 3543 | |
| Model | Yanmar 37.7 HP | Stage 47.8 HP |
| Fuel | Diesel | Diesel |
| Type | Vertical 4-cylinder water-cooled direct injection diesel engine | Water Cooled |
| Rated Engine Power | 37.7 HP (28.1 kW) @ 2200 rpm | 47.8 HP (35.7 kW) @ 2600 rpm |
| Maximum Torque | NA | 143 Nm @ 1800 rpm |
| Piston Displacement | NA | 2.179 L |
| Alternator | NA | 85A |
| Battery | NA | 12V , 75 Ah |
| Starting Motor | NA | 2 kW |
| 2 kW | 2 kW | |
| No of Top rollers | NA | 1 |
| No of bottom rollers | NA | 4 |
| Track Shoes (Each Side) | NA | NA |
| Track Guard | NA | NA |
| Track Shoe width | 350 mm | 400 mm |
| Ground bearing pressure | 29.9 kPa | 34.3 kPa / 24.5 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | NA | 35 ° |
| Travel Speed-Low | 2.1 Km/h | 3 Km/h |
| Travel Speed-High | 4.3 Km.h | 4.6 Km/h |
| Max Tracking Force | NA | 38.1 kN |
| Yanmar Vi050-6B | JCB 55Z | |
| Hydraulic pump | Variable Displacement Pump | Piston |
| Maximum Flow | 2 x 42.5 L/min | 126 L/min |
| Pilot Pump | 1 Gear Pump | Gear Pump |
| Implement Circuit | 24.5 MPa | 26.5 MPa |
| Swing Circuit | 21.6 MPa | 21.6 MPa |
| Travel circuit | 24.5 MPa | NA |
| Pilot circuit | 3.9 MPa | NA |
| Yanmar Vi050-6B | JCB 55Z | |
| Travel | NA | NA |
| Swing | NA | NA |
| Yanmar Vi050-6B | JCB 55Z | |
| Fuel tank | 66 L | 76 L |
| Engine Coolant | NA | 12 L |
| Engine oil | NA | 9.1 L |
| Hydraulic system | NA | 100 L |
| Hydraulic tank | 38 L | 55 L |
| Yanmar Vi050-6B | JCB 55Z | |
| Operating Weight | 4735 Kg | 5520 Kg |
| Yanmar Vi050-6B | JCB 55Z | |
| Boom length | NA | 2866 mm |
| Arm length | NA | 1570 mm |
| Max Digging Reach | NA | 6200 mm |
| Max Digging Reach on ground | NA | 6000 mm |
| Max digging depth | 3360 mm | 3600 mm |
| Max digging height | 5530 mm | 5660 mm |
| Max Dump Height | 3870 mm | 4270 mm |
| Max vertical wallcut depth | 2690 mm | 2050 mm |
| Min swing radius | 2190 mm | 2640 mm |
| Max Height at Min Swing radius | NA | 2160 mm |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 36.5 kN | 42 kN |
| Arm Digging Force | 22.7 kN | 29 kN |
| Swing Speed | 10 rpm | 8.3 rpm |
| Yanmar Vi050-6B | JCB 55Z | |
| Dozer Type | NA | NA |
| Dozer Length | NA | 1140 mm |
| Digging depth for ground level | NA | 433 mm |
| Approach Angle | NA | 31° |
| Width | 1970 mm | 1960 mm |
| Height | 400 mm | 400 mm |
| Yanmar Vi050-6B | JCB 55Z | |
| Bucket Capacity | 0.15 m³ | 0.22 m³ |
| Yanmar Vi050-6B | JCB 55Z | |
| Overall Length | 5230 mm | 5520 mm |
| Overall width | 1940 mm | 1850 mm |
| Overall Height | 2540 mm | 2550 mm |
| Overall Height of Cab | NA | 2550 mm |
| Upper Width | NA | NA |
| Track Lengh on Ground | NA | 1990 mm |
| Undercarriage overall length | 2590 mm | 2490 mm |
| Tailswing radius | NA | 975 mm |
| Min Ground clearance | 345 mm | 300 mm |
| Track gauge | 1590 mm | 1550 mm |
| Width over tracks | 1940 mm | 1950 mm |
| Track Height | NA | 560 mm |
| Counterweight Clearance | NA | 618 mm |
| Track Shoe Width | 350 mm | 400 mm |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Model | |
| Yanmar 37.7 HP | Stage 47.8 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| Vertical 4-cylinder water-cooled direct injection diesel engine | Water Cooled |
| Rated Engine Power | |
| 37.7 HP (28.1 kW) @ 2200 rpm | 47.8 HP (35.7 kW) @ 2600 rpm |
| Maximum Torque | |
| NA | 143 Nm @ 1800 rpm |
| Piston Displacement | |
| NA | 2.179 L |
| Alternator | |
| NA | 85A |
| Battery | |
| NA | 12V , 75 Ah |
| Starting Motor | |
| NA | 2 kW |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| No of Top rollers | |
| NA | 1 |
| No of bottom rollers | |
| NA | 4 |
| Track Shoes (Each Side) | |
| NA | NA |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 350 mm | 400 mm |
| Ground bearing pressure | |
| 29.9 kPa | 34.3 kPa / 24.5 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| NA | 35 ° |
| Travel Speed-Low | |
| 2.1 Km/h | 3 Km/h |
| Travel Speed-High | |
| 4.3 Km.h | 4.6 Km/h |
| Max Tracking Force | |
| NA | 38.1 kN |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Hydraulic pump | |
| Variable Displacement Pump | Piston |
| Maximum Flow | |
| 2 x 42.5 L/min | 126 L/min |
| Pilot Pump | |
| 1 Gear Pump | Gear Pump |
| Implement Circuit | |
| 24.5 MPa | 26.5 MPa |
| Swing Circuit | |
| 21.6 MPa | 21.6 MPa |
| Travel circuit | |
| 24.5 MPa | NA |
| Pilot circuit | |
| 3.9 MPa | NA |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Fuel tank | |
| 66 L | 76 L |
| Engine Coolant | |
| NA | 12 L |
| Engine oil | |
| NA | 9.1 L |
| Hydraulic system | |
| NA | 100 L |
| Hydraulic tank | |
| 38 L | 55 L |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Operating Weight | |
| 4735 Kg | 5520 Kg |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Boom length | |
| NA | 2866 mm |
| Arm length | |
| NA | 1570 mm |
| Max Digging Reach | |
| NA | 6200 mm |
| Max Digging Reach on ground | |
| NA | 6000 mm |
| Max digging depth | |
| 3360 mm | 3600 mm |
| Max digging height | |
| 5530 mm | 5660 mm |
| Max Dump Height | |
| 3870 mm | 4270 mm |
| Max vertical wallcut depth | |
| 2690 mm | 2050 mm |
| Min swing radius | |
| 2190 mm | 2640 mm |
| Max Height at Min Swing radius | |
| NA | 2160 mm |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 36.5 kN | 42 kN |
| Arm Digging Force | |
| 22.7 kN | 29 kN |
| Swing Speed | |
| 10 rpm | 8.3 rpm |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | 1140 mm |
| Digging depth for ground level | |
| NA | 433 mm |
| Approach Angle | |
| NA | 31° |
| Width | |
| 1970 mm | 1960 mm |
| Height | |
| 400 mm | 400 mm |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Bucket Capacity | |
| 0.15 m³ | 0.22 m³ |
| Yanmar Vi050-6B | JCB 55Z |
|---|---|
| Overall Length | |
| 5230 mm | 5520 mm |
| Overall width | |
| 1940 mm | 1850 mm |
| Overall Height | |
| 2540 mm | 2550 mm |
| Overall Height of Cab | |
| NA | 2550 mm |
| Upper Width | |
| NA | NA |
| Track Lengh on Ground | |
| NA | 1990 mm |
| Undercarriage overall length | |
| 2590 mm | 2490 mm |
| Tailswing radius | |
| NA | 975 mm |
| Min Ground clearance | |
| 345 mm | 300 mm |
| Track gauge | |
| 1590 mm | 1550 mm |
| Width over tracks | |
| 1940 mm | 1950 mm |
| Track Height | |
| NA | 560 mm |
| Counterweight Clearence | |
| NA | 618 mm |
| Track Shoe Width | |
| 350 mm | 400 mm |
