    Sany SMG200C-8 Motor Grader

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    • Brand

      Sany

    • Type

      Large (>50 Ton)

    • Operating Cost

      Price Available Soon

    • Ex-Showroom Price

      Price Available Soon

    • Engine

      Cummins 250 HP

    • Blade

      4270 mm

    • icon alt1
      Weight

      20760 kg

    • Turning Radius

      7500 mm

    • Forward Speed

      46.8 km/hr

    • Reverse Speed

      37 km/hr

    Quick Overview:

    The Sany SMG200C-8 motor grader is designed to enhance productivity across all roadwork projects, offering excellent strength and reliability for grading tasks.

    Connect With Us:

    Looking for the best price on a Sany SMG200C-8 from authorized dealers? We can help you find exclusive deals and connect you with trusted sellers.​

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    Key Highlights

    Engine Make

    Cummins QSL 9

    Max Torque

    1085 @ 1500 Nm

    Fuel Tank

    340 L

    Hydraulic System

    NA

    Tires

    17.5 - 25-20PR

    Frame Height

    NA

    Max Lift Above Ground

    480 mm

    Max Cutting Depth

    715 mm

    Blade Pitch Angle

    40° forward; 5° backward

    Wheel Base

    6300 mm

    Overall Length

    11554 mm

    Overall Height

    3498 mm

    Medal Image
    Warranty

    1 Yr. / 2500 hr.

    air-conditioner-alt
    AC Cabin

    Standard

    GPS Tracking
    GPS

    NA

    Features

    Powerful Engine

    Powerful Engine

    • Cummins QSL9 Series EPA Tier 4 Low Emission engine ensures high productivity.

    • Common rail injection system provides precise throttle control, and thus, it delivers higher work speeds with high horsepower and high productivity to perform better in the toughest mining applications.

    Draw Bar Pull & Blade Downforce

    Draw Bar Pull & Blade Downforce

    • SMG series Grader has excellent traction and powerful blade downforce and is designed with the operator’s needs in mind.

    • Easy to operate and maintain, it’s a machine built for hard work in the toughest conditions.

    • The long wheelbase, long blade base and optimum weight distribution of the SMG200C-8 provide a smooth-grade finish and high cutting capacity at the moldboard edge. This improves productivity by ensuring high downforce.

    Ergonomic Cabin

    Ergonomic Cabin

    • Cabin is designed to keep the operators more comfortable, relaxed and productive in longer hours of operation.

    • Cabin is designed to keep the operators more comfortable, relaxed and productive in longer hours of operation.

    • A clear view of the moldboard heel and rear tires enhances productivity and safe operation. It also comes with superior features like a crystal display monitor, air suspension multi-adjustable operator seat, sun visors,

    • Standard Rear Camera & high capacity A/C

    Powerful Engine

    • Cummins QSL9 Series EPA Tier 4 Low Emission engine ensures high productivity.

    • Common rail injection system provides precise throttle control, and thus, it delivers higher work speeds with high horsepower and high productivity to perform better in the toughest mining applications.

    Draw Bar Pull & Blade Downforce

    • SMG series Grader has excellent traction and powerful blade downforce and is designed with the operator’s needs in mind.

    • Easy to operate and maintain, it’s a machine built for hard work in the toughest conditions.

    • The long wheelbase, long blade base and optimum weight distribution of the SMG200C-8 provide a smooth-grade finish and high cutting capacity at the moldboard edge. This improves productivity by ensuring high downforce.

    Ergonomic Cabin

    • Cabin is designed to keep the operators more comfortable, relaxed and productive in longer hours of operation.

    • Cabin is designed to keep the operators more comfortable, relaxed and productive in longer hours of operation.

    • A clear view of the moldboard heel and rear tires enhances productivity and safe operation. It also comes with superior features like a crystal display monitor, air suspension multi-adjustable operator seat, sun visors,

    • Standard Rear Camera & high capacity A/C

    Specifications

    Product specification of Sany SMG200C-8 Motor Grader

    ENGINE

    • Model

      Cummins QSL 9

    • Fuel

      Diesel

    • Type

      EPA Tier 4 (f)

    • Number of Cylinders

      NA

    • Gross Power

      250 HP (186 kW) @ 2200 rpm

    • Max Torque

      1085 @ 1500 Nm

    • Displacement

      9 L

    • Battery

      NA

    • Alternator

      NA

    TRANSMISSION

    • Type

      Direct Drive Power Shift Transmission

    SPEED

    • Max. Forward Speed

      46.8 km/hr

    • Max. Reverse Speed

      37 km/hr

    AXLES

    • Rear Axle

      NA

    • Front Axle

      NA

    TIRES

    • Size

      17.5 - 25-20PR

    STEERING

    • Type

      Hydraulic Articulated Steering

    • Minimum Turning Radius

      7500 mm

    • Steering Angle

      50°

    BRAKES

    • Service

      Air-over-hydraulic, multi-disc wet brakes.

    • Parking

      Spring-applied, air-released type

    FRAME

    • Front Frame Structure - Height

      NA

    • Front Frame Structure - Width

      NA

    • Front Frame Structure - Thickness

      NA

    MOLDBOARD

    • Type

      NA

    • Blade Length

      4270 mm

    • Blade Height

      620 mm

    • Blade Thickness

      NA

    • Cutting Edge

      NA

    • Blade Pull

      NA

    • Blade Down Pressure

      10605 kgf

    • Moldboard Side Shift (Right/Left)

      NA

    • Maximum Shoulder Reach (Right/Left)

      NA

    • Maximum Lift Above Ground

      480 mm

    • Maximum Cutting Depth

      715 mm

    • Blade Pitch Angle

      40° forward, 5° backward

    HYDRAULICS

    • Type

      NA

    • Maximum Pump Flow

      NA

    • Maximum System Pressure

      NA

    SERVICE CAPACITIES

    • Fuel Tank

      340 L

    • Cooling System

      NA

    • Engine Oil

      NA

    • DEF Tank

      NA

    • Transmission Oil

      NA

    • Final Drive

      NA

    • Hydraulic System

      115 L

    • Circle Reverse Housing

      NA

    WEIGHT

    • Gross Vehicle Weight

      20760 kg

    STATIC DIMENSIONS

    • Overall Height

      3498 mm

    • Moldboard Base

      2520 mm

    • Wheelbase

      6300 mm

    • Tandem Wheelbase

      1524 mm

    • Width of Standard Moldboard

      4270 mm

    • Overall Length

      11554 mm

    • Tread Gauge

      2184 mm

    • Width of Tires

      2725 mm

    • Articulation, left or right

      NA

    • Minimum Ground Clearence

      370 mm

    Frequently Asked Question

    01. What is the price of the Sany SMG200C-8 Motor Grader in India?

    Ans.

    The price of the Sany SMG200C-8 Motor Grader in India will be available soon. Stay connected with Desi Machines to get the latest and most accurate pricing updates as soon as they are released.

    02. Where can I buy Sany SMG200C-8 motor grader in india?

    Ans.

    You can buy the Sany SMG200C-8 motor grader from Desi Machines, your trusted platform for construction and heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the motor grader you want, or contact us directly for expert assistance and competitive pricing.

    03. Does the Sany SMG200C-8 motor grader comes with financing & insurance options?

    Ans.

    Yes, the Sany SMG200C-8 motor grader comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Connect with us and our team will help you secure the best deals.

    04. What is the engine power of the Sany SMG200C-8 Motor Grader?

    Ans.

    The Sany SMG200C-8 motor grader is powered by a Cummins QSL 9 diesel engine, delivering 250 HP (186 kW) @ 2200 rpm.

    05. What is the weight of the Sany SMG200C-8 Motor Grader?

    Ans.

    The weight of the Sany SMG200C-8 motor grader is approximately 20760 kg. The weight may vary slightly depending on specific configurations and attachments.

    06. What is the blade width of the Sany SMG200C-8 Motor Grader?

    Ans.

    The Sany SMG200C-8 Motor Grader features a blade width of 4270 mm (14.01 feet), making it ideal for large-scale and heavy construction work.

    07. What is the turning radius of the Sany SMG200C-8 Motor Grader?

    Ans.

    The Sany SMG200C-8 Motor Grader has a turning radius of 7500 mm, offering versatility for mixed-terrain projects.

    08. What is the fuel tank capacity of the Sany SMG200C-8 Motor Grader?

    Ans.

    The Sany SMG200C-8 motor grader has a 340-liter diesel fuel tank, providing extended operation time without frequent refueling.

    09. What is the warranty period of Sany SMG200C-8 motor grader?

    Ans.

    The Sany SMG200C-8 in India typically comes with a standard warranty of 1 year or 2500 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. Please verify with authorized dealers or the official brand website for the most accurate and up-to-date information.

    10. Where can I find spare parts for the Sany SMG200C-8 motor grader?

    Ans.

    You can find genuine spare parts for the Sany SMG200C-8 at authorized SANY dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on motor grader spare parts.
