The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Hyundai HL650I-V | CAT 950GC |
|---|
| Particulars | Hyundai HL650I-V | CAT 950GC |
|---|
| Brand | Hyundai Wheel Loader | Caterpillar Wheel loader |
|---|---|---|
| Type | Medium (15-30 Ton) | Medium (15-30 Ton) |
| Ex-Showroom Price | ₹ 85-89 Lakhs | ₹ 64-66 Lakhs |
| Engine | Weichai 226 HP | Cat 225 HP |
| Bucket | 3.0 m³ | 2.9 - 4.4 m³ |
| Weight | 17600 kg | 18849 kg |
| Max. Forward Speed | 35 km/h | 36.0 km/h |
| Dump Height | 3056 mm | 3050 mm |
| Tripping Load | NA | 11006 kg |
| Quick Overview: | The Hyundai HL650I-V Wheel Loader is a heavy-duty payloader built for construction, mining, port, and industrial uses. It comes with a 226 HP Weichai CEV V engine, delivering impressive power, quicker cycle times, and better fuel efficiency. It has a strong 5000 kg payload capacity with 2.7 to 5.0 m³ bucket options, allowing for efficient handling of large material amounts. The roomy ROPS/FOPS cabin, real-time monitoring system, rear-view camera, and automatic braking improve operator safety. Its easy maintenance, low noise, and lower emissions make the HL650I-V a lasting, eco-friendly choice among Hyundai Wheel Loaders. |
Cat’s 950GC Wheel Loader is built for durability and performance, meeting the rigorous demands of Indian construction and mining sectors. |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Brand | |
| Hyundai Wheel Loader | Caterpillar Wheel loader |
| Type | |
| Medium (15-30 Ton) | Medium (15-30 Ton) |
| Ex-Showroom Price | |
| ₹ 85-89 Lakhs | ₹ 64-66 Lakhs |
| Engine | |
| Weichai 226 HP | Cat 225 HP |
| Bucket | |
| 3.0 m³ | 2.9 - 4.4 m³ |
| Weight | |
| 17600 kg | 18849 kg |
| Fwd. Speed | |
| 35 km/h | 36.0 km/h |
| Dump Height | |
| 3056 mm | 3050 mm |
| Tripping Load | |
| NA | 11006 kg |
| Quick Overview: | |
The Hyundai HL650I-V Wheel Loader is a heavy-duty payloader built for construction, mining, port, and industrial uses. It comes with a 226 HP Weichai CEV V engine, delivering impressive power, quicker cycle times, and better fuel efficiency. It has a strong 5000 kg payload capacity with 2.7 to 5.0 m³ bucket options, allowing for efficient handling of large material amounts. The roomy ROPS/FOPS cabin, real-time monitoring system, rear-view camera, and automatic braking improve operator safety. Its easy maintenance, low noise, and lower emissions make the HL650I-V a lasting, eco-friendly choice among Hyundai Wheel Loaders. |
Cat’s 950GC Wheel Loader is built for durability and performance, meeting the rigorous demands of Indian construction and mining sectors. |
| Hyundai HL650I-V | CAT 950GC | |
| Engine Make | Weichai WP8G231E671 | Cat C7.1 |
| Max Torque | 1200 Nm @ 1500 rpm | 931 Nm |
| Fuel Tank | 285 L | 290 L |
| Hydraulic System | 220 L/min | 256 L/min @ 2390 rpm |
| Min. Ground Clearance | 398 mm | 460 mm |
| Payload | 5000 kg | NA |
| Steering Angle | ±35° | ±40° |
| Drive Type | 4-wheel drive (4WD) | 4-wheel drive (4WD) |
| Wheelbase | 3300 mm | 3300 mm |
| Tyres | 23.5-25 L-3 16PR TT | 23.5R25 |
| Max. Breakout Force | 186 kN | 154 kN |
| Overall Length | 8288 mm | 8238 mm |
| Warranty | 1 Yr. / 2000 hr. | 1 Year |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Engine Make | |
| Weichai WP8G231E671 | Cat C7.1 |
| Max Torque | |
| 1200 Nm @ 1500 rpm | 931 Nm |
| Fuel Tank | |
| 285 L | 290 L |
| Hydraulic System | |
| 220 L/min | 256 L/min @ 2390 rpm |
| Min. Ground Clearance | |
| 398 mm | 460 mm |
| Payload | |
| 5000 kg | NA |
| Steering Angle | |
| ±35° | ±40° |
| Drive Type | |
| 4-wheel drive (4WD) | 4-wheel drive (4WD) |
| Wheelbase | |
| 3300 mm | 3300 mm |
| Tyres | |
| 23.5-25 L-3 16PR TT | 23.5R25 |
| Max. Breakout Force | |
| 186 kN | 154 kN |
| Overall Length | |
| 8288 mm | 8238 mm |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Year |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| Hyundai HL650I-V | CAT 950GC | |
| Engine Make | Weichai WP8G231E671 | Cat C7.1 |
| Engine Type | 6 Cylinders; Electronic Engine | 4-stroke; turbocharged; air-to-air aftercooled diesel engine |
| Aspiration | NA | Tubocharged |
| Emission | CEV - V | U.S. EPA Tier 4 Final and EU Stage IV |
| Max Torque | 1200 Nm @ 1500 rpm | 931 Nm |
| Max Power | 226 HP (170 kW) @ 2200 rpm | 225 HP (168 kW) @ 2000 rpm |
| Piston Displacement | 7.47 L | 7.01 L |
| No Of Cylinders | 6 | 6 Cylinders |
| Battery | 24V / 120Ah | 2 x 12V / 140 Ah |
| Alternator | 24V / 70A | 24V / 115A |
| Hyundai HL650I-V | CAT 950GC | |
| Transmission | Countershaft Powershift; Mechanical Powershift Control | Electronically Controlled & Automatic Powershift Countershaft Transmission |
| Drive Type | 4-wheel drive (4WD) | 4-wheel drive (4WD) |
| Torque Converter | Single-stage & duo turbine; 4-element | Single-stage torque converter |
| Hyundai HL650I-V | CAT 950GC | |
| Service | Gas Push Oil Caliper Brake | Hydraulic; fully enclosed wet disc brakes |
| Parking | Air Actuated Caliper Brake | Spring-applied; hydraulically released caliper disc brake |
| Hyundai HL650I-V | CAT 950GC | |
| Type | Hydraulic Load Sensing System | Load-Sensing Hydrostatic Articulated Steering |
| Steering-Angle | ±35° | ±40° |
| Hyundai HL650I-V | CAT 950GC | |
| Front Axle | Rigid axle | Fixed |
| Rear Axle | Oscillating axle | Oscillating |
| Oscillating Angle | ±10° | ±13° |
| Hyundai HL650I-V | CAT 950GC | |
| Max. Forward Speed | 35 km/h | 36.0 km/h |
| Max. Reverse Speed | 16 km/h | 22.0 km/h |
| Hyundai HL650I-V | CAT 950GC | |
| System Type | Joystick Control | Load-Sensing Hydraulic System |
| Pump Type | NA | Piston |
| Maximum Pump Flow | 220 L/min | 256 L/min @ 2390 rpm |
| System Pressure | 18 MPa | 279 bar |
| Hyundai HL650I-V | CAT 950GC | |
| Fuel Tank | 285 L | 290 L |
| Hydraulic System | NA | NA |
| Engine Oil | 22 L | 18 L |
| Cooling System | NA | 50 L |
| Rear Axle Oil | 28 L | 38 L |
| Front Axle Oil | 25 L | 40 L |
| Hydraulic Tank | 265 L | 12 L |
| Transmission Oil | 48 L | 45 L |
| Def Tank | NA | 16 L |
| Hyundai HL650I-V | CAT 950GC | |
| Overall Length With Bucket | 8288 mm | 8238 mm |
| Wheel Base | 3300 mm | 3300 mm |
| Height Over Cab | 3400 mm | 3458 mm |
| Height Over Exhaust | NA | 3416 mm |
| Min Grond Clearance | 398 mm | 460 mm |
| Width Over Tyres | 2835 mm | 2745 mm |
| Wheel Tread | 2240 mm | 2130 mm |
| Tyre Size | 23.5-25 L-3 16PR TT | 23.5R25 |
| Hyundai HL650I-V | CAT 950GC | |
| Bucket Capacity | 3.0 m³ | 2.9 - 4.4 m³ |
| Bucket Width | 3000 mm | 2927 mm |
| Payload | 5000 kg | NA |
| Tipping Load Straight | NA | 12178 kg |
| Tipping Load Full Turn | NA | 11006 kg |
| Max. Breakout Force | 186 kN | 154 kN |
| Operating Weight | 17600 kg | 18849 kg |
| Max Dump Angle | 43° | 52° |
| Bucket Roll Back Angle Full Height | 57° | 60° |
| Bucket Roll Back At Carry | 45° | 45° |
| Bucket Roll Back At Ground Level | 41° | 40° |
| Dumping Height, Fully Raised | 3056 mm | 3050 mm |
| Dumping Reach, Fully Raised | 1330 mm | 1262 mm |
| Max. Hinge Pin Height | 4115 mm | 4188 mm |
| Max. Digging Depth | 50 mm | 86 mm |
| Turning Radius Over Tyres | 6341 mm | 6164 mm |
| Turning Radius Over Bucket | 7264 mm | NA |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Engine Make | |
| Weichai WP8G231E671 | Cat C7.1 |
| Engine Type | |
| 6 Cylinders; Electronic Engine | 4-stroke; turbocharged; air-to-air aftercooled diesel engine |
| Aspiration | |
| NA | Tubocharged |
| Emission | |
| CEV - V | U.S. EPA Tier 4 Final and EU Stage IV |
| Max Torque | |
| 1200 Nm @ 1500 rpm | 931 Nm |
| Max Power | |
| 226 HP (170 kW) @ 2200 rpm | 225 HP (168 kW) @ 2000 rpm |
| Piston Displacement | |
| 7.47 L | 7.01 L |
| No Of Cylinders | |
| 6 | 6 Cylinders |
| Battery | |
| 24V / 120Ah | 2 x 12V / 140 Ah |
| Alternator | |
| 24V / 70A | 24V / 115A |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Transmission | |
| Countershaft Powershift; Mechanical Powershift Control | Electronically Controlled & Automatic Powershift Countershaft Transmission |
| Drive Type | |
| 4-wheel drive (4WD) | 4-wheel drive (4WD) |
| Torque Converter | |
| Single-stage & duo turbine; 4-element | Single-stage torque converter |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Service | |
| Gas Push Oil Caliper Brake | Hydraulic; fully enclosed wet disc brakes |
| Parking | |
| Air Actuated Caliper Brake | Spring-applied; hydraulically released caliper disc brake |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Type | |
| Hydraulic Load Sensing System | Load-Sensing Hydrostatic Articulated Steering |
| Steering-Angle | |
| ±35° | ±40° |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Max. Forward Speed | |
| 35 km/h | 36.0 km/h |
| Max. Reverse Speed | |
| 16 km/h | 22.0 km/h |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Front Axle | |
| Rigid axle | Fixed |
| Rear Axle | |
| Oscillating axle | Oscillating |
| Oscillating Angle | |
| ±10° | ±13° |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| System Type | |
| Joystick Control | Load-Sensing Hydraulic System |
| Pump Type | |
| NA | Piston |
| Maximum Pump Flow | |
| 220 L/min | 256 L/min @ 2390 rpm |
| System Pressure | |
| 18 MPa | 279 bar |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Size | |
| Not Available | Not Available |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Fuel Tank | |
| 285 L | 290 L |
| Hydraulic System | |
| NA | NA |
| Engine Oil | |
| 22 L | 18 L |
| Cooling System | |
| NA | 50 L |
| Rear Axle Oil | |
| 28 L | 38 L |
| Front Axle Oil | |
| 25 L | 40 L |
| Hydraulic Tank | |
| 265 L | 12 L |
| Transmission Oil | |
| 48 L | 45 L |
| Def Tank | |
| NA | 16 L |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Overall Length With Bucket | |
| 8288 mm | 8238 mm |
| Wheel Base | |
| 3300 mm | 3300 mm |
| Height Over Cab | |
| 3400 mm | 3458 mm |
| Height Over Exhaust | |
| NA | 3416 mm |
| Min Grond Clearance | |
| 398 mm | 460 mm |
| Width Over Tyres | |
| 2835 mm | 2745 mm |
| Wheel Tread | |
| 2240 mm | 2130 mm |
| Tyre Size | |
| 23.5-25 L-3 16PR TT | 23.5R25 |
| Hyundai HL650I-V | CAT 950GC |
|---|---|
| Bucket Capacity | |
| 3.0 m³ | 2.9 - 4.4 m³ |
| Bucket Width | |
| 3000 mm | 2927 mm |
| Payload | |
| 5000 kg | NA |
| Tipping Load Straight | |
| NA | 12178 kg |
| Tipping Load Full Turn | |
| NA | 11006 kg |
| Max. Breakout Force | |
| 186 kN | 154 kN |
| Operating Weight | |
| 17600 kg | 18849 kg |
| Max Dump Angle | |
| 43° | 52° |
| Bucket Roll Back Angle Full Height | |
| 57° | 60° |
| Bucket Roll Back At Carry | |
| 45° | 45° |
| Bucket Roll Back At Ground Level | |
| 41° | 40° |
| Dumping Height, Fully Raised | |
| 3056 mm | 3050 mm |
| Dumping Reach, Fully Raised | |
| 1330 mm | 1262 mm |
| Max. Hinge Pin Height | |
| 4115 mm | 4188 mm |
| Max. Digging Depth | |
| 50 mm | 86 mm |
| Turning Radius Over Tyres | |
| 6341 mm | 6164 mm |
| Turning Radius Over Bucket | |
| 7264 mm | NA |
