Add Equipment
The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Kubota U30-6S | Fine FM38 |
|---|
| Particulars | Kubota U30-6S | Fine FM38 |
|---|
Comparing the Fine FM38 and the Kubota U30-6S mini excavators requires evaluating their suitability for specific tasks. The FM38 is well-suited for urban construction with its zero-tail swing and higher digging capabilities, whereas the U30-6S offers better gradeability and GPS technology, making it apt for landscaping and agricultural work with tighter budget constraints.
The choice between the Fine FM38 and the Kubota U30-6S should be guided by specific job requirements and budget. If the work demands more in-depth excavation and operator comfort, the Fine FM38 might be preferable, despite its higher price point. Conversely, for those seeking cost-efficiency, easier maneuverability in confined spaces, and the inclusion of GPS, the Kubota U30-6S presents a compelling option.
| Brand | Escorts Kubota | Fine Equipments |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | ₹ 21-22 lakhs | ₹ 27 -29 Lakhs |
| Price | ₹ 21-22 lakhs | ₹ 27 -29 Lakhs |
| Weight | 3195 Kg | 3810 Kg |
| Bucket | 0.1 m³ | 0.12 m³ |
| Max Digging Depth | 2805 mm | 3208 mm |
| Engine | Kubota 27.5 HP | Kubota 24 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 1000 hr. |
| Boom | NA | 2535 mm |
| Quick Overview: | Ideal for landscaping and small agricultural tasks, Kubota’s U30-6S mini excavator integrates advanced technology and energy efficiency. |
The Fine FM38 is a robust 3.8-ton mini excavator featuring a zero-tail swing. It’s designed for efficient hydraulic performance in confined urban environments. |
| Agency review | Get the best price for the Kubota U30-6S Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Fine FM38 mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Comparing the Fine FM38 and the Kubota U30-6S mini excavators requires evaluating their suitability for specific tasks. The FM38 is well-suited for urban construction with its zero-tail swing and higher digging capabilities, whereas the U30-6S offers better gradeability and GPS technology, making it apt for landscaping and agricultural work with tighter budget constraints.
The choice between the Fine FM38 and the Kubota U30-6S should be guided by specific job requirements and budget. If the work demands more in-depth excavation and operator comfort, the Fine FM38 might be preferable, despite its higher price point. Conversely, for those seeking cost-efficiency, easier maneuverability in confined spaces, and the inclusion of GPS, the Kubota U30-6S presents a compelling option.
| Kubota U30-6S | Fine FM38 |
|---|---|
| Brand | |
| Escorts Kubota | Fine Equipments |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 21-22 lakhs | ₹ 27 -29 Lakhs |
| Weight | |
| 3195 Kg | 3810 Kg |
| Bucket | |
| 0.1 m³ | 0.12 m³ |
| Max Digging Depth | |
| 2805 mm | 3208 mm |
| Engine | |
| Kubota 27.5 HP | Kubota 24 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 1000 hr. |
| Boom | |
| NA | 2535 mm |
| Quick Overview: | |
Ideal for landscaping and small agricultural tasks, Kubota’s U30-6S mini excavator integrates advanced technology and energy efficiency. |
The Fine FM38 is a robust 3.8-ton mini excavator featuring a zero-tail swing. It’s designed for efficient hydraulic performance in confined urban environments. |
| Kubota U30-6S | Fine FM38 | |
| Engine Make | Kubota D1803-M-DI-E2-BH-TH1 | Kubota D1703 |
| Fuel Tank | 41.5 L | 42 L |
| Engine Displacment | 1.826 L | NA |
| Under Carriage | 2125 mm | 2125 mm |
| Hydraulic System | NA | 20.5 L |
| Arm | NA | 1400 mm |
| Max Digging Reach | 4905 mm | 5480 mm |
| Fuel Consumption | 4 L/hour | 4-6 L/hour |
| Overall Width | 1550 mm | 1755 mm |
| Overall Length | 4545 mm | 4915 mm |
| Bucket Digging Force | 30.1 kN | 30 kN |
| Tailswing Radius | 790 mm | 860 mm |
| Track Shoe Width | 300 mm | 350 mm |
| AC Cabin | Not Available | Standard |
| GPS | Standard | Not Available |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Engine Make | |
| Kubota D1803-M-DI-E2-BH-TH1 | Kubota D1703 |
| Fuel Tank | |
| 41.5 L | 42 L |
| Engine Displacment | |
| 1.826 L | NA |
| Under Carriage | |
| 2125 mm | 2125 mm |
| Hydraulic System | |
| NA | 20.5 L |
| Arm | |
| NA | 1400 mm |
| Max Digging Reach | |
| 4905 mm | 5480 mm |
| Fuel Consumption | |
| 4 L/hour | 4-6 L/hour |
| Overall Width | |
| 1550 mm | 1755 mm |
| Overall Length | |
| 4545 mm | 4915 mm |
| Bucket Digging Force | |
| 30.1 kN | 30 kN |
| Tailswing Radius | |
| 790 mm | 860 mm |
| Track Shoe Width | |
| 300 mm | 350 mm |
| AC Cabin | |
| Not Available | Standard |
| GPS | |
| Standard | Not Available |
| 3568 | 10995 | |
| Model | Kubota 27.5 HP | Kubota 24 HP |
| Fuel | Diesel | Diesel |
| Type | NA | NA |
| Rated Engine Power | 27.5 HP (20.5 kW) @ 2200 rpm | 24.40 HP (18.2 kW) @ 2200 rpm |
| Maximum Torque | NA | NA |
| Piston Displacement | 1.826 L | NA |
| Alternator | NA | NA |
| Battery | 12V | 12V |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | NA | NA |
| No of bottom rollers | NA | NA |
| Track Shoes (Each Side) | NA | NA |
| Track Guard | NA | NA |
| Track Shoe width | 300 mm | 350 mm |
| Ground bearing pressure | NA | NA |
| Track Tensioning | Grease | Grease |
| Gradeability | 30° | NA |
| Travel Speed-Low | 2.5 Km/h | 2.4 Km/h |
| Travel Speed-High | 4.4 Km/h | 4.4 Km/h |
| Max Tracking Force | NA | NA |
| Kubota U30-6S | Fine FM38 | |
| Hydraulic pump | Variable pump × 1 | Piston Pump |
| Maximum Flow | NA | 88 L/min |
| Pilot Pump | Gear Pump | NA |
| Implement Circuit | NA | 22.5 MPa |
| Swing Circuit | NA | NA |
| Travel circuit | NA | NA |
| Pilot circuit | NA | NA |
| Kubota U30-6S | Fine FM38 | |
| Travel | Hydraulic piston motor: 2F | Not Available |
| Swing | Hydraulic piston motor | Slew Reducer Type |
| Kubota U30-6S | Fine FM38 | |
| Fuel tank | 41.5 L | 42 L |
| Engine Coolant | NA | 14 L |
| Engine oil | NA | 7 L |
| Hydraulic system | NA | 20.5 L |
| Hydraulic tank | NA | 40 L |
| Kubota U30-6S | Fine FM38 | |
| Operating Weight | 3195 Kg | 3810 Kg |
| Kubota U30-6S | Fine FM38 | |
| Boom length | NA | 2535 mm |
| Arm length | NA | 1400 mm |
| Max Digging Reach | 4905 mm | 5480 mm |
| Max Digging Reach on ground | NA | NA |
| Max digging depth | 2805 mm | 3208 mm |
| Max digging height | 4265 mm | 4540 mm |
| Max Dump Height | 2880 mm | 3280 mm |
| Max vertical wallcut depth | 2275 mm | 2957 mm |
| Min swing radius | 2290 mm | NA |
| Max Height at Min Swing radius | 1845 mm | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 30.1 kN | 30 kN |
| Arm Digging Force | NA | 18 kN |
| Swing Speed | 8.6 rpm | NA |
| Kubota U30-6S | Fine FM38 | |
| Dozer Type | NA | Hydraulic Lifiting Type |
| Dozer Length | NA | NA |
| Digging depth for ground level | 360 mm | 385 mm |
| Approach Angle | NA | NA |
| Width | 1550 mm | 1720 mm |
| Height | 340 mm | 350 mm |
| Kubota U30-6S | Fine FM38 | |
| Bucket Capacity | 0.1 m³ | 0.12 m³ |
| Kubota U30-6S | Fine FM38 | |
| Overall Length | 4545 mm | 4915 mm |
| Overall width | 1550 mm | 1755 mm |
| Overall Height | 2485 mm | 2525 mm |
| Overall Height of Cab | 2485 mm | NA |
| Upper Width | NA | NA |
| Track Lengh on Ground | 1666 mm | 1670 mm |
| Undercarriage overall length | 2125 mm | 2125 mm |
| Tailswing radius | 790 mm | 860 mm |
| Min Ground clearance | 290 mm | 305 mm |
| Track gauge | NA | NA |
| Width over tracks | NA | 1755 mm |
| Track Height | NA | NA |
| Counterweight Clearance | NA | NA |
| Track Shoe Width | 300 mm | 350 mm |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Model | |
| Kubota 27.5 HP | Kubota 24 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| NA | NA |
| Rated Engine Power | |
| 27.5 HP (20.5 kW) @ 2200 rpm | 24.40 HP (18.2 kW) @ 2200 rpm |
| Maximum Torque | |
| NA | NA |
| Piston Displacement | |
| 1.826 L | NA |
| Alternator | |
| NA | NA |
| Battery | |
| 12V | 12V |
| Starting Motor | |
| NA | NA |
| Kubota U30-6S | Fine FM38 |
|---|---|
| No of Top rollers | |
| NA | NA |
| No of bottom rollers | |
| NA | NA |
| Track Shoes (Each Side) | |
| NA | NA |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 300 mm | 350 mm |
| Ground bearing pressure | |
| NA | NA |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 30° | NA |
| Travel Speed-Low | |
| 2.5 Km/h | 2.4 Km/h |
| Travel Speed-High | |
| 4.4 Km/h | 4.4 Km/h |
| Max Tracking Force | |
| NA | NA |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Hydraulic pump | |
| Variable pump × 1 | Piston Pump |
| Maximum Flow | |
| NA | 88 L/min |
| Pilot Pump | |
| Gear Pump | NA |
| Implement Circuit | |
| NA | 22.5 MPa |
| Swing Circuit | |
| NA | NA |
| Travel circuit | |
| NA | NA |
| Pilot circuit | |
| NA | NA |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Fuel tank | |
| 41.5 L | 42 L |
| Engine Coolant | |
| NA | 14 L |
| Engine oil | |
| NA | 7 L |
| Hydraulic system | |
| NA | 20.5 L |
| Hydraulic tank | |
| NA | 40 L |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Operating Weight | |
| 3195 Kg | 3810 Kg |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Boom length | |
| NA | 2535 mm |
| Arm length | |
| NA | 1400 mm |
| Max Digging Reach | |
| 4905 mm | 5480 mm |
| Max Digging Reach on ground | |
| NA | NA |
| Max digging depth | |
| 2805 mm | 3208 mm |
| Max digging height | |
| 4265 mm | 4540 mm |
| Max Dump Height | |
| 2880 mm | 3280 mm |
| Max vertical wallcut depth | |
| 2275 mm | 2957 mm |
| Min swing radius | |
| 2290 mm | NA |
| Max Height at Min Swing radius | |
| 1845 mm | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 30.1 kN | 30 kN |
| Arm Digging Force | |
| NA | 18 kN |
| Swing Speed | |
| 8.6 rpm | NA |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Dozer Type | |
| NA | Hydraulic Lifiting Type |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| 360 mm | 385 mm |
| Approach Angle | |
| NA | NA |
| Width | |
| 1550 mm | 1720 mm |
| Height | |
| 340 mm | 350 mm |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Bucket Capacity | |
| 0.1 m³ | 0.12 m³ |
| Kubota U30-6S | Fine FM38 |
|---|---|
| Overall Length | |
| 4545 mm | 4915 mm |
| Overall width | |
| 1550 mm | 1755 mm |
| Overall Height | |
| 2485 mm | 2525 mm |
| Overall Height of Cab | |
| 2485 mm | NA |
| Upper Width | |
| NA | NA |
| Track Lengh on Ground | |
| 1666 mm | 1670 mm |
| Undercarriage overall length | |
| 2125 mm | 2125 mm |
| Tailswing radius | |
| 790 mm | 860 mm |
| Min Ground clearance | |
| 290 mm | 305 mm |
| Track gauge | |
| NA | NA |
| Width over tracks | |
| NA | 1755 mm |
| Track Height | |
| NA | NA |
| Counterweight Clearence | |
| NA | NA |
| Track Shoe Width | |
| 300 mm | 350 mm |
