The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Kubota U30-6S | JCB 30 PLUS |
|---|
| Particulars | Kubota U30-6S | JCB 30 PLUS |
|---|
The JCB 30 PLUS and Kubota U30-6S are both mini excavators designed for tasks like landscaping and small construction or agricultural work. The JCB 30 PLUS has better fuel efficiency and travel speed, while the Kubota excels in power, bucket capacity, and includes a GPS system.
Given the analysis, if productivity and power are your primary needs and you can benefit from the GPS for fleet management, the Kubota U30-6S would be a better choice. However, if operation in confined areas and potential for easier transport due to a lighter weight are more important, along with slightly better fuel efficiency, then the JCB 30 PLUS would be the recommended option.
| Brand | Escorts Kubota Excavator | JCB Excavator |
|---|---|---|
| Type | Mini (0-6 Ton) | Mini (0-6 Ton) |
| Operating Cost | ₹ 28-30 lakhs | ₹ 26 - 28 Lakhs |
| Price | ₹ 28-30 lakhs | ₹ 26 - 28 Lakhs |
| Weight | 3195 Kg | 2870 Kg |
| Bucket | 0.1 m³ | 0.08 m³ |
| Max Digging Depth | 2805 mm | 2740 mm |
| Engine | Kubota 27.5 HP | Perkins 24.7 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2000 hr. |
| Boom | NA | 2130 mm |
| Quick Overview: | The Kubota U30-6S is a top zero tail swing mini excavator that emphasizes versatility and efficiency. It features a reliable 20.5 kW (27.5 HP) Kubota direct injection engine, delivering strong digging performance while using fuel efficiently. The operator space is improved, and it provides a smooth hydraulic response and great stability, making it ideal for various tasks. Designed for durability and easy maintenance, the Kubota U30-6S ensures consistent uptime and strong performance in challenging Indian construction environments. |
The JCB 30 Plus mini excavator is a compact and versatile machine designed for urban construction, landscaping, and utility trenching tasks. Powered by a Perkins 403D-15 engine delivering 24.7 HP with a 0.08 m³ bucket, it balances performance and fuel efficiency in tight workspaces. With an operating weight of around 2.87 tons, the 30 Plus offers smooth digging and material handling. The JCB 30 Plus price in India typically ranges between ₹26 lakh and ₹28 lakh, making it a practical choice for contractors seeking productivity and ease of use. |
| Agency review | Get the best price for the Kubota U30-6S Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the JCB 30 PLUS Mini Excavator from authorized dealers. Contact us now for exclusive deals! |
The JCB 30 PLUS and Kubota U30-6S are both mini excavators designed for tasks like landscaping and small construction or agricultural work. The JCB 30 PLUS has better fuel efficiency and travel speed, while the Kubota excels in power, bucket capacity, and includes a GPS system.
Given the analysis, if productivity and power are your primary needs and you can benefit from the GPS for fleet management, the Kubota U30-6S would be a better choice. However, if operation in confined areas and potential for easier transport due to a lighter weight are more important, along with slightly better fuel efficiency, then the JCB 30 PLUS would be the recommended option.
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Brand | |
| Escorts Kubota Excavator | JCB Excavator |
| Type | |
| Mini (0-6 Ton) | Mini (0-6 Ton) |
| Price | |
| ₹ 28-30 lakhs | ₹ 26 - 28 Lakhs |
| Weight | |
| 3195 Kg | 2870 Kg |
| Bucket | |
| 0.1 m³ | 0.08 m³ |
| Max Digging Depth | |
| 2805 mm | 2740 mm |
| Engine | |
| Kubota 27.5 HP | Perkins 24.7 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2000 hr. |
| Boom | |
| NA | 2130 mm |
| Quick Overview: | |
The Kubota U30-6S is a top zero tail swing mini excavator that emphasizes versatility and efficiency. It features a reliable 20.5 kW (27.5 HP) Kubota direct injection engine, delivering strong digging performance while using fuel efficiently. The operator space is improved, and it provides a smooth hydraulic response and great stability, making it ideal for various tasks. Designed for durability and easy maintenance, the Kubota U30-6S ensures consistent uptime and strong performance in challenging Indian construction environments. |
The JCB 30 Plus mini excavator is a compact and versatile machine designed for urban construction, landscaping, and utility trenching tasks. Powered by a Perkins 403D-15 engine delivering 24.7 HP with a 0.08 m³ bucket, it balances performance and fuel efficiency in tight workspaces. With an operating weight of around 2.87 tons, the 30 Plus offers smooth digging and material handling. The JCB 30 Plus price in India typically ranges between ₹26 lakh and ₹28 lakh, making it a practical choice for contractors seeking productivity and ease of use. |
| Kubota U30-6S | JCB 30 PLUS | |
| Engine Make | Kubota D1803-M-DI-E2-BH-TH1 | Perkins 403D-l5 |
| Fuel Tank | 41.5 L | 56 L |
| Engine Displacment | 1.826 L | 1.496 L |
| Under Carriage | 2125 mm | 1870 mm |
| Hydraulic System | NA | 7 L |
| Arm | NA | 1300 mm |
| Max Digging Reach | 4905 mm | 4770 mm |
| Fuel Consumption | 4 L/hour | 4.3 L/hour |
| Overall Width | 1550 mm | 1550 mm |
| Overall Length | 4545 mm | 4080 mm |
| Bucket Digging Force | 30.1 kN | 23 kN |
| Tailswing Radius | 790 mm | 1220 mm |
| Track Shoe Width | 300 mm | 250 mm |
| AC Cabin | Not Available | Optional |
| GPS | Standard | Not Available |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Engine Make | |
| Kubota D1803-M-DI-E2-BH-TH1 | Perkins 403D-l5 |
| Fuel Tank | |
| 41.5 L | 56 L |
| Engine Displacment | |
| 1.826 L | 1.496 L |
| Under Carriage | |
| 2125 mm | 1870 mm |
| Hydraulic System | |
| NA | 7 L |
| Arm | |
| NA | 1300 mm |
| Max Digging Reach | |
| 4905 mm | 4770 mm |
| Fuel Consumption | |
| 4 L/hour | 4.3 L/hour |
| Overall Width | |
| 1550 mm | 1550 mm |
| Overall Length | |
| 4545 mm | 4080 mm |
| Bucket Digging Force | |
| 30.1 kN | 23 kN |
| Tailswing Radius | |
| 790 mm | 1220 mm |
| Track Shoe Width | |
| 300 mm | 250 mm |
| AC Cabin | |
| Not Available | Optional |
| GPS | |
| Standard | Not Available |
| 3568 | 3538 | |
| Model | Kubota 27.5 HP | Perkins 24.7 HP |
| Fuel | Diesel | Diesel |
| Type | NA | Water Cooled |
| Rated Engine Power | 27.5 HP (20.5 kW) @ 2200 rpm | 24.7 HP (18.4 kW) @ 2100 rpm |
| Maximum Torque | NA | 96 Nm @ 1800 rpm |
| Piston Displacement | 1.826 L | 1.496 L |
| Alternator | NA | 65A |
| Battery | 12V | 12V , 75 Ah |
| Starting Motor | NA | 2 kW |
| 2 kW | 2 kW | |
| No of Top rollers | NA | NA |
| No of bottom rollers | NA | 3 |
| Track Shoes (Each Side) | NA | NA |
| Track Guard | NA | NA |
| Track Shoe width | 300 mm | 250 mm |
| Ground bearing pressure | NA | 39.2 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 30° | 36 ° |
| Travel Speed-Low | 2.5 Km/h | 2.5 Km/h |
| Travel Speed-High | 4.4 Km/h | 4.9 Km/h |
| Max Tracking Force | NA | 25 kN |
| Kubota U30-6S | JCB 30 PLUS | |
| Hydraulic pump | Variable pump × 1 | 2 Variable & I Gear |
| Maximum Flow | NA | 70.21 L/min |
| Pilot Pump | Gear Pump | Gear Pump |
| Implement Circuit | NA | 23.5 MPa |
| Swing Circuit | NA | 19.0 MPa |
| Travel circuit | NA | NA |
| Pilot circuit | NA | NA |
| Kubota U30-6S | JCB 30 PLUS | |
| Travel | Hydraulic piston motor: 2F | NA |
| Swing | Hydraulic piston motor | NA |
| Kubota U30-6S | JCB 30 PLUS | |
| Fuel tank | 41.5 L | 56 L |
| Engine Coolant | NA | 8.5 L |
| Engine oil | NA | 4.5 L |
| Hydraulic system | NA | 7 L |
| Hydraulic tank | NA | 45 L |
| Kubota U30-6S | JCB 30 PLUS | |
| Operating Weight | 3195 Kg | 2870 Kg |
| Kubota U30-6S | JCB 30 PLUS | |
| Boom length | NA | 2130 mm |
| Arm length | NA | 1300 mm |
| Max Digging Reach | 4905 mm | 4770 mm |
| Max Digging Reach on ground | NA | NA |
| Max digging depth | 2805 mm | 2740 mm |
| Max digging height | 4265 mm | 4495 mm |
| Max Dump Height | 2880 mm | 3220 mm |
| Max vertical wallcut depth | 2275 mm | 2080 mm |
| Min swing radius | 2290 mm | 2045 mm |
| Max Height at Min Swing radius | 1845 mm | 1870 mm |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 30.1 kN | 23 kN |
| Arm Digging Force | NA | 17 kN |
| Swing Speed | 8.6 rpm | 9.6 rpm |
| Kubota U30-6S | JCB 30 PLUS | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | 360 mm | 333 mm |
| Approach Angle | NA | 31 ° |
| Width | 1550 mm | 1550 mm |
| Height | 340 mm | 268 mm |
| Kubota U30-6S | JCB 30 PLUS | |
| Bucket Capacity | 0.1 m³ | 0.08 m³ |
| Kubota U30-6S | JCB 30 PLUS | |
| Overall Length | 4545 mm | 4080 mm |
| Overall width | 1550 mm | 1550 mm |
| Overall Height | 2485 mm | 2400 mm |
| Overall Height of Cab | 2485 mm | 2400 mm |
| Upper Width | NA | NA |
| Track Lengh on Ground | 1666 mm | 1440 mm |
| Undercarriage overall length | 2125 mm | 1870 mm |
| Tailswing radius | 790 mm | 1220 mm |
| Min Ground clearance | 290 mm | 270 mm |
| Track gauge | NA | 1252 mm |
| Width over tracks | NA | 1502 mm |
| Track Height | NA | 455 mm |
| Counterweight Clearance | NA | NA |
| Track Shoe Width | 300 mm | 250 mm |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Model | |
| Kubota 27.5 HP | Perkins 24.7 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| NA | Water Cooled |
| Rated Engine Power | |
| 27.5 HP (20.5 kW) @ 2200 rpm | 24.7 HP (18.4 kW) @ 2100 rpm |
| Maximum Torque | |
| NA | 96 Nm @ 1800 rpm |
| Piston Displacement | |
| 1.826 L | 1.496 L |
| Alternator | |
| NA | 65A |
| Battery | |
| 12V | 12V , 75 Ah |
| Starting Motor | |
| NA | 2 kW |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| No of Top rollers | |
| NA | NA |
| No of bottom rollers | |
| NA | 3 |
| Track Shoes (Each Side) | |
| NA | NA |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 300 mm | 250 mm |
| Ground bearing pressure | |
| NA | 39.2 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 30° | 36 ° |
| Travel Speed-Low | |
| 2.5 Km/h | 2.5 Km/h |
| Travel Speed-High | |
| 4.4 Km/h | 4.9 Km/h |
| Max Tracking Force | |
| NA | 25 kN |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Hydraulic pump | |
| Variable pump × 1 | 2 Variable & I Gear |
| Maximum Flow | |
| NA | 70.21 L/min |
| Pilot Pump | |
| Gear Pump | Gear Pump |
| Implement Circuit | |
| NA | 23.5 MPa |
| Swing Circuit | |
| NA | 19.0 MPa |
| Travel circuit | |
| NA | NA |
| Pilot circuit | |
| NA | NA |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Fuel tank | |
| 41.5 L | 56 L |
| Engine Coolant | |
| NA | 8.5 L |
| Engine oil | |
| NA | 4.5 L |
| Hydraulic system | |
| NA | 7 L |
| Hydraulic tank | |
| NA | 45 L |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Operating Weight | |
| 3195 Kg | 2870 Kg |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Boom length | |
| NA | 2130 mm |
| Arm length | |
| NA | 1300 mm |
| Max Digging Reach | |
| 4905 mm | 4770 mm |
| Max Digging Reach on ground | |
| NA | NA |
| Max digging depth | |
| 2805 mm | 2740 mm |
| Max digging height | |
| 4265 mm | 4495 mm |
| Max Dump Height | |
| 2880 mm | 3220 mm |
| Max vertical wallcut depth | |
| 2275 mm | 2080 mm |
| Min swing radius | |
| 2290 mm | 2045 mm |
| Max Height at Min Swing radius | |
| 1845 mm | 1870 mm |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 30.1 kN | 23 kN |
| Arm Digging Force | |
| NA | 17 kN |
| Swing Speed | |
| 8.6 rpm | 9.6 rpm |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| 360 mm | 333 mm |
| Approach Angle | |
| NA | 31 ° |
| Width | |
| 1550 mm | 1550 mm |
| Height | |
| 340 mm | 268 mm |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Bucket Capacity | |
| 0.1 m³ | 0.08 m³ |
| Kubota U30-6S | JCB 30 PLUS |
|---|---|
| Overall Length | |
| 4545 mm | 4080 mm |
| Overall width | |
| 1550 mm | 1550 mm |
| Overall Height | |
| 2485 mm | 2400 mm |
| Overall Height of Cab | |
| 2485 mm | 2400 mm |
| Upper Width | |
| NA | NA |
| Track Lengh on Ground | |
| 1666 mm | 1440 mm |
| Undercarriage overall length | |
| 2125 mm | 1870 mm |
| Tailswing radius | |
| 790 mm | 1220 mm |
| Min Ground clearance | |
| 290 mm | 270 mm |
| Track gauge | |
| NA | 1252 mm |
| Width over tracks | |
| NA | 1502 mm |
| Track Height | |
| NA | 455 mm |
| Counterweight Clearence | |
| NA | NA |
| Track Shoe Width | |
| 300 mm | 250 mm |
