The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|
| Particulars | Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|
The Sany SY120C-9 and Sany SY140C-9/9S Tunnel excavators are equipped with Cummins engines, providing reliable power and performance. The SY120C-9 is more compact and suitable for general excavating with a decent bucket force, while the SY140C-9/9S is tailored for specific tough tunnel environments, offering a higher tracking force and larger bucket capacity.
For projects requiring a versatile and general-purpose excavator, the Sany SY120C-9 could be the better choice due to its smaller dimensions and lower price point. However, if the focus is on stability, tracking force, and bucket capacity for challenging tunnel conditions, the Sany SY140C-9/9S Tunnel would be more appropriate, albeit with an increased cost.
| Brand | SANY | SANY |
|---|---|---|
| Type | Small (6-15 Ton) | Small (6-15 Ton) |
| Operating Cost | ₹ 52-53 Lakhs | ₹ 55-56 Lakhs |
| Price | ₹ 52-53 Lakhs | ₹ 55-56 Lakhs |
| Weight | 14260 Kg | 12400 Kg |
| Bucket | 0.7 m³ | 0.65 m³ |
| Max Digging Depth | 3131 mm | 4750 mm |
| Engine | Cummins 100.5 HP | Cummins 100.5 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 2900 mm | 4260 mm |
| Quick Overview: | Featuring advanced technology for construction in tight and challenging tunneling conditions Sany’s SY140C-9/9S Tunnel small excavator is ideal. |
Designed for efficiency, the Sany SY120C-9 small excavator ensures precise construction and earthmoving operations. |
| Agency review | Get the best price for the Sany SY140C-9/9S TUNNEL Small Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Sany SY120C-9 Small Excavator from authorized dealers. Contact us now for exclusive deals! |
The Sany SY120C-9 and Sany SY140C-9/9S Tunnel excavators are equipped with Cummins engines, providing reliable power and performance. The SY120C-9 is more compact and suitable for general excavating with a decent bucket force, while the SY140C-9/9S is tailored for specific tough tunnel environments, offering a higher tracking force and larger bucket capacity.
For projects requiring a versatile and general-purpose excavator, the Sany SY120C-9 could be the better choice due to its smaller dimensions and lower price point. However, if the focus is on stability, tracking force, and bucket capacity for challenging tunnel conditions, the Sany SY140C-9/9S Tunnel would be more appropriate, albeit with an increased cost.
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Brand | |
| SANY | SANY |
| Type | |
| Small (6-15 Ton) | Small (6-15 Ton) |
| Price | |
| ₹ 52-53 Lakhs | ₹ 55-56 Lakhs |
| Weight | |
| 14260 Kg | 12400 Kg |
| Bucket | |
| 0.7 m³ | 0.65 m³ |
| Max Digging Depth | |
| 3131 mm | 4750 mm |
| Engine | |
| Cummins 100.5 HP | Cummins 100.5 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 2900 mm | 4260 mm |
| Quick Overview: | |
Featuring advanced technology for construction in tight and challenging tunneling conditions Sany’s SY140C-9/9S Tunnel small excavator is ideal. |
Designed for efficiency, the Sany SY120C-9 small excavator ensures precise construction and earthmoving operations. |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Engine Make | Cummins B3.9-100c | Cummins B3.9-100c |
| Fuel Tank | 240 L | 240 L |
| Engine Displacment | 3.9 L | 3.9 L |
| Under Carriage | 3665 mm | 3360 mm |
| Hydraulic System | 150 L | 120 L |
| Arm | 1700 mm | 1960 mm |
| Max Digging Reach | 5918 mm | 7345 mm |
| Fuel Consumption | NA | 10 L/hour |
| Overall Width | 2510 mm | 2510 mm |
| Overall Length | 5772 mm | 7280 mm |
| Bucket Digging Force | 77.7 kN | 82.5 kN |
| Tailswing Radius | 2285 mm | 2280 mm |
| Track Shoe Width | 500 mm | 500 mm |
| AC Cabin | Optional | Optional |
| GPS | Standard | Standard |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Engine Make | |
| Cummins B3.9-100c | Cummins B3.9-100c |
| Fuel Tank | |
| 240 L | 240 L |
| Engine Displacment | |
| 3.9 L | 3.9 L |
| Under Carriage | |
| 3665 mm | 3360 mm |
| Hydraulic System | |
| 150 L | 120 L |
| Arm | |
| 1700 mm | 1960 mm |
| Max Digging Reach | |
| 5918 mm | 7345 mm |
| Fuel Consumption | |
| NA | 10 L/hour |
| Overall Width | |
| 2510 mm | 2510 mm |
| Overall Length | |
| 5772 mm | 7280 mm |
| Bucket Digging Force | |
| 77.7 kN | 82.5 kN |
| Tailswing Radius | |
| 2285 mm | 2280 mm |
| Track Shoe Width | |
| 500 mm | 500 mm |
| AC Cabin | |
| Optional | Optional |
| GPS | |
| Standard | Standard |
| 3604 | 3602 | |
| Model | Cummins 100.5 HP | Cummins 100.5 HP |
| Fuel | Diesel | Diesel |
| Type | 4 Cylinder , inline , Water Cooled | 4 Cylinder , inline , Water Cooled |
| Rated Engine Power | 100.5 HP (75 kW) @ 2200 rpm | 100.5 HP (75 kW) @ 2200 rpm |
| Maximum Torque | 385 Nm @ 1300 rpm | 385 Nm @ 1300 rpm |
| Piston Displacement | 3.9 L | 3.9 L |
| Alternator | NA | NA |
| Battery | 12 V System (2-12V) | 12 V System (2-12V) |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | 1 | 1 |
| No of bottom rollers | 7 | 6 |
| Track Shoes (Each Side) | 44 | 41 |
| Track Guard | 1 | 1 |
| Track Shoe width | 500 mm | 500 mm |
| Ground bearing pressure | 43.1 kPa | 41.6 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 70% (35°) | 70% (35°) |
| Travel Speed-Low | 3.5 Km/h | 3.5 Km/h |
| Travel Speed-High | 5.5 Km/h | 5.5 Km/h |
| Max Tracking Force | 124.1 kN | 113 kN |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Hydraulic pump | 2 Variable Displacement Axial Piston Pumps | 1 Variable Displacement Axial Piston Pump |
| Maximum Flow | 2 x 121 L/min | 225 L/min |
| Pilot Pump | 1 Gear Pump | 1 Gear Pump |
| Implement Circuit | 31.4 MPa | 31.4 MPa |
| Swing Circuit | 25.0 MPa | 25.0 MPa |
| Travel circuit | 31.4 MPa | 31.4 MPa |
| Pilot circuit | 3.9 MPa | 3.9 MPa |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Travel | 2 Axial Piston Motor With Parking Brake | 2 Axial Piston Motor With Parking Brake |
| Swing | 1 Axial Piston Motor with swing holding brake | 1 Axial Piston Motor with Swing Brake |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Fuel tank | 240 L | 240 L |
| Engine Coolant | 6.7 L | 6.7 L |
| Engine oil | 9 L | 9 L |
| Hydraulic system | 150 L | 120 L |
| Hydraulic tank | 120 L | 150 L |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Operating Weight | 14260 Kg | 12400 Kg |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Boom length | 2900 mm | 4260 mm |
| Arm length | 1700 mm | 1960 mm |
| Max Digging Reach | 5918 mm | 7345 mm |
| Max Digging Reach on ground | 5744 mm | NA |
| Max digging depth | 3131 mm | 4750 mm |
| Max digging height | 6868 mm | 7415 mm |
| Max Dump Height | 4534 mm | 5165 mm |
| Max vertical wallcut depth | 2633 mm | 4410 mm |
| Min swing radius | 2432 mm | 2625 mm |
| Max Height at Min Swing radius | 4713 mm | 5900 mm |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 77.7 kN | 82.5 kN |
| Arm Digging Force | 81.8 kN | 62.1 kN |
| Swing Speed | 12 rpm | 12 rpm |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Bucket Capacity | 0.7 m³ | 0.65 m³ |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 | |
| Overall Length | 5772 mm | 7280 mm |
| Overall width | 2510 mm | 2510 mm |
| Overall Height | 2825 mm | 2700 mm |
| Overall Height of Cab | 2825 mm | 2740 mm |
| Upper Width | 2517 mm | 2525 mm |
| Track Lengh on Ground | 2930 mm | 2680 mm |
| Undercarriage overall length | 3665 mm | 3360 mm |
| Tailswing radius | 2285 mm | 2280 mm |
| Min Ground clearance | 425 mm | 425 mm |
| Track gauge | 1990 mm | 1990 mm |
| Width over tracks | 2517 mm | 2525 mm |
| Track Height | NA | NA |
| Counterweight Clearance | NA | NA |
| Track Shoe Width | 500 mm | 500 mm |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Model | |
| Cummins 100.5 HP | Cummins 100.5 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4 Cylinder , inline , Water Cooled | 4 Cylinder , inline , Water Cooled |
| Rated Engine Power | |
| 100.5 HP (75 kW) @ 2200 rpm | 100.5 HP (75 kW) @ 2200 rpm |
| Maximum Torque | |
| 385 Nm @ 1300 rpm | 385 Nm @ 1300 rpm |
| Piston Displacement | |
| 3.9 L | 3.9 L |
| Alternator | |
| NA | NA |
| Battery | |
| 12 V System (2-12V) | 12 V System (2-12V) |
| Starting Motor | |
| NA | NA |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| No of Top rollers | |
| 1 | 1 |
| No of bottom rollers | |
| 7 | 6 |
| Track Shoes (Each Side) | |
| 44 | 41 |
| Track Guard | |
| 1 | 1 |
| Track Shoe width | |
| 500 mm | 500 mm |
| Ground bearing pressure | |
| 43.1 kPa | 41.6 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 70% (35°) | 70% (35°) |
| Travel Speed-Low | |
| 3.5 Km/h | 3.5 Km/h |
| Travel Speed-High | |
| 5.5 Km/h | 5.5 Km/h |
| Max Tracking Force | |
| 124.1 kN | 113 kN |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Hydraulic pump | |
| 2 Variable Displacement Axial Piston Pumps | 1 Variable Displacement Axial Piston Pump |
| Maximum Flow | |
| 2 x 121 L/min | 225 L/min |
| Pilot Pump | |
| 1 Gear Pump | 1 Gear Pump |
| Implement Circuit | |
| 31.4 MPa | 31.4 MPa |
| Swing Circuit | |
| 25.0 MPa | 25.0 MPa |
| Travel circuit | |
| 31.4 MPa | 31.4 MPa |
| Pilot circuit | |
| 3.9 MPa | 3.9 MPa |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Fuel tank | |
| 240 L | 240 L |
| Engine Coolant | |
| 6.7 L | 6.7 L |
| Engine oil | |
| 9 L | 9 L |
| Hydraulic system | |
| 150 L | 120 L |
| Hydraulic tank | |
| 120 L | 150 L |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Operating Weight | |
| 14260 Kg | 12400 Kg |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Boom length | |
| 2900 mm | 4260 mm |
| Arm length | |
| 1700 mm | 1960 mm |
| Max Digging Reach | |
| 5918 mm | 7345 mm |
| Max Digging Reach on ground | |
| 5744 mm | NA |
| Max digging depth | |
| 3131 mm | 4750 mm |
| Max digging height | |
| 6868 mm | 7415 mm |
| Max Dump Height | |
| 4534 mm | 5165 mm |
| Max vertical wallcut depth | |
| 2633 mm | 4410 mm |
| Min swing radius | |
| 2432 mm | 2625 mm |
| Max Height at Min Swing radius | |
| 4713 mm | 5900 mm |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 77.7 kN | 82.5 kN |
| Arm Digging Force | |
| 81.8 kN | 62.1 kN |
| Swing Speed | |
| 12 rpm | 12 rpm |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Bucket Capacity | |
| 0.7 m³ | 0.65 m³ |
| Sany SY140C-9/9S Tunnel | Sany SY120C-9 |
|---|---|
| Overall Length | |
| 5772 mm | 7280 mm |
| Overall width | |
| 2510 mm | 2510 mm |
| Overall Height | |
| 2825 mm | 2700 mm |
| Overall Height of Cab | |
| 2825 mm | 2740 mm |
| Upper Width | |
| 2517 mm | 2525 mm |
| Track Lengh on Ground | |
| 2930 mm | 2680 mm |
| Undercarriage overall length | |
| 3665 mm | 3360 mm |
| Tailswing radius | |
| 2285 mm | 2280 mm |
| Min Ground clearance | |
| 425 mm | 425 mm |
| Track gauge | |
| 1990 mm | 1990 mm |
| Width over tracks | |
| 2517 mm | 2525 mm |
| Track Height | |
| NA | NA |
| Counterweight Clearence | |
| NA | NA |
| Track Shoe Width | |
| 500 mm | 500 mm |
