    Liugong 836N Wheel Loader

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    • Brand

      LiuGong

    • Type

      Small (8-15 Ton)

    • Operating Cost

      ₹ 54-56 Lakhs

    • Ex-Showroom Price

      ₹ 54-56 Lakhs

    • Engine

      Ashok Leyland 160 HP

    • featIcon2 (1) alt
      Bucket

      2.2 m³

    • icon alt1
      Weight

      11660 kg

    • Fwd. Speed

      38 km/h

    • dumping height loader
      Dump Height

      2950 mm

    • tipping load
      Tipping Load

      7200 kg

    Quick Overview:

    The Liugong 836N Wheel Loader offers balanced performance and fuel efficiency, suitable for various Indian construction and agricultural tasks.

    Connect With Us:

    Get the best price for the Liugong 836N wheel loader from authorized dealers. Contact us now for exclusive deals!

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    Key Highlights

    Engine Make

    Ashok Leyland H6C416022

    Max Torque

    650 Nm @ 1400-1600 rpm

    Fuel Tank

    165 L

    Hydraulic System

    197 L/min

    grounding
    Min. Ground Clearance

    318 mm

    desi machines payload
    Payload

    3600 kg

    360 degree
    Steering Angle

    ±38°

    Drive Type

    4-wheel drive (4WD)

    Wheelbase

    2870 mm

    Tyres

    17.5 - 25 - 16PR

    down
    Max. Breakout Force

    120 kN

    Overall Length

    7400 mm

    Medal Image
    Warranty

    1 Yr. / 2000 hr.

    air-conditioner-alt
    AC Cabin

    Standard

    GPS Tracking
    GPS

    Standard

    Features

    Performance

    Performance

    • Precisely selection of CEV Stage IV Compliant Engine to ensure the unmatched performance to handle the toughest and heaviest jobs. Offering big capacity buckets large dump height and great stability on operation shown all time favourable features of LiuGong loader to its Customer.

    Performance

    • Precisely selection of CEV Stage IV Compliant Engine to ensure the unmatched performance to handle the toughest and heaviest jobs. Offering big capacity buckets large dump height and great stability on operation shown all time favourable features of LiuGong loader to its Customer.

    Efficiency

    • Perfect match of power trains and implementation units always succeed to deliver high efficiency factors in loaders for various application, and LiuGong has speciality of it.

    Reliability

    • Reliability is factor which cannot come from the brand make but from the product presence and adaptability in the market due to its continuous operating hours and LiuGong has a Expertise over 6 Decades in manufacturing of Wheel loader for toughest applications.

    Comfort

    • Every work get easier & productive if operator feels safety as well as comfort on his job. Our well designed AC Cab offers various features to create best working environment – a comfortable operator is a productive operator.

    Maximum uptime

    • Ground level serviceability give easy access to service touch points and minimize the down time.

    Specifications

    Product specification of Liugong 836N Wheel Loader

    ENGINE

    • Make

      Ashok Leyland H6C416022

    • Type

      6 Cylinder turbocharged engine with air intercooler offers best in class power and torque, Specially designed LSCHT helps to improve fuel efficiency.

    • Aspiration

      Turbocharged

    • Emission

      CEV Stage IV

    • Max. Power

      160 HP (118 kW) @ 2200 rpm

    • Max Torque

      650 Nm @ 1400-1600 rpm

    • Piston Displacement

      5,76 L

    • No. of Cylinders

      6 Cylinders

    • Battery

      2 x 12V

    • Alternator

      NA

    POWER TRAIN

    • Transmission

      Powershift

    • Drive Type

      4-wheel drive (4WD)

    • Torque Converter

      Twin Turbine, Four Members

    BRAKES

    • Service

      4 wheel applied air over hydraulic with independent circuit for front & rear axle

    • Parking

      Drum brake Mechanical Actuation

    STEERING SYSTEM

    • Type

      Articulated Steering

    • Steering Angle

      ±38°

    AXLE AND FINAL DRIVE

    • Front Axle Type

      NA

    • Rear Axle Type

      NA

    • Oscillation Angle

      ±11°

    SPEED

    • Top Forward Speed

      38 km/h

    • Top Reverse Speed

      17 km/h

    HYDRAULIC SYSTEM

    • System Type

      Open Center

    • Pump Type

      Gear Pump

    • Max. Pump Flow

      197 L/min

    • System Pressure

      210 bar

    SERVICE REFILL CAPACITIES

    • Fuel Tank

      165 L

    • Hydraulic System

      103 L

    • Engine Oil

      18 L

    • Cooling System

      30 L

    • Rear Axle Oil

      22 L

    • Front Axle Oil

      22 L

    • Hydraulic Tank

      NA

    • Transmission Oil

      34 L

    • DEF Tank

      NA

    DIMENSIONS

    • Overall Length With Bucket

      7400 mm

    • Wheel Base

      2870 mm

    • Height Over Cab

      3340 mm

    • Height Over Exhaust

      NA

    • Min. Ground Clearance

      318 mm

    • Width Over Tyres

      2500 mm

    • Wheel Tread

      2054 mm

    • Tyre Size

      17.5 - 25 - 16PR

    PERFORMANCE

    • Bucket Capacity

      2.2 m³

    • Bucket Width

      2704 mm

    • Payload

      3600 kg

    • Tipping Load Straight

      8200 kg

    • Tipping Load Full Turn

      7200 kg

    • Max. Breakout Force

      120 kN

    • Operating Weight

      11660 kg

    • Maximum Dump Angle

      45°

    • Bucket Roll Back Angle Full Height

      60°

    • Bucket Roll Back At Carry

      48°

    • Bucket Roll Back At Ground Level

      41°

    • Dumping Height, Fully Raised

      2950 mm

    • Dumping Reach, Fully Raised

      1060 mm

    • Max. Hinge Pin Height

      3998 mm

    • Max. Digging Depth

      40 mm

    • Turning Radius Over Tyres

      4900 mm

    • Turning Radius Over Bucket

      5750 mm

    Frequently Asked Question

    01. What is the Liugong 836N wheel loader price in India?

    Ans.

    The Liugong 836N wheel loader price in India ranges between ₹ 54-56 Lakhs. However, the exact price may vary depending on the location dealer, taxes, and additional features.

    02. Where can I buy the Liugong 836N wheel loader in India at the best price?

    Ans.

    You can buy the Liugong 836N wheel loader in India through Desi Machines, the best online platform to compare and purchase construction equipment from verified dealers near you. We connect you with authorized Liugong dealers across India and help you get multiple price quotes from different vendors , so you can choose the best deal. Simply fill out the inquiry form to receive customized offers, financing options, and real-time availability. Get the latest Liugong 836N price, compare dealer quotes, and enjoy expert assistance—all in one place.

    03. What is the engine power of the Liugong 836N wheel loader?

    Ans.

    The Liugong 836N wheel loader is powered by an Ashok Leyland H6C416022 diesel engine, delivering 160 HP (118 kW) @ 2200 rpm.

    04. What is the operating weight of the Liugong 836N wheel loader?

    Ans.

    The operating weight of the Liugong 836N wheel loader is approximately 11660 kg. The operating weight may vary slightly depending on specific configurations and attachments.

    05. What is the fuel tank capacity of the Liugong 836N wheel loader?

    Ans.

    The Liugong 836N wheel loader has a 165 litres diesel fuel tank, providing extended operation time without frequent refueling.

    06. What is the bucket capacity of the Liugong 836N wheel loader?

    Ans.

    The bucket capacity of the Liugong 836N is 2.2 cubic meters (m³).

    07. What is the dump height of the Liugong 836N wheel loader?

    Ans.

    The Liugong 836N wheel loader has a dump height of 2950 mm, enabling effective material discharge on construction projects.

    08. What is the warranty period of Liugong 836N wheel loader?

    Ans.

    The Liugong 836N wheel loader in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever comes first. The warranty covers defects from faulty materials or workmanship, but terms may vary. For the latest details, check with authorized dealers or visit the official brand website.

    09. How many gears are available in the Liugong 836N wheel loader?

    Ans.

    The Liugong 836N wheel loader features a 4-wheel drive (4WD) system with a Powershift transmission. It offers 2 forward and 1 reverse gear, enabling efficient operation at speeds up to 38 km/h.

    10. What are the key applications and uses of the Liugong 836N wheel loader?

    Ans.

    Designed for tough construction and mining tasks, the Liugong 836N heavy-duty loader offers strong breakout force, reliable hydraulics, and efficient fuel use for optimal productivity.

    11. Where can I find spare parts for the Liugong 836N wheel loader?

    Ans.

    You can find genuine spare parts for the Liugong 836N wheeled loader at authorized Liugong dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on wheeled loader spare parts.
