JCB 3DX Backhoe Loader

desi-machines-backhoe-loader-jcb-3dx-featured

Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

Brand
JCB
Type
2WD/4WD
Operating Cost
₹ 34-36 Lakhs
Ex-Showroom Price
₹ 34-36 Lakhs

Engine
JCB 49 HP
Bucket
0.26 m³
Shovel
1.0 m³
Digging Depth
4770 mm
Dump Height
2740 mm
Weight
7200 Kg

Quick Overview:

The JCB 3DX backhoe loader delivers high productivity, fuel efficiency, and superior durability, making it ideal for diverse construction and excavation tasks.

Connect With Us:

Looking for the best price on a JCB 3DX backhoe loader? Connect with authorized dealers today for exclusive deals!

Download Brochure

Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

Key Highlights

Engine Make

JCB 430

Fuel Tank

128 L

Max Torque

270 Nm @ 1320 RPM

Max Speed

32.3 km/hr

Hydraulic System

114 L/min @ 2000 RPM

Max Working Height

5970 mm

Excavator Max Lift Capacity

1490 Kg

Loader Load Over Height

3320 mm

Overall Length

6000 mm

Wheel Base

2170 mm

Bucket Digging Force

5959 kgf

Shovel Break Out Force

5272 kgf

Warranty

1 Yr. / 2000 hr.

AC Cabin

Optional

GPS

Standard

Features

Better Fuel Efficiency

The JCB 3DX, powered by the proven Stage 5-430 engine, sets new benchmarks in fuel efficiency with its advanced technology, ensuring significant savings while maintaining peak performance. If you’re considering the JCB 3DX price, its value becomes evident with features like:
Up to 10% Lower Fuel Consumption for cost-effective operations.
Variable Displacement Hydraulic Pump adjusts flow to match load demands.
Multiple Working Modes tailored for task-specific fuel optimization. With these features, the JCB 3DX delivers unmatched efficiency, making every operation more economical.

Better Performance & Productivity

The JCB 3DX Backhoe Loader aims to deliver great strength coupled with operational efficiency to ensure seamless productivity even under the toughest conditions. Equipped with advanced technologies, it provides a smoother operation and enhancement of reliability to push at the limits of achievable performance.
13%* higher torque for greater efficiency
Multiple working modes for task-specific optimization
e-Waste Gate Turbocharger for improved power and fuel efficiency

Better Comfort & Ease Of Use

The JCB 3DX Backhoe Loader redefines operator experience with its advanced safety and comfort features, ensuring seamless operation even in challenging environments. It’s built to keep operators safe, comfortable, and focused.
Standard ROPS & FOPS: Enhanced safety with Roll-Over and Falling Object Protective Structures.
Reduced In-Cab Noise: Provides a quieter, more comfortable workspace for extended use.
User-Centric Design: Prioritizes ease of use, making it a preferred choice for operators.

Better Reliability & Durability

This means the JCB Stage 5-430 engine was tested for over 2 lakh hours in Indian conditions for ultimate reliability and durability. Being tough enough to withstand all challenging applications, the machine makes for the least amount of idle time to maintain productivity. If you’re curious about the new JCB 3DX price, you’ll find that it offers excellent value given its proven performance and robust features.
Heavy-duty Boom & Dipper for robust structure
Advanced fuel & hydraulic filtration system for greater efficiency
Q-breaks protected from dirt & water, reducing maintenance needs

Better Maintenance

With over 750+ outlets and a vast network of trained engineers, JCB ensures that maintenance is hassle-free, quick, and efficient. The availability of genuine parts further enhances the ease of service, keeping your machine running smoothly.
Remote Diagnostics for faster error code identification
Extended fuel filter replacement interval from 500* to 1000* hours
Hydraulic system designed for cleaner oil with a 4000-hour interval
Open Loop Crankcase Ventilation eliminates filter changes, saving on maintenance.
Better uptime with remote diagnostics

Better Fuel Efficiency

The JCB 3DX, powered by the proven Stage 5-430 engine, sets new benchmarks in fuel efficiency with its advanced technology, ensuring significant savings while maintaining peak performance. If you’re considering the JCB 3DX price, its value becomes evident with features like:
Up to 10% Lower Fuel Consumption for cost-effective operations.
Variable Displacement Hydraulic Pump adjusts flow to match load demands.
Multiple Working Modes tailored for task-specific fuel optimization. With these features, the JCB 3DX delivers unmatched efficiency, making every operation more economical.

Better Performance & Productivity

The JCB 3DX Backhoe Loader aims to deliver great strength coupled with operational efficiency to ensure seamless productivity even under the toughest conditions. Equipped with advanced technologies, it provides a smoother operation and enhancement of reliability to push at the limits of achievable performance.
13%* higher torque for greater efficiency
Multiple working modes for task-specific optimization
e-Waste Gate Turbocharger for improved power and fuel efficiency

Better Comfort & Ease Of Use

The JCB 3DX Backhoe Loader redefines operator experience with its advanced safety and comfort features, ensuring seamless operation even in challenging environments. It’s built to keep operators safe, comfortable, and focused.
Standard ROPS & FOPS: Enhanced safety with Roll-Over and Falling Object Protective Structures.
Reduced In-Cab Noise: Provides a quieter, more comfortable workspace for extended use.
User-Centric Design: Prioritizes ease of use, making it a preferred choice for operators.

Better Reliability & Durability

This means the JCB Stage 5-430 engine was tested for over 2 lakh hours in Indian conditions for ultimate reliability and durability. Being tough enough to withstand all challenging applications, the machine makes for the least amount of idle time to maintain productivity. If you’re curious about the new JCB 3DX price, you’ll find that it offers excellent value given its proven performance and robust features.
Heavy-duty Boom & Dipper for robust structure
Advanced fuel & hydraulic filtration system for greater efficiency
Q-breaks protected from dirt & water, reducing maintenance needs

Better Maintenance

With over 750+ outlets and a vast network of trained engineers, JCB ensures that maintenance is hassle-free, quick, and efficient. The availability of genuine parts further enhances the ease of service, keeping your machine running smoothly.
Remote Diagnostics for faster error code identification
Extended fuel filter replacement interval from 500* to 1000* hours
Hydraulic system designed for cleaner oil with a 4000-hour interval
Open Loop Crankcase Ventilation eliminates filter changes, saving on maintenance.
Better uptime with remote diagnostics

Specifications

Product specification of JCB 3DX Backhoe Loader

ENGINE

Model

JCB 430, CRDi Stage 5 Engine
Type

4 cylinder, water cooled, Turbocharged with EGR and aftertreatment system DOC and DPF.
Gross Power

49 HP (37 kW) @ 2050 RPM
Max Torque

170 Nm @ 1320 RPM
Displacement

3.0 L
Battery

12 V
Alternator

130A

TRANSMISSION

Type

The JCB synchroshuttle transmission provides superb drive power in all conditions. It consists of a 4-speed, fully synchromesh, smooth shift gear box with integral torque convertor and electrically operated reversing shuttle.

STEERING

Type

Power track steering rod system provides equal turn steering & quick response with less operating force.
Working Pressure

160 bar

STEERING TURNING CIRCLE

Inner Wheels Braked - Outside Loader Bucket

8640 mm
Inner Wheels Braked - Outside Wheels

6200 mm
Inner Wheels not Braked - Outside Loader Bucket

11600 mm
Inner Wheels not Braked -Outside Wheels

8940 mm

BRAKES

Service

JCB ‘Q’ brakes, hydraulically actuated, dual line, self adjusting (compensated), oil immersed, multi-disc ype on the rear axle, well protected from dirt, water etc. equiring no maintenance.
Parking

Hand operated, disc brakes on rear axle input disc.

TYRES

Front

9 x 16 - 16 PR
Rear

16.9 x 28 - 12 PR (Industrial)

SPEED

Forward- 1st gear

5 km/hr
Reverse- 1st gear

5 km/hr
Forward- 2nd Gear

8 km/hr
Reverse- 2nd Gear

5 km/hr
Forward- 3rd gear

17 km/hr
Reverse- 3rd gear

Not Recommeded
Forward- 4th gear

32.3 km/hr
Reverse- 4th gear

Not recommended

HYDRAULICS

Type

Filtration through suction strainer and return line ‘JCB Filtromatic Filter’.
Maximum Pump Flow

114 L/min @ 2000 RPM
System Pressure

270 bar

AXLES

Rear axle

Drive axle rigidly mounted, incorporates JCB Max-Trac torque proportioning differential, driven by short prop shaft from gear box
Front axle

Steer axle, centrally pivoted, with oscillation angle of 16

SERVICE CAPACITIES

Fuel Tank

128 L
Engine Coolant

16.5 L
Engine Oil

15 L
Hydraulic Tank

NA
Hydraulic System

92 L
Transmission

17.5 L
Rear Axle

20 L

EXCAVATOR PERFORMANCE

Maximum Digging Depth

4770 mm
Reach-Ground Level to Rear Wheel Centre

6720 mm
Reach-Ground Level to Slew Centre

5400 mm
Reach at Full Height to Slew Centre

2900 mm
Side Reach to Centre Line of Machine

6020 mm
Maximum Working Height

5970 mm
Maximum Load Over Height

4180 mm
Bucket Rotation Angle

185°
Bucket Digging force

5959 kgf
Arm Digging force

3257 kgf
Maximum Lift Capacity

1490 kg
Standard Bucket Capacity

0.26 m³
Standard Bucket Width

790 mm

LOADER PERFORMANCE

Dump Height

2740 mm
Load Over Height

3320 mm
Pin Height

3540 mm
Pin Forward Reach

250 mm
Reach at Ground

1520 mm
Maximum Reach at Full Height

1150 mm
Maximum Reach at Full Height - Bucket Dumped

880 mm
Below Ground Level Dig Depth

70 mm
Rollback at Ground

45°
Dump Angle

38°
Shovel Breakout Force

5272 kgf
Loader Arm Breakout Force

5635 kgf
Maximum Payload

1650 kg
Standard Shovel Capacity

1.0 m³

OVERALL DIMENSIONS & WEIGHT

Machine Weight

7200 kg
Overall Length

6000 mm
Wheelbase

2170 mm
Slew Centre to Rear Axle Centre

1320 mm
Minimum Ground Clearance

310 mm
Slew Ground Clearance

510 mm
Height of Cabin

2870 mm
Overall Height

3610 mm
Track width - Rear

1730 mm
Track width - Front

1860 mm
Width Over Bucket

2350 mm

Frequently Asked Question

01. What is the JCB 3DX backhoe loader price in India?

Ans.

The JCB 3DX backhoe loader price in india ranges between ₹ 34-36 lakhs. However, the exact price may vary depending on the location dealer, taxes, and additional features.

02. Where can I buy JCB 3DX backhoe loader in India?

Ans.

You can buy the JCB 3DX backhoe loader from Desi Machines, your trusted platform for construction and heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the backhoe loader you want, or contact us directly for expert assistance and competitive pricing.

03. Does the JCB 3DX backhoe loader come with financing and insurance options?

Ans.

Yes, the JCB 3DX backhoe loader comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Connect with us and our team will help you secure the best deals.

04. What is the mileage of JCB 3DX backhoe loader?

Ans.

The mileage of the JCB 3DX backhoe loader typically ranges between 4 to 6 km per liter under standard working conditions. However, actual fuel consumption depends on factors such as load capacity, terrain, operator efficiency, and maintenance practices.

05. What is the engine power of JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader is powered by a JCB 430, CRDi Stage 5 Engine diesel engine, delivering 49 HP (37 kW) @ 2050 rpm.

06. What is the weight of JCB 3DX backhoe loader?

Ans.

The weight of the JCB 3DX backhoe loader is approximately 7200 kg. The weight may vary slightly depending on specific configurations and attachments.

07. What is the fuel tank capacity of the JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader has a 128 litres diesel fuel tank, providing extended operation time without frequent refueling.

08. What is the lifting capacity of JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader has a lifting capacity of 1490 kg, making it ideal for versatile applications.

09. What is the maximum digging depth of JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader has a maximum digging depth of 4770 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.

10. What is the loader bucket capacity of the JCB 3DX?

Ans.

The loader bucket capacity of the JCB 3DX is 1.0 cubic meters (m³).

11. What is the backhoe bucket capacity of the JCB 3DX?

Ans.

The backhoe bucket capacity of the JCB 3DX is 0.26 cubic meters (m³).

12. What is the warranty period of JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever comes first. The warranty covers defects from faulty materials or workmanship, but terms may vary. For the latest details, check with authorized dealers or visit the official brand website.

13. How many gears are available in JCB 3DX backhoe loader?

Ans.

The JCB 3DX backhoe loader features a 4-speed, fully synchromesh gearbox with a smooth shift and an electrically operated reversing shuttle.

14. Where can I find spare parts for the JCB 3DX backhoe loader?

Ans.

You can find genuine spare parts for the JCB 3DX backhoe loader at authorized JCB dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on backhoe loader spare parts.
