CASE 770 EX VS Escorts Digmax Super Backhoe Loader

CASE 770 EX

Engine

Ashok Leyland 74 HP
Bucket

0.26 m³
Shovel

1.1 m³
Dig. Depth

4440 mm
Dump Height

2730 mm
Weight

7780 Kg

₹ 25-27 Lakhs^*

2WD/4WD

Escorts Digmax Super

Engine

Escorts 74.5 HP
Bucket

0.26 m³
Shovel

1.2 m³
Dig. Depth

4800 mm
Dump Height

3000 mm
Weight

8190 Kg

₹ 35-37 Lakhs^*

2WD/4WD

Add Equipment

Enquire Now

Key Highlights	CASE 770 EX	Escorts Digmax Super

CASE 770 EX

₹ 25-27 Lakhs

Escorts Digmax Super

₹ 35-37 Lakhs

Particulars	CASE 770 EX	Escorts Digmax Super

Compare

Overview

	CASE 770 EX	Escorts Digmax Super
Brand	Case	Escorts Kubota
Type	2WD/4WD	2WD/4WD
Price	₹ 25-27 Lakhs	₹ 35-37 Lakhs
Engine	Ashok Leyland 74 HP	Escorts 74.5 HP
Bucket	0.26 m³	0.26 m³
Shovel	1.1 m³	1.2 m³
Max Digging Depth	4440 mm	4800 mm
Max Dump Height	2730 mm	3000 mm
Weight	7780 Kg	8190 Kg
Quick Overview:	Designed for power and durability, the CASE 770 EX backhoe loader delivers efficient performance with a robust engine and advanced features.	With faster cycle times and excellent fuel economy, the Escorts DIGMAX SUPER backhoe loader guarantees reliable performance in demanding construction environments.

Overview

CASE 770 EX	Escorts Digmax Super
Brand
Case	Escorts Kubota
Type
2WD/4WD	2WD/4WD
Price
₹ 25-27 Lakhs	₹ 35-37 Lakhs
Engine
Ashok Leyland 74 HP	Escorts 74.5 HP
Bucket
0.26 m³	0.26 m³
Shovel
1.1 m³	1.2 m³
Max Digging Depth
4440 mm	4800 mm
Max Dump Height
2730 mm	3000 mm
Weight
7780 Kg	8190 Kg
Quick Overview:
Designed for power and durability, the CASE 770 EX backhoe loader delivers efficient performance with a robust engine and advanced features.	With faster cycle times and excellent fuel economy, the Escorts DIGMAX SUPER backhoe loader guarantees reliable performance in demanding construction environments.

Key Highlights

	CASE 770 EX	Escorts Digmax Super
Engine Make	Ashok Leyland H4C4E7422*W	Escorts E4.346CRS4
Fuel Tank	9.1 L	134 L
Max Torque	340 Nm @ 1400 -1500 RPM	340 Nm @ 1400 RPM
Max Speed	34.1 km/hr	36.0 km/hr
Hydraulic System	107 L	80 L
Max Working Height	5500 mm	6300 mm
Excavator Max Lift Capacity	1464 kg	1554 kg
Loader Load Over Height	3800 mm	4390 mm
Overall Length	5880 mm	6280 mm
Wheel Base	2180 mm	2140 mm
Bucket Digging Force	5206 kgf	6018 kgf
Shovel Breakout Force	5805 kgf	6425 kgf
Warranty	1 Year	1 Year
AC Cabin	Optional	Optional
GPS	Standard	Standard

Key Highlights

CASE 770 EX	Escorts Digmax Super
Engine Make
Ashok Leyland H4C4E7422*W	Escorts E4.346CRS4
Fuel Tank
9.1 L	134 L
Max Torque
340 Nm @ 1400 -1500 RPM	340 Nm @ 1400 RPM
Max Speed
34.1 km/hr	36.0 km/hr
Hydraulic System
107 L	80 L
Max Working Height
5500 mm	6300 mm
Excavator Max Lift Capacity
1464 kg	1554 kg
Loader Load Over Height
3800 mm	4390 mm
Overall Length
5880 mm	6280 mm
Wheel Base
2180 mm	2140 mm
Bucket Digging Force
5206 kgf	6018 kgf
Shovel Breakout Force
5805 kgf	6425 kgf
Warranty
1 Year	1 Year
AC Cabin
Optional	Optional
GPS
Standard	Standard

Specifications

Engine

	CASE 770 EX	Escorts Digmax Super
Model	Ashok Leyland 74 HP	Escorts 74.5 HP
Type	Tier 4B/ CEV BS-IV; 4 Cylinders; Turbocharged Intercooled; Electronic; Common Rail Direct Injection	Proven; powerful and fuel efficient; water cooled tubocharged diesel engine. CEV - IV emission noms
Gross Power	74 HP (54.4 kW) @ 2200 RPM	74.5 HP (55 kW) @ 2200 RPM
Max Torque	340 Nm @ 1400 -1500 RPM	340 Nm @ 1400 RPM
Displacement	3.84 L	NA
Battery	12V / 110 Ah	12V 150 Ah
Alternator	NA	90A

Transmission

	CASE 770 EX	Escorts Digmax Super
Type	CARRARO 2WD; 4F-4R Power Shuttle Synchromesh Transmission	4F + 4R speeds; Syncro shift reversing shuttle

Steering

	CASE 770 EX	Escorts Digmax Super
Type	Power Steering	Hydrostatic power steering in front wheel.
Working Pressure	140 bar	120 bar

Steering Turning Circle

	CASE 770 EX	Escorts Digmax Super
Inner Wheels Braked - Outside Loader Bucket	9200 mm	NA
Inner Wheels Braked - Outside Wheels	NA	NA
Inner Wheels not Braked - Outside Loader Bucket	11100 mm	NA
Inner Wheels not Braked - Outside Wheels	NA	NA

Brakes

	CASE 770 EX	Escorts Digmax Super
Service	Hydraulic foot operated; 2 disc per side	Hydraulically actuated dual line ; self adjusting oil immersed; multi disc type on rear axle.
Parking	Mechanically actuated caliper type brake pack on Rear axle input shaft	Hand operated caliper disc brakes .

Tyres

	CASE 770 EX	Escorts Digmax Super
Front	9 x 16 - 16 PR	9.00 x 16 - 16 PR
Rear	16.9 x 28 - 12 PR	16.9 x 28 - 12 PR ( Industrial )

Speed

	CASE 770 EX	Escorts Digmax Super
Forward- 1st gear	5.8 km/hr	5.3 km/hr
Reverse- 1st gear	6.8 km/hr	4.6 km/hr
Forward- 2nd gear	9.3 Km.h	8.5 km/hr
Reverse- 2nd gear	10.8 km/hr	7.0 km/hr
Forward- 3rd gear	19.5 km/hr	18.2 km/hr
Reverse- 3rd gear	22.1 km/hr	Not recommended
Forward- 4th gear	34.1 km/hr	36.0 km/hr
Reverse- 4th gear	Not recommended	Not recommended

Hydraulics

	CASE 770 EX	Escorts Digmax Super
Type	Open Center Load Sensing; Twin Gear Pump	Tandem Gear Pump; Fixed flow open center two pump unloading energy efficient hydraulic system.
Maximum Pump Flow	126 L/min	116 L/min @ 2000 RPM
System Pressure	195 bar	225 bar

Axles

	CASE 770 EX	Escorts Digmax Super
Rear Axle	CARRARO 28.32M	Rear drive axle; rigidly mounted to chassis
Front Axle	CNH PS1300 (2WD)	Front steer axle with 16 oscillation for maximum ground contact in an undulated condition.

Service Capacities

	CASE 770 EX	Escorts Digmax Super
Fuel Tank	9.1 L	134 L
Engine Coolant	20 L	15 L
Engine Oil	9.1 L	11.5 L
Hydraulic Tank	80 L	NA
Hydraulic System	107 L	80 L
Transmission	18 L	16.5 L
Rear Axle	17.1 L	17.1 L

Excavator Performance

	CASE 770 EX	Escorts Digmax Super
Maximum Digging Depth	4440 mm	4800 mm
Reach-Ground Level to Rear Wheel Centre	6950 mm	6970 mm
Reach-Ground Level to Slew Centre	5625 mm	5650 mm
Reach-Ground Level to Slew Centre	5625 mm	5650 mm
Side Reach to Centre Line of Machine	NA	6000 mm
Maximum Working Height	5500 mm	6300 mm
Maximum Load Over Height	3800 mm	4390 mm
Bucket Rotation Angle	204°	187°
Bucket Digging force	5206 kgf	6018 kgf
Arm Digging force	3031 kgf	3250 kgf
Maximum Lift Capacity	1464 kg	1554 kg
Standard Bucket Capacity	0.26 m³	0.26 m³
Standard Bucket Width	NA	NA

Loader Performance

	CASE 770 EX	Escorts Digmax Super
Dump Height	2730 mm	3000 mm
Load Over Height	3300 mm	3510 mm
Pin Height	3600 mm	3700 mm
Pin Forward Reach	240 mm	430 mm
Reach At Ground	1980 mm	1570 mm
Maximum Reach at Full Height	1190 mm	1220 mm
Max Reach Full Height Dumped	760 mm	850 mm
Below Ground Level Dig Depth	110 mm	130 mm
Rollback at Ground	33°	45°
Dump Angle	45°	45°
Shovel Breakout Force	5805 kgf	6425 kgf
Loader Arm Breakout Force	4750 kgf	5777 kgf
Maximum Payload	1925 kg	1980 kg

Overall Dimensions And Weight

	CASE 770 EX	Escorts Digmax Super
Machine Weight	7780-7840 kg	8190 kg
Overall Length	5880 mm	6280 mm
Wheelbase	2180 mm	2140 mm
Slew Centre to Rear Axle Centre	NA	1380 mm
Minimum Ground Clearance	380 mm	350 mm
Slew Ground Clearance	NA	590 mm
Height of Cabin	2800 mm	2880 mm
Overall Height	3850 mm	3780 mm
Track Width-Rear	1700 mm	1750 mm
Track Width-Front	1880 mm	1870 mm
Width Over Bucket	2800 mm	2380 mm

Specifications

Engine

CASE 770 EX	Escorts Digmax Super
Model
Ashok Leyland 74 HP	Escorts 74.5 HP
Type
Tier 4B/ CEV BS-IV; 4 Cylinders; Turbocharged Intercooled; Electronic; Common Rail Direct Injection	Proven; powerful and fuel efficient; water cooled tubocharged diesel engine. CEV - IV emission noms
Gross Power
74 HP (54.4 kW) @ 2200 RPM	74.5 HP (55 kW) @ 2200 RPM
Max Torque
340 Nm @ 1400 -1500 RPM	340 Nm @ 1400 RPM
Displacement
3.84 L	NA
Battery
12V / 110 Ah	12V 150 Ah
Alternator
NA	90A

Transmission

CASE 770 EX	Escorts Digmax Super
Type
CARRARO 2WD; 4F-4R Power Shuttle Synchromesh Transmission	4F + 4R speeds; Syncro shift reversing shuttle

Steering

CASE 770 EX	Escorts Digmax Super
Type
Power Steering	Hydrostatic power steering in front wheel.
Working Pressure
140 bar	120 bar

Steering Turning Circle

CASE 770 EX	Escorts Digmax Super
Inner Wheels Braked - Outside Loader Bucket
9200 mm	NA
Inner Wheels Braked - Outside Wheels
NA	NA
Inner Wheels not Braked - Outside Loader Bucket
11100 mm	NA
Inner Wheels not Braked - Outside Wheels
NA	NA

Brakes

CASE 770 EX	Escorts Digmax Super
Service
Hydraulic foot operated; 2 disc per side	Hydraulically actuated dual line ; self adjusting oil immersed; multi disc type on rear axle.
Parking
Mechanically actuated caliper type brake pack on Rear axle input shaft	Hand operated caliper disc brakes .

Tyres

CASE 770 EX	Escorts Digmax Super
Front
9 x 16 - 16 PR	9.00 x 16 - 16 PR
Rear
16.9 x 28 - 12 PR	16.9 x 28 - 12 PR ( Industrial )

Speed

CASE 770 EX	Escorts Digmax Super
Forward- 1st gear
5.8 km/hr	5.3 km/hr
Reverse- 1st gear
6.8 km/hr	4.6 km/hr
Forward- 2nd gear
9.3 Km.h	8.5 km/hr
Reverse- 2nd gear
10.8 km/hr	7.0 km/hr
Forward- 3rd gear
19.5 km/hr	18.2 km/hr
Reverse- 3rd gear
22.1 km/hr	Not recommended
Forward- 4th gear
34.1 km/hr	36.0 km/hr
Reverse- 4th gear
Not recommended	Not recommended

Hydraulics

CASE 770 EX	Escorts Digmax Super
Type
Open Center Load Sensing; Twin Gear Pump	Tandem Gear Pump; Fixed flow open center two pump unloading energy efficient hydraulic system.
Maximum Pump Flow
126 L/min	116 L/min @ 2000 RPM
System Pressure
195 bar	225 bar

Axles

CASE 770 EX	Escorts Digmax Super
Rear Axle
CARRARO 28.32M	Rear drive axle; rigidly mounted to chassis
Front Axle
CNH PS1300 (2WD)	Front steer axle with 16 oscillation for maximum ground contact in an undulated condition.

Service Capacities

CASE 770 EX	Escorts Digmax Super
Fuel Tank
9.1 L	134 L
Engine Coolant
20 L	15 L
Engine Oil
9.1 L	11.5 L
Hydraulic Tank
80 L	NA
Hydraulic System
107 L	80 L
Transmission
18 L	16.5 L
Rear Axle
17.1 L	17.1 L

Excavator Performance

CASE 770 EX	Escorts Digmax Super
Maximum Digging Depth
4440 mm	4800 mm
Reach-Ground Level to Rear Wheel Centre
6950 mm	6970 mm
Reach-Ground Level to Slew Centre
5625 mm	5650 mm
Reach-Ground Level to Slew Centre
5625 mm	5650 mm
Side Reach to Centre Line of Machine
NA	6000 mm
Maximum Working Height
5500 mm	6300 mm
Maximum Load Over Height
3800 mm	4390 mm
Bucket Rotation Angle
204°	187°
Bucket Digging force
5206 kgf	6018 kgf
Arm Digging force
3031 kgf	3250 kgf
Maximum Lift Capacity
1464 kg	1554 kg
Standard Bucket Capacity
0.26 m³	0.26 m³
Standard Bucket Width
NA	NA

Loader Performance

CASE 770 EX	Escorts Digmax Super
Dump Height
2730 mm	3000 mm
Load Over Height
3300 mm	3510 mm
Pin Height
3600 mm	3700 mm
Pin Forward Reach
240 mm	430 mm
Reach At Ground
1980 mm	1570 mm
Maximum Reach at Full Height
1190 mm	1220 mm
Max Reach Full Height Dumped
760 mm	850 mm
Below Ground Level Dig Depth
110 mm	130 mm
Rollback at Ground
33°	45°
Dump Angle
45°	45°
Shovel Breakout Force
5805 kgf	6425 kgf
Loader Arm Breakout Force
4750 kgf	5777 kgf
Maximum Payload
1925 kg	1980 kg

Overall Dimensions And Weight

CASE 770 EX	Escorts Digmax Super
Machine Weight
7780-7840 kg	8190 kg
Overall Length
5880 mm	6280 mm
Wheelbase
2180 mm	2140 mm
Slew Centre to Rear Axle Centre
NA	1380 mm
Minimum Ground Clearance
380 mm	350 mm
Slew Ground Clearance
NA	590 mm
Height of Cabin
2800 mm	2880 mm
Overall Height
3850 mm	3780 mm
Track Width-Rear
1700 mm	1750 mm
Track Width-Front
1880 mm	1870 mm
Width Over Bucket
2800 mm	2380 mm

Frequently Asked Question

1. How does the comparison process work?

Ans.

Our comparison process is designed with simplicity and precision. You have to select the equipment you are interested in and choose models to view specifications, performance metrics, and other features side-by-side.

2. Can I connect with dealers through Desi Machines?

Ans.

Yes, you can. Once you find out your desired product, you can submit the lead form to connect with the local dealers. The local dealers can help you with pricing, availability, and further inquiries.

3. Do you offer financing or insurance options?

Ans.

We help buyers choose from industry-specific financing and insurance providers that are tailor-made for heavy machinery. These ensure that you get coverage and financing options for the needs of construction and engineering equipment.

4. How does Desi Machines earn revenue?

Ans.

Desi Machines earns revenue from selling leads to sellers, financial companies, and insurance providers. It does not charge any single rupee to the buyer.

5. Is Desi Machines suitable for small businesses?

Ans.

Absolutely! It is suitable for all sizes of businesses, from small contractors to large construction firms. We showcase all products that help everyone find their product suitable for their scope of work or budget.

6. Can I compare excavators from different brands?

Ans.

Yes, you can compare excavators from different/same brands. Our comparison tool allows you to select excavators from various brands and see detailed specifications side by side.

7. What types of excavators are there?

Ans.

There are various types of excavators, including standard crawler excavators, wheeled excavators, mini (compact) excavators, and long-reach excavators. Each type is designed for specific applications or work environments.

8. What is an excavator used for?

Ans.

Excavators are heavy construction equipment used for digging, grading, lifting, and moving materials. They are employed in most constructions, demolitions, mining operations, and landscaped works.

9. How do excavators work?

Ans.

Excavators work through the hydraulic system. Its rotating upper part, or the house, has the engine and controls, with a boom, stick, and bucket to scoop up materials during digging or for lifting purposes. The operator can manipulate these to dig trenches, move huge loads, and many others.

10. What is the difference between an excavator and a backhoe?

Ans.

Their main difference is based on design and purpose. An excavator is big, with the rotating upper structure, and is especially used in digging and lifting. A backhoe is smaller, has a fixed cab, and is more flexible for smaller tasks with digging and loading in smaller confinement areas.

Login

Categories

Contact Us

Contact Info

CASE 770 EX VS Escorts Digmax Super Backhoe Loader

CASE 770 EX

Engine

Ashok Leyland 74 HP

Bucket

0.26 m³

Shovel

1.1 m³

Dig. Depth

4440 mm

Dump Height

2730 mm

Weight

7780 Kg

₹ 25-27 Lakhs*

Escorts Digmax Super

Engine

Escorts 74.5 HP

Bucket

0.26 m³

Shovel

1.2 m³

Dig. Depth

4800 mm

Dump Height

3000 mm

Weight

8190 Kg

₹ 35-37 Lakhs*

CASE 770 EX

₹ 25-27 Lakhs

Escorts Digmax Super

₹ 35-37 Lakhs

Compare

Overview

Overview

Key Highlights

Key Highlights

Specifications

Engine

Transmission

Steering

Steering Turning Circle

Brakes

Tyres

Speed

Hydraulics

Axles

Service Capacities

Excavator Performance

Loader Performance

Overall Dimensions And Weight

Specifications

Engine

Transmission

Steering

Steering Turning Circle

Brakes

Tyres

Speed

Hydraulics

Axles

Service Capacities

Excavator Performance

Loader Performance

Overall Dimensions And Weight

Kindly fill out the below form. Our representative will get in touch with you

Popular Comparisons with JCB 30 Plus

Related Blogs

Frequently Asked Question

1. How does the comparison process work?

2. Can I connect with dealers through Desi Machines?

3. Do you offer financing or insurance options?

4. How does Desi Machines earn revenue?

5. Is Desi Machines suitable for small businesses?

6. Can I compare excavators from different brands?

₹ 25-27 Lakhs^*

₹ 35-37 Lakhs^*
