The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | XCMG XE520C | Liugong 950E |
|---|
| Particulars | XCMG XE520C | Liugong 950E |
|---|
The Liugong 950E and XCMG XE520C are both heavy-duty excavators suitable for large-scale earthmoving and mining operations. They offer similar engine power and capabilities but differ in features like in-cabin technology, fuel tank capacity, and hydraulic systems.
Selecting between the Liugong 950E and XCMG XE520C should be based on the specific needs of your operation. If fuel capacity and hydraulic system operation time are critical, the XCMG XE520C might be more suitable. However, for those who prioritize in-built navigation technology and slightly better digging reach, the Liugong 950E would be a better choice.
| Brand | XCMG | LiuGong |
|---|---|---|
| Type | Large (25-50 Ton) | Large (25-50 Ton) |
| Operating Cost | ₹ 1.75-1.8 Crore | Price Available Soon |
| Price | ₹ 1.75-1.8 Crore | Price Available Soon |
| Weight | 50000 Kg | 46500 Kg |
| Bucket | 2.3 - 3.1 m³ | 2.6 - 3.2 m³ |
| Max Digging Depth | 6530 mm | 6521 mm |
| Engine | Cummins 380.6 HP | Cummins 375 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 6670 mm | 6500 mm |
| Quick Overview: | XCMG XE520C large excavator ensures heavy-duty performance for demanding large-scale mining and engineering. |
Exceptional performance-driven Liugong 950E large excavator is reliable for large-scale earthmoving and mining. |
| Agency review | Get the best price for the XCMG XE520C Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Liugong 950E Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The Liugong 950E and XCMG XE520C are both heavy-duty excavators suitable for large-scale earthmoving and mining operations. They offer similar engine power and capabilities but differ in features like in-cabin technology, fuel tank capacity, and hydraulic systems.
Selecting between the Liugong 950E and XCMG XE520C should be based on the specific needs of your operation. If fuel capacity and hydraulic system operation time are critical, the XCMG XE520C might be more suitable. However, for those who prioritize in-built navigation technology and slightly better digging reach, the Liugong 950E would be a better choice.
| XCMG XE520C | Liugong 950E |
|---|---|
| Brand | |
| XCMG | LiuGong |
| Type | |
| Large (25-50 Ton) | Large (25-50 Ton) |
| Price | |
| ₹ 1.75-1.8 Crore | Price Available Soon |
| Weight | |
| 50000 Kg | 46500 Kg |
| Bucket | |
| 2.3 - 3.1 m³ | 2.6 - 3.2 m³ |
| Max Digging Depth | |
| 6530 mm | 6521 mm |
| Engine | |
| Cummins 380.6 HP | Cummins 375 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 6670 mm | 6500 mm |
| Quick Overview: | |
XCMG XE520C large excavator ensures heavy-duty performance for demanding large-scale mining and engineering. |
Exceptional performance-driven Liugong 950E large excavator is reliable for large-scale earthmoving and mining. |
| XCMG XE520C | Liugong 950E | |
| Engine Make | Cummins , QSM 11 | Cummins QSM 11 |
| Fuel Tank | 725 L | 620 L |
| Engine Displacment | 11 L | 10.8 L |
| Under Carriage | 5353 mm | 5266 mm |
| Hydraulic System | 560 L | 520 L |
| Arm | 2400 mm | 2550m |
| Max Digging Reach | NA | 10625 mm |
| Fuel Consumption | NA | NA |
| Overall Width | 3582 mm | 3340 mm |
| Overall Length | 11830 mm | 11515 mm |
| Bucket Digging Force | NA | 265 kN |
| Tailswing Radius | 3800 mm | 3640 mm |
| Track Shoe Width | 600 mm | 600 mm |
| AC Cabin | Standard | Standard |
| GPS | Not Available | Standard |
| XCMG XE520C | Liugong 950E |
|---|---|
| Engine Make | |
| Cummins , QSM 11 | Cummins QSM 11 |
| Fuel Tank | |
| 725 L | 620 L |
| Engine Displacment | |
| 11 L | 10.8 L |
| Under Carriage | |
| 5353 mm | 5266 mm |
| Hydraulic System | |
| 560 L | 520 L |
| Arm | |
| 2400 mm | 2550m |
| Max Digging Reach | |
| NA | 10625 mm |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 3582 mm | 3340 mm |
| Overall Length | |
| 11830 mm | 11515 mm |
| Bucket Digging Force | |
| NA | 265 kN |
| Tailswing Radius | |
| 3800 mm | 3640 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Not Available | Standard |
| 3671 | 3586 | |
| Model | Cummins 380.6 HP | Cummins 375 HP |
| Fuel | Diesel | Diesel |
| Type | 6 Cylinder. Turbocharged , Air to air intercooler | 6 Cylinders , Turbocharged CAC |
| Rated Engine Power | 380.6 HP (283.8 kW) @ 2000 rpm | 375 HP (279 kW) @ 2100 rpm |
| Maximum Torque | 1898 Nm @ 1300 rpm | 1898 Nm @ 1400 rpm |
| Piston Displacement | 11 L | 10.8 L |
| Alternator | NA | NA |
| Battery | 12 V x 2 | NA |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | 2 | 2 |
| No of bottom rollers | 9 | 9 |
| Track Shoes (Each Side) | 49 | 51 |
| Track Guard | NA | NA |
| Track Shoe width | 600 mm | 600 mm |
| Ground bearing pressure | NA | 82.2 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 35° | 70% (35 °) |
| Travel Speed-Low | NA | 3.3 Km/h |
| Travel Speed-High | 5.4 Km/h | 5.5 Km/h |
| Max Tracking Force | 338 kN | 386 kN |
| XCMG XE520C | Liugong 950E | |
| Hydraulic pump | 2 Variable Displacement Piston Pumps | Two Varibale Displacement Piston Pump |
| Maximum Flow | 2 x 360 L/min | 2 x 380 L/min |
| Pilot Pump | 1 Gear Pump | Gear Pump |
| Implement Circuit | 34.3 MPa / 37 MPa | 32.3 MPa |
| Swing Circuit | 31 MPa | 28 MPa |
| Travel circuit | 34.3 MPa | 32.3 MPa |
| Pilot circuit | 3.9 MPa | 3.9 MPa |
| XCMG XE520C | Liugong 950E | |
| Travel | NA | Axial Piston Motor |
| Swing | NA | Axial Piston Motor |
| XCMG XE520C | Liugong 950E | |
| Fuel tank | 725 L | 620 L |
| Engine Coolant | 50 L | 37.8 L |
| Engine oil | 40 L | 50 L |
| Hydraulic system | 560 L | 520 L |
| Hydraulic tank | 430 L | 290 L |
| XCMG XE520C | Liugong 950E | |
| Operating Weight | 50000 Kg | 46500 Kg |
| XCMG XE520C | Liugong 950E | |
| Boom length | 6670 mm | 6500 mm |
| Arm length | 2400 mm | 2550m |
| Max Digging Reach | NA | 10625 mm |
| Max Digging Reach on ground | NA | 10388 mm |
| Max digging depth | 6530 mm | 6521 mm |
| Max digging height | 9480 mm | 9977 mm |
| Max Dump Height | 6800 mm | 7038 mm |
| Max vertical wallcut depth | 3840 mm | 5204 mm |
| Min swing radius | 4550 mm | 4645 mm |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | NA | 265 kN |
| Arm Digging Force | NA | 255 kN |
| Swing Speed | NA | 8.5 rpm |
| XCMG XE520C | Liugong 950E | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| XCMG XE520C | Liugong 950E | |
| Bucket Capacity | 2.3 - 3.1 m³ | 2.6 - 3.2 m³ |
| XCMG XE520C | Liugong 950E | |
| Overall Length | 11830 mm | 11515 mm |
| Overall width | 3582 mm | 3340 mm |
| Overall Height | 3770 mm | 3810 mm |
| Overall Height of Cab | NA | 3550 mm |
| Upper Width | 3095 mm | 3170 mm |
| Track Lengh on Ground | 4292 mm | 4257 mm |
| Undercarriage overall length | 5353 mm | 5266 mm |
| Tailswing radius | 3800 mm | 3640 mm |
| Min Ground clearance | 519 mm | 532 mm |
| Track gauge | 2750 mm | 2740 mm |
| Width over tracks | 3582 mm | NA |
| Track Height | 1198 mm | NA |
| Counterweight Clearance | 1324 mm | 1324 mm |
| Track Shoe Width | 600 mm | 600 mm |
| XCMG XE520C | Liugong 950E |
|---|---|
| Model | |
| Cummins 380.6 HP | Cummins 375 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 6 Cylinder. Turbocharged , Air to air intercooler | 6 Cylinders , Turbocharged CAC |
| Rated Engine Power | |
| 380.6 HP (283.8 kW) @ 2000 rpm | 375 HP (279 kW) @ 2100 rpm |
| Maximum Torque | |
| 1898 Nm @ 1300 rpm | 1898 Nm @ 1400 rpm |
| Piston Displacement | |
| 11 L | 10.8 L |
| Alternator | |
| NA | NA |
| Battery | |
| 12 V x 2 | NA |
| Starting Motor | |
| NA | NA |
| XCMG XE520C | Liugong 950E |
|---|---|
| No of Top rollers | |
| 2 | 2 |
| No of bottom rollers | |
| 9 | 9 |
| Track Shoes (Each Side) | |
| 49 | 51 |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 600 mm | 600 mm |
| Ground bearing pressure | |
| NA | 82.2 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 35° | 70% (35 °) |
| Travel Speed-Low | |
| NA | 3.3 Km/h |
| Travel Speed-High | |
| 5.4 Km/h | 5.5 Km/h |
| Max Tracking Force | |
| 338 kN | 386 kN |
| XCMG XE520C | Liugong 950E |
|---|---|
| Hydraulic pump | |
| 2 Variable Displacement Piston Pumps | Two Varibale Displacement Piston Pump |
| Maximum Flow | |
| 2 x 360 L/min | 2 x 380 L/min |
| Pilot Pump | |
| 1 Gear Pump | Gear Pump |
| Implement Circuit | |
| 34.3 MPa / 37 MPa | 32.3 MPa |
| Swing Circuit | |
| 31 MPa | 28 MPa |
| Travel circuit | |
| 34.3 MPa | 32.3 MPa |
| Pilot circuit | |
| 3.9 MPa | 3.9 MPa |
| XCMG XE520C | Liugong 950E |
|---|---|
| Fuel tank | |
| 725 L | 620 L |
| Engine Coolant | |
| 50 L | 37.8 L |
| Engine oil | |
| 40 L | 50 L |
| Hydraulic system | |
| 560 L | 520 L |
| Hydraulic tank | |
| 430 L | 290 L |
| XCMG XE520C | Liugong 950E |
|---|---|
| Operating Weight | |
| 50000 Kg | 46500 Kg |
| XCMG XE520C | Liugong 950E |
|---|---|
| Boom length | |
| 6670 mm | 6500 mm |
| Arm length | |
| 2400 mm | 2550m |
| Max Digging Reach | |
| NA | 10625 mm |
| Max Digging Reach on ground | |
| NA | 10388 mm |
| Max digging depth | |
| 6530 mm | 6521 mm |
| Max digging height | |
| 9480 mm | 9977 mm |
| Max Dump Height | |
| 6800 mm | 7038 mm |
| Max vertical wallcut depth | |
| 3840 mm | 5204 mm |
| Min swing radius | |
| 4550 mm | 4645 mm |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| NA | 265 kN |
| Arm Digging Force | |
| NA | 255 kN |
| Swing Speed | |
| NA | 8.5 rpm |
| XCMG XE520C | Liugong 950E |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| XCMG XE520C | Liugong 950E |
|---|---|
| Bucket Capacity | |
| 2.3 - 3.1 m³ | 2.6 - 3.2 m³ |
| XCMG XE520C | Liugong 950E |
|---|---|
| Overall Length | |
| 11830 mm | 11515 mm |
| Overall width | |
| 3582 mm | 3340 mm |
| Overall Height | |
| 3770 mm | 3810 mm |
| Overall Height of Cab | |
| NA | 3550 mm |
| Upper Width | |
| 3095 mm | 3170 mm |
| Track Lengh on Ground | |
| 4292 mm | 4257 mm |
| Undercarriage overall length | |
| 5353 mm | 5266 mm |
| Tailswing radius | |
| 3800 mm | 3640 mm |
| Min Ground clearance | |
| 519 mm | 532 mm |
| Track gauge | |
| 2750 mm | 2740 mm |
| Width over tracks | |
| 3582 mm | NA |
| Track Height | |
| 1198 mm | NA |
| Counterweight Clearence | |
| 1324 mm | 1324 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
