Ammann ARS 110.2 Compactor

The 4-bearing vibratory system offers the highest centrifugal force, uniform vibration, fewer passes, and increased drum and component life.

A frequency range of 32/35 Hz and an amplitude of 0.9/1.85 mm ensure efficient compaction for different soil conditions.

Centrifugal force reaches up to 275 kN, providing reliable compaction for highways, airports, embankments, and infrastructure projects.

A static linear load of 28.6–29.6 kg/cm achieves effective soil density, reducing overall passes and ensuring consistent productivity.

The Ashok Leyland H4C510122 engine, compliant with CEV Stage V, delivers 74 kW (101 HP) and 450 Nm torque at 1400–1500 rpm.

Water-cooled engine features DOC, SCR, ASC, and DPF after-treatment, ensuring cleaner emissions, efficient performance, and a long service life.

The closed loop axial piston drive system along with hydrostatic vibration offers smooth operation, reliability, and consistent power output.

The drum drive (HX version) improves climbing ability by up to 45, ensuring strong performance on steep slopes and challenging terrains.

The operator platform features ROPS-FOPS and is isolated on four rubber mounts, which reduces vibration transfer and improves operator comfort.

An ergonomic dashboard includes a digital cluster, vandalism protection cover, and a single drive lever to enhance operational efficiency and safety.

The standard seat has a sliding function, a seat belt, and handrails, which provide secure and fatigue-free working conditions during long compaction operations.

Excellent visibility (1x1m), plus higher safety and dual adjustable scrapers, ensure safe and efficient operation at all job sites.

The standard 12PR rugged tyres offer extended life, better traction, and adaptability in rocky, wet areas with high plying rates.

A drum shell thickness of 25 mm ensures durability, a long service life, and reduced wear in demanding construction applications.

Four shock mounts isolate the operator platform, extending the machine's life by reducing vibrations transmitted to structural components and the operator seat.

The optimized hydraulic oil tank and sturdy frame design ensure reliability, long-term durability, and low maintenance needs.

Ground-level access to all service and maintenance points speeds up servicing, reduces downtime, and increases machine availability.

Dual scrapers on the drum are standard and prevent soil build-up, ensuring consistent compaction results and lowering maintenance needs.

The Ammann telematics option allows for monitoring of compaction performance, machine health, and service scheduling for increased efficiency.

Available features include a master electrical disconnect switch, a compaction meter, and a warning beacon to improve operational safety and serviceability.

Designed for national and state highways, city roads, municipal projects, and smart city developments that need efficient compaction solutions.

It is widely used for railway embankments, airport runways, and mining haul roads, ensuring high performance in heavy-duty infrastructure projects.

It's ideal for dam embankments, port distribution hubs, and internal roads in power and steel plants, delivering versatile performance.

Options like the PD shell kit, traction optimizer, and working speed increase kit enhance usability for various compaction applications.
