The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | ACE ASD 115 | Volvo SD110 |
|---|
| Particulars | ACE ASD 115 | Volvo SD110 |
|---|
The Volvo SD110 and ACE ASD 115 are both single drum vibratory rollers designed for soil compaction in road construction and infrastructure projects. While the Volvo SD110 offers dual centrifugal force levels and a high gradeability, the ACE ASD 115 excels with a higher engine power and greater centrifugal force. The choice between the two may hinge on specific project requirements and operator preferences.
Considering performance and operational efficiency, the ACE ASD 115 may be the better option for projects requiring higher power and gradeability. However, for projects that value system monitoring and potentially better manoeuvrability, the Volvo SD110 could be more suitable.
| Brand | ACE Compactor | Volvo Compactor |
|---|---|---|
| Type | Soil | Soil |
| Ex-Showroom Price | ₹ 32-34 Lakhs | ₹ 38-40 Lakhs |
| Weight | 11000 kg | 11150 kg |
| Drum Width | 2130 mm | 2134 mm |
| Engine | M&M 112 HP | VECV 99.2 HP |
| Static Linear Load | 30.52 kg/cm | 29.3 kg/cm |
| Centrifugal Force (High/Low) | 243/130 kN | 243/130 kN |
| Travel Speed | 0-12 km/hr | 0-12 km/hr |
| Quick Overview: | The ACE ASD 115-STD Vibratory Roller is a powerful single drum soil compactor made for road construction, highways, and large infrastructure projects. It handles loose soil, asphalt, and ground stabilization, ensuring uniform density and durability on every project. With ACE’s experience in manufacturing, the ASD 115-STD vibratory roller combines smart technology, high productivity, and low maintenance. ACE also provides soil compactors in the 10 to 12 ton range and tandem compactors from 3.5 to 9 tons, making it a trusted Indian brand known for efficient, cost-effective, and performance-driven road rollers across various applications. |
The Volvo SD110 Soil Compactor is a top-quality single-drum road roller designed for maximum compaction in road construction, site preparation, and large infrastructure projects. This powerful vibratory road roller offers dual centrifugal force levels of 165 kN and 245 kN, along with a 30 Hz vibration frequency, ensuring consistent density across various soils and aggregates. With an operating weight close to 11,125 kg and a 2,134 mm drum width, the SD110 road roller compactor combines strength and precision. Its 99 kW engine, hydrostatic drive, and 52% gradeability guarantee high performance even on slopes. Built for durability and easy service, this robust road roller ensures productivity and longevity. |
The Volvo SD110 and ACE ASD 115 are both single drum vibratory rollers designed for soil compaction in road construction and infrastructure projects. While the Volvo SD110 offers dual centrifugal force levels and a high gradeability, the ACE ASD 115 excels with a higher engine power and greater centrifugal force. The choice between the two may hinge on specific project requirements and operator preferences.
Considering performance and operational efficiency, the ACE ASD 115 may be the better option for projects requiring higher power and gradeability. However, for projects that value system monitoring and potentially better manoeuvrability, the Volvo SD110 could be more suitable.
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Brand | |
| ACE Compactor | Volvo Compactor |
| Type | |
| Soil | Soil |
| Ex-Showroom Price | |
| ₹ 32-34 Lakhs | ₹ 38-40 Lakhs |
| Weight | |
| 11000 kg | 11150 kg |
| Drum Width | |
| 2130 mm | 2134 mm |
| Engine | |
| M&M 112 HP | VECV 99.2 HP |
| Static Linear Load | |
| 30.52 kg/cm | 29.3 kg/cm |
| Centrifugal Force (High/Low) | |
| 254/176 kN | 243/130 kN |
| Travel Speed | |
| 0–29 km/hr | 0-12 km/hr |
| Quick Overview: | |
The ACE ASD 115-STD Vibratory Roller is a powerful single drum soil compactor made for road construction, highways, and large infrastructure projects. It handles loose soil, asphalt, and ground stabilization, ensuring uniform density and durability on every project. With ACE’s experience in manufacturing, the ASD 115-STD vibratory roller combines smart technology, high productivity, and low maintenance. ACE also provides soil compactors in the 10 to 12 ton range and tandem compactors from 3.5 to 9 tons, making it a trusted Indian brand known for efficient, cost-effective, and performance-driven road rollers across various applications. |
The Volvo SD110 Soil Compactor is a top-quality single-drum road roller designed for maximum compaction in road construction, site preparation, and large infrastructure projects. This powerful vibratory road roller offers dual centrifugal force levels of 165 kN and 245 kN, along with a 30 Hz vibration frequency, ensuring consistent density across various soils and aggregates. With an operating weight close to 11,125 kg and a 2,134 mm drum width, the SD110 road roller compactor combines strength and precision. Its 99 kW engine, hydrostatic drive, and 52% gradeability guarantee high performance even on slopes. Built for durability and easy service, this robust road roller ensures productivity and longevity. |
| ACE ASD 115 | Volvo SD110 | |
| Engine Make | M&M MCVCN C35TL112CE5 | VECV E494 TCI-HPCR |
| Fuel Tank | 315 L | 196 L |
| Hydraulic Tank | 80 L | 70 L |
| Vibration Frequency (Hi/Low) | 40/33 Hz | 0–30 Hz |
| Nominal Amplitude (High/Low) | 1.85/0.8 mm | 1.9/1.0 mm |
| Max. Gradeability | 45% | 26 % |
| Steering Angle | ±37° | ±40° |
| Turning Radius, Outside | 6050 mm | NA |
| Wheelbase | 2980 mm | 3345 mm |
| Tyre Size | 12 PR x 23.1 x 26 | 23.1 x 26 VRC 18-R3 8PR TL |
| Overall Length | 5400 mm | 5875 mm |
| Overall Width | 2285 mm | 2340 mm |
| Overall Height | 3100 mm | 3100 mm |
| Telematics | Optional | Standard |
| Warranty | 1 Year | 1 Yr. / 2000 hr. |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Engine Make | |
| M&M MCVCN C35TL112CE5 | VECV E494 TCI-HPCR |
| Fuel Tank | |
| 315 L | 196 L |
| Hydraulic Tank | |
| 80 L | 70 L |
| Vibration Frequency (Hi/Low) | |
| 40/33 Hz | 0–30 Hz |
| Nominal Amplitude (High/Low) | |
| 1.85/0.8 mm | 1.9/1.0 mm |
| Max. Gradeability | |
| 45% | 26 % |
| Steering Angle | |
| ±37° | ±40° |
| Turning Radius, Outside | |
| 6050 mm | NA |
| Wheelbase | |
| 2980 mm | 3345 mm |
| Tyre Size | |
| 12 PR x 23.1 x 26 | 23.1 x 26 VRC 18-R3 8PR TL |
| Overall Length | |
| 5400 mm | 5875 mm |
| Overall Width | |
| 2285 mm | 2340 mm |
| Overall Height | |
| 3100 mm | 3100 mm |
| Telematics | |
| Optional | Standard |
| Warranty | |
| 1 Year | 1 Yr. / 2000 hr. |
| ACE ASD 115 | Volvo SD110 | |
| Engine Make | M&M MCVCN C35TL112CE5 | VECV E494 TCI-HPCR |
| Engine Type | CEV-V; 4 Cylinder; Water-cooled turbocharged diesel engine | CEV-V; Turbo charged Inter cooled |
| Max. Power | 112 HP (83.5 kW) @ 2200 rpm | 99.2 HP (74 kW) @ 2200 rpm |
| Battery | 12V, 130AMP | 12V |
| ACE ASD 115 | Volvo SD110 | |
| Static Linear Load | 30.52 kg/cm | 29.3 kg/cm |
| Nominal Amplitude (High/Low) | 1.85/0.8 mm | 1.9/1.0 mm |
| Vibration Frequency (Hi/Low) | 40/33 Hz | 0–30 Hz |
| Centrifugal Force (High/Low) | 254/176 kN | 243/130 kN |
| ACE ASD 115 | Volvo SD110 | |
| Transmission Type | Hydrostatic drive; infinitely variable planetary axle with limited slip differential | Hydrostatic |
| Max. Gradeability | 45% | 26 % |
| Working Speed | 0–29 km/hr | 0-6 km/hr |
| Travel Speed | 0–29 km/hr | 0-12 km/hr |
| ACE ASD 115 | Volvo SD110 | |
| Travel System | Variable displacement axial piston pump and constant displacement motor | Hydrostatic |
| Vibration System | Variable displacement axial piston pump and constant displacement motor | Hydraulic eccentric assembly mounted inside the drum |
| ACE ASD 115 | Volvo SD110 | |
| Service | Closed loop hydrostatic brakes on forward/reverse lever | Hydrostatic |
| Parking/Emergency | Spring applied/hydraulically released multi disc brake on drum drive gear reducer & rear axle | Spring-applied; hydraulically released on axle |
| ACE ASD 115 | Volvo SD110 | |
| Fuel Tank | 315 L | 196 L |
| Hydraulic Tank | 80 L | 70 L |
| Engine Crank Case | 13.5 L | NA |
| Coolant | 13 L | NA |
| Adblue/ DEF tank | 20 L | NA |
| ACE ASD 115 | Volvo SD110 | |
| Steering Type | Hydrostatic Steering | Articulated Steering |
| Steering Angle | ±37° | ±40° |
| Oscillation | ±10° | ±17° |
| Turning Radius, Outside | 6050 mm | NA |
| Turning Radius, Inside | 3950 mm | 3850 mm |
| ACE ASD 115 | Volvo SD110 | |
| Operating Weight | 11000 kg | 11150 kg |
| ACE ASD 115 | Volvo SD110 | |
| Overall Length | 5400 mm | 5875 mm |
| Overall Width | 2285 mm | 2340 mm |
| Overall Height | 3100 mm | 3100 mm |
| Wheelbase | 2980 mm | 3345 mm |
| Drum Diameter | 1530 mm | 1500 mm |
| Drum Width | 2130 mm | 2134 mm |
| Drum Shell Thickness | 25 mm | 25 mm |
| Ground Clearance | 450 mm | 472 mm |
| Curb Clearance | NA | 510 mm |
| Tyre Size | 12 PR x 23.1 x 26 | 23.1 x 26 VRC 18-R3 8PR TL |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Engine Make | |
| M&M MCVCN C35TL112CE5 | VECV E494 TCI-HPCR |
| Engine Type | |
| CEV-V; 4 Cylinder; Water-cooled turbocharged diesel engine | CEV-V; Turbo charged Inter cooled |
| Max. Power | |
| 112 HP (83.5 kW) @ 2200 rpm | 99.2 HP (74 kW) @ 2200 rpm |
| Battery | |
| 12V, 130AMP | 12V |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Static Linear Load | |
| 30.52 kg/cm | 29.3 kg/cm |
| Nominal Amplitude (High/Low) | |
| 1.85/0.8 mm | 1.9/1.0 mm |
| Vibration Frequency (Hi/Low) | |
| 40/33 Hz | 0–30 Hz |
| Centrifugal Force (High/Low) | |
| 254/176 kN | 243/130 kN |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Transmission Type | |
| Hydrostatic drive; infinitely variable planetary axle with limited slip differential | Hydrostatic |
| Max Gradeability | |
| Not Available | Not Available |
| Working Speed | |
| 0–29 km/hr | 0-6 km/hr |
| Travel Speed | |
| 0–29 km/hr | 0-12 km/hr |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Travel System | |
| Variable displacement axial piston pump and constant displacement motor | Hydrostatic |
| Vibration System | |
| Variable displacement axial piston pump and constant displacement motor | Hydraulic eccentric assembly mounted inside the drum |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Service | |
| Closed loop hydrostatic brakes on forward/reverse lever | Hydrostatic |
| Parking/Emergency | |
| Spring applied/hydraulically released multi disc brake on drum drive gear reducer & rear axle | Spring-applied; hydraulically released on axle |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Fuel Tank | |
| 315 L | 196 L |
| Hydraulic Tank | |
| 80 L | 70 L |
| Engine Crank Case | |
| 13.5 L | NA |
| Coolant | |
| 13 L | NA |
| Adblue/ DEF tank | |
| 20 L | NA |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Steering Type | |
| Hydrostatic Steering | Articulated Steering |
| Steering Angle | |
| ±37° | ±40° |
| Oscillation | |
| ±10° | ±17° |
| Turning Radius, Outside | |
| 6050 mm | NA |
| Turning Radius, Inside | |
| 3950 mm | 3850 mm |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Operating Weight | |
| 11000 kg | 11150 kg |
| ACE ASD 115 | Volvo SD110 |
|---|---|
| Overall Length | |
| 5400 mm | 5875 mm |
| Overall Width | |
| 2285 mm | 2340 mm |
| Overall Height | |
| 3100 mm | 3100 mm |
| Wheelbase | |
| 2980 mm | 3345 mm |
| Drum Diameter | |
| 1530 mm | 1500 mm |
| Drum Width | |
| 2130 mm | 2134 mm |
| Drum Shell Thickness | |
| 25 mm | 25 mm |
| Ground Clearance | |
| 450 mm | 472 mm |
| Curb Clearance | |
| NA | 510 mm |
| Tyre Size | |
| 12 PR x 23.1 x 26 | 23.1 x 26 VRC 18-R3 8PR TL |
