The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|
| Particulars | Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|
The Kobelco SK520XDLC and Liebherr R 945 Litronic are both large excavators designed for heavy-duty work. Kobelco offers higher engine power and a broader bucket capacity which could be essential for high-load work. On the other hand, Liebherr presents a more fuel-efficient system and better swing speed, important for operational efficiency.
The choice between these two machines should be guided by the specific needs of the project. For tasks requiring greater engine capacity and larger volume excavation, the Kobelco SK520XDLC would be preferable. Meanwhile, for operations looking to optimize fuel efficiency and maneuverability, the Liebherr R 945 Litronic is a compelling option.
| Brand | Kobelco | Liebherr |
|---|---|---|
| Type | Large (25-50 Ton) | Large (25-50 Ton) |
| Operating Cost | ₹ 1.85-1.88 Crore | Price Available Soon |
| Price | ₹ 1.85-1.88 Crore | Price Available Soon |
| Weight | 50800 Kg | 40800 Kg |
| Bucket | 2.1 - 3.4 m³ | 2.00 - 3.00 m³ |
| Max Digging Depth | 6820 mm | 7600 mm |
| Engine | HINO 344 HP | Liebherr 299 HP |
| Warranty | 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | 6500 mm | 6450 mm |
| Quick Overview: | An extra-large excavator, Kobelco SK520XDLC delivers unmatched power and heavy-duty performance for mining and demanding construction tasks. |
Built for power and precision, the Liebherr R 945 Litronic large excavator excels in mining and heavy engineering projects. |
| Agency review | Get the best price for the Kobelco SK520XDLC Extra-Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Liebherr R 945 Litronic Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The Kobelco SK520XDLC and Liebherr R 945 Litronic are both large excavators designed for heavy-duty work. Kobelco offers higher engine power and a broader bucket capacity which could be essential for high-load work. On the other hand, Liebherr presents a more fuel-efficient system and better swing speed, important for operational efficiency.
The choice between these two machines should be guided by the specific needs of the project. For tasks requiring greater engine capacity and larger volume excavation, the Kobelco SK520XDLC would be preferable. Meanwhile, for operations looking to optimize fuel efficiency and maneuverability, the Liebherr R 945 Litronic is a compelling option.
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Brand | |
| Kobelco | Liebherr |
| Type | |
| Large (25-50 Ton) | Large (25-50 Ton) |
| Price | |
| ₹ 1.85-1.88 Crore | Price Available Soon |
| Weight | |
| 50800 Kg | 40800 Kg |
| Bucket | |
| 2.1 - 3.4 m³ | 2.00 - 3.00 m³ |
| Max Digging Depth | |
| 6820 mm | 7600 mm |
| Engine | |
| HINO 344 HP | Liebherr 299 HP |
| Warranty | |
| 1 Yr. / 2500 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 6500 mm | 6450 mm |
| Quick Overview: | |
An extra-large excavator, Kobelco SK520XDLC delivers unmatched power and heavy-duty performance for mining and demanding construction tasks. |
Built for power and precision, the Liebherr R 945 Litronic large excavator excels in mining and heavy engineering projects. |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Engine Make | HINO P11C-WF | Liebherr D944 A7-23 |
| Fuel Tank | 638 L | 729 L |
| Engine Displacment | 10.52 L | 8.0 L |
| Under Carriage | 5460 mm | 5365 mm |
| Hydraulic System | 631 L | 475 L |
| Arm | 2600 mm | 3250 mm |
| Max Digging Reach | 11250 mm | NA |
| Fuel Consumption | NA | 23.26 L/hour |
| Overall Width | 3350 mm | 3490 mm |
| Overall Length | 11980 mm | 11200 mm |
| Bucket Digging Force | 282 kN | 238 kN |
| Tailswing Radius | 3800 mm | 3450 mm |
| Track Shoe Width | 600 mm | 600 mm |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Engine Make | |
| HINO P11C-WF | Liebherr D944 A7-23 |
| Fuel Tank | |
| 638 L | 729 L |
| Engine Displacment | |
| 10.52 L | 8.0 L |
| Under Carriage | |
| 5460 mm | 5365 mm |
| Hydraulic System | |
| 631 L | 475 L |
| Arm | |
| 2600 mm | 3250 mm |
| Max Digging Reach | |
| 11250 mm | NA |
| Fuel Consumption | |
| NA | 23.26 L/hour |
| Overall Width | |
| 3350 mm | 3490 mm |
| Overall Length | |
| 11980 mm | 11200 mm |
| Bucket Digging Force | |
| 282 kN | 238 kN |
| Tailswing Radius | |
| 3800 mm | 3450 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| 3564 | 3707 | |
| Model | HINO 344 HP | Liebherr 299 HP |
| Fuel | Diesel | Diesel |
| Type | 4cycle 6cylinder direct injection type diesel engine with intercooler turbo-charger , water-cooled | 4 Cylinder in-line , 4-stroke diesel Common-Rail Turbo-charged and after-cooler , after-cooled and fuel cooled , Engine equivalent to EU Stage IIIA / EPA Tier 3: with EGR , Water-cooled and oil cooler |
| Rated Engine Power | 344 HP (257 kW) @ 1850 rpm | 299 HP (220 kW) @ 1800 rpm |
| Maximum Torque | 1470 N.m @1400 rpm | 1421 Nm @ 1350 rpm |
| Piston Displacement | 10.52 L | 8.0 L |
| Alternator | 60A | Three-phase current 28 V / 140 A |
| Battery | 104 Ah , 2 x 12V | 12 V , 2 x 135 Ah |
| Starting Motor | 24V - 6kW | 24 V |
| 24 V | 24 V | |
| No of Top rollers | NA | 2 |
| No of bottom rollers | NA | 10 |
| Track Shoes (Each Side) | 50 | NA |
| Track Guard | NA | NA |
| Track Shoe width | 600 mm | 600 mm |
| Ground bearing pressure | 88 kPa | 70.6 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 70% (35 °) | NA |
| Travel Speed-Low | 3.4 Km/h | 2.9 km/h |
| Travel Speed-High | 5.4 Km/h | 4.6 Km/h |
| Max Tracking Force | 415 kN | 363 kN |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Hydraulic pump | Two variable displacement piston pumps | Liebherr swashplate double pump and variable displacement |
| Maximum Flow | 2 x 370 L/min | 2 x 315 L/min |
| Pilot Pump | 1 Gear Pump | NA |
| Implement Circuit | 31.4 MPa | 38.0 MPa |
| Swing Circuit | 26.0 MPa | NA |
| Travel circuit | 34.3 MPa | NA |
| Pilot circuit | 5.0 MPa | NA |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Travel | Variable displacement piston pump | Liebherr swashplate motor with brake valves on both sides |
| Swing | Axial-piston mortor | Liebherr swashplate motor with integrated brake valve and torque control |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Fuel tank | 638 L | 729 L |
| Engine Coolant | 47.4 L | NA |
| Engine oil | 42.5 L | NA |
| Hydraulic system | 631 L | 475 L |
| Hydraulic tank | 371 L | 239 L |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Operating Weight | 50800 Kg | 40800 Kg |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Boom length | 6500 mm | 6450 mm |
| Arm length | 2600 mm | 3250 mm |
| Max Digging Reach | 11250 mm | NA |
| Max Digging Reach on ground | 11010 mm | 11170 mm |
| Max digging depth | 6820 mm | 7600 mm |
| Max digging height | 11150 mm | 10530 mm |
| Max Dump Height | 7180 mm | 6930 mm |
| Max vertical wallcut depth | 6110 mm | NA |
| Min swing radius | 4960 mm | NA |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 282 kN | 238 kN |
| Arm Digging Force | 239 kN | 183 kN |
| Swing Speed | 7.6 rpm | 8.6 rpm |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Bucket Capacity | 2.1 - 3.4 m³ | 2.00 - 3.00 m³ |
| Kobelco SK520XDLC | Liebherr R 945 Litronic | |
| Overall Length | 11980 mm | 11200 mm |
| Overall width | 3350 mm | 3490 mm |
| Overall Height | 4330 mm | 3800 mm |
| Overall Height of Cab | 3320 mm | 3125 mm |
| Upper Width | 2980 mm | 2990 mm |
| Track Lengh on Ground | 4400 mm | 4400 mm |
| Undercarriage overall length | 5460 mm | 5365 mm |
| Tailswing radius | 3800 mm | 3450 mm |
| Min Ground clearance | 510 mm | 550 mm |
| Track gauge | 2750 mm | 2890 mm |
| Width over tracks | NA | 3490 mm |
| Track Height | NA | 1145 mm |
| Counterweight Clearance | 1260 mm | 1240 mm |
| Track Shoe Width | 600 mm | 600 mm |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Model | |
| HINO 344 HP | Liebherr 299 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4cycle 6cylinder direct injection type diesel engine with intercooler turbo-charger , water-cooled | 4 Cylinder in-line , 4-stroke diesel Common-Rail Turbo-charged and after-cooler , after-cooled and fuel cooled , Engine equivalent to EU Stage IIIA / EPA Tier 3: with EGR , Water-cooled and oil cooler |
| Rated Engine Power | |
| 344 HP (257 kW) @ 1850 rpm | 299 HP (220 kW) @ 1800 rpm |
| Maximum Torque | |
| 1470 N.m @1400 rpm | 1421 Nm @ 1350 rpm |
| Piston Displacement | |
| 10.52 L | 8.0 L |
| Alternator | |
| 60A | Three-phase current 28 V / 140 A |
| Battery | |
| 104 Ah , 2 x 12V | 12 V , 2 x 135 Ah |
| Starting Motor | |
| 24V - 6kW | 24 V |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| No of Top rollers | |
| NA | 2 |
| No of bottom rollers | |
| NA | 10 |
| Track Shoes (Each Side) | |
| 50 | NA |
| Track Guard | |
| NA | NA |
| Track Shoe width | |
| 600 mm | 600 mm |
| Ground bearing pressure | |
| 88 kPa | 70.6 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 70% (35 °) | NA |
| Travel Speed-Low | |
| 3.4 Km/h | 2.9 km/h |
| Travel Speed-High | |
| 5.4 Km/h | 4.6 Km/h |
| Max Tracking Force | |
| 415 kN | 363 kN |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Hydraulic pump | |
| Two variable displacement piston pumps | Liebherr swashplate double pump and variable displacement |
| Maximum Flow | |
| 2 x 370 L/min | 2 x 315 L/min |
| Pilot Pump | |
| 1 Gear Pump | NA |
| Implement Circuit | |
| 31.4 MPa | 38.0 MPa |
| Swing Circuit | |
| 26.0 MPa | NA |
| Travel circuit | |
| 34.3 MPa | NA |
| Pilot circuit | |
| 5.0 MPa | NA |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Fuel tank | |
| 638 L | 729 L |
| Engine Coolant | |
| 47.4 L | NA |
| Engine oil | |
| 42.5 L | NA |
| Hydraulic system | |
| 631 L | 475 L |
| Hydraulic tank | |
| 371 L | 239 L |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Operating Weight | |
| 50800 Kg | 40800 Kg |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Boom length | |
| 6500 mm | 6450 mm |
| Arm length | |
| 2600 mm | 3250 mm |
| Max Digging Reach | |
| 11250 mm | NA |
| Max Digging Reach on ground | |
| 11010 mm | 11170 mm |
| Max digging depth | |
| 6820 mm | 7600 mm |
| Max digging height | |
| 11150 mm | 10530 mm |
| Max Dump Height | |
| 7180 mm | 6930 mm |
| Max vertical wallcut depth | |
| 6110 mm | NA |
| Min swing radius | |
| 4960 mm | NA |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 282 kN | 238 kN |
| Arm Digging Force | |
| 239 kN | 183 kN |
| Swing Speed | |
| 7.6 rpm | 8.6 rpm |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Bucket Capacity | |
| 2.1 - 3.4 m³ | 2.00 - 3.00 m³ |
| Kobelco SK520XDLC | Liebherr R 945 Litronic |
|---|---|
| Overall Length | |
| 11980 mm | 11200 mm |
| Overall width | |
| 3350 mm | 3490 mm |
| Overall Height | |
| 4330 mm | 3800 mm |
| Overall Height of Cab | |
| 3320 mm | 3125 mm |
| Upper Width | |
| 2980 mm | 2990 mm |
| Track Lengh on Ground | |
| 4400 mm | 4400 mm |
| Undercarriage overall length | |
| 5460 mm | 5365 mm |
| Tailswing radius | |
| 3800 mm | 3450 mm |
| Min Ground clearance | |
| 510 mm | 550 mm |
| Track gauge | |
| 2750 mm | 2890 mm |
| Width over tracks | |
| NA | 3490 mm |
| Track Height | |
| NA | 1145 mm |
| Counterweight Clearence | |
| 1260 mm | 1240 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
