Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.
Bull
2WD/4WD
₹ 30-32 Lakhs
₹ 30-32 Lakhs
Kirloskar 75 HP
0.27 m³
1.26 m³
4770 mm
2960 mm
8010 Kg
Engineered for efficiency, the Bull SD76 BS4 CHAMPION backhoe loader meets BS4 standards while delivering reliable performance for excavation and loading needs.
Looking for the best price on a Bull SD76 BS4 CHAMPION backhoe loader? Connect with authorized dealers today for exclusive deals!
Please fil the below form to start the download
Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.
Kirloskar 4R 1190
115 L
300 Nm @ 1300 RPM
40 km/hr
120 L/min
5980 mm
1642 kg
3390 mm
7400 mm
2220 mm
5936 kgf
8183 kgf
1 Year
Optional
Standard
The machine is equipped with a powerful and fuel-efficient BS4-compliant engine, ensuring high productivity while keeping fuel consumption low.
It delivers excellent torque, allowing the backhoe loader to perform demanding excavation, loading, and material handling tasks with ease.
The advanced cooling system prevents overheating, ensuring optimal performance during prolonged work hours in extreme conditions.
The engine is designed for low maintenance, reducing downtime and operational costs while enhancing overall durability.
A high-performance hydraulic system ensures smooth and responsive controls, improving work efficiency and operator comfort.
The engine adheres to BS4 emission norms, making it an environmentally friendly choice with reduced emissions and better fuel efficiency.
The backhoe offers deep digging depth, making it ideal for various excavation tasks, including trenching, foundation work, and site leveling.
A powerful breakout force enables easy penetration through hard soil, compact ground, and rocky surfaces, increasing productivity.
The multi-purpose bucket enhances versatility, allowing for excavation, material handling, grading, and leveling in a single operation.
Precision joystick controls provide smooth and effortless operation, minimizing operator fatigue and improving accuracy.
A side-shift boom allows better reach and flexibility, especially in confined spaces or urban construction sites with limited working areas.
Heavy-duty stabilizers provide exceptional balance and safety, ensuring stable operations even on uneven and sloped terrains.
A high lift height makes it easy to load trucks and transport materials efficiently, reducing cycle times and increasing productivity.
The large bucket capacity allows for the movement of a greater volume of material per cycle, improving overall work efficiency.
Strong and durable loader arms ensure the machine can handle heavy loads without compromising structural integrity.
Fast cycle times enable quicker loading and unloading operations, minimizing downtime and increasing overall output.
Advanced hydraulic controls allow for smooth and effortless loader operation, providing precision and ease of use.
A quick-attach mechanism enables seamless switching between different attachments, making the machine highly versatile for multiple applications.
The ergonomically designed and spacious cabin ensures a comfortable working environment, reducing operator fatigue during long shifts.
An adjustable suspension seat absorbs vibrations and shocks, providing a smoother ride even on rough terrains.
The ROPS/FOPS-certified cabin enhances safety, protecting the operator from rollovers and falling objects in hazardous conditions.
Noise and vibration reduction features ensure a quieter working environment, enhancing operator focus and reducing stress.
Large windows and well-placed mirrors provide excellent visibility, improving precision and reducing the risk of accidents on-site.
An intuitive control panel with digital displays and user-friendly controls simplifies machine operation, improving overall efficiency.
A reinforced chassis and high-strength frame provide superior durability, ensuring long-lasting performance in tough working conditions.
Heavy-duty hydraulic components offer excellent wear resistance, minimizing breakdowns and reducing maintenance costs.
A corrosion-resistant body protects the machine from rust and environmental damage, extending its operational lifespan.
High-quality hydraulic seals prevent leaks and ensure smooth performance, reducing the risk of failures in demanding applications.
The machine is designed for low maintenance, requiring minimal servicing while maximizing uptime and operational efficiency.
Rugged, deep-tread tires offer exceptional grip and stability, allowing the loader to perform efficiently on uneven, muddy, or rocky surfaces.
The backhoe loader comes equipped with advanced telematics, enabling real-time tracking, diagnostics, and performance monitoring for better fleet management.
A smart fuel management system optimizes fuel consumption, reducing operational costs while maintaining high-performance efficiency.
An automatic self-leveling feature ensures stability while lifting and loading, increasing precision and reducing the risk of load spills.
Integrated GPS tracking provides location monitoring and security, helping prevent unauthorized usage and improving job-site coordination.
A highly efficient braking system enhances control and safety, ensuring smooth and reliable stopping power even on inclined terrains.
Energy-efficient LED lighting improves visibility during night operations, allowing for safe and efficient work in low-light conditions.
The machine is equipped with a powerful and fuel-efficient BS4-compliant engine, ensuring high productivity while keeping fuel consumption low.
It delivers excellent torque, allowing the backhoe loader to perform demanding excavation, loading, and material handling tasks with ease.
The advanced cooling system prevents overheating, ensuring optimal performance during prolonged work hours in extreme conditions.
The engine is designed for low maintenance, reducing downtime and operational costs while enhancing overall durability.
A high-performance hydraulic system ensures smooth and responsive controls, improving work efficiency and operator comfort.
The engine adheres to BS4 emission norms, making it an environmentally friendly choice with reduced emissions and better fuel efficiency.
The backhoe offers deep digging depth, making it ideal for various excavation tasks, including trenching, foundation work, and site leveling.
A powerful breakout force enables easy penetration through hard soil, compact ground, and rocky surfaces, increasing productivity.
The multi-purpose bucket enhances versatility, allowing for excavation, material handling, grading, and leveling in a single operation.
Precision joystick controls provide smooth and effortless operation, minimizing operator fatigue and improving accuracy.
A side-shift boom allows better reach and flexibility, especially in confined spaces or urban construction sites with limited working areas.
Heavy-duty stabilizers provide exceptional balance and safety, ensuring stable operations even on uneven and sloped terrains.
A high lift height makes it easy to load trucks and transport materials efficiently, reducing cycle times and increasing productivity.
The large bucket capacity allows for the movement of a greater volume of material per cycle, improving overall work efficiency.
Strong and durable loader arms ensure the machine can handle heavy loads without compromising structural integrity.
Fast cycle times enable quicker loading and unloading operations, minimizing downtime and increasing overall output.
Advanced hydraulic controls allow for smooth and effortless loader operation, providing precision and ease of use.
A quick-attach mechanism enables seamless switching between different attachments, making the machine highly versatile for multiple applications.
The ergonomically designed and spacious cabin ensures a comfortable working environment, reducing operator fatigue during long shifts.
An adjustable suspension seat absorbs vibrations and shocks, providing a smoother ride even on rough terrains.
The ROPS/FOPS-certified cabin enhances safety, protecting the operator from rollovers and falling objects in hazardous conditions.
Noise and vibration reduction features ensure a quieter working environment, enhancing operator focus and reducing stress.
Large windows and well-placed mirrors provide excellent visibility, improving precision and reducing the risk of accidents on-site.
An intuitive control panel with digital displays and user-friendly controls simplifies machine operation, improving overall efficiency.
A reinforced chassis and high-strength frame provide superior durability, ensuring long-lasting performance in tough working conditions.
Heavy-duty hydraulic components offer excellent wear resistance, minimizing breakdowns and reducing maintenance costs.
A corrosion-resistant body protects the machine from rust and environmental damage, extending its operational lifespan.
High-quality hydraulic seals prevent leaks and ensure smooth performance, reducing the risk of failures in demanding applications.
The machine is designed for low maintenance, requiring minimal servicing while maximizing uptime and operational efficiency.
Rugged, deep-tread tires offer exceptional grip and stability, allowing the loader to perform efficiently on uneven, muddy, or rocky surfaces.
The backhoe loader comes equipped with advanced telematics, enabling real-time tracking, diagnostics, and performance monitoring for better fleet management.
A smart fuel management system optimizes fuel consumption, reducing operational costs while maintaining high-performance efficiency.
An automatic self-leveling feature ensures stability while lifting and loading, increasing precision and reducing the risk of load spills.
Integrated GPS tracking provides location monitoring and security, helping prevent unauthorized usage and improving job-site coordination.
A highly efficient braking system enhances control and safety, ensuring smooth and reliable stopping power even on inclined terrains.
Energy-efficient LED lighting improves visibility during night operations, allowing for safe and efficient work in low-light conditions.
Product specification of Bull SD76 BS4 Champion Backhoe Loader
Model
Kirloskar 4R 1190
Type
BS lV Diesel Engine, 4 Cylinders
Gross Power
75 HP (54.8 kW) @ 2200 RPM
Max Torque
300 Nm @ 1300 RPM
Displacement
4.76 L
Battery
12V / 150Ah
Alternator
NA
Type
CARRARO synchro - shuttle transmission with integral torque converter
Type
Full power, front wheel hydraulic power steering with manual capability in the event of engine or hydraullic power failure.
Working Pressure
110 bar
Inner Wheels Braked - Outside Loader Bucket
8800 mm
Inner Wheels Braked - Outside Wheels
6300 mm
Inner Wheels not Braked - Outside Loader Bucket
11600 mm
Inner Wheels not Braked -Outside Wheels
8900 mm
Service
Hydraulically actuated, duel line, self adjusting, compensated oil immersed, multi-disc type on the rear axle, well protected from dirt, water etc., requiring no maintenance. Operation Through independent pedals linked together for normal use.Two independently operatable foot pedals enable machine to maneuver in tight spaces.
Parking
Hand operated, oil immersed multi disc on the rear axle.
Front
12.5 / 80 x 18 -12 PR
Rear
16.9 x 28 -12 PR (STD INDUSTRIAL TYRE)
Forward- 1st gear
NA
Reverse- 1st gear
NA
Forward- 2nd Gear
NA
Reverse- 2nd Gear
NA
Forward- 3rd gear
40 km/hr
Reverse- 3rd gear
9.3 km/hr
Forward- 4th gear
NA
Reverse- 4th gear
28 km/hr
Type
Gear Pump
Maximum Pump Flow
120 L/min
System Pressure
230 bar
Rear axle
Drive axle rigidly mounted, incorporates Max-trac torque proportioning differential, driven by short propshaft from gear box.
Front axle
Steer axle, centrally pivoted with oscillation angle ±16°.
Fuel Tank
115 L
Engine Coolant
17 L
Engine Oil
10 L
Hydraulic Tank
100 L
Hydraulic System
115 L
Transmission
19.5 L
Rear Axle
17 L
Maximum Digging Depth
4770 mm
Reach-Ground Level to Rear Wheel Centre
6770 mm
Reach-Ground Level to Slew Centre
5470 mm
Reach at Full Height to Slew Centre
2820 mm
Side Reach to Centre Line of Machine
6080 mm
Maximum Working Height
5980 mm
Maximum Load Over Height
4190 mm
Bucket Rotation Angle
201°
Bucket Digging force
5936 kgf
Arm Digging force
8936 kgf
Maximum Lift Capacity
1642 Kg
Standard Bucket Capacity
0.27 m³
Standard Bucket Width
NA
Dump Height
2960 mm
Load Over Height
3390 mm
Pin Height
3610 mm
Pin Forward Reach
420 mm
Reach at Ground
1470 mm
Maximum Reach at Full Height
1280 mm
Maximum Reach at Full Height - Bucket Dumped
890 mm
Below Ground Level Dig Depth
100 mm
Rollback at Ground
49°
Dump Angle
45°
Shovel Breakout Force
8183 kgf
Loader Arm Breakout Force
5251 kgf
Maximum Payload
2400 kg
Standard Shovel Capacity
1.26 m³
Machine Weight
8010 kg
Overall Length
7400 mm
Wheelbase
2220 mm
Slew Centre to Rear Axle Centre
NA
Minimum Ground Clearance
480 mm
Slew Ground Clearance
650 mm
Height of Cabin
3000 mm
Overall Height
3560 mm
Track width - Rear
1700 mm
Track width - Front
1930 mm
Width Over Bucket
2350 mm
The Bull SD76 BS4 Champion backhoe loader price in india ranges between ₹ 30-32 lakhs. However, the exact price may vary depending on the location dealer, taxes, and additional features.
You can buy the Bull SD76 BS4 Champion backhoe loader from Desi Machines, your trusted platform for construction and heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the backhoe loader you want, or contact us directly for expert assistance and competitive pricing.
Yes, the Bull SD76 BS4 Champion backhoe loader comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Connect with us and our team will help you secure the best deals.
The mileage of the Bull SD76 BS4 Champion backhoe loader typically ranges between 4 to 6 km per liter under standard working conditions. However, actual fuel consumption depends on factors such as load capacity, terrain, operator efficiency, and maintenance practices.
The Bull SD76 BS4 Champion backhoe loader is powered by a Kirloskar 4R 1190 diesel engine, delivering 75 HP (54.8 kW) @ 2200 rpm.
The weight of the Bull SD76 BS4 Champion backhoe loader is approximately 8010 kg. The weight may vary slightly depending on specific configurations and attachments.
The Bull SD76 BS4 Champion backhoe loader has a 115 litres diesel fuel tank, providing extended operation time without frequent refueling.
The Bull SD76 BS4 Champion backhoe loader has a lifting capacity of 1642 kg, making it ideal for versatile applications.
The Bull SD76 BS4 Champion backhoe loader has a maximum digging depth of 4770 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.
The loader bucket capacity of the Bull SD76 BS4 Champion is 1.26 cubic meters (m³).
The backhoe bucket capacity of the Bull SD76 BS4 Champion is 0.27 cubic meters (m³).
The Bull SD76 BS4 Champion backhoe loader in India typically comes with a standard warranty of 1 year. The warranty covers defects from faulty materials or workmanship, but terms may vary. For the latest details, check with authorized dealers or visit the official brand website.
The Bull SD76 BS4 Champion backhoe loader features a 4-speed fully synchromesh gearbox with an integral torque converter and electrically operated forward & reversing shuttle, meaning it has 4 gears.
You can find genuine spare parts for the Bull SD76 BS4 Champion backhoe loader at authorized Bull dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on backhoe loader spare parts.
