The Tata Hitachi Shinrai Prime CEV 5 backhoe loader is designed for efficiency and durability, offering powerful performance for construction and excavation tasks.
Tata Hitachi
2WD/4WD
₹ 33-35 Lakhs
₹ 33-35 Lakhs
Kubota 74.3 HP
0.27 m³
1.1 m³
4700 mm
2720 mm
8120 Kg
Looking for the best price on a Tata Hitachi Shinrai Prime CEV 5 backhoe loader? Connect with authorized dealers today for exclusive deals!
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Please fil the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Kubota V3800-CR-TE5
128 L
310 Nm @ 1500 rpm
32 km/hr
113 L/min @ 1950 RPM
6050 mm
NA
3305 mm
6040 mm
2130 mm
5685 kgf
6580 kgf
1 Yr. / 2000 hr.
Optional
Standard
New fuel efficient CEV 5 Japanese engine
Superior engine performance
Engine control unit (ECU) equipped with CRDI (Common Rail Direct Injection) system - Provides higher output power and torque rise while offering exceptional fuel efficiency
4 valve per cylinder
Engine mounted After Treatment Device (DOC - Diesel Oxidation Catalyst + DPF - Diesel Particulate Filter)
Automatic fuel priming system
Rotary fuel injection pump
Electronically controlled parameters for optimized performance and increased life
Proven transmission and axle system
4 wheel drive**
Provides great performance with fuel efficiency
High/Low pressure unloader systems ensure optimum hydraulic oil, when needed
Ensures optimal utilisation of engine and hydraulic power
Long lasting hydraulic hoses for superior life
Well ventilated and spacious cabin
Excellent visibility
Comfortable operator seat
Large leg space for comfortable operation
Ergonomic controls
User-friendly consoles
Ample storage space
Multi-functional digital display
Air-conditioner**
Powerful music system with FM, USB, AUX, Bluetooth and calling facility
Meets FOPS level-ll and ROPS safety requirements as standard
Quieter engine
Ergonomically inclined rear side cabin floor for operator comfort during backhoe operation
Pocket mesh for keeping documents and mobile phones
Used for standard operations like loading and dozing.
Multipurpose attachments used for loading, dozing, leveling, grabbing, spreading and backfilling.
GPS and GPRS based remote tracking through InSite
Monitors machine location and operations
Offers information about the machine and the fleet
Warranty, extended warranty and post-warranty services
On-site services through a wide network of dealerships
Fault codes display in the cluster for ease of maintenance and troubleshooting
Field diagnostic vehicle for immediate on-site resolution
On-site and plant-based training programmes
Hydraulic oil change interval of 4500 hours
New fuel efficient CEV 5 Japanese engine
Superior engine performance
Engine control unit (ECU) equipped with CRDI (Common Rail Direct Injection) system - Provides higher output power and torque rise while offering exceptional fuel efficiency
4 valve per cylinder
Engine mounted After Treatment Device (DOC - Diesel Oxidation Catalyst + DPF - Diesel Particulate Filter)
Automatic fuel priming system
Rotary fuel injection pump
Electronically controlled parameters for optimized performance and increased life
Proven transmission and axle system
4 wheel drive**
Provides great performance with fuel efficiency
High/Low pressure unloader systems ensure optimum hydraulic oil, when needed
Ensures optimal utilisation of engine and hydraulic power
Long lasting hydraulic hoses for superior life
Well ventilated and spacious cabin
Excellent visibility
Comfortable operator seat
Large leg space for comfortable operation
Ergonomic controls
User-friendly consoles
Ample storage space
Multi-functional digital display
Air-conditioner**
Powerful music system with FM, USB, AUX, Bluetooth and calling facility
Meets FOPS level-ll and ROPS safety requirements as standard
Quieter engine
Ergonomically inclined rear side cabin floor for operator comfort during backhoe operation
Pocket mesh for keeping documents and mobile phones
Used for standard operations like loading and dozing.
Multipurpose attachments used for loading, dozing, leveling, grabbing, spreading and backfilling.
GPS and GPRS based remote tracking through InSite
Monitors machine location and operations
Offers information about the machine and the fleet
Warranty, extended warranty and post-warranty services
On-site services through a wide network of dealerships
Fault codes display in the cluster for ease of maintenance and troubleshooting
Field diagnostic vehicle for immediate on-site resolution
On-site and plant-based training programmes
Hydraulic oil change interval of 4500 hours
Product specification of Tata Hitachi Shinrai Prime CEV 5 Backhoe Loader
Model
Kubota V3800-CR-TE5
Type
Turbo-Charged, Direct Injection, 4 Cylinders
Gross Power
74.3 HP (55.4 kW) @ 2200 RPM
Max Torque
310 Nm @ 1500 RPM
Displacement
3.7 L
Battery
12 V / 150 Ah
Alternator
100A
Type
Equipped with Carraro-make synchro-shuttle transmission.
Type
Hydraulic actuation with priority for smooth control.
Working Pressure
NA
Inner Wheels Braked - Outside Loader Bucket
11730 mm
Inner Wheels Braked - Outside Wheels
8600 mm
Inner Wheels not Braked - Outside Loader Bucket
NA
Inner Wheels not Braked -Outside Wheels
NA
Service
Oil-immersed wet disc, hydraulic-actuated with independent pedals for better control in narrow spaces
Parking
Hand operated disc brake on the rear axle.
Front
9 x 16.16 PR
Rear
16.9 x 28, 12 PR
Forward- 1st gear
5 km/hr
Reverse- 1st gear
6 km/hr
Forward- 2nd Gear
8 km/hr
Reverse- 2nd Gear
9 km/hr
Forward- 3rd gear
17 km/hr
Reverse- 3rd gear
Not recommended
Forward- 4th gear
32 km/hr
Reverse- 4th gear
Not recommended
Type
Excellent Hydraulic system (EHS) with tandem gear pump for lower fuel consumption.
Maximum Pump Flow
113 L/min @ 1950 RPM
System Pressure
245 bar
Rear axle
Rear heavy-duty carraro axle with high brake torque
Front axle
Heavy-duty, non-powered axle
Fuel Tank
128 L
Engine Coolant
14.4 L
Engine Oil
13.2 L
Hydraulic Tank
86 L
Hydraulic System
NA
Transmission
16 L
Rear Axle
17.1 L
Maximum Digging Depth
4700 mm
Reach-Ground Level to Rear Wheel Centre
6880 mm
Reach-Ground Level to Slew Centre
5440 mm
Reach at Full Height to Slew Centre
2001 mm
Side Reach to Centre Line of Machine
6050 mm
Maximum Working Height
6050 mm
Maximum Load Over Height
4200 mm
Bucket Rotation Angle
180°
Bucket Digging force
5685 kgf
Arm Digging force
3220 kgf
Maximum Lift Capacity
NA
Standard Bucket Capacity
0.27 m³
Standard Bucket Width
784 mm
Dump Height
2720 mm
Load Over Height
3305 mm
Pin Height
3550 mm
Pin Forward Reach
367 mm
Reach at Ground
1620 mm
Maximum Reach at Full Height
1332 mm
Maximum Reach at Full Height - Bucket Dumped
4840 mm
Below Ground Level Dig Depth
110 mm
Rollback at Ground
45°
Dump Angle
45°
Shovel Breakout Force
6580 kgf
Loader Arm Breakout Force
5488 kgf
Maximum Payload
1920 kg
Standard Shovel Capacity
1.1 m³
Machine Weight
8120 kg
Overall Length
6040 mm
Wheelbase
2130 mm
Slew Centre to Rear Axle Centre
1370 mm
Minimum Ground Clearance
320 mm
Slew Ground Clearance
485 mm
Height of Cabin
2970 mm
Overall Height
3530 mm
Track width - Rear
1700 mm
Track width - Front
1900 mm
Width Over Bucket
2354 mm
The Tata Hitachi Shinrai Prime CEV 5 backhoe loader price in india ranges between ₹ 33-35 lakhs. However, the exact price may vary depending on the location dealer, taxes, and additional features.
You can buy the Tata Hitachi Shinrai Prime CEV 5 backhoe loader from Desi Machines, your trusted platform for construction and heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the backhoe loader you want, or contact us directly for expert assistance and competitive pricing.
Yes, the Tata Hitachi Shinrai Prime CEV 5 backhoe loader comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Connect with us and our team will help you secure the best deals.
The mileage of the Tata Hitachi Shinrai Prime CEV 5 backhoe loader typically ranges between 4 to 6 km per liter under standard working conditions. However, actual fuel consumption depends on factors such as load capacity, terrain, operator efficiency, and maintenance practices.
The Tata Hitachi Shinrai Prime backhoe loader is powered by a Kubota V3800-CR-TE5 diesel engine, delivering 74.3 HP (55.4 kW) @ 2200 rpm.
The weight of the Tata Hitachi Shinrai Prime CEV 5 backhoe loader is approximately 8120 kg. The weight may vary slightly depending on specific configurations and attachments.
The Tata Hitachi Shinrai Prime CEV 5 backhoe loader has a 128 litres diesel fuel tank, providing extended operation time without frequent refueling.
The Tata Hitachi Shinrai Prime CEV 5 backhoe loader has a maximum digging depth of 4700 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.
The loader bucket capacity of the Tata Hitachi Shinrai Prime CEV 5 is 1.1 cubic meters (m³).
The backhoe bucket capacity of the Tata Hitachi Shinrai Prime CEV 5 is 0.27 cubic meters (m³).
The Tata Hitachi Shinrai Prime CEV 5 backhoe loader in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever comes first. The warranty covers defects from faulty materials or workmanship, but terms may vary. For the latest details, check with authorized dealers or visit the official brand website.
The Tata Hitachi Shinrai Prime CEV 5 backhoe loader has a synchro – shuttle transmission that allows for four forward and two reverse speeds.
You can find genuine spare parts for the Tata Hitachi Shinrai Prime CEV 5 backhoe loader at authorized Tata Hitachi dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on backhoe loader spare parts.
A joint venture between Tata Motors Limited (40%) and Hitachi Construction Machinery Company Limited (60%), Tata Hitachi provides world-class construction equipment to address India’s infrastructure and mining needs.
Focused on developing global products to suit Indian working conditions, the organization’s product lineup includes a wide range of excavators, backhoe loaders, wheel loaders, and rigid dump trucks. Tata Hitachi has two plants at Dharwad (Karnataka) and Kharagpur (West Bengal). The plants epitomize world-class manufacturing and state-of-the-art technology.
Product Portfolio: Excavators, Backhoe Loaders, Wheel Loaders
