The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Hyundai HX380L | CAT 345 GC |
|---|
| Particulars | Hyundai HX380L | CAT 345 GC |
|---|
The CAT 345 GC and Hyundai HX380L are both large excavators designed for demanding tasks like mining and earthmoving. The CAT 345 GC outshines with superior engine power and bucket capacity, while the Hyundai HX380L offers detailed engine and hydraulic specifications as well as travel performance, topped with a clear price point.
For projects requiring higher power and load capacity, the CAT 345 GC is the preferable option. However, for cost-sensitive operations that need good gradeability and travel performance, the Hyundai HX380L would be a more suitable choice.
| Brand | Hyundai | Caterpillar |
|---|---|---|
| Type | Large (25-50 Ton) | Large (25-50 Ton) |
| Operating Cost | ₹ 1.24- 1.26 Crore | Price Available Soon |
| Price | ₹ 1.24- 1.26 Crore | Price Available Soon |
| Weight | 37200 Kg | 42200 Kg |
| Bucket | 2.10 m³ | 2.41 m³ |
| Max Digging Depth | 6820 mm | 7040 mm |
| Engine | Hyundai 260 HP | CAT 347 HP |
| Warranty | 1 Yr. / 2000 hr. | 1 Year |
| Boom | 6450 mm | 6900 mm |
| Quick Overview: | Large excavator comprising enhanced durability and high capacity, Hyundai’s HX380L is fabricated for mining and earthmoving. |
The CAT 345 GC large excavator is designed for high-load tasks and delivers exceptional reliability in mining and earthmoving operations. |
| Agency review | Get the best price for the Hyundai HX380L Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the CAT 345 GC Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The CAT 345 GC and Hyundai HX380L are both large excavators designed for demanding tasks like mining and earthmoving. The CAT 345 GC outshines with superior engine power and bucket capacity, while the Hyundai HX380L offers detailed engine and hydraulic specifications as well as travel performance, topped with a clear price point.
For projects requiring higher power and load capacity, the CAT 345 GC is the preferable option. However, for cost-sensitive operations that need good gradeability and travel performance, the Hyundai HX380L would be a more suitable choice.
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Brand | |
| Hyundai | Caterpillar |
| Type | |
| Large (25-50 Ton) | Large (25-50 Ton) |
| Price | |
| ₹ 1.24- 1.26 Crore | Price Available Soon |
| Weight | |
| 37200 Kg | 42200 Kg |
| Bucket | |
| 2.10 m³ | 2.41 m³ |
| Max Digging Depth | |
| 6820 mm | 7040 mm |
| Engine | |
| Hyundai 260 HP | CAT 347 HP |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Year |
| Boom | |
| 6450 mm | 6900 mm |
| Quick Overview: | |
Large excavator comprising enhanced durability and high capacity, Hyundai’s HX380L is fabricated for mining and earthmoving. |
The CAT 345 GC large excavator is designed for high-load tasks and delivers exceptional reliability in mining and earthmoving operations. |
| Hyundai HX380L | CAT 345 GC | |
| Engine Make | Hyundai - HM8.3 | Cat C9.3 |
| Fuel Tank | 600 L | 600 L |
| Engine Displacment | 8.3 L | 9.3 L |
| Under Carriage | 4940 mm | 5029 mm |
| Hydraulic System | 414 L | 423 L |
| Arm | 2650 mm | 2900 mm |
| Max Digging Reach | 10710 mm | NA |
| Fuel Consumption | NA | NA |
| Overall Width | 3190 mm | 3340 mm |
| Overall Length | 11340 mm | 11620 mm |
| Bucket Digging Force | 215.7 kN | 235 kN |
| Tailswing Radius | 3570 mm | 3530 mm |
| Track Shoe Width | 600 mm | 600 mm |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Engine Make | |
| Hyundai - HM8.3 | Cat C9.3 |
| Fuel Tank | |
| 600 L | 600 L |
| Engine Displacment | |
| 8.3 L | 9.3 L |
| Under Carriage | |
| 4940 mm | 5029 mm |
| Hydraulic System | |
| 414 L | 423 L |
| Arm | |
| 2650 mm | 2900 mm |
| Max Digging Reach | |
| 10710 mm | NA |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 3190 mm | 3340 mm |
| Overall Length | |
| 11340 mm | 11620 mm |
| Bucket Digging Force | |
| 215.7 kN | 235 kN |
| Tailswing Radius | |
| 3570 mm | 3530 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| 3535 | 3523 | |
| Model | Hyundai 260 HP | CAT 347 HP |
| Fuel | Diesel | Diesel |
| Type | 4 Cycle , 6 Cylinder , Charge Air Cooled , direct injection , Mechanical Control Diesel Engine , Turboharged , Water Cooled | NA |
| Rated Engine Power | 260 HP (194 kW) @ 2200 rpm | 347 HP (259 kW) @1750 rpm |
| Maximum Torque | 1150 N.m @1300 rpm | NA |
| Piston Displacement | 8.3 L | 9.3 L |
| Alternator | 24V / 90A | NA |
| Battery | 160 Ah , 2 x 12V | NA |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | 2 | NA |
| No of bottom rollers | 8 | NA |
| Track Shoes (Each Side) | 48 | NA |
| Track Guard | 2 | NA |
| Track Shoe width | 600 mm | 600 mm |
| Ground bearing pressure | 69.6 kPa | NA |
| Track Tensioning | Grease | Grease |
| Gradeability | 35 ° / 70% | NA |
| Travel Speed-Low | 3.1 Km/h | NA |
| Travel Speed-High | 5.0 Km/h | NA |
| Max Tracking Force | 313.9 kN | NA |
| Hyundai HX380L | CAT 345 GC | |
| Hydraulic pump | Variable Displacement Tandem Axis Piston Pumps | NA |
| Maximum Flow | 2 x 315 L/min | 630 L/min |
| Pilot Pump | Gear Pump | Gear Pump |
| Implement Circuit | 34.3 MPa | 35 MPa |
| Swing Circuit | 29.4 MPa | 28 MPa |
| Travel circuit | 34.3 MPa | 35 MPa |
| Pilot circuit | 3.9 MPa | NA |
| Hyundai HX380L | CAT 345 GC | |
| Travel | Two speed axial pistons motor with brake valve & parking brake | NA |
| Swing | Axial piston motor with automatic brake | NA |
| Hyundai HX380L | CAT 345 GC | |
| Fuel tank | 600 L | 600 L |
| Engine Coolant | 25 L | 40 L |
| Engine oil | 26.5 L | 32 L |
| Hydraulic system | 414 L | 423 L |
| Hydraulic tank | 210 L | 186 L |
| Hyundai HX380L | CAT 345 GC | |
| Operating Weight | 37200 Kg | 42200 Kg |
| Hyundai HX380L | CAT 345 GC | |
| Boom length | 6450 mm | 6900 mm |
| Arm length | 2650 mm | 2900 mm |
| Max Digging Reach | 10710 mm | NA |
| Max Digging Reach on ground | 10580 mm | 11290 mm |
| Max digging depth | 6820 mm | 7040 mm |
| Max digging height | 10190 mm | 10540 mm |
| Max Dump Height | 7120 mm | NA |
| Max vertical wallcut depth | 6320 mm | 5390 mm |
| Min swing radius | 4620 mm | NA |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 215.7 kN | 235 kN |
| Arm Digging Force | 184.4 kN | 198 kN |
| Swing Speed | 11.2 rpm | 8.27 rpm |
| Hyundai HX380L | CAT 345 GC | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Hyundai HX380L | CAT 345 GC | |
| Bucket Capacity | 2.10 m³ | 2.41 m³ |
| Hyundai HX380L | CAT 345 GC | |
| Overall Length | 11340 mm | 11620 mm |
| Overall width | 3190 mm | 3340 mm |
| Overall Height | 3760 mm | 3370 mm |
| Overall Height of Cab | 3160 mm | 3230 mm |
| Upper Width | 2980 mm | NA |
| Track Lengh on Ground | 4030 mm | 4040 mm |
| Undercarriage overall length | 4940 mm | 5029 mm |
| Tailswing radius | 3570 mm | 3530 mm |
| Min Ground clearance | 500 mm | 520 mm |
| Track gauge | 2590 mm | 2740 mm |
| Width over tracks | NA | NA |
| Track Height | NA | NA |
| Counterweight Clearance | 1200 mm | 1300 mm |
| Track Shoe Width | 600 mm | 600 mm |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Model | |
| Hyundai 260 HP | CAT 347 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4 Cycle , 6 Cylinder , Charge Air Cooled , direct injection , Mechanical Control Diesel Engine , Turboharged , Water Cooled | NA |
| Rated Engine Power | |
| 260 HP (194 kW) @ 2200 rpm | 347 HP (259 kW) @1750 rpm |
| Maximum Torque | |
| 1150 N.m @1300 rpm | NA |
| Piston Displacement | |
| 8.3 L | 9.3 L |
| Alternator | |
| 24V / 90A | NA |
| Battery | |
| 160 Ah , 2 x 12V | NA |
| Starting Motor | |
| NA | NA |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| No of Top rollers | |
| 2 | NA |
| No of bottom rollers | |
| 8 | NA |
| Track Shoes (Each Side) | |
| 48 | NA |
| Track Guard | |
| 2 | NA |
| Track Shoe width | |
| 600 mm | 600 mm |
| Ground bearing pressure | |
| 69.6 kPa | NA |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 35 ° / 70% | NA |
| Travel Speed-Low | |
| 3.1 Km/h | NA |
| Travel Speed-High | |
| 5.0 Km/h | NA |
| Max Tracking Force | |
| 313.9 kN | NA |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Hydraulic pump | |
| Variable Displacement Tandem Axis Piston Pumps | NA |
| Maximum Flow | |
| 2 x 315 L/min | 630 L/min |
| Pilot Pump | |
| Gear Pump | Gear Pump |
| Implement Circuit | |
| 34.3 MPa | 35 MPa |
| Swing Circuit | |
| 29.4 MPa | 28 MPa |
| Travel circuit | |
| 34.3 MPa | 35 MPa |
| Pilot circuit | |
| 3.9 MPa | NA |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Fuel tank | |
| 600 L | 600 L |
| Engine Coolant | |
| 25 L | 40 L |
| Engine oil | |
| 26.5 L | 32 L |
| Hydraulic system | |
| 414 L | 423 L |
| Hydraulic tank | |
| 210 L | 186 L |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Operating Weight | |
| 37200 Kg | 42200 Kg |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Boom length | |
| 6450 mm | 6900 mm |
| Arm length | |
| 2650 mm | 2900 mm |
| Max Digging Reach | |
| 10710 mm | NA |
| Max Digging Reach on ground | |
| 10580 mm | 11290 mm |
| Max digging depth | |
| 6820 mm | 7040 mm |
| Max digging height | |
| 10190 mm | 10540 mm |
| Max Dump Height | |
| 7120 mm | NA |
| Max vertical wallcut depth | |
| 6320 mm | 5390 mm |
| Min swing radius | |
| 4620 mm | NA |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 215.7 kN | 235 kN |
| Arm Digging Force | |
| 184.4 kN | 198 kN |
| Swing Speed | |
| 11.2 rpm | 8.27 rpm |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Bucket Capacity | |
| 2.10 m³ | 2.41 m³ |
| Hyundai HX380L | CAT 345 GC |
|---|---|
| Overall Length | |
| 11340 mm | 11620 mm |
| Overall width | |
| 3190 mm | 3340 mm |
| Overall Height | |
| 3760 mm | 3370 mm |
| Overall Height of Cab | |
| 3160 mm | 3230 mm |
| Upper Width | |
| 2980 mm | NA |
| Track Lengh on Ground | |
| 4030 mm | 4040 mm |
| Undercarriage overall length | |
| 4940 mm | 5029 mm |
| Tailswing radius | |
| 3570 mm | 3530 mm |
| Min Ground clearance | |
| 500 mm | 520 mm |
| Track gauge | |
| 2590 mm | 2740 mm |
| Width over tracks | |
| NA | NA |
| Track Height | |
| NA | NA |
| Counterweight Clearence | |
| 1200 mm | 1300 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
