The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Hyundai HX380L | JCB 315LC HD |
|---|
| Particulars | Hyundai HX380L | JCB 315LC HD |
|---|
The Hyundai HX380L and JCB 315LC HD excavators are both robust machines designed for mining and heavy-duty operations. The Hyundai model boasts higher engine power and a larger bucket capacity, while the JCB model offers a lower price point and better high-speed travel performance.
If your priority is engine power and digging capacity for more exhaustive tasks, the Hyundai HX380L may be the better choice, though it comes at a higher cost. However, if budget constraints and travel speed are significant factors, the JCB 315LC HD presents a more economical option with efficient travel capabilities.
| Brand | Hyundai | JCB |
|---|---|---|
| Type | Large (25-50 Ton) | Large (25-50 Ton) |
| Operating Cost | ₹ 1.24- 1.26 Crore | ₹ 1.10-1.12 Crore |
| Price | ₹ 1.24- 1.26 Crore | ₹ 1.10-1.12 Crore |
| Weight | 37200 Kg | 34462 Kg |
| Bucket | 2.10 m³ | 1.24 - 1.80 m³ |
| Max Digging Depth | 6820 mm | 6570 mm |
| Engine | Hyundai 260 HP | JCB 221 HP |
| Warranty | 1 Yr. / 2000 hr. | 1 Yr. / 2000 hr. |
| Boom | 6450 mm | 6200 mm |
| Quick Overview: | Large excavator comprising enhanced durability and high capacity, Hyundai’s HX380L is fabricated for mining and earthmoving. |
Meeting the demand for mining and heavy engineering operations, the durable JCB 315LC HD large excavator is ideal. |
| Agency review | Get the best price for the Hyundai HX380L Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the JCB 315LC HD Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The Hyundai HX380L and JCB 315LC HD excavators are both robust machines designed for mining and heavy-duty operations. The Hyundai model boasts higher engine power and a larger bucket capacity, while the JCB model offers a lower price point and better high-speed travel performance.
If your priority is engine power and digging capacity for more exhaustive tasks, the Hyundai HX380L may be the better choice, though it comes at a higher cost. However, if budget constraints and travel speed are significant factors, the JCB 315LC HD presents a more economical option with efficient travel capabilities.
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Brand | |
| Hyundai | JCB |
| Type | |
| Large (25-50 Ton) | Large (25-50 Ton) |
| Price | |
| ₹ 1.24- 1.26 Crore | ₹ 1.10-1.12 Crore |
| Weight | |
| 37200 Kg | 34462 Kg |
| Bucket | |
| 2.10 m³ | 1.24 - 1.80 m³ |
| Max Digging Depth | |
| 6820 mm | 6570 mm |
| Engine | |
| Hyundai 260 HP | JCB 221 HP |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Yr. / 2000 hr. |
| Boom | |
| 6450 mm | 6200 mm |
| Quick Overview: | |
Large excavator comprising enhanced durability and high capacity, Hyundai’s HX380L is fabricated for mining and earthmoving. |
Meeting the demand for mining and heavy engineering operations, the durable JCB 315LC HD large excavator is ideal. |
| Hyundai HX380L | JCB 315LC HD | |
| Engine Make | Hyundai - HM8.3 | JCB DIESELMAX 672 Mechanical Engine |
| Fuel Tank | 600 L | 590 L |
| Engine Displacment | 8.3 L | 7.2 L |
| Under Carriage | 4940 mm | 4950 mm |
| Hydraulic System | 414 L | 430 L |
| Arm | 2650 mm | 2500 mm |
| Max Digging Reach | 10710 mm | 10150 mm |
| Fuel Consumption | NA | NA |
| Overall Width | 3190 mm | 3070 mm |
| Overall Length | 11340 mm | 10740 mm |
| Bucket Digging Force | 215.7 kN | 221.3 kN |
| Tailswing Radius | 3570 mm | 3210 mm |
| Track Shoe Width | 600 mm | 600 mm |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Engine Make | |
| Hyundai - HM8.3 | JCB DIESELMAX 672 Mechanical Engine |
| Fuel Tank | |
| 600 L | 590 L |
| Engine Displacment | |
| 8.3 L | 7.2 L |
| Under Carriage | |
| 4940 mm | 4950 mm |
| Hydraulic System | |
| 414 L | 430 L |
| Arm | |
| 2650 mm | 2500 mm |
| Max Digging Reach | |
| 10710 mm | 10150 mm |
| Fuel Consumption | |
| NA | NA |
| Overall Width | |
| 3190 mm | 3070 mm |
| Overall Length | |
| 11340 mm | 10740 mm |
| Bucket Digging Force | |
| 215.7 kN | 221.3 kN |
| Tailswing Radius | |
| 3570 mm | 3210 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| 3535 | 3553 | |
| Model | Hyundai 260 HP | JCB 221 HP |
| Fuel | Diesel | Diesel |
| Type | 4 Cycle , 6 Cylinder , Charge Air Cooled , direct injection , Mechanical Control Diesel Engine , Turboharged , Water Cooled | 4- stroke , 6 - cylinder in line , intercooled , mechanical direct injection , turbocharged , Water Cooled |
| Rated Engine Power | 260 HP (194 kW) @ 2200 rpm | 221 HP (165 kW) @ 1800 rpm |
| Maximum Torque | 1150 N.m @1300 rpm | NA |
| Piston Displacement | 8.3 L | 7.2 L |
| Alternator | 24V / 90A | 24V / 55A |
| Battery | 160 Ah , 2 x 12V | 2 x 12V |
| Starting Motor | NA | 24V |
| 24V | 24V | |
| No of Top rollers | 2 | 2 |
| No of bottom rollers | 8 | 9 |
| Track Shoes (Each Side) | 48 | 50 |
| Track Guard | 2 | 2 |
| Track Shoe width | 600 mm | 600 mm |
| Ground bearing pressure | 69.6 kPa | 61.7 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 35 ° / 70% | 70% (35 °) continuous. |
| Travel Speed-Low | 3.1 Km/h | 2.1 Km/h |
| Travel Speed-High | 5.0 Km/h | 5.2 km/h |
| Max Tracking Force | 313.9 kN | 246.3 kN |
| Hyundai HX380L | JCB 315LC HD | |
| Hydraulic pump | Variable Displacement Tandem Axis Piston Pumps | 2 variable displacement axial piston type. Maximum flow |
| Maximum Flow | 2 x 315 L/min | 2 x 250 L/min |
| Pilot Pump | Gear Pump | Gear Pump |
| Implement Circuit | 34.3 MPa | 34.3 MPa |
| Swing Circuit | 29.4 MPa | 29.0 MPa |
| Travel circuit | 34.3 MPa | 34.3 MPa |
| Pilot circuit | 3.9 MPa | 3.9 MPa |
| Hyundai HX380L | JCB 315LC HD | |
| Travel | Two speed axial pistons motor with brake valve & parking brake | Variable swash axial piston type; fully guarded within undercarriage |
| Swing | Axial piston motor with automatic brake | Axial piston type |
| Hyundai HX380L | JCB 315LC HD | |
| Fuel tank | 600 L | 590 L |
| Engine Coolant | 25 L | 32 L |
| Engine oil | 26.5 L | 30 L |
| Hydraulic system | 414 L | 430 L |
| Hydraulic tank | 210 L | 239 L |
| Hyundai HX380L | JCB 315LC HD | |
| Operating Weight | 37200 Kg | 34462 Kg |
| Hyundai HX380L | JCB 315LC HD | |
| Boom length | 6450 mm | 6200 mm |
| Arm length | 2650 mm | 2500 mm |
| Max Digging Reach | 10710 mm | 10150 mm |
| Max Digging Reach on ground | 10580 mm | 9940 mm |
| Max digging depth | 6820 mm | 6570 mm |
| Max digging height | 10190 mm | 9940 mm |
| Max Dump Height | 7120 mm | 6900 mm |
| Max vertical wallcut depth | 6320 mm | 5780 mm |
| Min swing radius | 4620 mm | 4070 mm |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 215.7 kN | 221.3 kN |
| Arm Digging Force | 184.4 kN | 156.2 kN |
| Swing Speed | 11.2 rpm | 9.4 rpm |
| Hyundai HX380L | JCB 315LC HD | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Hyundai HX380L | JCB 315LC HD | |
| Bucket Capacity | 2.10 m³ | 1.24 - 1.80 m³ |
| Hyundai HX380L | JCB 315LC HD | |
| Overall Length | 11340 mm | 10740 mm |
| Overall width | 3190 mm | 3070 mm |
| Overall Height | 3760 mm | 3450 mm |
| Overall Height of Cab | 3160 mm | 3300 mm |
| Upper Width | 2980 mm | NA |
| Track Lengh on Ground | 4030 mm | 3990 mm |
| Undercarriage overall length | 4940 mm | 4950 mm |
| Tailswing radius | 3570 mm | 3210 mm |
| Min Ground clearance | 500 mm | 550 mm |
| Track gauge | 2590 mm | 2600 mm |
| Width over tracks | NA | 3200 mm |
| Track Height | NA | 1030 mm |
| Counterweight Clearance | 1200 mm | 1200 mm |
| Track Shoe Width | 600 mm | 600 mm |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Model | |
| Hyundai 260 HP | JCB 221 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4 Cycle , 6 Cylinder , Charge Air Cooled , direct injection , Mechanical Control Diesel Engine , Turboharged , Water Cooled | 4- stroke , 6 - cylinder in line , intercooled , mechanical direct injection , turbocharged , Water Cooled |
| Rated Engine Power | |
| 260 HP (194 kW) @ 2200 rpm | 221 HP (165 kW) @ 1800 rpm |
| Maximum Torque | |
| 1150 N.m @1300 rpm | NA |
| Piston Displacement | |
| 8.3 L | 7.2 L |
| Alternator | |
| 24V / 90A | 24V / 55A |
| Battery | |
| 160 Ah , 2 x 12V | 2 x 12V |
| Starting Motor | |
| NA | 24V |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| No of Top rollers | |
| 2 | 2 |
| No of bottom rollers | |
| 8 | 9 |
| Track Shoes (Each Side) | |
| 48 | 50 |
| Track Guard | |
| 2 | 2 |
| Track Shoe width | |
| 600 mm | 600 mm |
| Ground bearing pressure | |
| 69.6 kPa | 61.7 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 35 ° / 70% | 70% (35 °) continuous. |
| Travel Speed-Low | |
| 3.1 Km/h | 2.1 Km/h |
| Travel Speed-High | |
| 5.0 Km/h | 5.2 km/h |
| Max Tracking Force | |
| 313.9 kN | 246.3 kN |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Hydraulic pump | |
| Variable Displacement Tandem Axis Piston Pumps | 2 variable displacement axial piston type. Maximum flow |
| Maximum Flow | |
| 2 x 315 L/min | 2 x 250 L/min |
| Pilot Pump | |
| Gear Pump | Gear Pump |
| Implement Circuit | |
| 34.3 MPa | 34.3 MPa |
| Swing Circuit | |
| 29.4 MPa | 29.0 MPa |
| Travel circuit | |
| 34.3 MPa | 34.3 MPa |
| Pilot circuit | |
| 3.9 MPa | 3.9 MPa |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Fuel tank | |
| 600 L | 590 L |
| Engine Coolant | |
| 25 L | 32 L |
| Engine oil | |
| 26.5 L | 30 L |
| Hydraulic system | |
| 414 L | 430 L |
| Hydraulic tank | |
| 210 L | 239 L |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Operating Weight | |
| 37200 Kg | 34462 Kg |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Boom length | |
| 6450 mm | 6200 mm |
| Arm length | |
| 2650 mm | 2500 mm |
| Max Digging Reach | |
| 10710 mm | 10150 mm |
| Max Digging Reach on ground | |
| 10580 mm | 9940 mm |
| Max digging depth | |
| 6820 mm | 6570 mm |
| Max digging height | |
| 10190 mm | 9940 mm |
| Max Dump Height | |
| 7120 mm | 6900 mm |
| Max vertical wallcut depth | |
| 6320 mm | 5780 mm |
| Min swing radius | |
| 4620 mm | 4070 mm |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 215.7 kN | 221.3 kN |
| Arm Digging Force | |
| 184.4 kN | 156.2 kN |
| Swing Speed | |
| 11.2 rpm | 9.4 rpm |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Bucket Capacity | |
| 2.10 m³ | 1.24 - 1.80 m³ |
| Hyundai HX380L | JCB 315LC HD |
|---|---|
| Overall Length | |
| 11340 mm | 10740 mm |
| Overall width | |
| 3190 mm | 3070 mm |
| Overall Height | |
| 3760 mm | 3450 mm |
| Overall Height of Cab | |
| 3160 mm | 3300 mm |
| Upper Width | |
| 2980 mm | NA |
| Track Lengh on Ground | |
| 4030 mm | 3990 mm |
| Undercarriage overall length | |
| 4940 mm | 4950 mm |
| Tailswing radius | |
| 3570 mm | 3210 mm |
| Min Ground clearance | |
| 500 mm | 550 mm |
| Track gauge | |
| 2590 mm | 2600 mm |
| Width over tracks | |
| NA | 3200 mm |
| Track Height | |
| NA | 1030 mm |
| Counterweight Clearence | |
| 1200 mm | 1200 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
