The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|
| Particulars | Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|
The Liebherr R 928 Litronic and the Tata Hitachi EX 350LC Prime are both large excavators designed for mining and heavy-duty excavation. The Liebherr R 928 Litronic offers a balance of performance and operational efficiency with its optimized hydraulic system, while the Tata Hitachi EX 350LC showcases higher power and bucket force suitable for challenging excavation tasks.
When choosing between the two, it comes down to specific requirements of the job. If higher engine power and superior gradeability are crucial, the Tata Hitachi EX 350LC Prime would be the preferred choice. However, if a broader range of bucket capacities and fuel efficiency are more important for your operation, then the Liebherr R 928 Litronic may be the better option, provided its unlisted maximum digging reach meets the job's demands.
| Brand | Tata Hitachi | Liebherr |
|---|---|---|
| Type | Large (25-50 Ton) | Large (25-50 Ton) |
| Operating Cost | Price Available Soon | Price Available Soon |
| Price | Price Available Soon | Price Available Soon |
| Weight | 33800 Kg | 28750 Kg |
| Bucket | 1.3 - 2.0 m³ | 0.55 - 1.75 m³ |
| Max Digging Depth | 6353 mm | 6910 mm |
| Engine | Cummins 60 HP | Liebherr 204 HP |
| Warranty | 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | 6200 mm | 6000 mm |
| Quick Overview: | With exceptional power and efficiency, Tata Hitachi EX 350 LC Prime is a large excavator built for mining and heavy-duty excavation. |
Catering to demanding mining activities and earthmoving operations Liebherr R 928 Litronic large excavator is best fit due to high-capacity performance. |
| Agency review | Get the best price for the Tata Hitachi EX350LC Prime Large Excavator from authorized dealers. Contact us now for exclusive deals! |
Get the best price for the Liebherr R 928 Litronic Large Excavator from authorized dealers. Contact us now for exclusive deals! |
The Liebherr R 928 Litronic and the Tata Hitachi EX 350LC Prime are both large excavators designed for mining and heavy-duty excavation. The Liebherr R 928 Litronic offers a balance of performance and operational efficiency with its optimized hydraulic system, while the Tata Hitachi EX 350LC showcases higher power and bucket force suitable for challenging excavation tasks.
When choosing between the two, it comes down to specific requirements of the job. If higher engine power and superior gradeability are crucial, the Tata Hitachi EX 350LC Prime would be the preferred choice. However, if a broader range of bucket capacities and fuel efficiency are more important for your operation, then the Liebherr R 928 Litronic may be the better option, provided its unlisted maximum digging reach meets the job's demands.
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Brand | |
| Tata Hitachi | Liebherr |
| Type | |
| Large (25-50 Ton) | Large (25-50 Ton) |
| Price | |
| Price Available Soon | Price Available Soon |
| Weight | |
| 33800 Kg | 28750 Kg |
| Bucket | |
| 1.3 - 2.0 m³ | 0.55 - 1.75 m³ |
| Max Digging Depth | |
| 6353 mm | 6910 mm |
| Engine | |
| Cummins 60 HP | Liebherr 204 HP |
| Warranty | |
| 1 Yr. / 2000 hr. | 1 Yr. / 2500 hr. |
| Boom | |
| 6200 mm | 6000 mm |
| Quick Overview: | |
With exceptional power and efficiency, Tata Hitachi EX 350 LC Prime is a large excavator built for mining and heavy-duty excavation. |
Catering to demanding mining activities and earthmoving operations Liebherr R 928 Litronic large excavator is best fit due to high-capacity performance. |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Engine Make | Cummins QSB 6.7 | Liebherr D934 A7-23 |
| Fuel Tank | 560 L | 620 L |
| Engine Displacment | 6.702 L | 7.0 L |
| Under Carriage | 4950 mm | 4840 mm |
| Hydraulic System | 298.0 L | 475 L |
| Arm | 2300 mm | 3000 mm |
| Max Digging Reach | 10119 mm | NA |
| Fuel Consumption | NA | 16.92 L/hour |
| Overall Width | 3190 mm | 3190 mm |
| Overall Length | 11130 mm | 10100 mm |
| Bucket Digging Force | 217 kN | 187 kN |
| Tailswing Radius | 3590 mm | 3200 mm |
| Track Shoe Width | 600 mm | 600 mm |
| AC Cabin | Standard | Standard |
| GPS | Standard | Standard |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Engine Make | |
| Cummins QSB 6.7 | Liebherr D934 A7-23 |
| Fuel Tank | |
| 560 L | 620 L |
| Engine Displacment | |
| 6.702 L | 7.0 L |
| Under Carriage | |
| 4950 mm | 4840 mm |
| Hydraulic System | |
| 298.0 L | 475 L |
| Arm | |
| 2300 mm | 3000 mm |
| Max Digging Reach | |
| 10119 mm | NA |
| Fuel Consumption | |
| NA | 16.92 L/hour |
| Overall Width | |
| 3190 mm | 3190 mm |
| Overall Length | |
| 11130 mm | 10100 mm |
| Bucket Digging Force | |
| 217 kN | 187 kN |
| Tailswing Radius | |
| 3590 mm | 3200 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
| AC Cabin | |
| Standard | Standard |
| GPS | |
| Standard | Standard |
| 8880 | 3703 | |
| Model | Cummins 60 HP | Liebherr 204 HP |
| Fuel | Diesel | Diesel |
| Type | 4 cycle electronic engine. , 6 Cylinder , In-line | 4 Cylinder in-line , 4-stroke diesel Common-Rail Turbo-charged and after-cooler , after-cooled and fuel cooled , Engine equivalent to EU Stage IIIA / EPA Tier 3: with EGR , Water-cooled and oil cooler |
| Rated Engine Power | 260 HP (194 kW) @ 2200 rpm | 204 HP (150 kW) @ 1800 rpm |
| Maximum Torque | 1100 Nm @ 1300 rpm | 1245 Nm @ 1100 rpm |
| Piston Displacement | 6.702 L | 7.0 L |
| Alternator | NA | 24 V / 140 A |
| Battery | 2 x 12 V | 12 V , 2 x 135 Ah |
| Starting Motor | NA | NA |
| NA | NA | |
| No of Top rollers | 2 | 2 |
| No of bottom rollers | 8 | 9 |
| Track Shoes (Each Side) | 48 | NA |
| Track Guard | 3 | NA |
| Track Shoe width | 600 mm | 600 mm |
| Ground bearing pressure | 63 kPa | 54.9 kPa |
| Track Tensioning | Grease | Grease |
| Gradeability | 70% Continuous (35°) | NA |
| Travel Speed-Low | 3.0 Km/h | 3.5 Km/h |
| Travel Speed-High | 4.6 Km/h | 5.8 Km/h |
| Max Tracking Force | 273 kN | 261 kN |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Hydraulic pump | 2 Variable displacement axial piston pumps. | Liebherr swashplate double pump and variable displacement |
| Maximum Flow | 2 x 273 L/min | 2 x 265 L/min |
| Pilot Pump | 1 Gear Pump | NA |
| Implement Circuit | 31.9 MPa | 38.0 MPa |
| Swing Circuit | 29.5 MPa | NA |
| Travel circuit | 31.9 MPa | NA |
| Pilot circuit | 3.9 MPa | NA |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Travel | 2 Variable displacements axial piston pumps | Liebherr swashplate motor with brake valves on both sides |
| Swing | 1 Axial Piston Motor | Liebherr swashplate motor with integrated brake valve and torque control |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Fuel tank | 560 L | 620 L |
| Engine Coolant | 65.0 L | NA |
| Engine oil | 25.0 L | NA |
| Hydraulic system | 298.0 L | 475 L |
| Hydraulic tank | 179.0 L | 239 L |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Operating Weight | 33800 Kg | 28750 Kg |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Boom length | 6200 mm | 6000 mm |
| Arm length | 2300 mm | 3000 mm |
| Max Digging Reach | 10119 mm | NA |
| Max Digging Reach on ground | 9898 mm | 10010 mm |
| Max digging depth | 6353 mm | 6910 mm |
| Max digging height | 9534 mm | 9780 mm |
| Max Dump Height | 3603 mm | 7000 mm |
| Max vertical wallcut depth | 4505 mm | NA |
| Min swing radius | 4372 mm | NA |
| Max Height at Min Swing radius | NA | NA |
| Max height (above ground) | NA | NA |
| Dig depth (below ground) | NA | NA |
| Bucket Digging Force | 217 kN | 187 kN |
| Arm Digging Force | 209 kN | 134 kN |
| Swing Speed | 10.1 rpm | 10.1 rpm |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Dozer Type | NA | NA |
| Dozer Length | NA | NA |
| Digging depth for ground level | NA | NA |
| Approach Angle | NA | NA |
| Width | NA | NA |
| Height | NA | NA |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Bucket Capacity | 1.3 - 2.0 m³ | 0.55 - 1.75 m³ |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic | |
| Overall Length | 11130 mm | 10100 mm |
| Overall width | 3190 mm | 3190 mm |
| Overall Height | 3500 mm | 3150 mm |
| Overall Height of Cab | 3280 mm | 3150 mm |
| Upper Width | 2980 mm | 2990 mm |
| Track Lengh on Ground | 4050 mm | 3990 mm |
| Undercarriage overall length | 4950 mm | 4840 mm |
| Tailswing radius | 3590 mm | 3200 mm |
| Min Ground clearance | 440 mm | 505 mm |
| Track gauge | 2590 mm | 2590 mm |
| Width over tracks | 3190 mm | 3190 mm |
| Track Height | 1080 mm | 1055 mm |
| Counterweight Clearance | 1170 mm | 1175 mm |
| Track Shoe Width | 600 mm | 600 mm |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Model | |
| Cummins 60 HP | Liebherr 204 HP |
| Fuel | |
| Diesel | Diesel |
| Type | |
| 4 cycle electronic engine. , 6 Cylinder , In-line | 4 Cylinder in-line , 4-stroke diesel Common-Rail Turbo-charged and after-cooler , after-cooled and fuel cooled , Engine equivalent to EU Stage IIIA / EPA Tier 3: with EGR , Water-cooled and oil cooler |
| Rated Engine Power | |
| 260 HP (194 kW) @ 2200 rpm | 204 HP (150 kW) @ 1800 rpm |
| Maximum Torque | |
| 1100 Nm @ 1300 rpm | 1245 Nm @ 1100 rpm |
| Piston Displacement | |
| 6.702 L | 7.0 L |
| Alternator | |
| NA | 24 V / 140 A |
| Battery | |
| 2 x 12 V | 12 V , 2 x 135 Ah |
| Starting Motor | |
| NA | NA |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| No of Top rollers | |
| 2 | 2 |
| No of bottom rollers | |
| 8 | 9 |
| Track Shoes (Each Side) | |
| 48 | NA |
| Track Guard | |
| 3 | NA |
| Track Shoe width | |
| 600 mm | 600 mm |
| Ground bearing pressure | |
| 63 kPa | 54.9 kPa |
| Track Tensioning | |
| Grease | Grease |
| Gradeability | |
| 70% Continuous (35°) | NA |
| Travel Speed-Low | |
| 3.0 Km/h | 3.5 Km/h |
| Travel Speed-High | |
| 4.6 Km/h | 5.8 Km/h |
| Max Tracking Force | |
| 273 kN | 261 kN |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Hydraulic pump | |
| 2 Variable displacement axial piston pumps. | Liebherr swashplate double pump and variable displacement |
| Maximum Flow | |
| 2 x 273 L/min | 2 x 265 L/min |
| Pilot Pump | |
| 1 Gear Pump | NA |
| Implement Circuit | |
| 31.9 MPa | 38.0 MPa |
| Swing Circuit | |
| 29.5 MPa | NA |
| Travel circuit | |
| 31.9 MPa | NA |
| Pilot circuit | |
| 3.9 MPa | NA |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Fuel tank | |
| 560 L | 620 L |
| Engine Coolant | |
| 65.0 L | NA |
| Engine oil | |
| 25.0 L | NA |
| Hydraulic system | |
| 298.0 L | 475 L |
| Hydraulic tank | |
| 179.0 L | 239 L |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Operating Weight | |
| 33800 Kg | 28750 Kg |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Boom length | |
| 6200 mm | 6000 mm |
| Arm length | |
| 2300 mm | 3000 mm |
| Max Digging Reach | |
| 10119 mm | NA |
| Max Digging Reach on ground | |
| 9898 mm | 10010 mm |
| Max digging depth | |
| 6353 mm | 6910 mm |
| Max digging height | |
| 9534 mm | 9780 mm |
| Max Dump Height | |
| 3603 mm | 7000 mm |
| Max vertical wallcut depth | |
| 4505 mm | NA |
| Min swing radius | |
| 4372 mm | NA |
| Max Height at Min Swing radius | |
| NA | NA |
| Max height (above ground) | |
| NA | NA |
| Dig depth (below ground) | |
| NA | NA |
| Bucket Digging Force | |
| 217 kN | 187 kN |
| Arm Digging Force | |
| 209 kN | 134 kN |
| Swing Speed | |
| 10.1 rpm | 10.1 rpm |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Dozer Type | |
| NA | NA |
| Dozer Length | |
| NA | NA |
| Digging depth for ground level | |
| NA | NA |
| Approach Angle | |
| NA | NA |
| Width | |
| NA | NA |
| Height | |
| NA | NA |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Bucket Capacity | |
| 1.3 - 2.0 m³ | 0.55 - 1.75 m³ |
| Tata Hitachi EX 350LC Prime | Liebherr R 928 Litronic |
|---|---|
| Overall Length | |
| 11130 mm | 10100 mm |
| Overall width | |
| 3190 mm | 3190 mm |
| Overall Height | |
| 3500 mm | 3150 mm |
| Overall Height of Cab | |
| 3280 mm | 3150 mm |
| Upper Width | |
| 2980 mm | 2990 mm |
| Track Lengh on Ground | |
| 4050 mm | 3990 mm |
| Undercarriage overall length | |
| 4950 mm | 4840 mm |
| Tailswing radius | |
| 3590 mm | 3200 mm |
| Min Ground clearance | |
| 440 mm | 505 mm |
| Track gauge | |
| 2590 mm | 2590 mm |
| Width over tracks | |
| 3190 mm | 3190 mm |
| Track Height | |
| 1080 mm | 1055 mm |
| Counterweight Clearence | |
| 1170 mm | 1175 mm |
| Track Shoe Width | |
| 600 mm | 600 mm |
