The CASE 451 NX Mini Tandem Roller, also called a mini roller compactor or baby roller, is designed for asphalt and soil compaction in confined worksites. Powered by a reliable engine with a 2,900 kg operating weight and efficient vibratory roller system, it delivers up to 43 kN force for smooth, uniform results. This mini road roller combines hydrostatic articulation with excellent maneuverability, ensuring productivity in urban and highway projects. Equipped with ergonomic controls, ROPS canopy, rust-proof tanks, and smart water sprinkling, the CASE roller is a trusted for durability, efficiency, and long-term performance.
CASE
Tandem Roller
₹ 18-20 Lakhs
₹ 18-20 Lakhs
2900 kg
1000 mm
M&M 25 HP
14.8/14.2 kg/cm
28.43/16.20 kN
0 - 9 km/hr
Looking for the best CASE 450NX Mini Roller price in India? Connect with us today and unlock exclusive offers on this reliable road roller!
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Please fil the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Mahindra & Mahindra 275DI
38 L
40 L
61/46 Hz
0.5 mm
35%
± 27°
NA
1925 mm
150 L
2871 mm
1184 mm
2697 mm
Standard
1 Year
Optimized machine weight and repowering with 18.5 KW CEV Stage V engine, with mechanical fuel pump ensures peace of mind
Intelligent hydraulic system and 25HP engine delivers high efficiency than CEV-V 45hp models.
Well protected rust proof plastic fuel tank with lockable cap
Powered by M&M 275DI mechanical engine
180+ years of legacy, delivering breakthrough technology
Compact design for hassle-free maintenance
Single piece openable engine hood with provision to lock
Engine and all serviceable parts are easily accessible
Ease of accessibility of Hydraulic pumps, Valve block, from Hood opening.
Gas strut assisted engine hood for ease of lifting and serviceability
Enhanced monitoring and streamlined operations with my CASE Construction Telematics
Boosted productivity through efficient resource allocation with fleet management
Improved safety and security with advanced tracking and recovery capabilities
Real-time data and downtime reduction for superior customer service
Data-driven decision-making to increase profitability
Two post foldable ROPS structure for better visibility and ease of ingress/egress
Electro Magnetic Immunity and compliance
Both sides rear-view mirror
Excellent visibility of drum edges thanks to optimized width
New ergonomic footsteps
New operator station with newly designed controls and speed settings
Best in class ergonomically designed comfortable seat with adjustable arm rest and high back-rest
Wide canopy for better sun and rain protection
High backrest seat with mechanical suspension with adjustments such as weight setting, backrest incline, arm rest position, forward and backward movement.
Compact contemporary looks
New robust frame suitable for confined space
New intuitive instrument cluster with Vandal Guard
Plastic water tank with strainer/filler for clean water, rust free for lifetime, 150L big size.
Plastic fuel tanks with strainer and lockable cap, rust free for lifetime, Vandalism protection from all sides. Ground level filling ease.
The vehicle experiences reduced noise pollution due to the engine fan being positioned at the front
Fuel level gauge on cluster and low water level sensor
Standard drum width of 1 m for ease of maneuverability
Optimized machine weight and repowering with 18.5 KW CEV Stage V engine, with mechanical fuel pump ensures peace of mind
Intelligent hydraulic system and 25HP engine delivers high efficiency than CEV-V 45hp models.
Well protected rust proof plastic fuel tank with lockable cap
Powered by M&M 275DI mechanical engine
180+ years of legacy, delivering breakthrough technology
Compact design for hassle-free maintenance
Single piece openable engine hood with provision to lock
Engine and all serviceable parts are easily accessible
Ease of accessibility of Hydraulic pumps, Valve block, from Hood opening.
Gas strut assisted engine hood for ease of lifting and serviceability
Enhanced monitoring and streamlined operations with my CASE Construction Telematics
Boosted productivity through efficient resource allocation with fleet management
Improved safety and security with advanced tracking and recovery capabilities
Real-time data and downtime reduction for superior customer service
Data-driven decision-making to increase profitability
Two post foldable ROPS structure for better visibility and ease of ingress/egress
Electro Magnetic Immunity and compliance
Both sides rear-view mirror
Excellent visibility of drum edges thanks to optimized width
New ergonomic footsteps
New operator station with newly designed controls and speed settings
Best in class ergonomically designed comfortable seat with adjustable arm rest and high back-rest
Wide canopy for better sun and rain protection
High backrest seat with mechanical suspension with adjustments such as weight setting, backrest incline, arm rest position, forward and backward movement.
Compact contemporary looks
New robust frame suitable for confined space
New intuitive instrument cluster with Vandal Guard
Plastic water tank with strainer/filler for clean water, rust free for lifetime, 150L big size.
Plastic fuel tanks with strainer and lockable cap, rust free for lifetime, Vandalism protection from all sides. Ground level filling ease.
The vehicle experiences reduced noise pollution due to the engine fan being positioned at the front
Fuel level gauge on cluster and low water level sensor
Standard drum width of 1 m for ease of maneuverability
Product specification of CASE 450NX Compactor
Model
Mahindra & Mahindra 275DI
Type
CEV Emission Stage-V, Liquid Cooled
Max. Power
25 HP (18.5 kW) @ 2200 rpm
Displacement
2.048 L
Max. Torque
130 Nm @ 1200 rpm
Battery
12V
Fuel Tank
38 L
Hydraulic Tank
40 L
Engine Oil
5 L
Engine Coolant
6.8 L
Max. Travel Speed
0 - 9 km/hr
Max. Working Speed
0 - 9 km/hr
Max Gradeability with Vibration
35%
Centrifugal Force (High/Low)
28.43/16.20 kN
Nominal Amplitude - High/Low
0.5 mm
Frequency High/Low
61/46 Hz
Vibration Stages
2
Static Linear Load (Front/Rear)
14.8/14.2 kg/cm
Travel System
Hydrostatic drive acting on both drums with tank mounted type axial-piston variable displacement pump
Vibration System
Tank mounted fixed-displacement gear pump supplying flow to exciter gear motors
Type
Hydrostatic (Center Point Articulation)
Steering Angle
± 27°
Oscillation
±10°
Service
Hydrostatic
Parking
Spring applied, hydraulically released
Type
Pressurized water sprinkler system.
Water Tank
150 L
Operating Weight
2900 kg
Max. Operating Weight
NA
Front Axle Load
1480 kg
Rear Axle Load
1420 kg
Wheelbase
1925 mm
Overall Width
1184 mm
Overall Height
2697 mm
Height (Top of Steering)
1827 mm
Overall Length
2871 mm
Drum Width
1000 mm
Drum Diameter
700 mm
Drum Shell Thickness
12 mm
Ground Clearance
307 mm
Curb Clearance
560 mm
Turning radius, Outside
NA
Turning radius, Inside
3320 mm
The CASE 450NX compactor price in India ranges between ₹ 18 – 20 Lakhs. The final CASE 450NX on-road price in India may vary based on state taxes, dealer location, and optional features.
You can buy the CASE 450NX Tandem Roller from Desi Machines, your trusted platform for construction and heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the road roller you want, or contact us directly for expert assistance and competitive pricing.
The operating weight of the CASE 450NX compactor is approximately 2900 kg. The weight may vary slightly depending on specific configurations and attachments.
The drum width of the CASE 450NX compactor is 1000 mm.
The CASE 450NX compactor is powered by a Mahindra & Mahindra 275DI CEV Emission Stage-V engine, delivering 25 HP (18.5 kW) @ 2200 RPM.
The CASE 450NX has a 38 litres diesel fuel tank, providing extended operation time without frequent refuelling.
The CASE 450NX compactor has a turning radius of 3320 mm inner.
The CASE 450NX tandem roller uses hydrostatic steering with center point articulation.
The CASE 450NX compactor typically comes with a 1-year standard warranty. The warranty covers defects from faulty materials or workmanship, but terms may vary. For accurate details, check with authorized dealers, OEMs, or visit the official brand website.
You can find genuine spare parts for the CASE 450NX compactor at authorized CASE dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers and assist you in getting the best deals based on your location. Fill out the form now to get the best offers on compactor spare parts.
