The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | ACE F210 | Escorts HYDRA 1565 |
|---|
| Particulars | ACE F210 | Escorts HYDRA 1565 |
|---|
| Brand | ACE Crane | Escorts Kubota Crane |
|---|---|---|
| Type | Pick & Carry Crane | Pick & Carry Crane |
| Ex-Showroom Price | ₹ 41 - 43 Lakhs | ₹ 21 - 24 Lakhs |
| Lift Capacity | 20 Tonnes | 15 Tonnes |
| Boom Height | 20.1 m | 21.5 m |
| Engine | VECV 101 HP | Escorts Kubota 50 HP |
| Weight | 19855 kg | 13295 kg |
| Turning Radius | 7600 mm | 7000 mm |
| Drive Type | 4 Wheel Drive | 2 Wheel drive |
| Quick Overview: | Known for precision, the ACE F210 Hydra crane provides 20-ton lift capacity, aiding infrastructure and metro segment placement work. |
The Escorts Hydra 1565 offers a 15-ton lifting capacity and is a strong lift-and-carry option designed for heavy construction and industrial handling tasks. It is powered by a 50 hp Escorts Kubota CEV Stage V diesel engine that provides 217 Nm of torque for steady output and good fuel efficiency. The crane has a slotted telescopic boom with a maximum boom height of 21.5 meters, with a fly jib and a wide luffing range for accurate load placement. Its strong operating weight, high stability, and reliable hydraulics make it a dependable choice for a 15 ton hydra crane in daily site operations. |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Brand | |
| ACE Crane | Escorts Kubota Crane |
| Type | |
| Pick & Carry Crane | Pick & Carry Crane |
| Ex-Showroom Price | |
| ₹ 41 - 43 Lakhs | ₹ 21 - 24 Lakhs |
| Lift Capacity | |
| 20 Tonnes | 15 Tonnes |
| Boom Height | |
| 20.1 m | 21.5 m |
| Engine | |
| VECV 101 HP | Escorts Kubota 50 HP |
| Weight | |
| 19855 kg | 13295 kg |
| Turning Radius | |
| 7600 mm | 7000 mm |
| Drive Type | |
| 4 Wheel Drive | 2 Wheel drive |
| Quick Overview: | |
Known for precision, the ACE F210 Hydra crane provides 20-ton lift capacity, aiding infrastructure and metro segment placement work. |
The Escorts Hydra 1565 offers a 15-ton lifting capacity and is a strong lift-and-carry option designed for heavy construction and industrial handling tasks. It is powered by a 50 hp Escorts Kubota CEV Stage V diesel engine that provides 217 Nm of torque for steady output and good fuel efficiency. The crane has a slotted telescopic boom with a maximum boom height of 21.5 meters, with a fly jib and a wide luffing range for accurate load placement. Its strong operating weight, high stability, and reliable hydraulics make it a dependable choice for a 15 ton hydra crane in daily site operations. |
| ACE F210 | Escorts HYDRA 1565 | |
| Engine Make | Volvo Eicher E483 CRDI (CEV Stage IV) | Escorts Kubota E4.391NA |
| Articulation | 40° | Up to 48° |
| Max. Speed | 38 km/h | 29 km/h |
| Fuel Tank | NA | 38 L |
| Hydraulic Tank | NA | 65 L |
| Overall Length | NA | 10800 mm |
| Overall Width | 2500 mm | 2550 mm |
| Wheelbase | 4300 mm | 4880 mm |
| Boom Luffing Range | -7° to +70° | -5° to + 63° |
| Warranty | 1 Year | 1 Year |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Engine Make | |
| Volvo Eicher E483 CRDI (CEV Stage IV) | Escorts Kubota E4.391NA |
| Articulation | |
| 40° | Up to 48° |
| Max. Speed | |
| 38 km/h | 29 km/h |
| Fuel Tank | |
| NA | 38 L |
| Hydraulic Tank | |
| NA | 65 L |
| Overall Length | |
| NA | 10800 mm |
| Overall Width | |
| 2500 mm | 2550 mm |
| Wheelbase | |
| 4300 mm | 4880 mm |
| Boom Luffing Range | |
| -7° to +70° | -5° to + 63° |
| Warranty | |
| 1 Year | 1 Year |
| ACE F210 | Escorts HYDRA 1565 | |
| Engine Make | Volvo Eicher E483 CRDI (CEV Stage IV) | Escorts Kubota E4.391NA |
| Engine Type | 4 cylinder water cooled diesel engine; Turbo Charged Engine with Electronic Control Unit | 4 Cylinders (3.9 L); Naturally Aspirated Electronic; Common Rail Direct Injection; CEV-V diesel engine |
| Max Power | 101 HP (74 kW) @ 2200 RPM | 50 HP (37 kW) @ 2200 RPM |
| Battery | 12V; Negative earth; 100Ah | 12V; Negative earth; 88Ah |
| Alternator | NA | NA |
| ACE F210 | Escorts HYDRA 1565 | |
| Max. Lifting Capacity | 20 Tonnes | 15 Tonnes |
| ACE F210 | Escorts HYDRA 1565 | |
| Drive | 4 Wheel Drive | 2 Wheel drive |
| Type | Heavy-duty; synchromesh transmission with 10 forward and 2 reverse speeds. Auxiliary Gear Box with Hi/Low & 2WD/4WD Selector | Heavy duty transmission especially developed for crane application; constant mesh gearbox coupled with straight drive axle; 8F & 2R speeds with high/low selector lever |
| ACE F210 | Escorts HYDRA 1565 | |
| Steering Type | Full power orbitrol with twin hydraulic double acting cylinders | Articulated power steering hydraulically controlled through 2 hydraulic jacks |
| Articulation | 40° | Up to 48° |
| Turning Radius | 7600 mm | 7000 mm |
| ACE F210 | Escorts HYDRA 1565 | |
| Hoist | 6 Falls; 3.5 Tonnes Line Pull Winch driven by Hydraulic motor; Rope dia 13 mm fitted with self-adjusting hook block and rope tensioner | 6 Falls; Hydraulic winch 12 t capacity with inbuilt safety brakes; Rope Dia 13 mm |
| Hoist Speed | 35 Mtrs./Min (Line Speed) | NA |
| ACE F210 | Escorts HYDRA 1565 | |
| Front Wheels | Fully pneumatic brakes on front wheels | ‘S’ cam pneumatically actuated drum brakes |
| Rear Wheels | Fully pneumatic brakes on rear wheels | Pneumatically actuated disc brakes |
| Parking Brake | Parking brake is pneumatically operated fail safe type | Hand control valve operated; Air-assisted parking brake at front wheels |
| ACE F210 | Escorts HYDRA 1565 | |
| Engine Oil | NA | NA |
| Fuel Tank | NA | 38 L |
| Hydraulic Tank | NA | 65 L |
| Transmission Oil | NA | NA |
| ACE F210 | Escorts HYDRA 1565 | |
| Overall Length With Bucket | NA | 10800 mm |
| Overall Width | 2500 mm | 2550 mm |
| Overall Height | NA | 3470 mm |
| Wheel Base | 4300 mm | 4880 mm |
| Operating Weight | 19855 kg | 13295 kg |
| Front Track | 1840 mm | 1980 mm |
| Rear Track | 1840 mm | 1680 mm |
| Front Tyres | 12.00 x 20- 18 PR (4 Nos.) | 11 x 20-16 PR (4 Nos.) |
| Rear Tyres | 12.00 x 20- 18 PR (4 Nos.) | 13.00 x 24-12 PR (2 Nos.) |
| ACE F210 | Escorts HYDRA 1565 | |
| Telescoping | Four-part slotted boom with 2 hydraulically operated & synchronized and 4th part powered extended | 4-part; 3 part hydraulically powered & fully synchronized; 4th part power extended & manually pinned |
| Derricking | Through one double-acting extension cylinder | Through double acting jacks |
| Boom Luffing Time | NA | NA |
| Boom Luffing Range | -7° to +70° | -5° to + 63° |
| Boom Height | 20.1 m | 21.5 m |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Engine Make | |
| Volvo Eicher E483 CRDI (CEV Stage IV) | Escorts Kubota E4.391NA |
| Engine Type | |
| 4 cylinder water cooled diesel engine; Turbo Charged Engine with Electronic Control Unit | 4 Cylinders (3.9 L); Naturally Aspirated Electronic; Common Rail Direct Injection; CEV-V diesel engine |
| Max Power | |
| 101 HP (74 kW) @ 2200 RPM | 50 HP (37 kW) @ 2200 RPM |
| Battery | |
| 12V; Negative earth; 100Ah | 12V; Negative earth; 88Ah |
| Alternator | |
| NA | NA |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Max. Lifting Capacity | |
| 20 Tonnes | 15 Tonnes |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Drive | |
| 4 Wheel Drive | 2 Wheel drive |
| Type | |
| Heavy-duty; synchromesh transmission with 10 forward and 2 reverse speeds. Auxiliary Gear Box with Hi/Low & 2WD/4WD Selector | Heavy duty transmission especially developed for crane application; constant mesh gearbox coupled with straight drive axle; 8F & 2R speeds with high/low selector lever |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Steering Type | |
| Full power orbitrol with twin hydraulic double acting cylinders | Articulated power steering hydraulically controlled through 2 hydraulic jacks |
| Articulation | |
| 40° | Up to 48° |
| Turning Radius | |
| 7600 mm | 7000 mm |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Hoist | |
| 6 Falls; 3.5 Tonnes Line Pull Winch driven by Hydraulic motor; Rope dia 13 mm fitted with self-adjusting hook block and rope tensioner | 6 Falls; Hydraulic winch 12 t capacity with inbuilt safety brakes; Rope Dia 13 mm |
| Hoist Speed | |
| 35 Mtrs./Min (Line Speed) | NA |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Front Wheels | |
| Fully pneumatic brakes on front wheels | ‘S’ cam pneumatically actuated drum brakes |
| Rear Wheels | |
| Fully pneumatic brakes on rear wheels | Pneumatically actuated disc brakes |
| Parking Brake | |
| Parking brake is pneumatically operated fail safe type | Hand control valve operated; Air-assisted parking brake at front wheels |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Engine Oil | |
| NA | NA |
| Fuel Tank | |
| NA | 38 L |
| Hydraulic Tank | |
| NA | 65 L |
| Transmission Oil | |
| NA | NA |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Overall Length With Bucket | |
| NA | 10800 mm |
| Overall Width | |
| 2500 mm | 2550 mm |
| Overall Height | |
| NA | 3470 mm |
| Wheel Base | |
| 4300 mm | 4880 mm |
| Operating Weight | |
| 19855 kg | 13295 kg |
| Front Track | |
| 1840 mm | 1980 mm |
| Rear Track | |
| 1840 mm | 1680 mm |
| Front Tyres | |
| 12.00 x 20- 18 PR (4 Nos.) | 11 x 20-16 PR (4 Nos.) |
| Rear Tyres | |
| 12.00 x 20- 18 PR (4 Nos.) | 13.00 x 24-12 PR (2 Nos.) |
| ACE F210 | Escorts HYDRA 1565 |
|---|---|
| Telescoping | |
| Four-part slotted boom with 2 hydraulically operated & synchronized and 4th part powered extended | 4-part; 3 part hydraulically powered & fully synchronized; 4th part power extended & manually pinned |
| Derricking | |
| Through one double-acting extension cylinder | Through double acting jacks |
| Boom Luffing Time | |
| NA | NA |
| Boom Luffing Range | |
| -7° to +70° | -5° to + 63° |
| Boom Height | |
| 20.1 m | 21.5 m |
