XCMG XE20U Mini Excavator is compact and powerful, ideal for landscaping, small construction, and agricultural applications.
XCMG
Mini (0-6 Ton)
₹ 22 - 24 Lakhs
₹ 22 - 24 Lakhs
1800 Kg
0.04 m³
2290 mm
Kubota 13.2 HP
1 Yr. / 2500 hr.
1828 mm
Get the best price for the XCMG XE20U Mini Excavator from authorized dealers. Contact us now for exclusive deals!
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Please fil the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Kubota D782
17 L
0.778 L
1630 mm
1 x 57.5 L/min
950 mm
3900 mm
NA
990 mm / 1240 mm
3560 mm
NA
620 mm
230 mm
Not Available
Not Available
Reinforced Boom, Arm and Bucket for Tough Indian Conditions
Wear Resistance Buckets
Ground Accessible Maintenance Points
Fast and Easy Maintenance thus Saving Time
Expandable / Retractable Track for Space Restricted Areas - First in Indian Industry
Optimum Ground Pressure suitable for all applications
Enhanced Grip for Loose Surface
Efficient Kubota Engine ensures Optimum Power
Low Fuel Consumption and High Reliability
Smart Hydraulics with Quicker Response & Precise Control
Power of Engine and Hydraulic ensure improved Fuel Utilisation
Best in class Pump flow for Maximum working efficiency
All Around 360 degree visibility
Newly Designed Arm rest, Seat for Convenience of Operation
Large LCD Display for Quick Machine Preview
Product specification of XCMG XE20U Excavator
Model
Kubota D782
Fuel
Diesel
Type
3 cylinder , four stroke water cooled
Rated Engine Power
13.2 HP (9.9 kW) @ 2300 rpm
Maximum Torque
44.5 Nm @ 1800 rpm
Piston Displacement
0.778 L
Alternator
NA
Battery
NA
Starting Motor
NA
No of Top Rollers
1
No of Bottom Rollers
3
Track Shoes (Each Side)
38
Track Guard
NA
Track Shoe Width
230 mm
Ground Bearing Pressure
NA
Track Tensioning
Grease
Gradeability
30°
Travel Speed-Low
NA
Travel Speed-High
3.0 Km/h
Max Tracking Force
15.6 kN
Hydraulic Pump
1 Variable Displacement Axial Piston Pump
Maximum Flow
1 x 57.5 L/min
Pilot Pump
NA
Implement Circuit
25.3 MPa
Swing Circuit
11 MPa
Travel Circuit
21 MPa
Pilot Circuit
3.5 MPa
Travel
NA
Swing
NA
Fuel Tank
17 L
Engine Coolant
4 L
Engine Oil
3.8 L
Hydraulic System
26 L
Hydraulic Tank
18 L
Operating Weight
1800 Kg
Boom Length
1828 mm
Arm Length
950 mm
Max. Digging Reach
3900 mm
Max. Digging Reach on Ground
NA
Max. Digging Depth
2290 mm
Max. Digging Height
3475 mm
Max. Dumping Height
2415 mm
Max. Vertical Wallcut Depth
1750 mm
Min. Swing Radius
1550 mm
Max. Height at Min Swing Radius
NA
Max. Height (Above Ground)
NA
Dig Depth (Below Ground)
NA
Bucket Digging Force
NA
Arm Digging Force
NA
Swing Speed
9 rpm
Dozer Type
NA
Dozer Length
NA
Digging Depth for Ground Level
180 mm
Vertical Lift from Ground level
260 mm
Approach Angle
NA
Width
NA
Height
NA
Bucket Capacity
0.04 m³
Overall Length
3560 mm
Overall Width
990 mm / 1240 mm
Overall Height
2350 mm
Overall Height of Cab
NA
Upper Width
990 mm
Track Lengh on Ground
1270 mm
Undercarriage Overall Length
1630 mm
Tailswing Radius
620 mm
Min. Ground Clearance
145 mm
Track Gauge
760 mm / 1010 mm
Width Over Tracks
990 mm / 1240 mm
Track Height
380 mm
Counterweight Clearence
450 mm
Track Shoe Width
230 mm
The XCMG XE20U Excavator price in India ranges between ₹ 22 – 24 Lakhs. However, the exact price may vary depending on the location, dealer, taxes, and additional features.
You can buy the XCMG XE20U excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.
Yes, the XCMG XE20U comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.
The operating weight of the XCMG XE20U excavator is approximately 1800 Kg. The operating weight may vary slightly depending on specific configurations and attachments.
The XCMG XE20U excavator is powered by a Kubota D782 engine, delivering 13.2 HP (9.9 kW) at 2300 rpm.
The XCMG XE20U excavator has a maximum digging depth of 2290 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.
The bucket capacity of the XCMG XE20U Excavator is 0.04 cubic meters (m³).
The XCMG XE20U Excavator in India typically comes with a standard warranty of 1 year or 2500 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.
You can find genuine spare parts for the XCMG XE20U excavator at authorized XCMG dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.
The XCMG XE20U excavator has a 17 litres diesel fuel tank, providing extended operation time without frequent refueling.
XCMG is a well-known construction and mining equipment brand that has been steadily gaining trust across India. Contractors value XCMG machines for their durability, practical design, and reliable performance on real job sites. The company offers excavators, loaders, graders, cranes, and road construction equipment suited for Indian conditions. With growing local support, service reach, and parts availability, XCMG continues to be a dependable choice for infrastructure and earthmoving projects.
