    Liebherr L580 Wheel Loader

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    • Brand

      Liebherr

    • Type

      Medium (15-30 Ton)

    • Operating Cost

      Price Available Soon

    • Ex-Showroom Price

      Price Available Soon

    • Engine

      John Deere 298 HP

    • featIcon2 (1) alt
      Bucket

      5.2 m³

    • icon alt1
      Weight

      26950 kg

    • Fwd. Speed

      40 km/h

    • dumping height loader
      Dump Height

      3300 mm

    • tipping load
      Tipping Load

      18950 kg

    Quick Overview:

    Robust and fuel-efficient, the Liebherr L580 Wheel Loader meets India’s high-load material handling needs with advanced technology.

    Connect With Us:

    Get the best price for the Liebherr L580 wheel loader from authorized dealers. Contact us now for exclusive deals!

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    Key Highlights

    engine-make-alt
    Engine Make

    John Deere 6090HFL75

    Max Torque

    1228 Nm @ 1600 rpm

    Fuel Tank

    450 L

    Hydraulic System

    290 L/min

    grounding
    Min. Ground Clearance

    465 mm

    desi machines payload
    Payload

    8640 kg

    360 degree
    Steering Angle

    ±38°

    Drive Type

    4-wheel drive (4WD)

    Wheelbase

    3970 mm

    Tyres

    26.5R25 L3

    down
    Max. Breakout Force

    220 kN

    Overall Length

    9545 mm

    Medal Image
    Warranty

    1 Yr. / 2000 hr.

    air-conditioner-alt
    AC Cabin

    Standard

    GPS Tracking
    GPS

    Optional

    Features

    High-Performance Powertrain

    High-Performance Powertrain

    • The Liebherr L580 wheel loader in India offers bulk handling with high torque and big bucket capacity.

    • A long wheelbase provides stability and balance for heavy lifting activities in mining or ports.

    High-Performance Powertrain

    • The Liebherr L580 wheel loader in India offers bulk handling with high torque and big bucket capacity.

    • A long wheelbase provides stability and balance for heavy lifting activities in mining or ports.

    Maintenance-Friendly Design

    • Swing-out fan and modular radiator make cleaning easier and minimize dust accumulation, perfect for Indian industrial environments.

    • Grouped access points enable quicker servicing with less tool changing.

    Rugged Reliability

    • Components built by Liebherr make the L580 last longer in high-pressure applications with fewer breakdowns.

    • Heavy-duty frames mitigate stress and wear with sustained applications.

    Cleaner, Greener Operation

    • Low fuel intake minimizes your environmental footprint and operating expenses over time.

    • The engine is compliant with international emission standards, ideal for environmentally responsible Indian contractors.

    Local Service Support

    • Indian technicians are trained to service the L580, supported by a central warehouse supply of original spare parts.

    • Liebherr service plans enhance machine availability for projects with high demand.

    Tailored Warranty & Care Plans

    • Select one of three CarePack warranty options: Service, Comfort, or Premium, based on your fleet's operational requirements.

    • Extended protection maximizes ROI and provides peace of mind for Indian fleet owners.

    Specifications

    Product specification of Liebherr L580 Wheel Loader

    ENGINE

    • Make

      John Deere 6090HFL75

    • Type

      Water-cooled, turbo charged, intercooled, Electronic Common Rail high-pressure injection

    • Aspiration

      Turbocharged

    • Emission

      Stage II

    • Max. Power

      298 HP (219 kW) @ 2000 rpm

    • Max Torque

      1228 Nm @ 1600 rpm

    • Piston Displacement

      9.0 L

    • No. of Cylinders

      6 Cylinders

    • Battery

      24V / 180Ah

    • Alternator

      24V / 100A

    POWER TRAIN

    • Transmission

      Hydrostatic

    • Drive Type

      4-wheel drive (4WD)

    • Torque Converter

      NA

    BRAKES

    • Service

      Self-locking of the hydrostatic driveline (acting on all four wheels) and additional pumpaccumulator brake system with wet multi- disc brakes (two seperate brake circuits)

    • Parking

      Electro-hydraulically actuated spring-loaded disc brake system on the transmission

    STEERING SYSTEM

    • Type

      Load-sensing articulated steering

    • Steering Angle

      ±38°

    AXLE AND FINAL DRIVE

    • Front Axle Type

      Fixed

    • Rear Axle Type

      Centre pivot, oscillating

    • Oscillation Angle

      ±13°

    SPEED

    • Top Forward Speed

      40 km/h

    • Top Reverse Speed

      NA

    HYDRAULIC SYSTEM

    • System Type

      Load-sensing

    • Pump Type

      Swash plate type variable flow pump

    • Max. Pump Flow

      290 L/min

    • System Pressure

      380 bar

    SERVICE REFILL CAPACITIES

    • Fuel Tank

      450 L

    • Hydraulic System

      280 L

    • Engine Oil

      34 L

    • Cooling System

      55 L

    • Rear Axle Oil

      58 L

    • Front Axle Oil

      58 L

    • Hydraulic Tank

      160 L

    • Transmission Oil

      12.5 L

    • DEF Tank

      20 L

    DIMENSIONS

    • Overall Length With Bucket

      9545 mm

    • Wheel Base

      3970 mm

    • Height Over Cab

      3590 mm

    • Height Over Exhaust

      3315 mm

    • Min. Ground Clearance

      465 mm

    • Width Over Tyres

      2960 mm

    • Wheel Tread

      2230 mm

    • Tyre Size

      26.5R25 L3

    PERFORMANCE

    • Bucket Capacity

      5.2 m³

    • Bucket Width

      3300 mm

    • Payload

      8640 kg

    • Tipping Load Straight

      21650 kg

    • Tipping Load Full Turn

      18950 kg

    • Max. Breakout Force

      220 kN

    • Operating Weight

      26950 kg

    • Maximum Dump Angle

      NA

    • Bucket Roll Back Angle Full Height

      NA

    • Bucket Roll Back At Carry

      NA

    • Bucket Roll Back At Ground Level

      NA

    • Dumping Height, Fully Raised

      3300 mm

    • Dumping Reach, Fully Raised

      1330 mm

    • Max. Hinge Pin Height

      4580 mm

    • Max. Digging Depth

      100 mm

    • Turning Radius Over Tyres

      7300 mm

    • Turning Radius Over Bucket

      8075 mm

    Frequently Asked Question

    01. What is the Liebherr L580 wheel loader price in India?

    Ans.

    The Liebherr L580 wheel loader price in India is available on request. To get the latest on-road price of the Liebherr L580 based on your location, simply fill out the inquiry form. Our team will provide customized pricing and financing options tailored to your region and needs.

    02. Where can I buy the Liebherr L580 wheel loader in India at the best price?

    Ans.

    You can buy the Liebherr L580 wheel loader in India through Desi Machines, the best online platform to compare and purchase construction equipment from verified dealers near you. We connect you with authorized Liebherr dealers across India and help you get multiple price quotes from different vendors , so you can choose the best deal. Simply fill out the inquiry form to receive customized offers, financing options, and real-time availability. Get the latest Liebherr L580 price, compare dealer quotes, and enjoy expert assistance—all in one place.

    03. What is the engine power of the Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 wheel loader is powered by a John Deere 6090HFL75 diesel engine, delivering 298 HP (219 kW) @ 2000 rpm.

    04. What is the operating weight of the Liebherr L580 wheel loader?

    Ans.

    The operating weight of the Liebherr L580 wheel loader is approximately 26950 kg. The operating weight may vary slightly depending on specific configurations and attachments.

    05. What is the fuel tank capacity of the Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 wheel loader has a 450 litres diesel fuel tank, providing extended operation time without frequent refueling.

    06. What is the bucket capacity of the Liebherr L580 wheel loader?

    Ans.

    The bucket capacity of the Liebherr L580 is 5.2 cubic meters (m³).

    07. What is the dump height of the Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 wheel loader provides a dump height of 3300 mm, supporting high-volume earthmoving operations.

    08. What is the warranty period of Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 wheel loader in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever comes first. The warranty covers defects from faulty materials or workmanship, but terms may vary. For the latest details, check with authorized dealers or visit the official brand website.

    09. How many gears are available in the Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 wheel loader features a 4-wheel drive (4WD) system with a Hydrostatic transmission. It uses a continuously variable transmission (CVT) system, enabling efficient operation at speeds up to 40 km/h.

    10. What are the key applications and uses of the Liebherr L580 wheel loader?

    Ans.

    The Liebherr L580 is a large loader built for construction and mining efficiency, offering powerful lifting capacity and fuel economy.

    11. Where can I find spare parts for the Liebherr L580 wheel loader?

    Ans.

    You can find genuine spare parts for the Liebherr L580 wheeled loader at authorized Liebherr dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on wheeled loader spare parts.
