Kobelco
Large (25-50 Ton)
₹ 1.85-1.88 Crore
₹ 1.85-1.88 Crore
50800 Kg
2.1 - 3.4 m³
6820 mm
HINO 344 HP
1 Yr. / 2500 hr.
6500 mm
An extra-large excavator, Kobelco SK520XDLC delivers unmatched power and heavy-duty performance for mining and demanding construction tasks.
Get the best price for the Kobelco SK520XDLC Extra-Large Excavator from authorized dealers. Contact us now for exclusive deals!
Please fil the below form to start the download
Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.
HINO P11C-WF
638 L
10.52 L
5460 mm
2 x 370 L/min
2600 mm
11250 mm
NA
3350 mm
11980 mm
282 kN
3800 mm
600 mm
Standard
Standard
Newly developed XD boom made of stronger plates
Top class traveling force
Reinforced boom and arm
Large, reinforced track guides
Powerful travel system
Improved filtration system
Thick upper under covers for increased durability
Long, solid rock guards
Hydraulic drive for engine cooling fan
Independent oil cooler fan
Reinforced guide frame
Double-support outer flange upper rollers
Thicker steel plate for shoes
Increased durability of the track link
Lower frame underside cover to protect against damage
Arm regeneration system
Fuel efficient ECO-mode
Larger cab for easy ingress & egress
More comfortable seat
Air conditioner louvers behind the seat
Super airtight cab
Multi-display in color
Low vibration
One-touch attachment mode switch
Wide front window for unobstructed view
Convenient interior equipment
A lighter touch lever for reducing operator fatigue
Improved operational safety cab guard (optional)
Rearview mirrors for wide view during operations
Rear view camera (optional)
Travel alarm(optional)
Hammer for emergency exit
Spacious engine compartment for easy, on-the-spot maintenance
The layout allows for easy access from ground level
Special crawler frame for easy mud removal
Easy cleaning with detachable two-piece floor mat and a floor drain
Engine oil pan equipped with drain valve
Easy removal of internal and external air conditioner filters
Newly developed XD boom made of stronger plates
Top class traveling force
Reinforced boom and arm
Large, reinforced track guides
Powerful travel system
Improved filtration system
Thick upper under covers for increased durability
Long, solid rock guards
Hydraulic drive for engine cooling fan
Independent oil cooler fan
Reinforced guide frame
Double-support outer flange upper rollers
Thicker steel plate for shoes
Increased durability of the track link
Lower frame underside cover to protect against damage
Arm regeneration system
Fuel efficient ECO-mode
Larger cab for easy ingress & egress
More comfortable seat
Air conditioner louvers behind the seat
Super airtight cab
Multi-display in color
Low vibration
One-touch attachment mode switch
Wide front window for unobstructed view
Convenient interior equipment
A lighter touch lever for reducing operator fatigue
Improved operational safety cab guard (optional)
Rearview mirrors for wide view during operations
Rear view camera (optional)
Travel alarm(optional)
Hammer for emergency exit
Spacious engine compartment for easy, on-the-spot maintenance
The layout allows for easy access from ground level
Special crawler frame for easy mud removal
Easy cleaning with detachable two-piece floor mat and a floor drain
Engine oil pan equipped with drain valve
Easy removal of internal and external air conditioner filters
Product specification of Kobelco SK520XDLC Excavator
Model
HINO P11C-WF
Fuel
Diesel
Type
Water-cooled, 4cycle 6cylinder direct injection type diesel engine with intercooler turbo-charger
Rated Engine Power
344 HP (257 kW) @ 1850 rpm
Maximum Torque
1470 N.m @1400 rpm
Piston Displacement
10.52 L
Alternator
60A
Battery
2 x 12V, 104 Ah
Starting Motor
24V - 6kW
No of Top Rollers
NA
No of Bottom Rollers
NA
Track Shoes (Each Side)
50
Track Guard
NA
Track Shoe Width
600 mm
Ground Bearing Pressure
88 kPa
Track Tensioning
Grease
Gradeability
70% (35 °)
Travel Speed-Low
3.4 Km/h
Travel Speed-High
5.4 Km/h
Max Tracking Force
415 kN
Hydraulic Pump
Two Variable displacement piston pumps
Maximum Flow
2 x 370 L/min
Pilot Pump
1 Gear pump
Implement Circuit
31.4 MPa
Swing Circuit
26.0 MPa
Travel Circuit
34.3 MPa
Pilot Circuit
5.0 MPa
Travel
Variable displacement piston pump
Swing
Axial-piston mortor
Fuel Tank
638 L
Engine Coolant
47.4 L
Engine Oil
42.5 L
Hydraulic System
631 L
Hydraulic Tank
371 L
Operating Weight
50,800 - 51,100 Kg
Boom Length
6500 mm
Arm Length
2600 mm
Max. Digging Reach
11250 mm
Max. Digging Reach on Ground
11010 mm
Max. Digging Depth
6820 mm
Max. Digging Height
11150 mm
Max. Dumping Height
7180 mm
Max. Vertical Wallcut Depth
6110 mm
Min. Swing Radius
4960 mm
Max. Height at Min Swing Radius
NA
Max. Height (Above Ground)
NA
Dig Depth (Below Ground)
NA
Bucket Digging Force
282 kN
Arm Digging Force
239 kN
Swing Speed
7.6 rpm
Dozer Type
NA
Dozer Length
NA
Digging Depth for Ground Level
NA
Vertical Lift from Ground level
NA
Approach Angle
NA
Width
NA
Height
NA
Bucket Capacity
2.1 - 3.4 m³
Overall Length
11980 mm
Overall Width
3350 mm
Overall Height
4330 mm
Overall Height of Cab
3320 mm
Upper Width
2980 mm
Track Lengh on Ground
4400 mm
Undercarriage Overall Length
5460 mm
Tailswing Radius
3800 mm
Min. Ground Clearance
510 mm
Track Gauge
2750 mm
Width Over Tracks
NA
Track Height
NA
Counterweight Clearence
1260 mm
Track Shoe Width
600 mm
The Kobelco SK520XDLC Excavator price in India ranges between ₹ 1.85 – 1.88 Crore. However, the exact price may vary depending on the location, dealer, taxes, and additional features.
You can buy the Kobelco SK520XDLC excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.
Yes, the Kobelco SK520XDLC comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.
The operating weight of the Kobelco SK520XDLC excavator is approximately 50800 Kg. The operating weight may vary slightly depending on specific configurations and attachments.
The Kobelco SK520XDLC excavator is powered by a HINO P11C-WF engine, delivering 344 HP (257 kW) at 1850 rpm.
The Kobelco SK520XDLC excavator has a maximum digging depth of 6820 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.
The bucket capacity of the Kobelco SK520XDLC Excavator ranges from 2.1 to 3.4 cubic meters (m³).
The Kobelco SK520XDLC Excavator in India typically comes with a standard warranty of 1 year or 2500 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.
You can find genuine spare parts for the Kobelco SK520XDLC excavator at authorized Kobelco dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.
The Kobelco SK520XDLC excavator has a 638 litres diesel fuel tank, providing extended operation time without frequent refueling.
