Leeboy 523 Excavator

desi-machines-leeboy-excaavtor-523-featured

Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

Brand
Leeboy
Type
Medium (15-25 Ton)
Operating Cost
₹ 92-94 lakhs
Ex-Showroom Price
₹ 92-94 lakhs

Weight
24200 Kg
Bucket
1.0 m³
Digging Depth
6290 mm
Engine
Cummins 169 HP
Warranty
1 Yr. / 2500 hr.
Boom
5700 mm

Quick Overview:

Delivering unmatched maneuverability and cost-effective operations, Leeboy 523 medium excavator caters to light to medium-scale construction projects.

Connect With Us:

Get the best price for the Leeboy 523 Medium Excavator from authorized dealers. Contact us now for exclusive deals!

Download Brochure

Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

Key Highlights

Engine Make

Cummins 6BTA 5.9 (BSII)

Fuel Tank

400 L

Engine Displacement

5.9 L

Under Carriage

4634 mm

Hydraulic System

2 x 224, 1 x 21 L/min

Arm

2400 mm

Max Digging Reach

9536 mm

Fuel Consumption

12 L/hour

Overall Width

3180 mm

Overall Length

9848 mm

Bucket Digging Force

145 kN

Tailswing Radius

2985 mm

Track Shoe Width

600 mm

AC Cabin

Standard

GPS

Standard

Features

Engine Performance

Equipped with a Cummins 6BTA 5.9 engine delivering 169 HP, ensuring high productivity.
Water-cooled system maintains optimal operating temperatures.
Fuel capacity of 400 liters supports extended operations without frequent refueling.

Advanced Hydraulic System

Open loop, variable displacement system with summation horsepower control for efficient power management.
Main system maximum flow of 224 liters per minute enhances operational efficiency.
Negacon system incorporated for improved hydraulic performance.

Operating Specifications

Operating weight of 24,200 kg provides stability during heavy-duty tasks.
Maximum digging depth of 6290 mm allows for deep excavation capabilities.
Bucket capacity of 1.0 cubic meters facilitates efficient material handling.

Undercarriage and Mobility

Heavy-duty, triple grouser shoe profile undercarriage from Berco, Italy, ensures durability and traction.
Ground pressure of 0.46 kg/cm₹ minimizes soil disturbance, making it suitable for various terrains.
51 shoes per side contribute to balanced weight distribution and stability.

Operator Comfort and Controls

Ergonomically designed cabin with a reclining seat and electronic display enhances operator comfort.
Differential piston joysticks from Kawasaki provide precise control.
Features like power boost, auto-idle, and variable power modes (rock-breaker, economy, productivity) optimize performance for different tasks.

Swing Mechanism

Rothe Erde slewing ring driven by a Kawasaki swing motor and gearbox ensures smooth and efficient rotation.
Dynamic hydraulic brakes and static brakes with a 5-second delay ramp enhance operational safety.
Swing speed ranges from 0 to 13 rpm, allowing for precise maneuvering.

Engine Performance

Equipped with a Cummins 6BTA 5.9 engine delivering 169 HP, ensuring high productivity.
Water-cooled system maintains optimal operating temperatures.
Fuel capacity of 400 liters supports extended operations without frequent refueling.

Advanced Hydraulic System

Open loop, variable displacement system with summation horsepower control for efficient power management.
Main system maximum flow of 224 liters per minute enhances operational efficiency.
Negacon system incorporated for improved hydraulic performance.

Operating Specifications

Operating weight of 24,200 kg provides stability during heavy-duty tasks.
Maximum digging depth of 6290 mm allows for deep excavation capabilities.
Bucket capacity of 1.0 cubic meters facilitates efficient material handling.

Undercarriage and Mobility

Heavy-duty, triple grouser shoe profile undercarriage from Berco, Italy, ensures durability and traction.
Ground pressure of 0.46 kg/cm₹ minimizes soil disturbance, making it suitable for various terrains.
51 shoes per side contribute to balanced weight distribution and stability.

Operator Comfort and Controls

Ergonomically designed cabin with a reclining seat and electronic display enhances operator comfort.
Differential piston joysticks from Kawasaki provide precise control.
Features like power boost, auto-idle, and variable power modes (rock-breaker, economy, productivity) optimize performance for different tasks.

Swing Mechanism

Rothe Erde slewing ring driven by a Kawasaki swing motor and gearbox ensures smooth and efficient rotation.
Dynamic hydraulic brakes and static brakes with a 5-second delay ramp enhance operational safety.
Swing speed ranges from 0 to 13 rpm, allowing for precise maneuvering.

Specifications

Product specification of Leeboy 523 Excavator

ENGINE

Model

Cummins 6BTA 5.9 (BSII)
Fuel

Diesel
Type

6 Cylinders, Water Cooled, 4 Stroke, Direct Injection with Turbo Charger
Rated Engine Power

169 HP (126 kW) @ 2100 rpm
Maximum Torque

660 Nm @ 1500 rpm
Piston Displacement

5.9 L
Alternator

90A
Battery

2 x 12 V
Starting Motor

24 V

UNDERCARRIAGE

No of Top Rollers

2
No of Bottom Rollers

9
Track Shoes (Each Side)

51
Track Guard

NA
Track Shoe Width

600 mm
Ground Bearing Pressure

45.1 kPa
Track Tensioning

Grease
Gradeability

70% (35°)
Travel Speed-Low

3.0 Km/h
Travel Speed-High

5.5 Km/h
Max Tracking Force

230 kN

HYDRAULIC SYSTEM

Hydraulic Pump

2 Variable Displacement Pumps
Maximum Flow

2 x 224, 1 x 21 L/min
Pilot Pump

1 Gear Pump
Implement Circuit

32.4 MPa
Swing Circuit

26.5 MPa
Travel Circuit

32.4 MPa
Pilot Circuit

NA

HYDRAULIC MOTORS

Travel

Variable Displacement Cartridge Type
Swing

Axial Piston with in-built static brakes, rebound damping valve and anti-shock, anti cavitational valve

SERVICE CAPACITIES

Fuel Tank

400 L
Engine Coolant

20 L
Engine Oil

20 L
Hydraulic System

260 L
Hydraulic Tank

210 L

MACHINE WEIGHTS

Operating Weight

24200 Kg

WORKING RANGE

Boom Length

5700 mm
Arm Length

2400 mm
Max. Digging Reach

9536 mm
Max. Digging Reach on Ground

9430 mm
Max. Digging Depth

6290 mm
Max. Digging Height

9671 mm
Max. Dumping Height

6886 mm
Max. Vertical Wallcut Depth

5494 mm
Min. Swing Radius

3858 mm
Max. Height at Min Swing Radius

NA
Max. Height (Above Ground)

NA
Dig Depth (Below Ground)

NA
Bucket Digging Force

145 kN
Arm Digging Force

111 kN
Swing Speed

13 rpm

DOZER BLADE

Dozer Type

NA
Dozer Length

NA
Digging Depth for Ground Level

NA
Vertical Lift from Ground level

NA
Approach Angle

NA
Width

NA
Height

NA

BUCKET

Bucket Capacity

1.0 m³

STATIC DIMENSIONS

Overall Length

9848 mm
Overall Width

3180 mm
Overall Height

3265 mm
Overall Height of Cab

3111 mm
Upper Width

2710 mm
Track Lengh on Ground

3825 mm
Undercarriage Overall Length

4634 mm
Tailswing Radius

2985 mm
Min. Ground Clearance

460 mm
Track Gauge

2580 mm
Width Over Tracks

3180 mm
Track Height

NA
Counterweight Clearence

1042 mm
Track Shoe Width

600 mm

Frequently Asked Question

01. What is the Leeboy 523 Excavator price in India?

Ans.

The Leeboy 523 Excavator price in India ranges between ₹ 92 – 94 lakhs. However, the exact price may vary depending on the location, dealer, taxes, and additional features.

02. Where can I buy a Leeboy 523 excavator?

Ans.

You can buy the Leeboy 523 excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.

03. Does the Leeboy 523 Excavator come with financing and insurance options?

Ans.

Yes, the Leeboy 523 comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.

04. What is the operating weight of the Leeboy 523 excavator?

Ans.

The operating weight of the Leeboy 523 excavator is approximately 24200 Kg. The operating weight may vary slightly depending on specific configurations and attachments.

05. What type of engine is used in the Leeboy 523 excavator?

Ans.

The Leeboy 523 excavator is powered by a Cummins 6BTA 5.9 (BSII) engine, delivering 169 HP (126 kW) at 2100 rpm.

06. What is the maximum digging depth of the Leeboy 523 excavator?

Ans.

The Leeboy 523 excavator has a maximum digging depth of 6290 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.

07. What is the bucket capacity of the Leeboy 523 Excavator?

Ans.

The bucket capacity of the Leeboy 523 Excavator is 1.0 cubic meters (m³).

08. What is the warranty period for the Leeboy 523 excavator?

Ans.

The Leeboy 523 Excavator in India typically comes with a standard warranty of 1 year or 2500 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.

09. Where can I find spare parts for the Leeboy 523 excavator?

Ans.

You can find genuine spare parts for the Leeboy 523 excavator at authorized Leeboy dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.

10. What is the fuel tank capacity of the Leeboy 523 Excavator?

Ans.

The Leeboy 523 excavator has a 400 litres diesel fuel tank, providing extended operation time without frequent refueling.

11. What is the mileage of the Leeboy 523 excavator?

Ans.

The Leeboy 523 excavator has an average fuel consumption of 12 litres per hour, depending on factors such as load, terrain, and operating conditions
