    Hyundai R30Z-9AK Excavator

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    • Brand

      Hyundai

    • Type

      Mini (0-6 Ton)

    • Operating Cost

      Price Available Soon

    • Ex-Showroom Price

      Price Available Soon

    • Weight

      2895 Kg

    • Bucket

      0.08 m³

    • Digging Depth

      2500 mm

    • Engine

      Kubota 24.2 HP

    • Warranty

      1 Yr. / 2000 hr.

    • Boom

      2030 mm

    Quick Overview:

    With a compact design and advanced control, Hyundai’s R30Z-9AK mini excavator is ideal for landscaping and agricultural tasks.

    Connect With Us:

    Get the best price for the Hyundai R30Z-9AK Mini Excavator from authorized dealers. Contact us now for exclusive deals!

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    Key Highlights

    Engine Make

    Kubota D1305

    Fuel Tank

    30 L

    Engine Displacement

    1.261 L

    Under Carriage

    1970 mm

    Hydraulic System

    2 x 27.6 + 19.6 L/min

    Arm

    1120 mm

    Max Digging Reach

    4650 mm

    Fuel Consumption

    NA

    Overall Width

    1550 mm

    Overall Length

    4180 mm

    Bucket Digging Force

    20.1 kN

    Tailswing Radius

    775 mm

    Track Shoe Width

    300 mm

    AC Cabin

    Not Available

    GPS

    Not Available

    Features

    Performance

    Performance

    • R30Z-9AK features a Tier 4 Final Kubota D1305 4 Cycle, In line, water cooled Diesel with 24.9 HP at 2,350rpm

    • The 9AK series machines all feature a boom swing function to improve productivity in confined work spaces.

    • All 9AK series excavators feature as standard equipment a large dozer blade that provides added versatility, efficiency and stability.

    • Zero-tail swing excavator allows you greater flexibility when working in narrow urban areas from an alley and indoor to residential and small gardens.

    Efficiency

    Efficiency

    • The monitoring system of the R30Z-9AK provides the operator with machine status information, including: engine oil pressure lamp, battery charge lamp, engine coolant temperature and a fuel gauge.

    • Hyundai R30Z-9AK's adjustable suspension seat, wrist rests, ergonomically designed joysticks and plenty of space help to reduce stress on the operator.

    • The left and right control levers are ergonomically located for convenient access. Pilot operated hand levers are easily accessible for controlling the dozer blade and track extension. Easy-to-access control switches on the left side console improve operating comfort and productivity.

    • All pedals are foldable for additional floor space. Footrest, attachment pedal, left and right travel pedals and boom swing pedal are arranged for convenient access.

    Serviceability

    Serviceability

    • A centralized lubrication bank is available for faster, easier service and maintenance.

    • 9AK series excavators were designed with bushings designed for extended lube intervals (250 hrs) & polymer shims (wear resistant, noise reducing), extended-life hydraulic filters (1,000hrs), long-life hydraulic oil (5,000hrs), more efficient cooling systems and integrated preheating systems which extend service intervals, minimize operating costs and reduce machine down time.

    • The R30Z-9AK was built with accessibility in mind. All doors, covers and hoods were built for complete open access. Regular service and maintenance is easy and convenient with the R30Z-9AK.

    • High Strength Steel Cowl provides enhanced strength, Easy Repair and Low Maintenance Cost.

    Safety

    Safety

    • The R30Z-9AK comes equipped with dual locking quick coupler that complies with the latest safety standards and improves the safety when using a coupler with various attachments.

    • Hyundai's R30Z-9AK is tested in accordance with stringent ISO standards. The canopy features a reinforced steel pillar design that complies with TOPS (turn over protection system) and FOG (falling object guard) level 1 ISO standards.

    • The R30Z-9AK has a compact design and swings within the width of the tracks which allows for safe swing and maneuverability in tight spaces.

    • Hyundai engineers updated the cab designs to provide more space, a wider field of vision and more operator comfort.

    Performance

    • R30Z-9AK features a Tier 4 Final Kubota D1305 4 Cycle, In line, water cooled Diesel with 24.9 HP at 2,350rpm

    • The 9AK series machines all feature a boom swing function to improve productivity in confined work spaces.

    • All 9AK series excavators feature as standard equipment a large dozer blade that provides added versatility, efficiency and stability.

    • Zero-tail swing excavator allows you greater flexibility when working in narrow urban areas from an alley and indoor to residential and small gardens.

    Efficiency

    • The monitoring system of the R30Z-9AK provides the operator with machine status information, including: engine oil pressure lamp, battery charge lamp, engine coolant temperature and a fuel gauge.

    • Hyundai R30Z-9AK's adjustable suspension seat, wrist rests, ergonomically designed joysticks and plenty of space help to reduce stress on the operator.

    • The left and right control levers are ergonomically located for convenient access. Pilot operated hand levers are easily accessible for controlling the dozer blade and track extension. Easy-to-access control switches on the left side console improve operating comfort and productivity.

    • All pedals are foldable for additional floor space. Footrest, attachment pedal, left and right travel pedals and boom swing pedal are arranged for convenient access.

    Serviceability

    • A centralized lubrication bank is available for faster, easier service and maintenance.

    • 9AK series excavators were designed with bushings designed for extended lube intervals (250 hrs) & polymer shims (wear resistant, noise reducing), extended-life hydraulic filters (1,000hrs), long-life hydraulic oil (5,000hrs), more efficient cooling systems and integrated preheating systems which extend service intervals, minimize operating costs and reduce machine down time.

    • The R30Z-9AK was built with accessibility in mind. All doors, covers and hoods were built for complete open access. Regular service and maintenance is easy and convenient with the R30Z-9AK.

    • High Strength Steel Cowl provides enhanced strength, Easy Repair and Low Maintenance Cost.

    Safety

    • The R30Z-9AK comes equipped with dual locking quick coupler that complies with the latest safety standards and improves the safety when using a coupler with various attachments.

    • Hyundai's R30Z-9AK is tested in accordance with stringent ISO standards. The canopy features a reinforced steel pillar design that complies with TOPS (turn over protection system) and FOG (falling object guard) level 1 ISO standards.

    • The R30Z-9AK has a compact design and swings within the width of the tracks which allows for safe swing and maneuverability in tight spaces.

    • Hyundai engineers updated the cab designs to provide more space, a wider field of vision and more operator comfort.

    Specifications

    Product specification of Hyundai R30Z-9AK Excavator

    ENGINE

    • Model

      Kubota D1305

    • Fuel

      Diesel

    • Type

      4 Cycle. In line, water cooled

    • Rated Engine Power

      24.2 HP (18.1 kW) @ 2350 rpm

    • Maximum Torque

      81.3 Nm @ 1600 rpm

    • Piston Displacement

      1.261 L

    • Alternator

      12V / 40A

    • Battery

      12V, 80 Ah

    • Starting Motor

      12V - 1.4 kW

    UNDERCARRIAGE

    • No of Top Rollers

      1

    • No of Bottom Rollers

      4

    • Track Shoes (Each Side)

      NA

    • Track Guard

      NA

    • Track Shoe Width

      300 mm

    • Ground Bearing Pressure

      26.4 kPa

    • Track Tensioning

      Grease

    • Gradeability

      30 °

    • Travel Speed-Low

      2.4 Km/h

    • Travel Speed-High

      4.4 Km/h

    • Max Tracking Force

      NA

    HYDRAULIC SYSTEM

    • Hydraulic Pump

      Variable Displacement Piston Pumps

    • Maximum Flow

      2 x 27.6 + 19.6 L/min

    • Pilot Pump

      Gear Pump

    • Implement Circuit

      21.5 MPa

    • Swing Circuit

      17.1 MPa

    • Travel Circuit

      21.5 MPa

    • Pilot Circuit

      2.9 MPa

    HYDRAULIC MOTORS

    • Travel

      Two speed axial piston motor with counter balance valve and parking brake

    • Swing

      Axial piston motor with automatic brake

    SERVICE CAPACITIES

    • Fuel Tank

      30 L

    • Engine Coolant

      5 L

    • Engine Oil

      5.9 L

    • Hydraulic System

      NA

    • Hydraulic Tank

      27 L

    MACHINE WEIGHTS

    • Operating Weight

      2895 Kg

    WORKING RANGE

    • Boom Length

      2030 mm

    • Arm Length

      1120 mm

    • Max. Digging Reach

      4650 mm

    • Max. Digging Reach on Ground

      4650 mm

    • Max. Digging Depth

      2500 mm

    • Max. Digging Height

      4235 mm

    • Max. Dumping Height

      2860 mm

    • Max. Vertical Wallcut Depth

      NA

    • Min. Swing Radius

      2065 mm

    • Max. Height at Min Swing Radius

      NA

    • Max. Height (Above Ground)

      NA

    • Dig Depth (Below Ground)

      NA

    • Bucket Digging Force

      20.1 kN

    • Arm Digging Force

      13.7 kN

    • Swing Speed

      9.1 rpm

    DOZER BLADE

    • Dozer Type

      NA

    • Dozer Length

      NA

    • Digging Depth for Ground Level

      NA

    • Vertical Lift from Ground level

      NA

    • Approach Angle

      NA

    • Width

      NA

    • Height

      NA

    BUCKET

    • Bucket Capacity

      0.08 m³

    STATIC DIMENSIONS

    • Overall Length

      4180 mm

    • Overall Width

      1550 mm

    • Overall Height

      NA

    • Overall Height of Cab

      2500 mm

    • Upper Width

      1485 mm

    • Track Lengh on Ground

      1550 mm

    • Undercarriage Overall Length

      1970 mm

    • Tailswing Radius

      775 mm

    • Min. Ground Clearance

      290 mm

    • Track Gauge

      1250 mm

    • Width Over Tracks

      NA

    • Track Height

      NA

    • Counterweight Clearence

      510 mm

    • Track Shoe Width

      300 mm

    Frequently Asked Question

    01. What is the Hyundai R30Z-9AK Excavator price in India?

    Ans.

    The exact Hyundai R30Z-9AK Excavator price in India is currently unavailable. To get the latest and most accurate pricing, please connect with us, and we will help you find the best price for the excavator.

    02. Where can I buy a Hyundai R30Z-9AK excavator?

    Ans.

    You can buy the Hyundai R30Z-9AK excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.

    03. Does the Hyundai R30Z-9AK Excavator come with financing and insurance options?

    Ans.

    Yes, the Hyundai R30Z-9AK comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.

    04. What is the operating weight of the Hyundai R30Z-9AK excavator?

    Ans.

    The operating weight of the Hyundai R30Z-9AK excavator is approximately 2895 Kg. The operating weight may vary slightly depending on specific configurations and attachments.

    05. What type of engine is used in the Hyundai R30Z-9AK excavator?

    Ans.

    The Hyundai R30Z-9AK excavator is powered by a Kubota D1305 engine, delivering 24.2 HP (18.1 kW) at 2350 rpm.

    06. What is the maximum digging depth of the Hyundai R30Z-9AK excavator?

    Ans.

    The Hyundai R30Z-9AK excavator has a maximum digging depth of 2500 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.

    07. What is the bucket capacity of the Hyundai R30Z-9AK Excavator?

    Ans.

    The bucket capacity of the Hyundai R30Z-9AK Excavator is 0.08 cubic meters (m³).

    08. What is the warranty period for the Hyundai R30Z-9AK excavator?

    Ans.

    The Hyundai R30Z-9AK Excavator in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.

    09. Where can I find spare parts for the Hyundai R30Z-9AK excavator?

    Ans.

    You can find genuine spare parts for the Hyundai R30Z-9AK excavator at authorized Hyundai dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.

    10. What is the fuel tank capacity of the Hyundai R30Z-9AK Excavator?

    Ans.

    The Hyundai R30Z-9AK excavator has a 30 litres diesel fuel tank, providing extended operation time without frequent refueling.
