With exceptional power, Liugong 975E-HD is an extra-large excavator built to handle the most demanding excavation and mining applications.
LiuGong
Extra-Large (>50 Ton)
Price Available Soon
Price Available Soon
75000 Kg
5.6 m³
7180 mm
Cummins 524 HP
1 Yr. / 2500 hr.
6600 mm
Get the best price for the Liugong 975E HD Extra Large Excavator from authorized dealers. Contact us now for exclusive deals!
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Please fil the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm exact pricing with the dealer or OEM.
Cummins QSM1577C
1100 L
15 L
5990 mm
2 x 476 L/min
2900 mm
11450 mm
NA
4260 mm
12630 mm
405/420 kN
4490 mm
650 mm
Standard
NA
The E Series excavators are designed to get more work done, in a short period of time, featuring stronger boom, arm & bucket, more breakout forces, greater hydraulic flow, higher swing torque with liugong’s intelligent power control (IPC) system delivers excellent performance, without excess fuel consumption.
The LiuGong 975E HD is an easy to use, highly efficient, powerful machine with highest output in this class of excavators. The hydraulics have been fine tuned to perfectly match the engine characteristics to deliver astonishing efficiency.
The use of thick, high-tensile strengthened, stress-relieved steel plates, makes the structures on E-series excavators, extra strong & reliable.
We understand how operators like to work. Our cabin is designed to ensure maximum operator comfort, enhanced productivity and excellent all around visibility with increased safety.
Machine availability enhanced, with use of world class reliable hydraulic components, engine designed to deliver high torque at low rpm, well designed rugged structures. Thereby making your work easier & faster throughout the operation. Easy visibility and accessibility to all service touch points from ground level, makes maintenance, safe, easy and fast.
Product specification of Liugong 975E HD Excavator
Model
Cummins QSM1577C
Fuel
Diesel
Type
Cummins EPA Tier 3 / EU Stage IIIA, Inline, 6 Cylinder, turbocharger, electronically controlled direct injection.
Rated Engine Power
524 HP (391 kW) @ 1800 rpm
Maximum Torque
2373 Nm @ 1400 rpm
Piston Displacement
15 L
Alternator
24 V-100 A
Battery
4 x 12 v
Starting Motor
24 V-9 kW
No of Top Rollers
3
No of Bottom Rollers
8
Track Shoes (Each Side)
48
Track Guard
NA
Track Shoe Width
650 mm
Ground Bearing Pressure
NA
Track Tensioning
Grease
Travel Speed-Low
3.0 Km/h
Travel Speed-High
4.0 Km/h
Gradeability
70% (35°)
Max Tracking Force
495 kN
Hydraulic Pump
Two Variable displacement piston pumps.
Max imum Flow
2 x 476 L/min
Pilot Pump
Gear pump
Implement Circuit
37.3 MPa
Swing Circuit
26.5 MPa
Travel Circuit
34.3 MPa
Pilot Circuit
3.9 MPa
Travel
2 Speed axial piston motors with oil disk brakes.
Swing
Planetary gear reduction driven by high torque axial piston motor.
Fuel Tank
1100 L
Engine Coolant
72 L
Engine Oil
46 L
Hydraulic System
680 L
Hydraulic Tank
360 L
Operating Weight
75000 Kg
Boom Length
6600 mm
Arm Length
2900 mm
Max. Digging Reach
11450 mm
Max. Digging Reach on Ground
11170 mm
Max. Digging Depth
7180 mm
Max. Digging Height
10950 mm
Max. Dumping Height
7030 mm
Max. Vertical Wallcut Depth
4080 mm
Min. Swing Radius
4900 mm
Max. Height at Min Swing Radius
NA
Max. Height (Above Ground)
NA
Dig Depth (Below Ground)
NA
Bucket Digging Force
405/420 kN
Arm Digging Force
630/375 kN
Swing Speed
6.8 rpm
Dozer Type
NA
Dozer Length
NA
Digging Depth for Ground Level
NA
Vertical Lift from Ground level
NA
Approach Angle
NA
Width
NA
Height
NA
Bucket Capacity
5.6 m³
Overall Length
12630 mm
Overall Width
4260 mm
Overall Height
4710 mm
Overall Height of Cab
3620 mm
Upper Width
4260 mm
Track Lenght on Ground
4750 mm
Undercarriage Overall Length
5990 mm
Tailswing Radius
4490 mm
Min. Ground Clearance
867 mm
Track Gauge
3350 mm
Width Over Tracks
4000 mm
Track Height
NA
Counterweight Clearence
1495 mm
Track Shoe Width
650 mm
The exact Liugong 975E HD Excavator price in India is currently unavailable. To get the latest and most accurate pricing, please connect with us, and we will help you find the best price for the excavator.
You can buy the Liugong 975E HD excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.
Yes, the Liugong 975E HD comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.
The operating weight of the Liugong 975E HD excavator is approximately 75000 Kg. The operating weight may vary slightly depending on specific configurations and attachments.
The Liugong 975E HD excavator is powered by a Cummins QSM1577C engine, delivering 524 HP (391 kW) at 1800 rpm.
The Liugong 975E HD excavator has a maximum digging depth of 7180 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.
The bucket capacity of the Liugong 975E HD Excavator is 5.6 cubic meters (m³).
The Liugong 975E HD Excavator in India typically comes with a standard warranty of 1 year or 2500 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.
You can find genuine spare parts for the Liugong 975E HD excavator at authorized Liugong dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.
The Liugong 975E HD excavator has a 1100 litres diesel fuel tank, providing extended operation time without frequent refueling.
