    Tata Hitachi ZAXIS 33U Excavator

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    • Brand

      Tata Hitachi

    • Type

      Mini (0-6 Ton)

    • Operating Cost

      ₹ 27 - 29 Lakhs

    • Ex-Showroom Price

      ₹ 27 - 29 Lakhs

    • Weight

      3650 Kg

    • Bucket

      0.04-0.09 m³

    • Digging Depth

      2790 mm

    • Engine

      Yanmar 28.2 HP

    • Warranty

      1 Yr. / 2000 hr.

    • Boom

      NA

    Quick Overview:

    Featured with advanced functionality and fuel efficiency Tata Hitachi ZAXIS 33U mini excavator is dedicated to landscaping and light construction tasks.

    Connect With Us:

    Get the best price for the Tata Hitachi ZAXIS 33U Mini Excavator from authorized dealers. Contact us now for exclusive deals!

    Note: All images, features, specifications, and brochures displayed on this website are sourced from the respective brands’ official websites and other publicly available resources.

    Key Highlights

    Engine Make

    Yanmar EDM-3TNV88

    Fuel Tank

    42 L

    Engine Displacement

    1.642 L

    Under Carriage

    2130 mm

    Hydraulic System

    2 x 38.4 L/min

    Arm

    NA

    Max Digging Reach

    4890 mm

    Fuel Consumption

    NA

    Overall Width

    1550 mm

    Overall Length

    4450 mm

    Bucket Digging Force

    27.2 kN

    Tailswing Radius

    775 mm

    Track Shoe Width

    300 mm

    AC Cabin

    Not Available

    GPS

    Not Available

    Features

    Superior Performance

    Superior Performance

    • Excellent control with best in class Swing speed - faster operations

    • Hitachi Pilot Control Hydraulics System ensures effortless handling of pilot lever

    • Zero tail swing & boom enables this compact excavator to work alongside walls

    • Special cooling system to keep engine & hydraulics cooler

    High Durability

    High Durability

    • Sturdy upper structure - reinforced with proven D-section skirts

    • Reinforced boom end bracket with high strength steel

    • Single swing post pin assures minimize backlash and improves performance

    • Box-sectioned rigid frame blade

    • Reinforce Sturdy Bucket - longer life

    Operator Comfort & Safety

    Operator Comfort & Safety

    • Single swing post pin assures minimize backlash and improves performance

    • Ergonomically designed console, seat, large anti-vibration mounts to maximize comfort

    • Protects operator in case of roll over or trip over accidents as ZX33U conforms with ROPS/TOPS standards

    • Lowering Lock lever is compulsory for engine start function

    Simplified Maintenance

    Simplified Maintenance

    • Dust proof indoor net, parallel ROC-easy to clean

    • Wide opening covers with grouped inspection points - easy to access

    • Longer greasing interval with HN bushes-educed maintenance cost

    • Slide open engine cover provides easy access to service in tight spaces.

    • Air pre-cleaner ensures longer life of filters and reduce maintenance cost

    Superior Performance

    • Excellent control with best in class Swing speed - faster operations

    • Hitachi Pilot Control Hydraulics System ensures effortless handling of pilot lever

    • Zero tail swing & boom enables this compact excavator to work alongside walls

    • Special cooling system to keep engine & hydraulics cooler

    High Durability

    • Sturdy upper structure - reinforced with proven D-section skirts

    • Reinforced boom end bracket with high strength steel

    • Single swing post pin assures minimize backlash and improves performance

    • Box-sectioned rigid frame blade

    • Reinforce Sturdy Bucket - longer life

    Operator Comfort & Safety

    • Single swing post pin assures minimize backlash and improves performance

    • Ergonomically designed console, seat, large anti-vibration mounts to maximize comfort

    • Protects operator in case of roll over or trip over accidents as ZX33U conforms with ROPS/TOPS standards

    • Lowering Lock lever is compulsory for engine start function

    Simplified Maintenance

    • Dust proof indoor net, parallel ROC-easy to clean

    • Wide opening covers with grouped inspection points - easy to access

    • Longer greasing interval with HN bushes-educed maintenance cost

    • Slide open engine cover provides easy access to service in tight spaces.

    • Air pre-cleaner ensures longer life of filters and reduce maintenance cost

    Specifications

    Product specification of Tata Hitachi ZAXIS 33U Excavator

    ENGINE

    • Model

      Yanmar EDM-3TNV88

    • Fuel

      Diesel

    • Type

      3 Cylinders 4 Cycle Water Cooled, direct injection

    • Rated Engine Power

      28.2 HP (21.1 kW) @ 2200 rpm

    • Maximum Torque

      105.5 Nm @ 1000 rpm

    • Piston Displacement

      1.642 L

    • Alternator

      NA

    • Battery

      NA

    • Starting Motor

      NA

    UNDERCARRIAGE

    • No of Top Rollers

      1

    • No of Bottom Rollers

      4

    • Track Shoes (Each Side)

      NA

    • Track Guard

      NA

    • Track Shoe Width

      300 mm

    • Ground Bearing Pressure

      NA

    • Track Tensioning

      Grease

    • Gradeability

      58% (30°)

    • Travel Speed-Low

      2.8 Km/h

    • Travel Speed-High

      4.3 Km/h

    • Max Tracking Force

      27 kN

    HYDRAULIC SYSTEM

    • Hydraulic Pump

      2 Variable Displacement Pump Axial Piston

    • Maximum Flow

      2 x 38.4 L/min

    • Pilot Pump

      Gear Pump

    • Implement Circuit

      24.5 MPa

    • Swing Circuit

      16.6 MPa

    • Travel Circuit

      24.5 MPa

    • Pilot Circuit

      3.9 MPa

    HYDRAULIC MOTORS

    • Travel

      NA

    • Swing

      NA

    SERVICE CAPACITIES

    • Fuel Tank

      42 L

    • Engine Coolant

      3.9 L

    • Engine Oil

      7.2 L

    • Hydraulic System

      56.0 L

    • Hydraulic Tank

      32.0 L

    MACHINE WEIGHTS

    • Operating Weight

      3270 - 3650 Kg

    WORKING RANGE

    • Boom Length

      NA

    • Arm Length

      NA

    • Max. Digging Reach

      4890 mm

    • Max. Digging Reach on Ground

      4750 mm

    • Max. Digging Depth

      2790 mm

    • Max. Digging Height

      4620 mm

    • Max. Dumping Height

      3200 mm

    • Max. Vertical Wallcut Depth

      2330 mm

    • Min. Swing Radius

      1970 mm

    • Max. Height at Min Swing Radius

      NA

    • Max. Height (Above Ground)

      NA

    • Dig Depth (Below Ground)

      NA

    • Bucket Digging Force

      27.2 kN

    • Arm Digging Force

      14.6 kN

    • Swing Speed

      NA

    DOZER BLADE

    • Dozer Type

      NA

    • Dozer Length

      NA

    • Digging Depth for Ground Level

      360 mm

    • Vertical Lift from Ground level

      320 mm

    • Approach Angle

      NA

    • Width

      NA

    • Height

      360 mm

    BUCKET

    • Bucket Capacity

      0.04 - 0.09 m³

    STATIC DIMENSIONS

    • Overall Length

      4450 mm

    • Overall Width

      1550 mm

    • Overall Height

      1510 mm

    • Overall Height of Cab

      2470 mm

    • Upper Width

      1550 mm

    • Track Lengh on Ground

      1670 mm

    • Undercarriage Overall Length

      2130 mm

    • Tailswing Radius

      775 mm

    • Min. Ground Clearance

      270 mm

    • Track Gauge

      1250 mm

    • Width Over Tracks

      1550 mm

    • Track Height

      470 mm

    • Counterweight Clearence

      540 mm

    • Track Shoe Width

      300 mm

    Frequently Asked Question

    01. What is the Tata Hitachi ZAXIS 33U Excavator price in India?

    Ans.

    The Tata Hitachi ZAXIS 33U Excavator price in India ranges between ₹ 27 – 29 Lakhs. However, the exact price may vary depending on the location, dealer, taxes, and additional features.

    02. Where can I buy a Tata Hitachi ZAXIS 33U excavator?

    Ans.

    You can buy the Tata Hitachi ZAXIS 33U excavator from Desi Machines, your trusted platform for heavy equipment purchases. We connect you with authorized dealers based on your location to ensure you get the best deals and genuine products. Simply fill out the inquiry form for the excavator you need, or contact us directly for expert assistance and competitive pricing.

    03. Does the Tata Hitachi ZAXIS 33U Excavator come with financing and insurance options?

    Ans.

    Yes, the Tata Hitachi ZAXIS 33U comes with financing and insurance options. Desi Machines offers the best-curated finance and insurance solutions from top providers. Simply fill out the form for the excavator, and our team will help you secure the best deals.

    04. What is the operating weight of the Tata Hitachi ZAXIS 33U excavator?

    Ans.

    The operating weight of the Tata Hitachi ZAXIS 33U excavator is approximately 3650 Kg. The operating weight may vary slightly depending on specific configurations and attachments.

    05. What type of engine is used in the Tata Hitachi ZAXIS 33U excavator?

    Ans.

    The Tata Hitachi ZAXIS 33U excavator is powered by a Yanmar EDM-3TNV88 engine, delivering 28.2 HP (21.1 kW) at 2200 rpm.

    06. What is the maximum digging depth of the Tata Hitachi ZAXIS 33U excavator?

    Ans.

    The Tata Hitachi ZAXIS 33U excavator has a maximum digging depth of 2790 mm, providing efficient excavation for various applications. The actual digging depth may vary based on optional attachments and configurations, ensuring versatility for different job site needs.

    07. What is the bucket capacity of the Tata Hitachi ZAXIS 33U Excavator?

    Ans.

    The bucket capacity of the Tata Hitachi ZAXIS 33U Excavator ranges from 0.04 to 0.09 cubic meters (m³).

    08. What is the warranty period for the Tata Hitachi ZAXIS 33U excavator?

    Ans.

    The Tata Hitachi ZAXIS 33U Excavator in India typically comes with a standard warranty of 1 year or 2000 operating hours, whichever occurs first. This warranty generally covers defects due to faulty materials or workmanship. Warranty terms can vary. For the most accurate and up-to-date information, please verify with authorized dealers or the official brand website.

    09. Where can I find spare parts for the Tata Hitachi ZAXIS 33U excavator?

    Ans.

    You can find genuine spare parts for the Tata Hitachi ZAXIS 33U excavator at authorized Tata Hitachi dealerships, service centers, and trusted suppliers. At Desi Machines, we help you connect with authorized dealers, and our experts assist you in finding the best deals based on your location. Fill out the form now to get the best offers on excavator spare parts.

    10. What is the fuel tank capacity of the Tata Hitachi ZAXIS 33U Excavator?

    Ans.

    The Tata Hitachi ZAXIS 33U excavator has a 42 litres diesel fuel tank, providing extended operation time without frequent refueling.
