The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | ACE Phantom 4WD N | BEML BL9H 4x4 |
|---|
| Particulars | ACE Phantom 4WD N | BEML BL9H 4x4 |
|---|
The BEML BL9H 4x4 and ACE Phantom 4WD N are backhoe loaders that present different strengths. The BEML BL9H 4x4 boasts powerful performance with a slightly larger shovel capacity, while the ACE Phantom 4WD N brings higher power and speed to the table, along with a GPS feature.
The best choice between the BEML BL9H 4x4 and ACE Phantom 4WD N depends on your specific needs. If digging force and shovel capacity are critical for your operations, the BEML may be preferable. However, if engine power and navigation capabilities are more important, then the ACE Phantom might be the better option.
| Brand | ACE | BEML |
|---|---|---|
| Type | 4WD | 4WD |
| Price | Price Available Soon | Price Available Soon |
| Engine | Kirloskar 96 HP | Koel 74 HP |
| Bucket | 0.30 m³ | 0.24 m³ |
| Shovel | 1.1 m³ | 1.20 m³ |
| Max Digging Depth | 4600 mm | 4585 mm |
| Max Dump Height | 2960 mm | 2700 mm |
| Weight | 8040 Kg | 7700 Kg |
| Quick Overview: | The ACE Phantom 4WD N backhoe loader features advanced specifications tailored for efficient performance in diverse construction applications |
BEML BL9H 4×4 backhoe loader offers powerful performance, superior digging, robust design, and versatility for construction tasks. |
The BEML BL9H 4x4 and ACE Phantom 4WD N are backhoe loaders that present different strengths. The BEML BL9H 4x4 boasts powerful performance with a slightly larger shovel capacity, while the ACE Phantom 4WD N brings higher power and speed to the table, along with a GPS feature.
The best choice between the BEML BL9H 4x4 and ACE Phantom 4WD N depends on your specific needs. If digging force and shovel capacity are critical for your operations, the BEML may be preferable. However, if engine power and navigation capabilities are more important, then the ACE Phantom might be the better option.
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Brand | |
| ACE | BEML |
| Type | |
| 4WD | 4WD |
| Price | |
| Price Available Soon | Price Available Soon |
| Engine | |
| Kirloskar 96 HP | Koel 74 HP |
| Bucket | |
| 0.30 m³ | 0.24 m³ |
| Shovel | |
| 1.1 m³ | 1.20 m³ |
| Max Digging Depth | |
| 4600 mm | 4585 mm |
| Max Dump Height | |
| 2960 mm | 2700 mm |
| Weight | |
| 8040 Kg | 7700 Kg |
| Quick Overview: | |
The ACE Phantom 4WD N backhoe loader features advanced specifications tailored for efficient performance in diverse construction applications |
BEML BL9H 4×4 backhoe loader offers powerful performance, superior digging, robust design, and versatility for construction tasks. |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Engine Make | Kirloskar 4R1040TA (BS III) | Koel 4R1190T-HT |
| Fuel Tank | 150 L | 135 L |
| Max Torque | 400 Nm @ 1400 RPM | 400 Nm @ 1200 RPM |
| Max Speed | 40 km/hr | 39 km/hr |
| Hydraulic System | NA | NA |
| Max Working Height | 5800 mm | 5880 mm |
| Excavator Max Lift Capacity | NA | NA |
| Loader Load Over Height | 3350 mm | 4025 mm |
| Overall Length | 6200 mm | 6270 mm |
| Wheel Base | 2180 mm | 2160 mm |
| Bucket Digging Force | 5700 kgf | 5557 kgf |
| Shovel Breakout Force | 5200 kgf | 5894 kgf |
| Warranty | 1 Year | 1 Yr. / 2500 hr. |
| AC Cabin | Optional | Optional |
| GPS | Standard | Not Available |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Engine Make | |
| Kirloskar 4R1040TA (BS III) | Koel 4R1190T-HT |
| Fuel Tank | |
| 150 L | 135 L |
| Max Torque | |
| 400 Nm @ 1400 RPM | 400 Nm @ 1200 RPM |
| Max Speed | |
| 40 km/hr | 39 km/hr |
| Hydraulic System | |
| NA | NA |
| Max Working Height | |
| 5800 mm | 5880 mm |
| Excavator Max Lift Capacity | |
| NA | NA |
| Loader Load Over Height | |
| 3350 mm | 4025 mm |
| Overall Length | |
| 6200 mm | 6270 mm |
| Wheel Base | |
| 2180 mm | 2160 mm |
| Bucket Digging Force | |
| 5700 kgf | 5557 kgf |
| Shovel Breakout Force | |
| 5200 kgf | 5894 kgf |
| Warranty | |
| 1 Year | 1 Yr. / 2500 hr. |
| AC Cabin | |
| Optional | Optional |
| GPS | |
| Standard | Not Available |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Model | Kirloskar 96 HP | Koel 74 HP |
| Type | 4 Cylinder water cooled turbo charged diesel engine | CEV-Stage 5, Turbocharged, 4 Cylinder, Water Cooled, Diesel Engine |
| Gross Power | 96 HP (71.5 kW) @ 2200 RPM | 74 HP (55 kW) @ 2200 RPM |
| Max Torque | 400 Nm @ 1400 RPM | 400 Nm @ 1200 RPM |
| Displacement | NA | 4.76 L |
| Battery | 12V | 12 V / 150Ah |
| Alternator | Suitable Alternator | 90A |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Type | Synchro shuttle transmission with torque converter & synchronised gear box. | Carraro, TCB80, Integral torque converter, 4 forward and 3 reverse speeds, optimally matched with engine. |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Type | Hydrostatic steering for reliability and better control. | Fully hydrostatic power steering system independent of engine speed |
| Working Pressure | NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Inner Wheels Braked - Outside Loader Bucket | 3500 mm | 13000 mm |
| Inner Wheels Braked - Outside Wheels | NA | 10000 mm |
| Inner Wheels not Braked - Outside Loader Bucket | 4400 mm | NA |
| Inner Wheels not Braked - Outside Wheels | NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Service | Hydraulically actuated wet disc brakes at rear wheels with twin pedals in cabin for better control. | Hydraulically actuated wet multiple disc brake at rear wheels. |
| Parking | Mechanically actuated disc brakes for parking . | Hand Operated; caliper brake on rear axle. |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Front | 12.5 / 80 - 18 - 12 PR | 16 PR , 9.0 x 16 |
| Rear | 16.90 - 28 - 12 PR | 12 PR , 14.0 x 25 |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Forward- 1st gear | NA | NA |
| Reverse- 1st gear | NA | NA |
| Forward- 2nd gear | NA | NA |
| Reverse- 2nd gear | NA | NA |
| Forward- 3rd gear | NA | NA |
| Reverse- 3rd gear | NA | 18 km/hr |
| Forward- 4th gear | 40 km/hr | 39 km/hr |
| Reverse- 4th gear | 40 km/hr | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Type | NA | Gear Pump |
| Maximum Pump Flow | 118 L/min | 110 L/min @ 2200 rpm |
| System Pressure | 225 bar | 210 bar |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Rear Axle | Rigid axle with CARRARO planetary drive. | On board rigidly fixed to the frame; 100% differential lock with electro-hydraulic control. |
| Front Axle | Drive & steer Axle; Centrally pivoted. | Drive Steerable |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Fuel Tank | 150 L | 135 L |
| Engine Coolant | NA | 14 L |
| Engine Oil | 11.5 L | 11.5 L |
| Hydraulic Tank | 90 L | 90 L |
| Hydraulic System | NA | NA |
| Transmission | 17 L | 16 L |
| Rear Axle | 3 L | 18 L |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Maximum Digging Depth | 4600 mm | 4585 mm |
| Reach-Ground Level to Rear Wheel Centre | 6800 mm | NA |
| Reach-Ground Level to Slew Centre | 5500 mm | NA |
| Reach at Full Height to Slew Centre | 2780 mm | NA |
| Side Reach to Centre Line of Machine | 5590 mm | NA |
| Maximum Working Height | 5800 mm | 5880 mm |
| Maximum Load Over Height | 3350 mm | 4025 mm |
| Bucket Rotation Angle | 175° | 180° |
| Bucket Digging force | 5700 kgf | 5557 kgf |
| Arm Digging force | NA | 3059 kgf |
| Maximum Lift Capacity | NA | NA |
| Standard Bucket Capacity | 0.30 m³ | 0.24 m³ |
| Standard Bucket Width | NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Dump Height | 2960 mm | 2700 mm |
| Load Over Height | 3350 mm | NA |
| Pin Height | 3630 mm | NA |
| Pin Forward Reach | NA | NA |
| Reach At Ground | 1770 mm | NA |
| Maximum Reach at Full Height | 1220 mm | 4360 mm |
| Max Reach Full Height Dumped | 890 mm | NA |
| Below Ground Level Dig Depth | 80 mm | 150 mm |
| Rollback at Ground | 44° | NA |
| Dump Angle | 45° | 45° |
| Shovel Breakout Force | 5200 kgf | 5894 kgf |
| Loader Arm Breakout Force | NA | 4793 kgf |
| Maximum Payload | 1900 kg | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 | |
| Machine Weight | 8040 kg | 7700 Kg |
| Overall Length | 6200 mm | 6270 mm |
| Wheelbase | 2180 mm | 2160 mm |
| Slew Centre to Rear Axle Centre | NA | NA |
| Minimum Ground Clearance | 350 mm | NA |
| Slew Ground Clearance | 660 mm | 580 mm |
| Height of Cabin | 2900 mm | 3034 mm |
| Overall Height | 3600 mm | 3890 mm |
| Track Width-Rear | 1550 mm | 2452 mm |
| Track Width-Front | 1840 mm | 2240 mm |
| Width Over Bucket | 2500 mm | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Model | |
| Kirloskar 96 HP | Koel 74 HP |
| Type | |
| 4 Cylinder water cooled turbo charged diesel engine | CEV-Stage 5, Turbocharged, 4 Cylinder, Water Cooled, Diesel Engine |
| Gross Power | |
| 96 HP (71.5 kW) @ 2200 RPM | 74 HP (55 kW) @ 2200 RPM |
| Max Torque | |
| 400 Nm @ 1400 RPM | 400 Nm @ 1200 RPM |
| Displacement | |
| NA | 4.76 L |
| Battery | |
| 12V | 12 V / 150Ah |
| Alternator | |
| Suitable Alternator | 90A |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Type | |
| Synchro shuttle transmission with torque converter & synchronised gear box. | Carraro, TCB80, Integral torque converter, 4 forward and 3 reverse speeds, optimally matched with engine. |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Type | |
| Hydrostatic steering for reliability and better control. | Fully hydrostatic power steering system independent of engine speed |
| Working Pressure | |
| NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Inner Wheels Braked - Outside Loader Bucket | |
| 3500 mm | 13000 mm |
| Inner Wheels Braked - Outside Wheels | |
| NA | 10000 mm |
| Inner Wheels not Braked - Outside Loader Bucket | |
| 4400 mm | NA |
| Inner Wheels not Braked - Outside Wheels | |
| NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Service | |
| Hydraulically actuated wet disc brakes at rear wheels with twin pedals in cabin for better control. | Hydraulically actuated wet multiple disc brake at rear wheels. |
| Parking | |
| Mechanically actuated disc brakes for parking . | Hand Operated; caliper brake on rear axle. |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Front | |
| 12.5 / 80 - 18 - 12 PR | 16 PR , 9.0 x 16 |
| Rear | |
| 16.90 - 28 - 12 PR | 12 PR , 14.0 x 25 |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Forward- 1st gear | |
| NA | NA |
| Reverse- 1st gear | |
| NA | NA |
| Forward- 2nd gear | |
| NA | NA |
| Reverse- 2nd gear | |
| NA | NA |
| Forward- 3rd gear | |
| NA | NA |
| Reverse- 3rd gear | |
| NA | 18 km/hr |
| Forward- 4th gear | |
| 40 km/hr | 39 km/hr |
| Reverse- 4th gear | |
| 40 km/hr | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Type | |
| NA | Gear Pump |
| Maximum Pump Flow | |
| 118 L/min | 110 L/min @ 2200 rpm |
| System Pressure | |
| 225 bar | 210 bar |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Rear Axle | |
| Rigid axle with CARRARO planetary drive. | On board rigidly fixed to the frame; 100% differential lock with electro-hydraulic control. |
| Front Axle | |
| Drive & steer Axle; Centrally pivoted. | Drive Steerable |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Fuel Tank | |
| 150 L | 135 L |
| Engine Coolant | |
| NA | 14 L |
| Engine Oil | |
| 11.5 L | 11.5 L |
| Hydraulic Tank | |
| 90 L | 90 L |
| Hydraulic System | |
| NA | NA |
| Transmission | |
| 17 L | 16 L |
| Rear Axle | |
| 3 L | 18 L |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Maximum Digging Depth | |
| 4600 mm | 4585 mm |
| Reach-Ground Level to Rear Wheel Centre | |
| 6800 mm | NA |
| Reach-Ground Level to Slew Centre | |
| 5500 mm | NA |
| Reach at Full Height to Slew Centre | |
| 2780 mm | NA |
| Side Reach to Centre Line of Machine | |
| 5590 mm | NA |
| Maximum Working Height | |
| 5800 mm | 5880 mm |
| Maximum Load Over Height | |
| 3350 mm | 4025 mm |
| Bucket Rotation Angle | |
| 175° | 180° |
| Bucket Digging force | |
| 5700 kgf | 5557 kgf |
| Arm Digging force | |
| NA | 3059 kgf |
| Maximum Lift Capacity | |
| NA | NA |
| Standard Bucket Capacity | |
| 0.30 m³ | 0.24 m³ |
| Standard Bucket Width | |
| NA | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Dump Height | |
| 2960 mm | 2700 mm |
| Load Over Height | |
| 3350 mm | NA |
| Pin Height | |
| 3630 mm | NA |
| Pin Forward Reach | |
| NA | NA |
| Reach At Ground | |
| 1770 mm | NA |
| Maximum Reach at Full Height | |
| 1220 mm | 4360 mm |
| Max Reach Full Height Dumped | |
| 890 mm | NA |
| Below Ground Level Dig Depth | |
| 80 mm | 150 mm |
| Rollback at Ground | |
| 44° | NA |
| Dump Angle | |
| 45° | 45° |
| Shovel Breakout Force | |
| 5200 kgf | 5894 kgf |
| Loader Arm Breakout Force | |
| NA | 4793 kgf |
| Maximum Payload | |
| 1900 kg | NA |
| ACE Phantom 4WD N | BEML BL9H 4×4 |
|---|---|
| Machine Weight | |
| 8040 kg | 7700 Kg |
| Overall Length | |
| 6200 mm | 6270 mm |
| Wheelbase | |
| 2180 mm | 2160 mm |
| Slew Centre to Rear Axle Centre | |
| NA | NA |
| Minimum Ground Clearance | |
| 350 mm | NA |
| Slew Ground Clearance | |
| 660 mm | 580 mm |
| Height of Cabin | |
| 2900 mm | 3034 mm |
| Overall Height | |
| 3600 mm | 3890 mm |
| Track Width-Rear | |
| 1550 mm | 2452 mm |
| Track Width-Front | |
| 1840 mm | 2240 mm |
| Width Over Bucket | |
| 2500 mm | NA |
© 2025 Desi Machines All rights reserved.
Designed & Developed by PromotEdge
Desi Machines is a platform where you can see and compare construction equipment. It showcases images, brochures, features, technical specifications, brand details & dealer information. All these are taken from respective brand websites, brochures, and other public resources. We do not claim ownership of these materials and strive to ensure their accuracy. However, the disparity may happen and we advise users to verify directly with respective brands and dealers. Desi Machines is not liable for any inaccuracies or reliance on the information provided. Use of this website is at your own discretion.
