The Cat D10 is a 70.3-tonne mining crawler dozer powered by a 603 HP engine. Its 18.5 m³ blade provides the material-moving capacity required for large overburden operations. The machine sits between the D8 and D11, giving mining operators a substantial step up without choosing Cat's largest crawler dozer. Ground clearance reaches 725 mm, helping on rough pit floors where loose rock is common. Ripper choices include a single-shank configuration with a pin puller and a 3-shank multi-shank setup. An optional counterweight adds force where harder breaking work requires it. Fuel capacity reaches 1,269 litres, supporting long working shifts. The D10 suits coal, iron ore and large-format mining rather than general construction. A mining company handling high-volume overburden can consider this dozer machine when the D8 no longer provides sufficient blade capacity. The larger operating weight supports heavier pushing work, while the available ripper configurations provide different approaches to breaking. Buyers can match the setup to the material and working conditions. The D10 offers a large mining crawler dozer option below the D11 while still providing substantial production capacity for major mining operations.
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm the final quote with our team before you buy.
Download Brochure
Please fill the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm the final quote with our team before you buy.
Key Highlights of Cat D10
Features of Cat D10
Engine and Output
Cat C32 diesel rated at about 450 kW (603 HP) for large-scale earthmoving and mining.
3-speed planetary power shift transmission with Enhanced Auto Shifting smooths delivery through the cycle.
SU ABR dozer blade holds 18.5 cubic metres, or 22 with the optional U ABR. Fewer passes either way.
Blade Volume and Cycle Time
Load-sensing hydraulics with dual tilt and a quick-drop valve give precise blade positioning.
Automated Blade Assist is standard, so grading quality stays consistent with fewer inputs.
AutoCarry and Auto Ripper Control are optional. Both automate repetitive functions and tighten cycles.
Undercarriage and Component Life
Suspension-type undercarriage with equalizer bar and greased end-pin bearings holds the dozer machine steady on rough mining ground.
Elevated final drives and reinforced structures protect the drivetrain through continuous heavy-duty work.
Operating weight of around 70,256 kg gives the bulldozer the traction overburden removal demands.
Cab, Monitoring and Automation
Sound-suppressed, isolation-mounted ROPS/FOPS cab with automatic climate control keeps noise and vibration low.
HD multifunction touchscreen with Work Monitor and standard VIMS puts diagnostics in front of the operator.
Powered ladder is available for safer daily access on a machine this size.
Coolant, lubricants, full fuel, ROPS/FOPS cab, SU ABR bulldozer, dual tilt, single-shank ripper w/ pin puller, fast fuel, 610 mm ES shoes, operator
STATIC DIMENSIONS
Overall Length
5,324 mm
Overall Width
3,311 mm
Overall Height
4,406 mm
Min. Ground Clearance
725 mm
SERVICE CAPACITIES
Fuel Tank
1,269 L total
Engine Oil
103 L (crankcase sump)
Engine Coolant
175 L (Tier 4)
Hydraulic System
160 L (tank only)
Transmission System
308 L (powertrain total); track roller frames 64 L each; pivot shaft 36 L
Final Drive (Each Side)
46 L
OPERATOR ENVIRONMENT
Operator Station
ROPS/FOPS sound-suppressed cab; HD primary touchscreen; powered ladder optional
AC Cabin
Standard (automatic climate control)
Monitoring
Touchscreen Information Display (41 languages); optional Work Monitor; VIMS std; Product Link Elite std; Autocarry, Auto Ripper Control, Cat GRADE 3D, 360-deg vision optional; MineStar Command (remote control) ready
Why Choose Cat D10
The D10 is the machine that introduced the elevated sprocket to the world, and the current version keeps that idea at its core. The final drives sit high, away from ground shock and abrasion, on a suspended undercarriage that holds more track on the ground.
In rock and hard-bank mining, that architecture is the reason to buy. Final drives are the most expensive wear point on a big dozer, and lifting them out of the impact zone is why D10 undercarriage and driveline life set the benchmark the industry measures against. Automatic shift management keeps three shifts of operators inside the engine's efficient band.
What it demands in return is the ecosystem: mining-scale maintenance facilities, parts stocking and Cat dealer mining support. There is no economical way to run a D10 casually.
It is built for large mines pushing rock and heavy overburden around the clock, operations where driveline life and fleet uptime over tens of thousands of hours decide the machine.
Common Questions
FAQs about Cat D10
What is the Cat D10 dozer price in India?
Pricing for the Cat D10 dozer is shared on request, since machines of this size are usually quoted against the specific project. Get in touch with us, or check the official OEM directly, for the final confirmed price.
Are finance & EMI options available for the Cat D10?
Finance and EMI options are available for the Cat D10 through several bank and NBFC partners. The final EMI figure depends on your confirmed price, down payment, lender, loan tenure and credit profile.
What type of work is the Cat D10 Dozer suitable for?
The Cat D10 handles overburden removal, haul-road maintenance and quarry face work effectively. A 70.3-tonne operating weight and 18.5 m³ blade capacity back that up.
Does the Cat D10 come with a warranty?
The Cat D10 is covered by a Caterpillar warranty of 12 months, running from the point of delivery. Confirm the final warranty terms with the official OEM before purchase.
Is service and parts support available for Cat D10 near me?
Service and parts support for the Cat D10 is available through Caterpillar’s dealer network across India. It’s worth confirming availability for your specific location before you buy.
What is the operating weight of the Cat D10?
The Cat D10 weighs 70.3 tonnes in standard configuration, sized as a mining dozer built for overburden removal, haul-road maintenance and quarry face work.
What engine does the Cat D10 use?
A Cat C27 engine powers the Cat D10, delivering 603 HP (450 kW). That’s backed by NA of drawbar pull for bulk grading work.
What is the blade capacity of Cat D10?
With a 18.5 m³ blade, the Cat D10 handles overburden removal, haul-road maintenance and quarry face work efficiently.
Does the Cat D10 come with a ripper?
The Cat D10 supports optional single-shank or multi-shank ripper configurations as an attachment for occasional rock-breaking work.
What is the fuel tank capacity of Cat D10?
A 1269 L total fuel tank comes standard on the Cat D10, built for a full day’s work without stopping to refuel.
With a strong dealer network and robust after-sales support, Caterpillar India focuses on customer-centric solutions. Its equipment has ergonomic designs, modern safety measures, and telematics for real-time monitoring, which helps in infrastructure growth and sustainability in India.
With a solid vendor organization and robust after-sales support, Cat Machines India centers around a client-driven approach. Its equipment focuses on ergonomic designs, advanced safety measures, and telematics for real-time monitoring, driving infrastructure growth and sustainability in India.
Cat D10 - Price & Availability Across 600+ Locations in India
Cat D10 is available for purchase and enquiry across all major cities in India including Mumbai, Pune, Kolkata, Hyderabad, Chennai, Bengaluru, Delhi, Ahmedabad, Indore, Jaipur, Guwahati, and 600+ more locations.
