The comparisons provided are based on the technical specifications published by the respective OEMs on their official websites and brochures. Please confirm these details directly with the OEMs before macking any final decision.
| Key Highlights | Indo Power 15FN | ACE FX 150 |
|---|
| Particulars | Indo Power 15FN | ACE FX 150 |
|---|
Comparing the Indo Power 15FN with the ACE FX 150, potential buyers must consider the differences in engine power, drive type, and boom height. The Indo Power 15FN offers more engine power and a higher maximum boom height, while the ACE FX 150 focuses on efficient fuel consumption.
If your priorities are higher lifting capabilities and robust engine performance for rugged terrains, the Indo Power 15FN would be the choice to consider. However, if operational efficiency and fuel economy are more important, the ACE FX 150 might suit your needs better.
| Brand | Indo Farm | ACE |
|---|---|---|
| Type | Pick & Carry Crane | Pick & Carry Crane |
| Ex-Showroom Price | ₹ 34 - 36 Lakhs | ₹ 31 - 33 Lakhs |
| Lift Capacity | 15 Tonnes | 15 Tonnes |
| Boom Height | 19.2 m | 16.3 m |
| Engine | VECV 101 HP | Tata 49 HP |
| Weight | 14770 kg | 15220 kg |
| Turning Radius | 7000 mm | 7000 mm |
| Drive Type | 4WD | 2 Wheel drive |
| Quick Overview: | The Indo Power 15FN farana crane is a powerful 15-ton pick-and-carry hydraulic crane machine built for heavy-duty lifting. It features a 101 HP BS-IV diesel engine, 4-wheel drive, and a 4-part telescopic boom with a height of 19.2 m. Ideal for construction and industrial lifting, this farana crane offers smooth hydraulic operation, low maintenance, and maximum stability across rough terrains. |
Providing 15-ton capability, the ACE FX 150 Hydra crane supports installations and industrial tasks with dependable pick-and-carry operations. |
Comparing the Indo Power 15FN with the ACE FX 150, potential buyers must consider the differences in engine power, drive type, and boom height. The Indo Power 15FN offers more engine power and a higher maximum boom height, while the ACE FX 150 focuses on efficient fuel consumption.
If your priorities are higher lifting capabilities and robust engine performance for rugged terrains, the Indo Power 15FN would be the choice to consider. However, if operational efficiency and fuel economy are more important, the ACE FX 150 might suit your needs better.
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Brand | |
| Indo Farm | ACE |
| Type | |
| Pick & Carry Crane | Pick & Carry Crane |
| Ex-Showroom Price | |
| ₹ 34 - 36 Lakhs | ₹ 31 - 33 Lakhs |
| Lift Capacity | |
| 15 Tonnes | 15 Tonnes |
| Boom Height | |
| 19.2 m | 16.3 m |
| Engine | |
| VECV 101 HP | Tata 49 HP |
| Weight | |
| 14770 kg | 15220 kg |
| Turning Radius | |
| 7000 mm | 7000 mm |
| Drive Type | |
| 4WD | 2 Wheel drive |
| Quick Overview: | |
The Indo Power 15FN farana crane is a powerful 15-ton pick-and-carry hydraulic crane machine built for heavy-duty lifting. It features a 101 HP BS-IV diesel engine, 4-wheel drive, and a 4-part telescopic boom with a height of 19.2 m. Ideal for construction and industrial lifting, this farana crane offers smooth hydraulic operation, low maintenance, and maximum stability across rough terrains. |
Providing 15-ton capability, the ACE FX 150 Hydra crane supports installations and industrial tasks with dependable pick-and-carry operations. |
| Indo Power 15FN | ACE FX 150 | |
| Engine Make | Volvo Eicher - CEV BS IV | Tata |
| Articulation | Upto 40° | 40° |
| Max. Speed | 42 km/h | 32 km/h |
| Fuel Tank | 195 L | NA |
| Hydraulic Tank | 170 L | NA |
| Overall Length | 10685 mm | NA |
| Overall Width | 2670 mm | 2400 mm |
| Wheelbase | 4000 mm | 4150 mm |
| Boom Luffing Range | NA | -3° to +75° |
| Warranty | 1 Year | 1 Year |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Engine Make | |
| Volvo Eicher - CEV BS IV | Tata |
| Articulation | |
| Upto 40° | 40° |
| Max. Speed | |
| 42 km/h | 32 km/h |
| Fuel Tank | |
| 195 L | NA |
| Hydraulic Tank | |
| 170 L | NA |
| Overall Length | |
| 10685 mm | NA |
| Overall Width | |
| 2670 mm | 2400 mm |
| Wheelbase | |
| 4000 mm | 4150 mm |
| Boom Luffing Range | |
| NA | -3° to +75° |
| Warranty | |
| 1 Year | 1 Year |
| Indo Power 15FN | ACE FX 150 | |
| Engine Make | Volvo Eicher - CEV BS IV | Tata |
| Engine Type | DI; TCIC water cooled diesel engine | 4 cylinder water cooled diesel engine. |
| Max Power | 101 HP (74 kW) @ 2200 RPM | 49 HP (36 kW) @ 2000 RPM |
| Battery | 12V - DC | 12V; Negative earth; 75Ah |
| Alternator | NA | 35A |
| Indo Power 15FN | ACE FX 150 | |
| Max. Lifting Capacity | 15 Tonnes | 15 Tonnes |
| Indo Power 15FN | ACE FX 150 | |
| Drive | 4WD | 2 Wheel drive |
| Type | Heavy-duty transmission for crane application. Synchromesh gearbox with auxiliary gearbox; 8 forward and 2 reverse speeds with the high and low selectors. | Heavy-duty TATA synchromesh transmission with 8 forward and 2 reverse speedsand high-low drive selector for creep speed |
| Indo Power 15FN | ACE FX 150 | |
| Steering Type | Articulated power steering; hydraulically controlled through two double acting hydraulic rams. | Full power orbitrol with twin hydraulic double acting cylinders |
| Articulation | Upto 40° | 40° |
| Turning Radius | 7000 mm | 7000 mm |
| Indo Power 15FN | ACE FX 150 | |
| Hoist | Six falls with fail safe brake. | 4 falls; Hydraulic winch; Rope dia 13 mm fitted with self-adjusting hook block and rope tensioner |
| Hoist Speed | NA | 50 Mtrs./Min (Line Speed) |
| Indo Power 15FN | ACE FX 150 | |
| Front Wheels | Fully air operated 'S' cam dual curcuit brakes on front wheels | Pneumatically assisted hydraulic brakes are provided on the front wheels |
| Rear Wheels | Fully air operated 'S' cam dual curcuit brakes on rear wheels | Fully air actuated brakes on rear wheels |
| Parking Brake | Air operated fail safe brakes on front & rear wheels. | Parking brake is pneumatically operated fail safe type |
| Indo Power 15FN | ACE FX 150 | |
| Engine Oil | 12.5 L | NA |
| Fuel Tank | 195 L | NA |
| Hydraulic Tank | 170 L | NA |
| Transmission Oil | 6.25 L | NA |
| Indo Power 15FN | ACE FX 150 | |
| Overall Length With Bucket | 10685 mm | NA |
| Overall Width | 2670 mm | 2400 mm |
| Overall Height | 3035 mm | NA |
| Wheel Base | 4000 mm | 4150 mm |
| Operating Weight | 14770 kg | 15220 kg |
| Front Track | 1830 mm | 1900 mm |
| Rear Track | 1830 mm | 1800 mm |
| Front Tyres | 11.00 x 20 - 16 PR (4 Nos.) | 11.00 x 20 (4 Nos.) |
| Rear Tyres | 11.00 x 20 - 16 PR (4 Nos.) | 14.00 x 20 (4 Nos.) |
| Indo Power 15FN | ACE FX 150 | |
| Telescoping | 4 part boom; 3 part hydraulically powered & fully synchronised. 4th part power extended and manually pinned for safety | Three-part slotted boom with hydraulically operated synchronized extensions |
| Derricking | Through two double acting cylinders. | Through one double-acting extension cylinder |
| Boom Luffing Time | NA | NA |
| Boom Luffing Range | NA | -3° to +75° |
| Boom Height | 19.2 m | 16.3 m |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Engine Make | |
| Volvo Eicher - CEV BS IV | Tata |
| Engine Type | |
| DI; TCIC water cooled diesel engine | 4 cylinder water cooled diesel engine. |
| Max Power | |
| 101 HP (74 kW) @ 2200 RPM | 49 HP (36 kW) @ 2000 RPM |
| Battery | |
| 12V - DC | 12V; Negative earth; 75Ah |
| Alternator | |
| NA | 35A |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Max. Lifting Capacity | |
| 15 Tonnes | 15 Tonnes |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Drive | |
| 4WD | 2 Wheel drive |
| Type | |
| Heavy-duty transmission for crane application. Synchromesh gearbox with auxiliary gearbox; 8 forward and 2 reverse speeds with the high and low selectors. | Heavy-duty TATA synchromesh transmission with 8 forward and 2 reverse speedsand high-low drive selector for creep speed |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Steering Type | |
| Articulated power steering; hydraulically controlled through two double acting hydraulic rams. | Full power orbitrol with twin hydraulic double acting cylinders |
| Articulation | |
| Upto 40° | 40° |
| Turning Radius | |
| 7000 mm | 7000 mm |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Hoist | |
| Six falls with fail safe brake. | 4 falls; Hydraulic winch; Rope dia 13 mm fitted with self-adjusting hook block and rope tensioner |
| Hoist Speed | |
| NA | 50 Mtrs./Min (Line Speed) |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Front Wheels | |
| Fully air operated 'S' cam dual curcuit brakes on front wheels | Pneumatically assisted hydraulic brakes are provided on the front wheels |
| Rear Wheels | |
| Fully air operated 'S' cam dual curcuit brakes on rear wheels | Fully air actuated brakes on rear wheels |
| Parking Brake | |
| Air operated fail safe brakes on front & rear wheels. | Parking brake is pneumatically operated fail safe type |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Engine Oil | |
| 12.5 L | NA |
| Fuel Tank | |
| 195 L | NA |
| Hydraulic Tank | |
| 170 L | NA |
| Transmission Oil | |
| 6.25 L | NA |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Overall Length With Bucket | |
| 10685 mm | NA |
| Overall Width | |
| 2670 mm | 2400 mm |
| Overall Height | |
| 3035 mm | NA |
| Wheel Base | |
| 4000 mm | 4150 mm |
| Operating Weight | |
| 14770 kg | 15220 kg |
| Front Track | |
| 1830 mm | 1900 mm |
| Rear Track | |
| 1830 mm | 1800 mm |
| Front Tyres | |
| 11.00 x 20 - 16 PR (4 Nos.) | 11.00 x 20 (4 Nos.) |
| Rear Tyres | |
| 11.00 x 20 - 16 PR (4 Nos.) | 14.00 x 20 (4 Nos.) |
| Indo Power 15FN | ACE FX 150 |
|---|---|
| Telescoping | |
| 4 part boom; 3 part hydraulically powered & fully synchronised. 4th part power extended and manually pinned for safety | Three-part slotted boom with hydraulically operated synchronized extensions |
| Derricking | |
| Through two double acting cylinders. | Through one double-acting extension cylinder |
| Boom Luffing Time | |
| NA | NA |
| Boom Luffing Range | |
| NA | -3° to +75° |
| Boom Height | |
| 19.2 m | 16.3 m |
