The Zoomlion ZD220-3 is a dozer from Zoomlion with 162 kW power and a 23400 kg operating weight. Full specifications, the current price and finance options are on this page.
Operating Weight: 23400 kg
Engine Power: 162 kW (217 HP) @ 1850 rpm
The Zoomlion ZD220-3 is a 23.4-tonne construction crawler dozer with a 217 HP engine. Its 6.4 m³ blade gives it considerably more material-moving capacity than the ZD160-3. Drawbar pull reaches 178 kN, while ground bearing pressure is 71 kPa for standard construction ground. There is no ripper listed for this configuration, so the machine remains dedicated to grading and pushing. Rated gradeability of 30 degrees supports sloped-site applications. A 400-litre fuel tank supports a full working shift, and 400 mm of ground clearance suits regular construction conditions. The ZD220-3 is the larger of Zoomlion's two listed construction dozers. Highway work and large-plot development can benefit from the additional blade volume. The Zoomlion ZD220-3 bulldozer price is ₹1.20 crore to ₹1.40 crore. A highway contractor can consider this machine when daily material movement has become more important than compact size. Buyers can compare the larger blade against the additional operating weight before choosing it over the ZD160-3. For projects involving broad grading areas, this dozer machine can reduce the number of passes required. It provides a larger construction option without moving into mining-class equipment and remains focused on regular earthwork, spreading and site preparation.
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm the final quote with our team before you buy.
Download Brochure
Please fill the below form to start the download
Note: All images, features, specifications, and brochures on this website are sourced from official brand sites and public resources. Prices are indicative; please confirm the final quote with our team before you buy.
Key Highlights of Zoomlion ZD220-3
Features of Zoomlion ZD220-3
Engine and Push Power
ZD220-3 runs a Weichai WD10G220E23 turbocharged diesel built for high torque.
Rated power of around 162 kW (approximately 217 HP) and strong drawbar pull let the bulldozer move large volumes in tough terrain.
Low fuel consumption keeps operating cost down across long earthmoving projects.
Blade Range and Grading
Blade capacity of 6.4 cubic metres handles serious soil, gravel and material movement.
Tilt, straight, U-blade and angle configurations adapt to different earthmoving and grading tasks.
High lift and tilt sharpen grading accuracy on road construction and land leveling.
Undercarriage and Frame
At an operating weight of about 23,600 kg, the dozer holds stability on slopes and soft soil.
Wide crawler tracks with a long ground contact length deliver traction at reduced ground pressure.
Gradeability is rated for steep gradients rather than flat site work alone.
Cab and Service Access
FOPS/ROPS reinforced cab improves operator safety and gives a clear view for precise work with the dozer machine.
Ground-level maintenance points cut downtime and simplify servicing.
Air conditioning and electronic controls are optional, adding comfort across climates.
Are you interested in buying Zoomlion ZD220-3 Dozer
4-stroke, water-cooled, turbocharged, direct injection
No. of Cylinders
6
Piston Displacement
9.726 L
Rated Engine Power
162 kW (217 HP) @ 1,850 rpm
Maximum Torque
NA
TRANSMISSION
Transmission Type
Planetary power shift, hydraulically actuated
Torque Converter
3-element, single-stage, single-phase
Speeds (F/R)
3F / 3R
Max Forward Speed
11.2 km/h
Max Reverse Speed
13.2 km/h
Final Drive
Spur gear, double reduction
PERFORMANCE
Max Drawbar Pull
178 kN
Gradeability
30 °
Min Turning Radius
NA
STEERING & BRAKES
Steering Type
Wet multiple-disc, spring loaded, hydraulically boosted
Brakes
Wet contracting band, foot operated
UNDERCARRIAGE
Suspension
Semi-rigid equalizer bar
No of Bottom Rollers
7
No of Top Rollers
2
Track Shoes (Each Side)
38
Track Shoe Width
560 mm
Grouser Height
NA
Track Gauge
2,000 mm
Ground Contact Area
NA
Ground Bearing Pressure
71 kPa
DOZER BLADE
Standard Blade Type
Straight tilt
Blade Capacity
6.4 m³
Blade Width x Height
NA
Max Lift Above Ground
NA
Max Drop Below Ground
NA
Blade Tilt Adjustment
NA
Blade Options
Straight tilt (std)
RIPPER
Ripper Availability
NA
HYDRAULIC SYSTEM
Hydraulic Pump
Gear pump
Maximum Flow
NA
Relief Pressure
NA
Blade Control
NA
MACHINE WEIGHTS
Operating Weight
23,400 kg
Weight Basis
As stated (configuration basis not specified)
STATIC DIMENSIONS
Overall Length
5,546 mm
Overall Width
3,725 mm
Overall Height
3,403 mm
Min. Ground Clearance
400 mm
SERVICE CAPACITIES
Fuel Tank
NA
Engine Oil
NA
Engine Coolant
NA
Hydraulic System
NA
Transmission System
NA
Final Drive (Each Side)
NA
OPERATOR ENVIRONMENT
Operator Station
Cab (as pictured)
AC Cabin
NA
Monitoring
NA
Why Choose Zoomlion ZD220-3
The ZD220-3 scales the same formula to the 220 HP class: Weichai power, planetary powershift and a straight tilt blade. A conventional big dozer positioned well below the Japanese and American machines it sizes against.
For the buyer, the arithmetic is acquisition-led. This class of work, bulk pushing, spreading and reclamation, often does not need electronic drivelines to be done profitably, and the conventional layout means any powershift-experienced mechanic can maintain it.
The gap to electronic competitors widens with size: at 220 HP the fuel-efficiency difference grows in absolute terms, and resale channels for Zoomlion dozers in India remain shallow.
Choose it for high-hour bulk earthwork where low capital cost per horsepower drives the business case, and the operation can absorb higher fuel burn as the known price of entry.
Common Questions
FAQs about Zoomlion ZD220-3
What is the Zoomlion ZD220-3 dozer price in India?
The Zoomlion ZD220-3 dozer price in India starts at ₹1.20 crore and goes up to ₹1.40 crore, with GST included. The on-road price adds transportation, TCS, warranty, insurance and FOC charges where applicable. Get a formal quote for your city before you finalise your budget.
Are finance & EMI options available for the Zoomlion ZD220-3?
Finance and EMI options are available for the Zoomlion ZD220-3 through several bank and NBFC partners. The final EMI figure depends on your confirmed price, down payment, lender, loan tenure and credit profile.
What type of work is the Zoomlion ZD220-3 Dozer suitable for?
For grading, land clearing and road-base preparation, the Zoomlion ZD220-3 is a strong fit given its 23.4-tonne weight class and 6.4 m³ blade capacity.
Does the Zoomlion ZD220-3 come with a warranty?
The Zoomlion ZD220-3 is covered by a Zoomlion warranty of 12 months / 2000 hrs, running from the point of delivery. Confirm the final warranty terms with the official OEM before purchase.
Is service and parts support available for Zoomlion ZD220-3 near me?
Service and parts support for the Zoomlion ZD220-3 is available through Zoomlion’s dealer network across India. It’s worth confirming availability for your specific location before you buy.
What is the operating weight of the Zoomlion ZD220-3?
The Zoomlion ZD220-3’s operating weight is 23.4 tonnes, in line with other construction dozers in this weight class.
What engine does the Zoomlion ZD220-3 use?
Under the hood, the Zoomlion ZD220-3 runs a Weichai WD10G220E23 engine rated at 217 HP (162 kW), with 178 kN of drawbar pull supporting it.
What is the blade capacity of Zoomlion ZD220-3?
The Zoomlion ZD220-3 moves up to 6.4 m³ per pass with its standard blade, sized for grading, land clearing and road-base preparation.
Does the Zoomlion ZD220-3 come with a ripper?
The Zoomlion ZD220-3 is configured purely for grading and pushing; a ripper attachment isn’t part of this model’s lineup.
What is the fuel tank capacity of Zoomlion ZD220-3?
The Zoomlion ZD220-3’s fuel tank holds 400 L, enough for a full shift of grading or pushing work.
